Hcj 2013-01-21

The Power of Hadoop to Transform Business©MapR Technologies - Confidential 1

My Background University, Startups – Aptex, MusicMatch, ID Analytics, Veoh – big data since before it was big Open source – even before the internet – Apache Hadoop, Mahout, Zookeeper, Drill – bought the beer at first HUG MapR Founding member of Apache Drill©MapR Technologies - Confidential 2

MapR Technologies Silicon Valley Startup – Top investors – Top technical and management team • Google, Microsoft, EMC, NetApp, Oracle Enterprise quality distribution for Hadoop Many extensions to basic Hadoop function Strong supporter of Apache Drill©MapR Technologies - Confidential 3

Philosophy First What is History?©MapR Technologies - Confidential 4

The study of the past(what came before now)©MapR Technologies - Confidential 5

What is the future? (it comes after now)©MapR Technologies - Confidential 6

©MapR Technologies - Confidential 7

But the future also has a past!©MapR Technologies - Confidential 10

Do you remember the future?©MapR Technologies - Confidential 11

Some things turned out as expected©MapR Technologies - Confidential 17

Many things are different!©MapR Technologies - Confidential 19

Hadoop has a history©MapR Technologies - Confidential 20

Hadoop also has a future©MapR Technologies - Confidential 21

The Old Future of Hadoop Map-reduce and HDFS – more and more, but not really different Eco-system additions – Simpler programming (Hive and Pig) – Key-value store – Ad hoc query Stands apart from other computing – Required by HDFS and other limitations©MapR Technologies - Confidential 22

The New Future of Hadoop Real-time processing – Combines real-time and long-time Integration with traditional IT – No need to stand apart Integration with new technologies – Solr, Node.js, Twisted all should interface directly Fast and flexible computation – Drill logical plan language©MapR Technologies - Confidential 23

Example #1 Search Abuse©MapR Technologies - Confidential 24

History matrix One row per user One column per thing©MapR Technologies - Confidential 25

Recommendation based on cooccurrence Cooccurrence gives item-item mapping One row and column per thing©MapR Technologies - Confidential 26

Cooccurrence matrix can also be implemented as a search index©MapR Technologies - Confidential 27

SolR SolR Complete Cooccurrence Indexer Solr Indexer history (Mahout) indexing Item meta- Index data shards©MapR Technologies - Confidential 28

SolR SolR User Indexer Solr Web tier Indexer history search Item meta- Index data shards©MapR Technologies - Confidential 29

Objective Results At a very large credit card company History is all transactions, all web interaction Processing time cut from 20 hours per day to 3 Recommendation engine load time decreased from 8 hours to 3 minutes©MapR Technologies - Confidential 30

Example #2 Web Technology©MapR Technologies - Confidential 31

Real-time Fast analysis data (Storm) Analytic Raw logs output©MapR Technologies - Confidential 32

Large analysis (map-reduce) Analytic Raw logs output©MapR Technologies - Confidential 33

Presentation Browser tier (d3 + query node.js) Analytic Raw logs output©MapR Technologies - Confidential 34

Objective Results Real-time + long-time analysis is seamless Web tier can be rooted directly on Hadoop cluster No need to move data©MapR Technologies - Confidential 35

Example #3 Apache Drill©MapR Technologies - Confidential 36

Big Data Processing – Hadoop Batch processing Query runtime Minutes to hours Data volume TBs to PBs Programming MapReduce model Users Developers Google project MapReduce Open source Hadoop project MapReduce©MapR Technologies - Confidential 37

Big Data Processing – Hadoop and Storm Batch processing Stream processing Query runtime Minutes to hours Never-ending Data volume TBs to PBs Continuous stream Programming MapReduce DAG model (pre-programmed) Users Developers Developers Google project MapReduce Open source Hadoop Storm or Apache S4 project MapReduce©MapR Technologies - Confidential 38

Big Data Processing – The missing part Batch processing Interactive analysis Stream processing Query runtime Minutes to hours Never-ending Data volume TBs to PBs Continuous stream Programming MapReduce DAG model (pre-programmed) Users Developers Developers Google project MapReduce Open source Hadoop Storm and S4 project MapReduce©MapR Technologies - Confidential 39

Big Data Processing – The missing part Batch processing Interactive analysis Stream processing Query runtime Minutes to hours Milliseconds to Never-ending minutes Data volume TBs to PBs GBs to PBs Continuous stream Programming MapReduce Queries DAG model (ad hoc) (pre-programmed) Users Developers Analysts and Developers developers Google project MapReduce Open source Hadoop Storm and S4 project MapReduce©MapR Technologies - Confidential 40

Big Data Processing Batch processing Interactive analysis Stream processing Query runtime Minutes to hours Milliseconds to Never-ending minutes Data volume TBs to PBs GBs to PBs Continuous stream Programming MapReduce Queries DAG model Users Developers Analysts and Developers developers Google project MapReduce Dremel Open source Hadoop Storm and S4 project MapReduce©MapR Technologies - Confidential 41

Big Data Processing Batch processing Interactive analysis Stream processing Query runtime Minutes to hours Milliseconds to Never-ending minutes Data volume TBs to PBs GBs to PBs Continuous stream Programming MapReduce Queries DAG model Users Developers Analysts and Developers developers Google project MapReduce Dremel Open source Hadoop Storm and S4 project MapReduce Apache Drill©MapR Technologies - Confidential 42

Design Principles Flexible Easy • Pluggable query languages • Unzip and run • Extensible execution engine • Zero configuration • Pluggable data formats • Reverse DNS not needed • Column-based and row-based • IP addresses can change • Schema and schema-less • Clear and concise log messages • Pluggable data sources Dependable Fast • No SPOF • C/C++ core with Java support • Instant recovery from crashes • Google C++ style guide • Min latency and max throughput (limited only by hardware)©MapR Technologies - Confidential 43

Simple Architecture Query Interface language Logical Transform Language Physical Optimize Execute Plan©MapR Technologies - Confidential 44

Standard Interfaces Query SQL 2003 Interface language Drill logical syntax Logical Transform Scanner Language API Physical Optimize Execute Plan©MapR Technologies - Confidential 45

Logical Plan Syntax: query:[ { op:"sequence", do:[ { op: "scan", memo: "initial_scan", ref: "donuts", source: "local-logs", selection: {data: "activity"} }, { op: "transform", transforms: [ { ref: "donuts.quanity", expr: "donuts.sales”} ] }, { op: "filter", expr: "donuts.ppu < 1.00" }, …©MapR Technologies - Confidential 46

Logical Streaming Example 01 23 4 { @id: <refnum>, op: “window-frame”, input: <input>, keys: [ 0 <name>,... 01 ], 012 ref: <name>, 123 before: 2, 234 after: here }©MapR Technologies - Confidential 47

Execution Plan scan-json "table-1" scan-json "table-1" scan-json "table-1" filter exp1 filter exp1 filter exp1 flatten flatten flatten node1 node2 node3 aggregate exp2©MapR Technologies - Confidential 49

Representing a DAG 18 aggregate exp2 19 { @id: 19, op: "aggregate", input: 18, type: <simple|running|repeat>, keys: [<name>,...], aggregations: [ {ref: <name>, expr: <aggexpr> },... ] }©MapR Technologies - Confidential 50

Non-SQL queries scan-json "table-1" scan-json "table-1" streaming k-means ball k- k means aggregate exp2 k-means join cluster features©MapR Technologies - Confidential 51

Design Principles Flexible Easy • Pluggable query languages • Unzip and run • Extensible execution engine • Zero configuration • Pluggable data formats • Reverse DNS not needed • Column-based and row-based • IP addresses can change • Schema and schema-less • Clear and concise log messages • Pluggable data sources Dependable Fast • No SPOF • C/C++ core with Java support • Instant recovery from crashes • Google C++ style guide • Min latency and max throughput (limited only by hardware)©MapR Technologies - Confidential 52

Get Involved! Download these slides – http://www.mapr.com/company/events/hcj-01-21-2013 Join the Drill project – drill-dev-subscribe@incubator.apache.org – #apachedrill Contact me: – tdunning@maprtech.com – tdunning@apache.org – @ted_dunning Join MapR (in Japan!) – jobs@mapr.com©MapR Technologies - Confidential 56
