Texas Floodplain Management Association               2011 Fall Conference                September 22, 2011Collaborations...
What is Flood Inundation Mapping?Flood Inundation Mapping (FIM) is a real-time,  operational tool that visually relates US...
Overview• Review of NWS Flood Inundation Mapping  Program  – Current locations and planned future work• Review of USGS Flo...
Status and GoalsNWS FLOOD INUNDATIONMAPPING PROGRAM
Status of AHPSFlood Inundation Mapping Services                                  http://water.weather.gov    62 AHPS Floo...
Direction of AHPSFlood Inundation Mapping Services            NWS Stakeholder Surveys      • Public wants Common Tools and...
Direction of AHPS Flood Inundation Mapping Services                     Meeting Stakeholder Needs              • Same Info...
Direction of AHPSFlood Inundation Mapping Services   Meeting Stakeholder Power User Needs                Better Visualizat...
Status and GoalsUSGS FLOOD INUNDATIONMAPPING INITIATIVE
Flood Library Tools
Static Inundation  Map Libraries
FIMI Web Mapping Application           “New” Features• Decision Matrix – ability to show  two linked dependent sites for o...
Next Steps in Products and            Communications• Toolbox and Map libraries   – Continue to elaborate on the guidance ...
Linking FIM to USGS WMA and FEMA HAZUSCOLLABORATIVE PROJECTS
Goals of the Interagency FloodInundation Mapping Meetings     Enhance inter-agency collaboration to bettercommunicate floo...
Interagency CoordinationRecent Activities Related to FIM       USGS and NWS SOW       Funding Documents       USGS cond...
USGS Hazus-MH Assessments                          Initial Results• USGS has processed large percentage of the NWS AHPS FI...
NWS AHPS FIM Lessons Learned              Cost Savings by Partnering               Costs go down                          ...
NWS AHPS and      USGS FIMI Lessons Learned            Cost Savings by Partnering          Costs go down                  ...
July 1994 Flooding in Albany, GA•17 inches of rain from Hurricane Alberto•Hundreds of millions in damages•23,000 people ev...
Functional Test Incorporating FIM into                  HAZUSPrototypeWeb Interface:RegionalAnalysis
Functional Test Incorporating FIM into                  HAZUSPrototypeWeb Interface:Analysis ofsingle censusblock         ...
Estimated Loss vs Stage - Flint River at                            Albany, new possibilities for analysis: Running HAZUS ...
USGS/FIMI Web Portal – Mockup of HAZUS Functionality
HAZUS Analysis of Single Census Block                Census Block Boundary
Web Application Schematic                           Offline                      Multiple HAZUS RunsInundation Polygons   ...
Notional Plan & TimelinePhase 1 (FY2011-12)•   Begin Level 1 HAZUS flood risk analyses for (~60) NWS Inundation Mapping   ...
NWS FIM Sites Ranked by AffectedPopulation and Dollar Value of Assets
The Path Forward• Commit to a Prototype Demonstration for Flood  Inundation Web Mapping Services, which will link real-  t...
Questions?
Upcoming SlideShare
Loading in...5
×

Nws floodplain inundation project

524

Published on



Presented at the 2011 Texas GIS Forum

Published in: Technology, Education
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
524
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
9
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

Nws floodplain inundation project

  1. 1. Texas Floodplain Management Association 2011 Fall Conference September 22, 2011Collaborations to Develop and Deploy Flood Inundation Maps David R. Maltby II USGS TX WSC Gregory P. Shelton NWS West Gulf RFC
  2. 2. What is Flood Inundation Mapping?Flood Inundation Mapping (FIM) is a real-time, operational tool that visually relates USGS streamgage readings and NWS forecasts to flood risk for the primary purpose of public safety, but also has significant benefits of: • Understanding changing natural processes that produce hazards • Development of hazard mitigation strategies and technologies • Effectively reduce vulnerability and repetition of loss to infrastructure • Promotion of risk-wise behavior
  3. 3. Overview• Review of NWS Flood Inundation Mapping Program – Current locations and planned future work• Review of USGS Flood Inundation Mapping Initiative (FIMI) – Current and future work• Review of Collaborative Projects between NWS and USGS – Incorporation of maps into HAZUS 3
  4. 4. Status and GoalsNWS FLOOD INUNDATIONMAPPING PROGRAM
  5. 5. Status of AHPSFlood Inundation Mapping Services http://water.weather.gov  62 AHPS Flood Inundation Map Libraries  Federal Guidelines Version 3 (Commonality Across Agencies)  QA/QC Plan and Training 5
  6. 6. Direction of AHPSFlood Inundation Mapping Services NWS Stakeholder Surveys • Public wants Common Tools and Features such as Google • Emergency Managers need Enhanced Decision Support Tools to support Weather Ready goals • According to recent NWS CFI customer survey, responses increased by 250%. • The number of respondents who claimed to be a personal user increased from 8 to 21 thousand or roughly 64% of all respondents. • The number of respondents for Emergency Response remained consistent. 6
  7. 7. Direction of AHPS Flood Inundation Mapping Services Meeting Stakeholder Needs • Same Information Across Multiple Platforms (Collaborations with Multiple Federal Agencies) Human • Common Tools and FeaturesDimension • Underlying Fundamental Science • Supported By Subject Matter ExpertsOperational Science Technical 7
  8. 8. Direction of AHPSFlood Inundation Mapping Services Meeting Stakeholder Power User Needs Better Visualization Enhanced Communication of Flood Risk and Likelihood for Flooding Flood Loss Potentials Concept from NWS Aptima Report, which surveyed EM, reservoir operator, and user.
  9. 9. Status and GoalsUSGS FLOOD INUNDATIONMAPPING INITIATIVE
  10. 10. Flood Library Tools
  11. 11. Static Inundation Map Libraries
  12. 12. FIMI Web Mapping Application “New” Features• Decision Matrix – ability to show two linked dependent sites for one reach• WaterAlert – Subscribe in the application• WaterWatch – Set the historical context for current flows using another USGS product• NWS forecast linkage – Working on which forecasts and how to display• SharePoint form for submission of libraries from USGS WSCs
  13. 13. Next Steps in Products and Communications• Toolbox and Map libraries – Continue to elaborate on the guidance and templates as needs arise through the pilot projects and cooperator/partner needs – Add NWS Inundation Libraries and more links to AHPS• Continue WMA development – Integrate more seamlessly with NWS forecasts • Combined live hydrograph and APTIS uncertainty communication ideas – Integrate with more NWS tools and web services – Work on including HAZUS information and maybe Dynamic Mapping – Explore print feature further with the SPN
  14. 14. Linking FIM to USGS WMA and FEMA HAZUSCOLLABORATIVE PROJECTS
  15. 15. Goals of the Interagency FloodInundation Mapping Meetings Enhance inter-agency collaboration to bettercommunicate flood risks and reduce repetitive flood losses RiskMAP (Mapping Assessment Planning) Incentives – NFIP Community Rating System Information - Coordinated Needs Mgmt System (CNMS) Hydraulic Models and Model Development Critical Infrastructure Data Geospatial Resources (LIDAR, DEM) Web Resources and Tools Coordinated outreach Real-time Data (River Stages, Precipitation, Soils, Projected Releases, Operational Data) Flood Warning and Observations Network Flood Forecast and Predictions
  16. 16. Interagency CoordinationRecent Activities Related to FIM  USGS and NWS SOW  Funding Documents  USGS conducted preliminary HAZUS Assessment using NWS AHPS Shapefiles and Depth Rasters  USACE National Levee Database  Review of Various Flood Awareness Tools  USACE FEMA Sponsored Silver Jackets Workshop in August 2011 16
  17. 17. USGS Hazus-MH Assessments Initial Results• USGS has processed large percentage of the NWS AHPS FIM Shapefiles and Depth Rasters• Half of the Initial Results show 1 to 4B dollars in financial exposure• Delaware River at Trenton, NJ had potentially 40,00 people at Risk• Iowa River at Iowa City had 3B dollars at risk 17
  18. 18. NWS AHPS FIM Lessons Learned Cost Savings by Partnering Costs go down Efficiency goes up• Additional cost to complete one inundation map library as part of a FEMA FIS or local Riverine Flood Study: 5 – 10 K (~5 to 10% cost increase)• Cost doubles and time increases if inundation map library is created after the study is completed: 15 – 20 K• Develop inundation libraries in conjunction with Flood Study yields significant user benefit for small incremental cost and address map maintenance for local communities 18
  19. 19. NWS AHPS and USGS FIMI Lessons Learned Cost Savings by Partnering Costs go down Efficiency goes upPhase 3 cost to implement one inundation map library:Current Implementation• on NWS AHPS via current interface: 8KProposed Implementation• on NWS AHPS Google interface: estimated 3-5K (Public)• on USGS FIMI Web Mapping Application: 1.5 K * (Power-user)* Need to be evaluated for web traffic, bandwidth, and high loading. 19
  20. 20. July 1994 Flooding in Albany, GA•17 inches of rain from Hurricane Alberto•Hundreds of millions in damages•23,000 people evacuated
  21. 21. Functional Test Incorporating FIM into HAZUSPrototypeWeb Interface:RegionalAnalysis
  22. 22. Functional Test Incorporating FIM into HAZUSPrototypeWeb Interface:Analysis ofsingle censusblock Albany State University
  23. 23. Estimated Loss vs Stage - Flint River at Albany, new possibilities for analysis: Running HAZUS for multiple stages opens up GA Breakout into low lying residential area
  24. 24. USGS/FIMI Web Portal – Mockup of HAZUS Functionality
  25. 25. HAZUS Analysis of Single Census Block Census Block Boundary
  26. 26. Web Application Schematic Offline Multiple HAZUS RunsInundation Polygons Local parcel & & Depth Grids infrastructure data Online Web Service Server Application Database FIMI Web Portal
  27. 27. Notional Plan & TimelinePhase 1 (FY2011-12)• Begin Level 1 HAZUS flood risk analyses for (~60) NWS Inundation Mapping Locations, (FEMA/USGS)• Add pilot HAZUS capability to FIMI Web portal. Begin development of manual with standards and guidelines for new site development.Phase 2 (FY2012-13)• Complete and QA/QC Level 1 HAZUS analyses.• Based on evaluations from Phase 1, develop Level 2 HAZUS capability for a selected subset of the 60 NOAA/NWS sites.• Draft manual with guidelines and standards for new site developmentPhase 3 and beyond….TBD
  28. 28. NWS FIM Sites Ranked by AffectedPopulation and Dollar Value of Assets
  29. 29. The Path Forward• Commit to a Prototype Demonstration for Flood Inundation Web Mapping Services, which will link real- time observations, flood forecasts and warnings, and FIM with geospatial flood hazard information from FEMA’s HAZUS program prior to December 31st.• Collect available resource to design, develop, implement subsequent prototype demonstrating coastal components of the Flood Inundation Mapping Tool.• Work towards common standards for flood inundation mapping products, such that shapefiles and rasters can be shared and consumed by various viewers for the public and power user. 29
  30. 30. Questions?
