An Introduction to Solr - Presentation Transcript

  1. Searching with Solr
    • Tom Hill
    • [email_address]
    • eBig Java SIG, June 18th, 2008
  2. Tonight's Talk
    • Tonight's Talk should run about 1 1/2 hours
    • About Solr
      • Background & overview
    • Installing & Bringing Up Solr
    • Rest Interface & Java Client
    • Configuring Solr
  3. Why Implement Search?
    • Does your site need search?
    • Do you need to implement it, or is Google enough?
      • Just text or Structured Data?
      • Do you need to control ranking?
  4. What is Solr?
    • Web application for text search
    • A wrapper around Apache Lucene
      • Lucene is a library (.jar file)
      • Solr is a web app (.war file)
    • Written at CNet, now at Apache
  5. What is Lucene?
    • Text search library in Java
      • Fast, feature rich.
      • Written by Doug Cutting
      • Active Apache development community
    • Versions also in C++, C#, Ruby, Python, Delphi, Lisp, etc...
  6. Why Solr?
      • Reliable
      • Fast
      • Supported
      • Open Source
      • Tunable Scoring
  7. Solr Versions
      • Current Version is 1.2
        • A year old
        • 1.3 is coming "sometime"
      • Large number of features in HEAD
        • Use the latest from subversion for new projects
  8. Alternatives to Solr
    • Just Use Google
    • Use Lucene
    • Use Your Database
    • Commercial Libraries
    • Write your own
  9. What Solr is Not
    • A replacement for a relational database
    • An embedded database*
    • Fully cross platform :-(
      • Replication depends on unix FS
      • Admin scripts are bash(minor)
  10. Solr Sites
    • CNet (Reviews & Products)
    • Internet Archive (Collections)
    • Netflix (Movies)
    • Zvents (Events)
    • StripSearch.ws (Comics)
    • And many more
  11. Features Here's a quick look at some of the features of Solr, as implemented on Zvents.com
  12.
  13. Faceted Navigation
    • Groups the results by category
    • Can do multiple facets at once
    • Returns matching counts
  14. Additional Constraints
  15. Synonyms, etc.
  16. Solr Overview
  17. Simple Webapp Web Servers[1..n] Database Master Database Slaves[0..n] Solr Master Solr Slaves[0..n]
  18. Scaling Solr
    • Master/Slave architecture
    • Writes to master/reads to slaves
    • Replication: Periodic transfers, not continuous
    • Rsync
  19. Updates
    • Updates flush caches, bad for performance
    • Master therefor much slower than slaves
      • So send all queries to slaves
    • Depends on your update rates
  20. Solr's Data Model
    • Solr maintains a collection of documents
    • A document is a collection of fields & values
    • A field can occur multiple times in a document
    • Documents are immutable.
      • They can be deleted, and a new version added, however.
  21. Querying
    • Http request
    • http://localhost:8080/comix/select/?q=java
  22. Solr Query Syntax
    • Lucene Query Syntax + a bit
    • paris
    • city:paris
    • title:"The Right Way" AND text:go
    • id:[* TO *]
  23. Solr Query Syntax II
    • -inStock:false
    • te?t
    • theat*
    • te*t
    • test~
  24. Using Solr
    • Getting data into Solr
    • Getting data out of Solr
  25. Getting Data Into Solr
    • POST it.
    <add> <doc> <field name=&quot;employeeId&quot;>05991</field> <field name=&quot;office&quot;>Bridgewater</field> <field name=&quot;skills&quot;>Perl</field> <field name=&quot;skills&quot;>Java</field> </doc> [<doc> ... </doc>[<doc> ... </doc>]] </add>
  26. Getting Data Into Solr
    • POST it.
    <add> < doc > <field name=&quot;employeeId&quot;>05991</field> <field name=&quot;office&quot;>Bridgewater</field> <field name=&quot;skills&quot;>Perl</field> <field name=&quot;skills&quot;>Java</field> </ doc > [<doc> ... </doc>[<doc> ... </doc>]] </add>
  27. Getting Data Into Solr
    • POST it.
    <add> <doc> <field name=&quot; employeeId &quot;> 05991 </field> <field name=&quot;office&quot;>Bridgewater</field> <field name=&quot;skills&quot;>Perl</field> <field name=&quot;skills&quot;>Java</field> </doc> [<doc> ... </doc>[<doc> ... </doc>]] </add>
  28. Committing
    • Nothing shows up in the index until you commit
    • You can just POST <commit/> to http:// host : port /solr/update
  29. Getting Data Out http://localhost:8080/comix/select/?q=data&indent=on
    • <response>
    • <lst name=&quot;responseHeader&quot;>
    • <int name=&quot;status&quot;>0</int>
    • <int name=&quot;QTime&quot;>0</int>
    • <lst name=&quot;params&quot;>
      • <str name=&quot;indent&quot;>on</str>
      • <str name=&quot;q&quot;>data</str>
    • </lst>
    • </lst>
    • <result name=&quot;response&quot; numFound=&quot;2&quot; start=&quot;0&quot;>
    • <doc>
      • <str name=&quot;id&quot;>strip.3136</str>
      • <str name=&quot;release_date&quot;>1992-05-07</str>
      • <date name=&quot;timestamp&quot;>2008-02-28T10:06:01.682Z</date>
      • <str name=&quot;type&quot;>strip</str>
    • </doc>
    • </result>
    • </response>
  30. Getting Data Out http://localhost:8080/comix/select/?q=data&indent=on
    • <response>
    • <lst name=&quot;responseHeader&quot;>
    • <int name=&quot;status&quot;>0</int>
    • <int name=&quot;QTime&quot;>0</int>
    • <lst name=&quot;params&quot;>
      • <str name=&quot;indent&quot;>on</str>
      • <str name=&quot;q&quot;>data</str> </lst>
    • </lst>
    • <result name=&quot;response&quot; numFound=&quot;2&quot; start=&quot;0&quot;>
    • <doc>
      • <str name=&quot;id&quot;>strip.3136</str>
      • <str name=&quot;release_date&quot;>1992-05-07</str>
      • <date name=&quot;timestamp&quot;>2008-02-28T10:06:01.682Z</date>
      • <str name=&quot;type&quot;>strip</str>
    • </doc>
    • </result>
    • </response>
  31. Getting Data Out http://localhost:8080/comix/select/?q=data&indent=on
    • <response>
    • <lst name=&quot;responseHeader&quot;>
    • <int name=&quot;status&quot;>0</int>
    • <int name=&quot;QTime&quot;>0</int>
    • <lst name=&quot;params&quot;>
      • <str name=&quot;indent&quot;>on</str>
      • <str name=&quot;q&quot;>data</str> </lst>
    • </lst>
    • <result name=&quot;response&quot; numFound=&quot;2&quot; start=&quot;0&quot;>
    • <doc>
      • <str name=&quot;id&quot;>strip.3136</str>
      • <str name=&quot;release_date&quot;>1992-05-07</str>
      • <date name=&quot;timestamp&quot;>2008-02-28T10:06:01.682Z</date>
      • <str name=&quot;type&quot;>strip</str>
    • </doc> ...
    • </result>
    • </response>
  32. Getting Data Out http://localhost:8080/comix/select/?q=data&indent=on { &quot;responseHeader&quot;:{ &quot;status&quot;:0, &quot;QTime&quot;:1, &quot;params&quot;:{ &quot;wt&quot;:&quot;json&quot;, &quot;rows&quot;:[&quot;1&quot;, &quot;1&quot;], &quot;start&quot;:&quot;0&quot;, &quot;indent&quot;:&quot;on&quot;, &quot;q&quot;:&quot;data&quot;, &quot;version&quot;:&quot;2.2&quot;}}, &quot;response&quot;:{&quot;numFound&quot;:2,&quot;start&quot;:0,&quot;docs&quot;:[ { &quot;feature_id&quot;:&quot;3&quot;, &quot;release_date&quot;:&quot;1992-05-07&quot;, &quot;id&quot;:&quot;strip.3136&quot;, &quot;timestamp&quot;:&quot;2008-02-28T10:06:01.682Z&quot;}] }} JSON format
  33. Debug Query Option
    • Add &debugQuery=on to request params
    • Returns parsed form of query
    <str name=&quot;rawquerystring&quot;>c.i.a</str><str name=&quot;querystring&quot;>c.i.a</str><str name=&quot;parsedquery&quot;>PhraseQuery(text:&quot;c i a&quot;)</str><str name=&quot;parsedquery_toString&quot;>text:&quot;c i a&quot;</str>
  34. Debug Query Option II
    • Add &debugQuery=on to request params
    • Returns scoring information
    <str name=&quot;id=strip.2781,internal_docid=29854&quot;> 2.6219895 = (MATCH) fieldWeight(text:calvin in 29854), product of: 1.0 = tf(termFreq(text:calvin)=1) 2.6219895 = idf(docFreq=6222) 1.0 = fieldNorm(field=text, doc=29854) </str> <str name=&quot;id=strip.4078,internal_docid=31151&quot;> 2.6219895 = (MATCH) fieldWeight(text:calvin in 31151), product of: 1.0 = tf(termFreq(text:calvin)=1) 2.6219895 = idf(docFreq=6222) 1.0 = fieldNorm(field=text, doc=31151) </str>
  35. Deleting Data
    • POST
    <delete><id>35</id></delete> <delete><query>city:paris</query></delete>
  36. Command Line Control
    • curl http://localhost:8983/solr/update -H &quot;Content-type: text/xml&quot; --data-binary '<commit/>'
    • <?xml version=&quot;1.0&quot; encoding=&quot;UTF-8&quot;?><response><lst name=&quot;responseHeader&quot;>
    • <int name=&quot;status&quot;>0</int>
      • <int name=&quot;QTime&quot;>20</int>
      • </lst></response>
    • </lst></response>
    • </lst></response>
  37. Solr in 3 minutes!
    • Download Solr from Apache
    • Untar
    • &quot;ant example&quot;
    • Start the example app
    • Load data into Solr
    • Query
  38. Solr in Ten Minutes <Context docBase=&quot;/var/solr/apache-solr-1.2.0.war&quot; debug=&quot;0&quot; crossContext=&quot;true&quot; > <Environment name=&quot;solr/home&quot; type=&quot;java.lang.String&quot; value=&quot;/var/solr&quot; override=&quot;true&quot; /></Context>
    • Copy Solr's example/solr dir to /var/solr
    • Edit schema.xml and solrconfig.xml
    • Load data into Solr
    • In $CATALINA_HOME/conf/Catalina/localhost/foo.xml
  39. Directory Layout
    • ${solr.home}/conf
      • schema.xml
      • solrconfig.xml
    • ${solr.home}/data
    • ${solr.home}/logs
    • ${solr.home}/bin
  40. Java Solr Client
    • Called SolrJ
    • Not in Solr 1.2.
      • I grabbed from the HEAD from svn
      • Works with Solr 1.2
    • Add/Delete/Query/Commit/Optimize
  41. Adding Docs w/SolrJ Given Map<String, String> fields; CommonsHttpSolrServer server = new CommonsHttpSolrServer( url ); SolrInputDocument doc= new SolrInputDocument(); for (Map.Entry<String, String> e : fields.entrySet()){ doc.addField(e.getKey(), e.getValue()); } UpdateResponse res = server .add( doc);
  42. Deleting Docs w/SolrJ CommonsHttpSolrServer server = new CommonsHttpSolrServer( url ); UpdateResponse res; res = server .deleteById(&quot;100&quot;); res = server .deleteByQuery(&quot;city:paris&quot;);
  43. Simple Query CommonsHttpSolrServer server = new CommonsHttpSolrServer( url ); SolrQuery query = new SolrQuery(); query.setQuery(&quot;dance&quot;); QueryResponse rsp = server .query(query);
  44. More Interesting Query CommonsHttpSolrServer server = new CommonsHttpSolrServer( url ); SolrQuery query = new SolrQuery(); query.setQuery(&quot;dance&quot;); query.setFacet( true ); query.addFacetField(&quot;city&quot;); query.setFacetMinCount(1); query.addSortField( &quot;price&quot;, SolrQuery.ORDER.asc ); QueryResponse rsp = server .query(query);
  45. Query Responses
    • QueryResponse qr = server .query(query);
    • SolrDocumentList docs = qr.getResults();
    • List<FacetField> lf = qr.getFacetFields();
    • for (FacetField ff: lf) {
    • String fieldName = ff.getName();
    • List<FacetField.Count> lc = ff.getValues();
    • for (FacetField.Count c: lc) {
    • String countName = c.getName();
      • long count = c.getCount();
    • }
    • }
  46. Other Commands
    • Commit
      • server.commit()
    • Optimize
      • server.optimize()
    • Not too complicated!
  47. Request Handlers
    • Request handler define how the query is processed.
    • Two main types
      • StandardRequestHandler
      • DisMaxRequestHandler
      • You can implement your own
    • Changing in Solr 1.3
  48. &quot;Standard&quot; Request Handler
    • Accepts Solr Query Syntax
    • I tend to use it for my queries, not user queries.
  49. DisMaxRequestHandler
    • Recommended for user queries
    • Allows simple users keywords to be applied to multiple fields, with weighting.
    • Boost Functions
    • Boost Queries
  50. Boost Functions
    • Allow you to influence scoring at run time
    • Computationally Expensive!
    • Really useful for tuning scoring
    • linear(x,2,4) returns 2*x+4
      • x is a field
  51. The Solr Schema
    • schema.xml
      • Defines types used in this webapp
      • Defines the fields and their types
      • Defines &quot;copyFields&quot;
      • READ THE EXAMPLE SCHEMA.XML
  52. Types
    • Types define processing for a field
      • How the words are split (Whitespace? Punctuation? CIA != C.I.A.)
        • Stemming
        • Case Folding, etc
        • Predefined date, int, float, etc
        • c
  53. Analysis: Index and Query Time
    • Types have two modes
      • Index Time
      • Query Time
  54. Simple Text Field <fieldType name=&quot;text&quot; class=&quot;solr.TextField&quot; positionIncrementGap= &quot;100&quot;> <analyzer type=&quot;index&quot;> <tokenizer class=&quot;solr.WhitespaceTokenizerFactory&quot;/> <filter class=&quot;solr.StopFilterFactory&quot; ignoreCase=&quot;true&quot; words=&quot;stopwords.txt&quot;/></analyzer><analyzer type=&quot;query&quot;><tokenizer class=&quot;solr.WhitespaceTokenizerFactory&quot;/> <filter class=&quot;solr.SynonymFilterFactory&quot; synonyms=&quot;synonyms.txt&quot; ignoreCase=&quot;true&quot; expand=&quot;true&quot;/> <filter class=&quot;solr.StopFilterFactory&quot; ignoreCase=&quot;true&quot; words=&quot;stopwords.txt&quot;/></analyzer></fieldType> <filter class=&quot;solr.StopFilterFactory&quot; ignoreCase=&quot;true&quot; words=&quot;stopwords.txt&quot;/></analyzer></fieldType> <filter class=&quot;solr.StopFilterFactory&quot; ignoreCase=&quot;true&quot; words=&quot;stopwords.txt&quot;/></analyzer></fieldType>
  55. Analysis & Facets
    • Make sure to use an untokenized field for faceting.
    • &quot;San Jose&quot; != &quot;San&quot; &quot;Jose&quot;
  56. Fields
    • Elements of a document
      • Both predefined & dynamic
      • Fields may occur multiple times
      • Maybe indexed and/or stored
  57. Example Fields <field name=&quot;id&quot; type=&quot;string&quot; indexed=&quot;true&quot; stored=&quot;true&quot; required=&quot;true&quot; /><field name=&quot;name&quot; type=&quot;text&quot; indexed=&quot;true&quot; stored=&quot;true&quot;/><field name=&quot;alphaNameSort&quot; type=&quot;alphaOnlySort&quot; indexed=&quot;true&quot; stored=&quot;false&quot;/>
  58. Copy Fields
    • Two main uses
      • To analyze a field in two different ways
      • To concatenate fields
  59. The Solr Config File
    • solrconfig.xml
      • Defines request handlers, defaults, caches,
      • Read the example solrconfig.xml
  60. Configuring DisMax
    • Parameter defaults set in solrconfig.xml
    • Can be overridden in each request
      • Except for params labeled invariant
  61. DisMax Config Example <requestHandler name=&quot;dismax&quot; class=&quot;solr.DisMaxRequestHandler&quot; > <lst name=&quot;defaults&quot;> <str name=&quot;echoParams&quot;>explicit</str> <float name=&quot;tie&quot;>0.01</float> <str name=&quot;qf&quot;> text^0.5 features^1.0 name^1.2 sku^1.5 id^10.0 manu^1.1 cat^1.4 </str> <str name=&quot;pf&quot;> text^0.2 features^1.1 name^1.5 manu^1.4 manu_exact^1.9 </str> ... </requestHandler>
  62. DisMax Config Example <requestHandler name=&quot;dismax&quot; class=&quot;solr.DisMaxRequestHandler&quot; > ... <str name=&quot;bf&quot;> ord(poplarity)^0.5 recip(rord(price),1,1000,1000)^0.3 </str> <str name=&quot;fl&quot;> id,name,price,score </str>... </requestHandler>
  63. DisMax Config Example <requestHandler name=&quot;dismax&quot; class=&quot;solr.DisMaxRequestHandler&quot; > ... <str name=&quot;mm&quot;> 2&lt;-1 5&lt;-2 6&lt;90% </str> <int name=&quot;ps&quot;>100</int> <str name=&quot;q.alt&quot;>*:*</str> </lst> </requestHandler>
  64. Wrap Up
  65. Resources
    • Solr http://lucene.apache.org/solr/
      • wiki, mailing list, jira (bugs/features)
    • Lucene http://lucene.apache.org /
  66. Lucene In Action
  67. Building Search Applications with Lucene, lingpipe and Gate Manu Konchady Manu Konchady Manu Konchady
  68. Other Presentations
    • Yonik Seely's Solr & Lucene
      • http://people.apache.org/~yonik/presentations/
    • Slideshare.net
      • Search for solr, or search for lucene
  69. Thanks! Thanks for coming. Feel free to email me if you have questions about Solr Tom Hill [email_address]
  70. Extra Slides Things I didn't have time for in the presentation. Some of them unfinished.
  71. Search Engines are not the Same as Users
    • Search engines have different usage patterns than users
  72. Response Writers
    • http://localhost:8983/solr/select/?q=text_t%3Atiger&version=2.2&start=0&rows=10&indent=on& wt=ruby
    • http://localhost:8983/solr/select/?q=text_t%3Atiger&version=2.2&start=0&rows=10&indent=on& wt=xml
  73. Explain
    • Just why did the documents come up in that order?
  74. Data Matters
    • Gigo
    • The better the data is, the better the search will be.
  75. Watch Your Caches
    • Just like any other app, check your statistics
    • What's the hit rate for your caches?
  76. Setting Up Replication
    • Run rsyncd on the master
    • Run snapshot on the master at intervals
    • Run snappuller on the slaves at (different) intervals.
    • Scripts don't print errors!
      • Check the logs
      • Use bash -xv
  77. Autowarming
    • Runs after an update to the index
      • Updates flush caches
    • Runs some queries to populate caches again
    • Can be a problem, with frequent updates
      • Don't autowarm master, if updating lots
  78. Tour Of Solr's Web UI
  79. Programming Collective Intelligence A Really Fun Book
  80. Geographic Searching
    • Local Lucene & Local Solr
    • http://locallucene.wiki.sourceforge.net
    • There's also geolucene, but it's not being actively developed, as far as I can tell.
    • http://www.gossamer-threads.com/lists/l ucene/java-dev/53378
  81. http://localhost:8983/solr/admin/stats.jsp#update Are there commits pending?
  82. http://localhost:8983/comix/admin/analysis.jsp?name=text&val=wi-fi Analysis Explanation

+ tomhilltomhill, 2 years ago

custom

6697 views, 15 favs, 0 embeds more stats

A brief introduction to using Apache Solr for imple more

More info about this document

© All Rights Reserved

Go to text version

  • Total Views 6697
    • 6697 on SlideShare
    • 0 from embeds
  • Comments 4
  • Favorites 15
  • Downloads 348
Most viewed embeds

more

All embeds

less

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate. If needed, use the feedback form to let us know more details.

Cancel
File a copyright complaint
Having problems? Go to our helpdesk?

Categories
