Complex problems demand Innovative Solutions… LONGWALL – A trip to China  Lolla Sudhakar,  Col. Mgr, GDK.10A Incline &  Te...
Team (from left to right): P. Srinivas,  R.V.Rao B.Chakravarthy D.N.Sharma Lolla Sudhakar   Taher Basha L.R.C.Reddy MD.Sur...
Presentation Profile <ul><li>Details of the Visit </li></ul><ul><li>Objective </li></ul><ul><li>China – Performance highli...
The Objective <ul><li>Background </li></ul><ul><ul><li>Opencastable reserves are depleting fast. </li></ul></ul><ul><ul><l...
Visit Particulars <ul><li>Total Period - 13 th  May to 13 th  June 2007 </li></ul><ul><li>Underground Visits - 11 days </l...
Training Schedule <ul><li>First Week - Visit to Pingdingshan Coal Company </li></ul><ul><li>  Study of Geology, Exploratio...
Training Schedule <ul><li>Third Week - Roadway Drivage – equipment, Operation &    Maintenance, Visit Pingdingshan Coal Mi...
China Mineral Map Pingdingshan Coal Mine
China Coal Map Pingdingshan Coal Belt
Chinese Coal Industry  <ul><li>Largest producer of coal in the world. </li></ul><ul><li>3rd largest proved coal reserve in...
<ul><li>95% of the coal produced is from underground mines. </li></ul><ul><li>Mechanization in key state-owned mines up to...
Salient features of the mines visited <ul><li>All the Mines except No-1 Mine have gradient from 20 0  to 30 0 .  </li></ul...
Visit to Pingdingshan  Coal Company
Location Pingdingshan Coal (Group) Co.Ltd is located in Pingdingshan City, Henan Province, China Pingdingshan  City Look a...
About Pingdingshan Coal Group <ul><li>It was the first extra large coal base which was prospected, designed and constructe...
<ul><li>The group has 31 production mines with approved production capacity of 31.01 MTPA. </li></ul><ul><li>3 mines under...
Pingdingshan Coal Group – Performance
The Pingdingshan coal field
The Pingdingshan Coal fields <ul><li>Its strike length (east to west) is about 40 Km and width (south to north) is 16 Km, ...
<ul><li>The COAL of Pingdingshan coal-field belongs  to  Permo-Carboniferous period. </li></ul><ul><li>Pingdingshan area c...
General Facts China coal 300m/drill/month. Drill is being run on three shift basis. (Ours is also around  300 mt/drill/ mo...
GENERAL EXPLORATION PRACTICES  IN CHINA Assigned to University. Not done Exploration wing. GEOMODEL of Block No preserving...
Emphasis is not given . In-Situ stress measurements  No additional BHs are drilled in  LW panels for more geological confi...
No 12 mine is having 2000 to 3000 GPM Study of inflow of water They adopt UG mapping techniques  to map particularly  stru...
VISIT TO  PINGDINGSHAN WUHUAN INDUSTRIAL COMPANY. <ul><li>Manufactures  various types of drill bits, core lifters, lifter ...
VARIOUS TYPES  OF DRILL BITS
VISIT TO  SINOCOAL INTERNATIONAL ENGINEERING GROUP(SCIEG )  BEIJING <ul><li>Provided information of various capacities of ...
DRILL SITE VISIT <ul><li>The BH is expected to complete total depth of 1500m, in 5 months. </li></ul><ul><li>6 workers are...
VIEW OF DRILL SITE
PRESERVATION OF CORE  IN BOXES SCCL CHINA
Exploration
INSIDE VIEW OF EXPLRN. CAMP
INFRASTRUCTURE
Bird’s eye view of mine premises
Control room
Coal Handling Plant
Man winding Shaft Ground mounted multi rope  Koepe winder
Surface Substation
Surface Substation
Transport on mine surface
No.13 Mine – Premises
Surface Coal Transport System
A glimpse of Transport route UG
Development - Roadway Drivage
Development – Roadway drivage <ul><li>All the trunk roadways are developed in Stone. </li></ul><ul><li>Longwall gate roads...
Development – Roadway drivage
Variants of Tunneling machines 660/1140V 660/1140V 660/1140V Power-supply voltage 45 kW 75 kW 55kW Power of oil pump motor...
Roadheader cutting pattern – based on Dip Cutting method with dip angle less than 20 °  and easily spalling off Cutting me...
LONGWALL
Longwall - Introduction <ul><li>China is producing around 1.0BT from Longwalls. </li></ul><ul><li>Face lengths varying fro...
Long wall mechanisation <ul><li>1970s  development of LW mechanization  started  </li></ul><ul><li>1980s its initial stage...
AFC <ul><li>750Kw  with two motors </li></ul><ul><li>Chain dimension  26mm × 92mm  to  34mm × 126mm.   </li></ul><ul><li>P...
Shearer Selection Multi motor  Shearer Installed power  475 & 930 KW Chainless haulage All electric haulage Voltage – 3300V
<ul><li>Only required Load center for AFC & Shearer are kept on trolley at TG. Similarly, one Load centre for BSL is place...
BSL <ul><li>200 kW motor, Length shortened to 20-25m </li></ul><ul><li>Light weight crusher 3Te </li></ul><ul><li>No Shiel...
WORKING OF LONGWALL FACES <ul><li>the Longwall face are being worked with 4 shifts basis with one maintenance shift and th...
Man Power Organisation in each shift  TOTAL  27   Team leader  -Incharge of face Dy.team leader -for gas drainage 6
Pattern of cutting <ul><li>Except for the special situation, Bi-directional cutting is being normally practiced in the LW ...
<ul><li>face crew is well trained  & experienced  in roof control techniques rather than depending on Numerical modeling, ...
<ul><li>Periodic weightings are reported at 15-20m  interval </li></ul><ul><li>Wherever, undue geological  disturbances en...
Strata control…….. <ul><ul><li>No undue strata problem during the main weighting </li></ul></ul><ul><ul><li>The leg pressu...
<ul><li>Oblique face or Staggering the bottom gate   </li></ul>Creep control <ul><ul><ul><li>Stability of Gate end support...
<ul><ul><ul><li>Loose Coal:  Special care is being taken not to </li></ul></ul></ul><ul><ul><ul><ul><li>advance the suppor...
<ul><ul><ul><li>Use of Side shields  :  The side alignment rams are not provided in the recently developed Supports, inste...
Capacity up to 3500 ton /hour AFC
Crusher Stage Loader
Power pack Selection Power pack Pumps 315LPM / 400LPM 200KW / 250 KW Motors 2500 L / 3200 L Tank Capacity NB31.5 Feed / NB...
Gate Belt + Trunk Belt
LONGWALL - SALVAGE
Longwall salvage <ul><li>No buttress supports </li></ul><ul><li>Wooden cogs,props erected by removing alternate one </li><...
Cross section of LW face under Installation
Supporting at the Longwall face Cross section of Longwall face under withdrawal of supports – Supporting method. Wooden Lo...
Loading of supports Ramp Trolley Hauler - loading Winch
Withdrawal of supports Plan View of Longwall face under withdrawal of supports TG MG Powered Supports Hauler - marching Ha...
Transportation of Supports <ul><li>Method of loading and fixing of support: </li></ul><ul><li>The support is disassembled ...
INFRASTRUCTURE – U/G
Underground roadway
Water barriers in underground
Belt Man riding system
Safety - Underground
Mines safety monitoring &  Communication technology
Mobile Communication System in Underground
Nitrogen Fire extinguishing equipments for coal mines
SAFETY & TRAINING
Employee Training <ul><li>Employee Training & Education Policy </li></ul><ul><ul><li>Strict Mine Working Permit System. </...
Employee Training <ul><li>The Pingdingshan vocation education college </li></ul><ul><ul><li>Supported by labor department ...
Vocational Training Centre
Vocational Training Centre – Class room
TECHNOLOGICAL DEVELOPMENTS (CHINA)
<ul><li>China has developed its own mining technologies suitable for its geological conditions. </li></ul><ul><li>Independ...
Technological development in China AFC  --  400,500,750 kW  Totally enclosed type  34mmX126mm twin inboard chain,  pan wid...
Manufacturing capabilities
Technological development in China Power Support  height 0.6 to 6.5 m
Technological development in China LTCC 2-Legged / 4-Legged  Chock shields High flow rate hydraulic system 6400 KN Yield l...
Technological development in China State of art Testing Facilities
Technological development in China Advanced Manufacturing  Facilities
What we learnt from the China Trip …
Notable Points  <ul><li>Commitment & Discipline </li></ul>
Things to be implemented <ul><li>Pump & sub-station . </li></ul>
Things to be implemented <ul><li>Track line & Slow speed hauler. </li></ul>
Things to be implemented <ul><li>Systematic Cable anchoring  </li></ul>CHINA GDK-10A
Things to be implemented <ul><li>House keeping - Underground </li></ul>
Things to be implemented <ul><li>Underground transport with Diesel vehicle </li></ul>
Things to be implemented <ul><li>Usage of dome washers for bolting with Resign capsules. </li></ul>
Things to be implemented <ul><li>Lamp Room </li></ul>
<ul><li>Existing Exploration should be extended from 600m to 900m depth. </li></ul><ul><li>Existing drill capacities from ...
Things to be implemented-Immediate <ul><li>Resin capsules for bolting. </li></ul><ul><li>Pipelines in sides. </li></ul><ul...
Things to be implemented -Long term <ul><li>As a nation as a company and as an individual we have to Think big & Plan big ...
<ul><li>1.Trunks development in stone roof </li></ul><ul><li>2. More number of deep shafts for future ventilation </li></u...
<ul><li>One mine like GDK10A has to be chosen as a model mine to adopt some good systems and implement the ideas for trans...
<ul><li>Certain Chinese items like sprayers; belting jointing machines are to be imported and avenues for its fabrication ...
<ul><li>The mines visited by the team are steeper than any of the SCCL mines. They are running Longwalls successfully with...
<ul><li>Chinese Package –with less sophistication </li></ul><ul><ul><li>One Panel – 1.0 MTPA Concept. </li></ul></ul><ul><...
<ul><li>Plantation of trees/trunks. </li></ul>
<ul><li>THANK ‘U’ </li></ul>
