Saying goodbye to SQL Server 2000 Presentation Transcript

  • 1. Andrew Fryer Evangelist Microsoft UK [email_address] http://blogs.technet.com/andrew
  • 2.
  • 3.
  • 4.
    • Microsoft ® .NET Framework
      • Common Language Runtime integration
      • User-defined Aggregates
      • User-defined Data Types
      • User-defined Functions
      • SQL Server .NET Data Provider
      • Extended Triggers
    • Data Types
      • Managed SQL Types
      • New XML Datatype
      • Varchar (MAX) Varbinary (MAX)
    • SQL Server Engine
      • New Message Service Broker
      • HTTP Support (Native HTTP)
      • Database Tuning Advisor
      • Multiple Active Result Sets
      • Persisted Computed Columns
      • Snapshot Isolation Level
      • Scale Up Partitioning
      • VIA support
      • NUMA support
    • Database Failure and Redundancy
      • Failover Clustering (up to 8 node)
      • Enhanced Multi-instance Support
      • Database Mirroring
      • Database Snapshots
    • XML
      • XQUERY Support
      • XML Data Manipulation Language
      • FOR XML Enhancements
      • XML Schema (XSD) Support
      • MSXML 6.0 (Native)
      • .NET XML Framework
    • Full-text Search
      • Indexing of XML Datatype
    • Database Maintenance
      • Backup and Restore Enhancements
      • Checksum Integrity Checks
      • Dedicated Administrator Connection
      • Dynamic AWE
      • Fast Recovery
      • Highly-available Upgrade
      • Online Index Operations
      • Online Restore
      • Parallel DBCC
      • Parallel Index Operations
    • Management Tools
      • New Management Studio
      • MDX Query Editor
      • Version Control Support
      • XML/A
      • SQLCMD Command Line Tool
    • Performance Tuning
      • Profiler Enhancements
      • Profiling Analysis Services
      • Exportable Showplan
      • Exportable Deadlock Traces
    • Replication
      • Auto-tuning replication agents
      • Oracle publication
      • Improved BLOB change tracking
      • Enhanced replication monitor
    • SQL Client .NET Data Provider
      • Server Cursor Support
      • Asynch
    • Security
      • All Permissions Grantable
      • Fine Grain Administration Rights
      • Separation of Users and Schema
      • Data encryption primitives
    • MDAC
      • SNAC
      • Microsoft installer based setup
      • Support for Active Directory ® deployment
    • OLAP and Data Mining
      • Analysis Management Objects
      • Windows Integrated Backup and Restore
      • Web Service/XML for Analysis
      • DTS and DM Integration
      • New Data Mining Algorithms
      • Auto Packaging and Deployment
    • Data Transformation Services
      • New Architecture (DTR + DTP)
      • Complex Control Flows
      • Control Flow Debugging
      • For Each Enumerations
      • Property Mappings
      • Full Data Flow Designer
      • Full DTS Control Flow Designer
      • Graphical Presentation of Pkg Execution
      • Immediate Mode and Project Mode
      • Package (Advanced) Deployment Tools
      • Custom Tasks and Transformations
    • Reporting Services
      • Multiple Output Formats
      • Parameters (Static, Dynamic, Hierarchical)
      • Bulk Delivery of Personalized Content
      • Support Multiple Data Sources
      • STS (Web Parts, Doc Libraries)
      • Visual Design Tool
      • Charting, Sorting, Filtering, Drill-Through
      • Scheduling, Caching
      • Complete Scripting Engine
      • Scale Out architecture
      • Open XML Report Definition
    • Notification Services and SQL Server Mobile
  • 5.
    • Transparent Data Encryption
    • External Key Management
    • Data Auditing
    • Pluggable CPU
    • Transparent Failover for Database Mirroring
    • Policy Management
    • Server Group Management
    • Streamlined Installation
    • Enterprise System Management
    • Performance Data Collection
    • System Analysis
    • Data Compression
    • Query Optimization Modes
    • Resource Governor
    • Entity Data Model
    • LINQ
    • Visual Entity Designer
    • Entity Aware Adapters
    • SQL Server Change Tracking
    • Synchronized Programming Model
    • Visual Studio Support
    • SQL Server Conflict Detection
    • FILESTREAM data type
    • Integrated Full Text Search
    • Sparse Columns
    • Large User Defined Types
    • Date/Time Data Type
    • LOCATION data type
    • SPATIAL data type
    • Virtual Earth Integration
    • Partitioned Table Parallelism
    • Query Optimizations
    • Persistent Lookups
    • Change Data Capture
    • Backup Compression
    • MERGE SQL Statement
    • Data Profiling
    • Star Join
    • Enterprise Reporting Engine
    • Internet Report Deployment
    • Block Computations
    • Scale out Analysis
    • BI Platform Management
    • Export to Word and Excel
    • Author reports in Word and Excel
    • Report Builder Enhancements
    • TABLIX
    • Rich Formatted Data
    • Personalized Perspectives
    • … and many more
  • 6.
  • 7.
  • 8.
  • 9.
  • 10.
    • Updates an existing installation while preserving user data
    • Instance name remains the same
    • Automated process
  • 11.
  • 12.
    • Install new instance of SQL Server
    • Database objects are copied between instances
    • Can be same server (named instance) or different server
    • Mostly Manual process
  • 13.
  • 14.
    • Clustering
    • Log Shipping
    • Replication
  • 15. 2000 – 2005 2000 - 2008 Analysis Services Different architecture and designer Different architecture and designer Reporting Services No significant Issues Issues with custom IIS/ SSRS settings Data Transformation Services (DTS) Runs natively Runs natively Integration Services (SSIS) DTS to SSIS Everything has changed Everything has changed
  • 16.
  • 17.
    • Analyzes
      • Configuration and objects within installed components
      • Trace files (captured using Profiler/SQL Trace)
      • T-SQL scripts (any script file)
    • Generates Detailed Issue Report:
      • Before – potential showstoppers, must resolve before upgrading
      • After – should be resolved after completing upgrade
      • Anytime
      • Advisory – notices and/or warnings
  • 18.
      • Analyzes SQL Server 2000/2005 database, trace files and script files
      • Read-only operation, can be CPU intensive
      • Supports remote execution
      • Supports default and named instance
      • Requires .NET framework 2.0 sp1 or later
      • Download latest version from web!
  • 19.
  • 20.
    • UA does not detect everything:
      • Dynamic SQL
      • Meta-data driven applications (both during application setup and regular use)
      • Changes in system objects (stored procedures, functions, tables, etc…) but uses the same name
    • UA does not have rules for all known issues
      • or any “yet to be known” issues
  • 21.
    • Developed in conjunction with Scalability Experts
    • Available for upgrades to SQL Server2005 and SQL Server 2008
  • 22.
    • Capture realistic workload from test/production
    • Establish a baseline in ACT environment:
      • Restore SQL Server 2000/2005 database environment
      • Replay captured trace and record baseline data
    • Determine functional and performance measures of same application on SQL Server 2008 32-bit
      • Upgrade database to SQL Server 2008
      • Replay captured trace and record functional and performance data
    • Repeat for x64 if required or just test against x64
  • 23.
  • 24.
    • Support for SQL 2000
    • Set by default after upgrade
    • Trace flags for deprecated events
  • 25.
    • Test with Compatibility Level 10
    • Test actual application against SQL Server 2008
    • Test setup of application against SQL Server 2008
    • Basic optimization review (e.g. run DTA)
    • Explore new/enhanced features with applications
  • 26.
    • Replaced by Integration Services
    • Deprecated in SQL Server 2008
    • But you can still use a DTS packages as is
    • Basic migration tool as part of setup
    • 3 rd Party tool DTSXchange.
  • 27.
  • 28.
    • Identify Upgrade Requirements
    • Agree Acceptance Criteria
    • Complete the Upgrade Checklist
    • Run the latest Upgrade Advisor
    • Pre-Upgrade Considerations
    • Determine Appropriate Upgrade Strategy
    • Upgrade Process
    • Post Upgrade Considerations
  • 29.
    • Document existing solution
    • Capture performance baseline data
    • Develop criteria and unit / verification tests
    • Optional: capture query plans for complex queries
    • Ensure Clean Environment
    • Backup old instance / database and Verify it!
    • Loop in Windows Administrators, SAN Administrators and Network Operations
    • Optional: Access to Support
  • 30.
    • Document EVERY step to the last detail and follow the document
    • Check database consistency
    • Monitor upgrade progress
      • Check timing and compare to test upgrade timing
  • 31.
    • Review all logs
    • Change the compatibility level
    • Change the page verify option
    • Revisit Upgrade Advisor recommendations
    • Update statistics to ensure performance
    • Reconfigure Log Shipping
    • Re-populate Full-Text catalogs
    • Verify Agent jobs and maintenance tasks
    • Verify security settings, especially cross server and/or cross-domain access privileges
  • 32.
    • Re-evaluate statistics
    • Check Optimizer Hints
    • Database Tuning Advisor
    • Leverage New ‘Low Cost’ Features
      • Backup compression
      • Transparent Data Encryption
    • Make use of schemas
    • Plan DTS Migration
  • 33.
    • The smallest detail missed can break the entire upgrade
    • A tested rollback plan is critical
    • Don’t jump to conclusions if performance issues are encountered
    • There are lots of resources to help you and your partners/customers…
  • 34.
    • Download the Upgrade Technical Reference Guide:
      • http://www.microsoft.com/downloads/details.aspx?FamilyID=66D3E6F5-6902-4FDD-AF75-9975AEA5BEA7&displaylang=en
    • Start Using SQL Server 2008 for management
      • http://www.microsoft.com/sql/2008/default.mspx
    • Be aware of deprecated features in SQL Server 2008
      • http://technet.microsoft.com/en-us/library/cc707789.aspx
    • Get the latest SQL Server 2008 Upgrade Advisor
      • http://www.microsoft.com/downloads/details.aspx?FamilyID=c6c3e9ef-ba29-4a43-8d69-a2bed18fe73c&DisplayLang=en
      • If you need the Upgrade Assistant
      • http://www.scalabilityexperts.com/default.asp?action=article&ID=43
    • If you need a better DTS Migration Tool
      • http://dtsxchange.com/
    • If you really haven’t got a TechNet+ subscription or just needs some help
      • [email_address] and http://blogs.technet.com/andrew
  • 35. © 2008 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries. The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.
