Nik Kalyani<br />DotNetNuke Corporation<br />Windows Azure: Building a Twitter Clone<br />Session Code: NE.09<br />
About<br />Nik Kalyani<br /><ul><li>Co-founder, DotNetNuke Corporation
Technology Entrepreneur, 15 years
Microsoft MVP (2005-2009)</li></ul>Online  <br /><ul><li>Email: nik@kalyani.com
Twitter: @techbubble
Blog: http://www.techbubble.net</li></li></ul><li>Session Objective<br />Provide insights on how to architect a large-scal...
Agenda<br />Azure Architecture<br />Storage Concepts<br />Micro-blogging Application <br />Requirements<br />Architecture<...
Azure Architecture<br />Your Applications<br />…<br />ServiceBus<br />Workflow<br />Database<br />Analytics<br />Identity<...
Azure Application Architecture<br />n<br />m<br />Worker Role<br />Web Role<br />LB<br />Cloud Storage (blob, table, queue...
Azure Durable Storage<br />Durable, scalable, available store<br />Simple interface<br />REST<br />ADO.NET Data Services<b...
Azure Data Storage Concepts<br /> Container<br />Blobs<br />http://&lt;account&gt;.blob.core.windows.net/&lt;container&gt;...
Block<br />Blob<br />Container<br />Account<br />Blob Storage Concepts<br />IMG001.JPG<br />pictures<br />IMG002.JPG<br />...
Blobs: Features and Functions<br />Store large objects <br />Associate metadata with blob<br />Metadata is &lt;name, value...
Table Storage Concepts<br />Entity<br />Table<br />Account<br />Name =…<br />Email = …<br />users<br />Name =…<br />Email ...
Tables: Features and Functions<br />Massively scalable, highly available and durable structured storage<br />Not RDMS -- n...
Queue Storage Concepts<br />Message<br />Queue<br />Account<br />128x128, http://…<br />thumbnail jobs<br />256x256, http:...
Queues: Features and Functions<br />An account can create many queues..<br />Queue Name is scoped by the account<br />A Qu...
Micro-blogging ApplicationRequirements<br />Relationships<br />Any user can “follow” any other user<br />A user can “unfol...
Micro-blogging ApplicationRequirements<br />Micro-blogging<br />Any user can post a message of up to 140 characters in len...
Micro-blogging ApplicationRequirements<br />Timeline<br />A public timeline of all posted messages is available to anybody...
Micro-blogging ApplicationArchitectural Considerations<br />Micro-blogging<br />The number of users will determine volume ...
Micro-blogging ApplicationArchitectural Considerations<br />Timelines<br />The public timeline is transient and will have ...
Micro-blogging ApplicationProfile, Messages and Relationships Storage<br />Table = User<br />PartitionKey = Username<br />...
Micro-blogging ApplicationFollow<br />User B Partition<br />User A follows User B<br />Following<br />[User D]<br />Messag...
Micro-blogging ApplicationFollow<br />User B Partition<br />Follower<br />[User A]<br />Following<br />[User D]<br />Messa...
Micro-blogging ApplicationFollow<br />User B Partition<br />User B follows User A<br />Following<br />[User D]<br />Follow...
Micro-blogging ApplicationFollow<br />User B Partition<br />Follower<br />[User A]<br />Following<br />[User A]<br />Follo...
Micro-blogging ApplicationMessage Posting<br />User B Partition<br />User A posts a message<br />Follower<br />[User A]<br...
Micro-blogging ApplicationMessage Posting<br />User B Partition<br />Message added to Message Queue<br />Follower<br />[Us...
Micro-blogging ApplicationMessage Posting<br />User B Partition<br />After Message Worker Role processes…<br />Follower<br...
Micro-blogging ApplicationMessage Posting<br />User B Partition<br />After Maintenance Worker Role processes…<br />Followe...
Micro-blogging ApplicationMessage Maintenance<br />User B Partition<br />User A posts a message<br />Follower<br />[User A...
Micro-blogging ApplicationMessage Maintenance<br />User B Partition<br />Message added to Message Queue<br />Follower<br /...
Micro-blogging ApplicationMessage Maintenance<br />User B Partition<br />After Message Worker Role processes…<br />Followe...
