(Almost) Everything You Ever Wanted To Know About Geo (with WOEIDs)

London Twitter #devnest 7, March 2010
(Almost) Everything You Ever WantedTo Know About Geo (with WOEIDs)…
Gary Gale, Yahoo! Geo Technologies

the agenda
louisvolant on Flickr : http://www.flickr.com/photos/27048731@N03/4003756731/

the agenda
the hello
the WOEIDs
the WTF?
the background
the geocoding and the geoparsing
the frustration
the WOEIDsredux
the APIs
the demo
the goodbye
3

4
KELLYLEEBARRETT on Flickr : http://www.flickr.com/photos/kellylee/4177529745/

5
Gary Gale on Flickr : http://www.flickr.com/photos/vicchi/4414198544/

WOEIDs
stevefaeembra on Flickr : http://www.flickr.com/photos/stevefaeembra/3567750853/

44418
12589342

8
David Armano on Flickr : http://www.flickr.com/photos/7855449@N02/3158864420/

some background
blakophoto on Flickr : http://www.flickr.com/photos/cleveralias/3158810304/

let’s talk about geocoding
inF! on Flickr : http://www.flickr.com/photos/nathanbarrow/3339245753/

geocoding is the process of finding associated geographic coordinates (often expressed as latitude and longitude) from other geographic data, such as street addresses, or zip codes (postal codes).

reverse geocoding is the process of back (reverse) coding of a point location (latitude, longitude) to a readable address or place name.

noway on Flickr : http://www.flickr.com/photos/noway/78606643/

what?
where?

what? (maybe) where? (maybe)

this is not geocoding, this is geoparsing
szim90 on Flickr : http://www.flickr.com/photos/szim90/272670479/

geoparsing is the process of assigning geographic identifiers (e.g., codes or geographic coordinates expressed as latitude-longitude) to textual words and phrases that occur in unstructured content.

cheap flights from london to paris in october

20
“I’m sorry dave; I can’t find that place”

21
web servers
Jamison Judd on Flickr : http://www.flickr.com/photos/jamisonjudd/2433102356/

22
51° 30' 50.0868", 0° 7' 42.8514"
(125 Shaftesbury Avenue, London, UK)
163.1.117.210
(Oxford, UK)
20442/6015
(Brest, France)
#C5243B212
(Wilmington, Delaware, USA)

23
web surfers
National Library NZ on The Commons on Flickr : http://www.flickr.com/photos/nationallibrarynz_commons/3326203787/

24
The West End
Downtown
The Shops
The High Street

25
The Online World
Formal, normalised, structured, regular
The Real World
“We Are Here”
The Offline World
Informal, eccentric, bizarre, irregular

cheap flights from london to paris in october
1) Tokenize
London
2) Remove common words
3) Remove words not in gazetteer
Paris

“in”… India?
bodhitjal on Flickr : http://www.flickr.com/photos/bodhithaj/361857780/

“in”… Indiana?
OZinOH on Flickr : http://www.flickr.com/photos/75905404@N00/505688957/

“to”… Tonga?
j_buswell on Flickr : http://www.flickr.com/photos/j_buswell/3683814556/

language
Jovike on Flickr : http://www.flickr.com/photos/jvk/19894053/

Thé?
a town in Burgundy, France
IN?
ISO 3166-1 Alpha-2
for India
To?
a town in Ibaraki
prefecture, Japan
Is?
another town in Burgundy, France
IT?
ISO 3166-1 Alpha-2 for Italy
AND?
ISO 31660-1 Alpha-3
for Andorra
You?
a town in Yatenga, Burkina Faso
Å?
a town in NorlandFylke,
Norway
That?
a town in Rajasthan, India

may cause frustration
paloaltosoftware on Flickr : http://www.flickr.com/photos/paloalto/3038701605/

disambiguation
KoenVereeken on Flickr : http://www.flickr.com/photos/koenvereeken/2088902012/

this is peru …

and so is this (in argentina)

and so is this (in bolivia)

semantics required
dullhunk on Flickr : http://www.flickr.com/photos/dullhunk/3525013547/

Hilton, Paris
Paris Hilton

London
Jack London

Panama
Panama Hats

who uses official names anyway?
takomabibelot on Flickr : http://www.flickr.com/photos/takomabibelot/234301712/

MOMA NYC
Museum of Modern Art, New York
paulamoya on Flickr : http://www.flickr.com/photos/40351463@N00/745012335/

Millennium Wheel
London Eye
hismith83 on Flickr : http://www.flickr.com/photos/hismith83/200701961/

San Francisco
City and County of San Francisco
SF Brit on Flickr : http://www.flickr.com/photos/cnbattson/192162591/

WOEIDs (redux)
stevefaeembra on Flickr : http://www.flickr.com/photos/stevefaeembra/3567750853/

44418
12589342

51° 30' 50.0868", 0° 7' 42.8514"

Unique
Permanent
Global
Language Neutral
London = Londra = Londres = ロンドン
United States = États-Unis = StatiUniti = 미국
Ensures that geography can be employed consistently and globally
straup on Flickr : http://www.flickr.com/photos/straup/3504862388/

GeoPlanet
A Global Location Repository
Names + Geometry +Topology
WOEIDs for
cities and towns
postal codes, airports
admin regions, time zones
telephone code areas
marketing areas
points of interest
colloquial areas
neighbourhoods
woodleywonderworks on Flickr : http://www.flickr.com/photos/wwworks/2222523978/

Continents
Countries
Counties
Regions
Colloquials
Targeting Zones
Postal Codes
Area Codes
Boroughs
Neighbourhoods
POIs

United Kingdom
23424975
VereinigtesKönigreich
Europe
24865675
Country
Continent
Royaume Uni
England
24554868
Great Britain
28298150
Country
Colloquial
イギリス
Warwickshire
12602190
Worcestershire
12602192
County
County
Earth
1
Supername
Stratford-on-Avon
12696101
District
Stratford-upon-Avon
36424
Warwick
39228
Town
Town
CV37
26787646
ZIP

http://engineering.twitter.com/2010/02/woeids-in-twitters-trends.html

http://isithackday.com/hacks/placemaker/tweet-locations.php

http://wherein.yahooapis.com/v1/document

unlock your api
https://developer.apps.yahoo.com/wsregapp/
sam.d on Flickr : http://www.flickr.com/photos/samd/65693717/

Placemaker Parameters
appid
100% mandatory
inputLanguage
en-US, fr-CA, …
outputType
XML or RSS
documentContent
text to geoparse
documentTitle
optional title
documentURL
URL to geoparse
documentType
MIME type of doc
autoDisambiguate
remove duplicates
focusWoeid
filter around a WOEID

// POST to Placemaker
$ch = curl_init();
define('POSTURL', 'http://wherein.yahooapis.com/v1/document');
define('POSTVARS', 'appid='. $key.'&documentContent='.urlencode($content).
'&documentType=text/plain&outputType=xml'.$lang);
$ch = curl_init(POSTURL);
curl_setopt($ch, CURLOPT_POST, 1);
curl_setopt($ch, CURLOPT_POSTFIELDS, POSTVARS);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, 1);
$placemaker = curl_exec($ch);
curl_close($ch);

places
that_james on Flickr : http://www.flickr.com/photos/that_james/496797309/

<placeDetails>
<place>
<woeId>44418</woeId>
<type>Town</type>
<name>
<![CDATA[London, England, GB]]>
</name>
<centroid>
<latitude>51.5063</latitude>
<longitude>-0.12714</longitude>
</centroid>
</place>
<matchType>0</matchType>
<weight>1</weight>
<confidence>10</confidence>
</placeDetails>
One place for WOEID 44418

references
misterbisson on Flickr : http://www.flickr.com/photos/maisonbisson/117720946/

<reference>
<woeIds>44418</woeIds>
<start>1079</start>
<end>1089</end>
<isPlaintextMarker>1</isPlaintextMarker>
<text><![CDATA[London, UK]]></text>
<type>plaintext</type>
<xpath><![CDATA[]]></xpath>
</reference>
<reference>
<woeIds>44418</woeIds>
<start>1116</start>
<end>1126</end>
<isPlaintextMarker>1</isPlaintextMarker>
<text><![CDATA[London, UK]]></text>
<type>plaintext</type>
<xpath><![CDATA[]]></xpath>
</reference>
Two references for WOEID 44418
Two references for WOEID 44418

// turn into an PHP object and loop over the results
$places = simplexml_load_string($placemaker, 'SimpleXMLElement',
LIBXML_NOCDATA);
if($places->document->placeDetails){
$foundplaces = array();
// create a hashmap of the places found to mix with
// the references found
foreach($places->document->placeDetails as $p){
$wkey = 'woeid'.$p->place->woeId;
$foundplaces[$wkey]=array(
'name'=>str_replace(', ZZ','',$p->place->name).'',
'type'=>$p->place->type.'',
'woeId'=>$p->place->woeId.'',
'lat'=>$p->place->centroid->latitude.'',
'lon'=>$p->place->centroid->longitude.'’
);
}
}

// loop over references and filter out duplicates
$refs = $places->document->referenceList->reference;
$usedwoeids = array();
foreach($refs as $r){
foreach($r->woeIds as $wi){
if(in_array($wi,$usedwoeids)){
continue;
} else {
$usedwoeids[] = $wi.'';
}
$currentloc = $foundplaces["woeid".$wi];
if($r->text!='' && $currentloc['name']!='' &&
$currentloc['lat']!='' && $currentloc['lon']!=''){
$text = preg_replace('/s+/',' ',$r->text);
$name = addslashes(str_replace(', ZZ’,
$currentloc['name']));
$desc = addslashes($text);
$lat = $currentloc['lat'];
$lon = $currentloc['lon'];
$class = stripslashes($desc)."|$name|$lat|$lon";
$placelist.= "<li>".
}
}

http://www.vicchi.org/speaking

the internet is broken
Nesster on Flickr : http://www.flickr.com/photos/nesster/3168425434/

// load the URL, using YQL to filter the HTML
// and fix UTF-8 nasties
$url = 'http://www.vicchi.org/speaking';
$realurl = 'http://query.yahooapis.com/v1/public/yql’.
'?q=select%20*%20'.
'from%20html%20where%20url%20%3D%20%22'.
urlencode($url).'%22&format=xml';
$ch = curl_init();
curl_setopt($ch, CURLOPT_URL, $realurl);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, 1);
$c = curl_exec($ch);
curl_close($ch);
if(strstr($c,'<')){
$c = preg_replace("/.*<results>|</results>.*/",'',$c);
$c = preg_replace("/<?xml version="1.0"".
" encoding="UTF-8"?>/",'',$c);
$c = strip_tags($c);
$c = preg_replace("/[ ? ]+/"," ",$c);
}

minor annoyances
swooshthesnail on Flickr : http://www.flickr.com/photos/swooshthesnail/3281681399/

50,000 bytes
ASurroca on Flickr : http://www.flickr.com/photos/asurroca/147049402/

X
no json

post not get
sludgegulper on Flickr : http://www.flickr.com/photos/sludgeulper/2645478209/

http://where.yahooapis.com/v1/

collections
bradman334 on Flickr : http://www.flickr.com/photos/bradman334/3402569690/

collections
lists of related resources, such as places
e.g. find all places called “london”
http://where.yahooapis.com/v1/places.q('london');count=0?appid=[your id]
e.g. find the most likely place called “london”
http://where.yahooapis.com/v1/places.q('london’)?appid=[your id]
74

<places xmlns="http://where.yahooapis.com/v1/schema.rng" xmlns:yahoo="http://www.yahooapis.com/v1/base.rng"
yahoo:start="0" yahoo:count="1" yahoo:total="22">
<place yahoo:uri="http://where.yahooapis.com/v1/place/44418" xml:lang="en-us">
<woeid>44418</woeid>
<placeTypeName code="7">Town</placeTypeName>
<name>London</name>
<country type="Country" code="GB">United Kingdom</country>
<admin1 type="Country" code="GB-ENG">England</admin1>
<admin2 type="County" code="">Greater London</admin2>
<admin3></admin3>
<locality1 type="Town">London</locality1>
<locality2></locality2>
<postal></postal>
<centroid>
<latitude>51.506321</latitude><longitude>-0.127140</longitude>
</centroid>
<boundingBox>
<southWest><latitude>51.261318</latitude><longitude>-0.563000</longitude></southWest>
<northEast><latitude>51.686031</latitude><longitude>0.280360</longitude></northEast>
</boundingBox>
</place>
</places>

resources
joshuarichards on Flickr : http://www.flickr.com/photos/joshywoshywoo/124671979/

resources
unique objects that contain multiple attributes, such as a place
e.g. get attributes for WOEID 44418
http://where.yahooapis.com/v1/place/44418?appid=[your id]
e.g. find the most likely place called “london”
http://where.yahooapis.com/v1/places.q('london’)?appid=[your id]
77

resources
unique objects that contain multiple attributes, such as a place
e.g. get places related to WOEID 44418
http://where.yahooapis.com/v1/place/44418/relation?appid=[your id]
parent, ancestors, belongsto, neighbours, siblings, children
78

<?xml version="1.0" encoding="UTF-8"?><places xmlns="http://where.yahooapis.com/v1/schema.rng" xmlns:yahoo="http://www.yahooapis.com/v1/base.rng" yahoo:start="0" yahoo:count="10" yahoo:total="34">
<placeTypeName code="10">Local Administrative Area</placeTypeName>
<name>City of London</name>
</place>
<name>London Borough of Camden</name>
</place>
<name>London Borough of Hackney</name>
</place>
…
</places>

Far more than you could ever want
http://delicious.com/codepo8/geotoys

never work with children, animals or live demos
elephipelephi on Flickr : http://www.flickr.com/photos/elephipelephi/1493013250/

not taking notes?
selva on Flickr : http://www.flickr.com/photos/selva/24604141/

London Twitter #devnest 7, March 2010
(Almost) Everything You Ever WantedTo Know About Geo (with WOEIDs)…
Gary Gale, Yahoo! Geo Technologies
http://slideshare.net/vicchi

thanks for listening
Paul Keleher on Flickr : http://www.flickr.com/photos/pkeleher/1658311814/

www.ygeoblog.com
twitter.com/vicchi
twitter.com/yahoogeo

http://www.vicchi.org	144
http://devnest.org	54
http://www.slideshare.net	25
http://londonfirst.dev01.maverick.local	13
http://twitterdevelopernest.com	12
http://api.rockmelt.com	2
http://www.mysparebrain.com	1

(Almost) Everything You Ever Wanted To Know About Geo (with WOEIDs)

by Gary Gale

Accessibility

Categories

Upload Details

Usage Rights

7 Embeds 251

Statistics
