Facebook flash api and social game development

  1. 1. Facebook Flash APIand Social Game Development<br />http://fb.me/tempofeng<br />
  2. 2. Agenda<br />Gamelet<br />Our Experiences<br />Tips & Tricks<br />Flash<br />Social<br />Facebook / Flash<br />Q & A<br />
  3. 3. Gamelet: Our Experiences<br />
  4. 4. Gamelet<br />
  5. 5. Web Traffics<br />
  6. 6. Gamelet<br />Published 17 Games<br />15 Real-Time Synchronized Games<br />2 Social Games<br />11 Employees<br />6 Engineers<br />3 Arts<br />
  7. 7. Gamelet<br />Bandwidth<br />60M/Month<br />Online Users<br />8000 users (max)<br />Aggregated MAU<br />400K (down from 800k)<br />
  8. 8. Servers<br />Web Servers<br />apache -> tomcat<br />2xDell PE R610 (1 Master-N Slave)<br />2xI5520, 6GB, SAS HDs<br />Static Files Servers<br />1xPC<br />Real-time Socket Servers<br />Java/Mina/ActiveMQ<br />3xDell PE R610<br />1xI5520, 6GB, SAS HDs<br />
  9. 9. Servers<br />DB Servers<br />MySQL<br />2xDell PE R710 (1Master, 1Standby)<br />2xI5530, 32GB, SAS HDs<br />Cassandra<br />2xDell PE R710<br />2xI5530, 32GB, SAS HDs<br />
  10. 10. Tip & Tricks - Flash<br />Development Environment<br />Art/Developers Workflow<br />Performance<br />Fighting Cheaters<br />Loader<br />crossdomain.xml<br />
  11. 11. Development Environment<br />Developers<br />Flash(Flex) Builder<br />Flex Components<br />Slow<br />Ram/CPU/SSD<br />Open Too Many Projects<br />Arts<br />Illustrator/Photoshop/Flash<br />
  12. 12. Arts/Developers Workflow<br />.as<br />Designers<br />Programmers<br />
  13. 13. Versioning Graphics Assets<br />Confusing!<br />SVN<br />Development Mode<br />car.fla, airplane.fla<br />Production Mode<br />car.fla, airplane.fla -> vehicle_v00.swf<br />
  14. 14. Performance<br />Monitoring Framerate<br />Don’t<br />Alpha, 變形工具<br />Large Bitmap<br />Parent/child Movieclip<br />Using<br />Sprite instead of Movieclip<br />
  15. 15. Performance<br />Slow Movieclip<br />cacheAsBitmap<br />Rotate, Scale, …<br />AnimationSlicer<br />http://blog.vandenoostende.com/2008/animationslicer/<br />Profiler<br />Memory Leak<br />
  16. 16. Fighting Cheaters<br />Manipulating Memory<br />Intercepting Packets<br />Accelerators<br />Double Login<br />Manipulating Code<br />Building a Bot<br />Fake Accounts<br />
  17. 17. Manipulating Memory<br />
  18. 18. Manipulating Memory<br />Cheat Engine<br />http://www.cheatengine.org/<br />Encode Critical Data<br />Heap Data<br />Scores, Weapon, …<br />
  19. 19. Manipulating Memory<br />class SecureInteger<br />{<br />int number;<br />int checksum;<br /> public void setNumber(int number)<br /> {<br />this.number = number;<br />this.checksum = md5(number);<br /> }<br /> public intgetNumber()<br /> {<br /> if(verifyMd5(number, checksum))<br /> return number;<br /> else<br /> throw new SecurityException();<br /> }<br />}<br />
  20. 20. Intercepting Packets<br />Add Signature<br />Encode<br />SSH<br />proprietary PKI solution<br />
  21. 21. Accelerators<br />變速精靈<br />http://tw.vrbrothers.com/speeder/<br />
  22. 22. Accelerators<br />Use Server Time Everywhere<br />Detecting<br />Calculate the difference between client time & server time<br />Network latency will be hard to predict<br />
  23. 23. Double Login<br />Logout Previous Logined User<br />Flash LocalConnect<br />Server Notification<br />
  24. 24. Manipulating Code<br />Obfuscator<br />Dynamically Download Encoded SWF<br />Loader.loadBytes(bytes)<br />
  25. 25. Building a Bot<br />Monitoring<br />Monitoring All Service Interfaces<br />AOP, Annotation<br />Limiting resource update<br />Limit by Time Period<br />Limit by User Roles, Levels<br />Guests, Unregistered Users<br />
  26. 26. Fake Accounts<br />Limit Help from Friends<br />
  27. 27. Loader<br />Loading Static Files<br />Always Retry!<br />
  28. 28. crossdomain.xml<br />crossdomain.xml<br />Access Remote Files<br />Security.allowDomain()<br />SWFs from Other Domain to Access Me<br />loader.loaderContext = new LoaderContext(true, ApplicationDomain.currentDomain)<br />Access Remote Image Files without crossdomain.xml<br />
  29. 29. Tips & Tricks – Social Games<br />Game Design<br />Viral Channels<br />Data Storage<br />
  30. 30. Game Design<br />Beautiful!<br />Gifting is the New Poke<br />Don’t Punish Users<br />Represent Relations between Friends<br />
  31. 31. Viral Channels<br />monfriends<br />
  32. 32. Data Storage<br />Read:Write = 1:1<br />MySQL<br />Transactional<br />Data Growing Slowly<br />Cassandra<br />Key/Value<br />Data Growing Fast<br />
  33. 33. Tips & Tricks – Facebook / Flash<br />Facebook API / Graph API<br />Chinese Input<br />Invite/Request without Page Reloaded<br />
  34. 34. Facebook API & Graph API<br />No Plan of Updating<br />Recommend<br />Calling Javascript API from Flash ExternalInterface<br /><ul><li>if (!ExternalInterface.available)
  35. 35. {
  36. 36. return;
  37. 37. }
  38. 38. ExternalInterface.call("lumixInviteFriends", invite, title, type, content, url, label, condensed, toUid(username));</li></li></ul><li>wmode = ‘opaque’<br />
  39. 39. wmode = ‘window’<br />
  40. 40. Chinese Input<br />Flash 9/10<br />Only wmode = ‘window’ Can Input Chinese<br />Will Hide javascript Windows<br />Flash 10.1<br />wmode = ‘opaque’ can input Chinese in IE/Firefox<br />
  41. 41. Flash 9,10 + wmode = ‘window’<br />Move or Hide the Flash<br />
  42. 42. Invite/Request without Page Reloaded<br />
  43. 43. Step 1: Dynamically Add an <iframe><br /><ul><li><iframe id='inviteFriendsIframe' name='inviteFriendsIframe' src='inviteFriendsIframe.do' scrolling='no' frameborder='0' width='760' height='800'></iframe></li></li></ul><li>Step 2: <fb:request-form> in <iframe><br /><fb:serverFbml><br /><fb:request-form action="closeFbmlIframe.do" invite="" type="" …><br />…<br /></fb:request-form><br /></fb:serverFbml><br />
  44. 44. Step 3: Close the <iframe> by Javascript<br /><script type="text/javascript"><br />$(document).ready(function()<br />{<br />window.parent.onFbmlIframeClosed();<br />});<br /></script><br />
  45. 45. Thanks<br />
  46. 46. http://apps.facebook.com/pizzaworld_tw/Pizza 世界<br />

×
