Making Exceptions on Exception Handling (WEH 2012 Keynote Speech)

  1. 1. Making Exceptions on Exception Handling Tao Xie Department of Computer Science North Carolina State University Raleigh, USAJoint work with Suresh Thummalapenta (IBM Research India) WEH 2012
  2. 2. Software Reuse Programmers commonly reuse APIs of existing frameworks or libraries – Advantages: High productivity of development – Challenges: Complexity and lack of documentation – Consequences: • Spend efforts in understanding APIs • Introduce defects in API client code 2 2
  3. 3. Exception Handling APIs throw exceptions during runtime errors Example: Session API of Hibernate framework throws HibernateException APIs expect client applications to implement recovery actions after exceptions occur Example: Session API of Hibernate expect client application to rollback open uncommitted transactions after HibernateException occurs 3 [Weimer&Necula 05]
  4. 4. Exception Handling Failing to handle exceptions results in  Fatal issues: Database lock won’t be released if the transaction is not rolled back  Performance degradation due to resource leaks: 17% increase in the performance is found in a 34KLOC program after properly handling exceptions [Weimer and Necula04] Use specification that describes exception- handling behavior  Write correct API client code  Detect defects in API client code 4
  5. 5. Problem  Problem: Often specifications are not documented  Solution: Mine specifications from existing code bases using APIsMining Software Repositories (MSR) Bugzilla Mailings International effort to make software repositories actionable Code Execution CVS 5 http://msrconf.org repository traces
  6. 6. Solution-Driven Problem-DrivenWhere can I apply X miner? What patterns do we really need? Basic Advanced mining mining New/adapted algorithms algorithms mining algorithmsE.g., association rule mining, E.g., frequent partial orderfrequent itemset mining… mining [ESEC/FSE 07] E.g., [ICSE 09], [ASE 09] 6
  7. 7. Solution-Driven Problem-DrivenWhere can I apply X miner? What patterns do we really need? Basic Advanced mining mining New/adapted algorithms algorithms mining algorithmsE.g., association rule E.g., frequent partial ordermining, frequent itemset mining [ESEC/FSE 07] E.g., [ICSE 09], [ASE 09]mining… 7
  8. 8. Example Scenario 11.1: ...  Defect: No rollback done1.2: OracleDataSource ods = null; Session session = null; Connection conn = null; Statement statement = null; when SQLException occurs1.3: logger.debug("Starting update");1.4: try {  Requires specification such1.5: ods = new OracleDataSource();1.6: ods.setURL("jdbc:oracle:thin:scott/tiger@192.168.1.2:1521:catfish"); as “Connection should be1.7: conn = ods.getConnection();1.8: statement = conn.createStatement(); rolled back when a1.9: statement.executeUpdate("DELETE FROM table1");1.10: connection.commit(); } connection is created and1.11: catch (SQLException se) { SQLException occurs”1.13: logger.error("Exception occurred"); }1.14: finally {1.15: if(statement != null) { statement.close(); }  Q: Should every connection1.16: if(conn != null) { conn.close(); } instance has to be rolled1.17: if(ods != null) { ods.close(); } }1.18: } back when SQLException occurs? Missing “conn.rollback()” 8
  9. 9. Example (cont.) Scenario 1 Scenario 21.1: ... 2.1: Connection conn = null;1.2: OracleDataSource ods = null; Session session = null; 2.2: Statement stmt = null; Connection conn = null; Statement statement = null; 2.3: BufferedWriter bw = null; FileWriter fw = null;1.3: logger.debug("Starting update"); 2.3: try {1.4: try { 2.4: fw = new FileWriter("output.txt");1.5: ods = new OracleDataSource(); 2.5: bw = BufferedWriter(fw);1.6: ods.setURL("jdbc:oracle:thin:scott/tiger@192.168.1.2:1521:catfish"); 2.6: conn = DriverManager.getConnection("jdbc:pl:db", "ps", "ps");1.7: conn = ods.getConnection(); 2.7: Statement stmt = conn.createStatement();1.8: c statement = conn.createStatement(); 2.8: ResultSet res = stmt.executeQuery("SELECT Path FROM Files");1.9: statement.executeUpdate("DELETE FROM table1"); 2.9: while (res.next()) {1.10: connection.commit(); } 2.10: bw.write(res.getString(1));1.11: catch (SQLException se) { 2.11: }1.12: if (conn != null) { conn.rollback(); } 2.12: res.close();1.13: logger.error("Exception occurred"); } 2.13: } catch(IOException ex) { logger.error("IOException occurred");1.14: finally { 2.14: } finally {1.15: if(statement != null) { statement.close(); } 2.15: if(stmt != null) stmt.close();1.16: if(conn != null) { conn.close(); } 2.16: if(conn != null) conn.close();1.17: if(ods != null) { ods.close(); } } 2.17: if (bw != null) bw.close();1.18: } 2.18: } Specification: “Connection creation => Connection rollback”  Satisfied by Scenario 1 but not by Scenario 2  But Scenario 2 has no defect 9
  10. 10. Example (cont.) Simple association rules of the form “FCa => FCe” are not expressive [Weimer&Necula 05] Requires more general association rules (sequence association rules) such as (FCc1 FCc2) Λ FCa => FCe1, where FCc1 -> Connection conn = OracleDataSource.getConnection() FCc2 -> Statement stmt = Connection.createStatement() FCa -> stmt.executeUpdate() FCe1 -> conn.rollback() 10
  11. 11. Example (cont.) Simple association rules of the form “FCa => FCe” are not expressive [Weimer&Necula 05] Requires more general association rules (sequence association rules) such as (FCc1 FCc2) Λ FCa => FCe1, where FCc1 -> Connection conn = OracleDataSource.getConnection() FCc2 -> Statement stmt = Connection.createStatement() FCa -> stmt.executeUpdate() //Triggering Action FCe1 -> conn.rollback() 11
  12. 12. Example (cont.) Simple association rules of the form “FCa => FCe” are not expressive [Weimer&Necula 05] Requires more general association rules (sequence association rules) such as (FCc1 FCc2) Λ FCa => FCe1, where FCc1 -> Connection conn = OracleDataSource.getConnection() FCc2 -> Statement stmt = Connection.createStatement() FCa -> stmt.executeUpdate() FCe1 -> conn.rollback() //Recovery Action 12
  13. 13. Example (cont.) Simple association rules of the form “FCa => FCe” are not expressive [Weimer&Necula 05] Requires more general association rules (sequence association rules) such as (FCc1 FCc2) Λ FCa => FCe1, where FCc1 -> Connection conn = OracleDataSource.getConnection() FCc2 -> Statement stmt = conn.createStatement() //Context FCa -> stmt.executeUpdate() FCe1 -> conn.rollback() 13
  14. 14. CAR-Miner ApproachIssue queries and collect relevant code examples. Eg: “lang:java Construct exception- java.sql.Statement executeUpdate” flow graphs Open Source Projects on web 1 2 … N Exception-Flow … Graphs Static TracesClasses and Functions Extract classes Collect static traces and functions Mine static traces reused Sequence Input Violations AssociationApplication Rules Check whether there are any exception-related Detect violations defects 14
  15. 15. CAR-Miner Approach Open Source Projects on web 1 2 … N Exception-Flow … Graphs Static TracesClasses and Functions Sequence Input Violations AssociationApplication Rules 15
  16. 16. Exception-Flow-Graph Construction Based on a previous algorithm [Sinha&Harrold TSE 00] : normal execution path ----: exceptional execution path
  17. 17. Exception-Flow-Graph Construction Prevent infeasible edges using a sound static analysis [Robillard&Murphy FSE 99] 17
  18. 18. CAR-Miner Approach Open Source Projects on web 1 2 … N Exception-Flow … Graphs Static TracesClasses and Methods Sequence Input Violations AssociationApplication Rules 18
  19. 19. Static Trace Generation  Collect static traces with the actions taken when exceptions occur  A static trace for Node 7: “4 -> 5 -> 6 -> 7 -> 15 -> 16 -> 17” 19
  20. 20. Static Trace Generation  Includes 3 sections:  Normal function- call sequence (4 -> 5 -> 6)  Function call (7)  Exception function-call sequence (15 -> 16 -> 17) A static trace for Node 7: “4 -> 5 -> 6 -> 7 -> 15 -> 16 -> 17” 20
  21. 21. Trace Post-Processing  Identify and remove unrelated function calls using data dependency  “4 -> 5 -> 6 -> 7 -> 15 -> 16 -> 17” 4: FileWriter fw = new FileWriter(“output.txt”) 5: BufferedWriter bw = new BufferedWriter(fw) ... 7: Statement stmt = conn.createStatement() ...  Filtered sequence “6 -> 7 -> 15 -> 16“ 21
  22. 22. CAR-Miner Approach Open Source Projects on web 1 2 … N Exception-Flow … Graphs Static TracesClasses and Methods Sequence Input Violations AssociationApplication Rules 22
  23. 23. Static Trace Mining Handle traces of each function call (triggering function call) individually Input: Two sequence databases with a one-to-one mapping • normal function-call sequences (context) • exception function-call sequences (recovery) Objective: Generate sequence association rules of the form (FCc1 ... FCcn) Λ FCa => FCe1 ... FCen Context Trigger Recovery 23
  24. 24. Mining Problem Definition Input: Two sequence databases with a one-to-one mapping Context Recovery Objective: To get association rules of the form FC1 FC2 ... FCm -> FE1 FE2 ... FEn where {FC1, FC2, ..., Fcm} Є SDB1 and {FE1, FE2, ..., Fen} Є SDB2 Existing association rule mining algorithms cannot be directly applied on multiple sequence databases 24
  25. 25. Mining Problem Solution Annotate the sequences to generate a single combined database Apply frequent subsequence mining algorithm [Wang and Han, ICDE 04] to get frequent sequences Transform mined sequences into sequence association rules (3 10) Λ FCa => (2 8) Context Trigger Recovery Rank rules based on the support assigned by frequent subsequence mining algorithm 25
  26. 26. CAR-Miner Approach Open Source Projects on web 1 2 … N Exception-Flow … Graphs Static TracesClasses and Methods Sequence Input Violations AssociationApplication Rules 26
  27. 27. Violation Detection Analyze each call site of triggering call FCa  Step 1: Extract context call sequence “CC1 CC2 ... CCm” from the beginning of the function to the call site of FCa  Step 2: If CC1 CC2 ... CCm is super-sequence of FCc1 ... FCcn  Report any missing function calls of {FCe1 ... FCen} in any exception path API client: (CC1 CC2 ... CCm) Λ FCa => Missing any? isSuperSeqOf API Rule: (FCc1 ... FCcn) Λ FCa => FCe1 ... FCen Context Trigger Recovery 27
  28. 28. EvaluationResearch Questions:1. Do the mined rules represent real rules?2. Do the detected violations represent real defects?3. Does CAR-Miner perform better than WN- miner [Weimer&Necula 05]?4. Do the sequence association rules help detect new defects? 28
  29. 29. Subjects Internal Info: classes and methods belonging to the app External Info: classes and methods used by the app Code examples: #files collected through code search engine 29
  30. 30. RQ1: Real Rules Do the mined rules represent real rules? Real rules: 55% (Total: 294) Usage patterns: 3% 30 False positives: 43%
  31. 31. RQ1: Distribution of Real Rules for Axion Distribution of rules based on ranks assigned by CAR-Miner #false positives is quite low between 1 to 60 rules 31
  32. 32. RQ2: Detected Violations Do the detected violations represent real defects? Total number of defects: 160 New defects not found by WN-Miner approach: 87 32
  33. 33. RQ2: Status of Detected Violations HsqlDB developers responded on the first 10 reported defects  Accepted 7 defects  Rejected 3 defects Reason given by HsqlDB developers for rejected defects: “Although it can throw exceptions in general, it should not throw with HsqlDB, So it is fine” 33
  34. 34. RQ3: Comparison with WN-miner Does CAR-Miner performs better than WN-miner? Found 224 new rules and missed 32 rules CAR-Miner detected most of the rules mined by WN-miner Two major factors:  sequence association rules 34  Increase in the data scope
  35. 35. RQ4: New defects by sequence association rules Do the sequence association rules detect new defects? Detected 21 new real defects among all applications 35
  36. 36. Agenda Motivation Mining Sequence Association Rules (CAR-Miner) [ICSE 09]  Detecting Exception-Handling Defects Mining Alternative Patterns (Alattin) [ASE 09]  Detecting Neglected Condition Defects Conclusion 36
  37. 37. Large Number of False Positives Existing approaches produce a large number of false positives One major observation:  Programmers often write code in different ways for achieving the same task  Some ways are more frequent than others Frequent Infrequent ways ways mine patterns detect violations Mined Patterns 37 37
  38. 38. Example: java.util.Iterator.next() Java.util.Iterator.next() throws NoSuchElementException when invoked on a list without any elements Code Example 2 Code Sample 1 Code Sample 2PrintEntries1(ArrayList<string> PrintEntries2(ArrayList<string> entries) entries){ { … … Iterator it = entries.iterator(); if(entries.size() > 0) { if(it.hasNext()) { Iterator it = entries.iterator(); string last = (string) it.next(); string last = (string) it.next(); } } … …} } 38
  39. 39. Example: java.util.Iterator.next() Code Sample 1 Code Sample 2PrintEntries1(ArrayList<string> PrintEntries2(ArrayList<string> entries) entries){ { … … Iterator it = entries.iterator(); if(entries.size() > 0) { if(it.hasNext()) { Iterator it = entries.iterator(); string last = (string) it.next(); string last = (string) it.next(); } } … …} } Sample 2 (6/1243) Sample 1 (1218 / 1243) 1243 code examples Mined Pattern from existing approaches: “boolean check on return of Iterator.hasNext before Iterator.next” 39
  40. 40. Example: java.util.Iterator.next() Code Sample 1 Code Sample 2 PrintEntries1(ArrayList<string> PrintEntries2(ArrayList<string> entries) entries) { { … … Iterator it = entries.iterator(); if(entries.size() > 0) { if(it.hasNext()) { Iterator it = entries.iterator(); string last = (string) it.next(); string last = (string) it.next(); } } … … } } Require more general patterns (alternative patterns): P1 or P2P1 : boolean check on return of Iterator.hasNext before Iterator.nextP2 : boolean check on return of ArrayList.size before Iterator.next Cannot be mined by existing approaches, since alternative P2 40is infrequent
  41. 41. Our Solution: ImMiner Algorithm Mines alternative patterns of the form P1 or P2 Based on the observation that infrequent alternatives such as P2 are frequent among code examples that do not support P1 1243 code examples Sample 2 (6/1243) Sample 1 (1218 / 1243) P2 is infrequent among entire P2 is frequent among code 1243 code examples examples not supporting P1 41
  42. 42. Alternative Patterns ImMiner mines three kinds of alternative patterns of the general form “P1 or P2” Balanced: all alternatives (both P1 and P2) are frequentImbalanced: some alternatives (P1) are frequent and others are infrequent (P2). Represented as “P1 or P^2”Single: only one alternative 42
  43. 43. ImMiner Algorithm Uses frequent-itemset mining [Burdick et al. ICDE 01] iteratively An input database with the following APIs for Iterator.next() Input database Mapping of IDs to APIs 43
  44. 44. ImMiner Algorithm: Frequent Alternatives Input database Frequent itemset mining (min_sup 0.5) Frequent item: 1 P1: boolean-check on the return of Iterator.hasNext() before Iterator.next() 44
  45. 45. ImMiner: Infrequent Alternatives of P1 Split input database into two databases: Positive and Negative Positive database (PSD) Negative database (NSD) Mine patterns that are frequent in NSD and are infrequent in PSD Reason: Only such patterns serve as alternatives for P1  Alternative Pattern : P “const check on the return of ArrayList.size() 2before Iterator.next()”  Alattin applies ImMiner algorithm to detect neglected conditions 45
  46. 46. Neglected Conditions Neglected conditions refer to  Missing conditions that check the arguments or receiver of the API call before the API call  Missing conditions that check the return or receiver of the API call after the API call One of the primary reasons for many fatal issues  security or buffer-overflow vulnerabilities [Chang et al. ISSTA 07] 46
  47. 47. Evaluation Research Questions:1. Do alternative patterns exist in real applications?2. How high percentage of false positives are reduced (with low or no increase of false negatives) in detected violations? 47
  48. 48. Subjects #Samples: #code examples collected from Google code search Two categories of subjects:  3 Java default API libraries  3 popular open source libraries 48
  49. 49. RQ1: Balanced and Imbalanced Patterns How high percentage of balanced and imbalanced patterns exist in real apps?  Balanced patterns: 0% to 30% (average: 9.69%)  Imbalanced patterns:  30% to 100% (average: 65%) for Java default API libraries  0% to 9.5% (average: 5%) for open source libraries  Explanation: Java default API libraries provide more different ways of 49 writing code compared to open source libraries
  50. 50. RQ2: False Positives and False Negatives How high % of false positives are reduced (with low or no increase of false negatives)? Applied mined patterns (“P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j ”) in three modes:  Existing mode: “P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j ”  P1 ,P2, ... , Pi  Balanced mode: “P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j ”  “P1 or P2 or ... or Pi”  Imbalanced mode: “P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j ”  “P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j ”50
  51. 51. RQ2: False Positives and False Negatives Existing Mode vs Balanced Mode Application Existing Mode Balanced Mode Defects False Defects False % of False Positives Positives reduction Negatives Java Util 37 104 37 104 0 0 Java 51 105 51 105 0 0 Transaction Java SQL 56 143 56 90 37.06 0 BCEL 2 14 2 8 42.86 0 HSqlDB 1 0 1 0 0 0 Hibernate 10 9 10 8 11.11 0 AVERAGE/ 15.17 0 TOTAL  Balanced mode reduced false positives by 15.17% without any increase in false negatives 51
  52. 52. RQ2: False Positives and False Negatives Existing Mode vs Imbalanced Mode Application Existing Mode Imbalanced Mode Defects False Defects False % of False Positives Positives reduction Negatives Java Util 37 104 36 74 28.85 1 Java 51 105 47 76 27.62 4 Transaction Java SQL 56 143 53 81 43.36 3 BCEL 2 14 2 6 57.04 0 HSqlDB 1 0 1 0 0 0 Hibernate 10 9 10 8 11.11 0 AVERAGE/ 28.01 8 TOTAL Imbalanced mode reduced false positives by 28% with quite small increase in false negatives 52
  53. 53. Conclusion Problem-driven methodology by identifying new problems, patterns mining algorithms, defects CAR-Miner [ICSE 09]: mining sequence association rules of the form (FCc1 ... FCcn) Λ FCa => (FCe1 ... Fcen) Context Trigger Recovery  reduce false negatives Alattin [ASE 09]: mining alternative patterns classified into three categories: balanced, imbalanced, and single P1 or P2 or ... or Pi or A^1 or A^2 or ... or A^j  reduce false positives Combining both 53 NLP on API documents [Pandita et al. ICSE 12]
  54. 54. Solution-Driven Problem-DrivenWhere can I apply X miner? What patterns do we really need? Basic Advanced mining mining New/adapted algorithms algorithms mining algorithmsE.g., association rule mining, E.g., frequent partial orderfrequent itemset mining… mining [ESEC/FSE 07] E.g., [ICSE 09], [ASE 09] 54
  55. 55. Road Ahead: Software Analytics Software analytics is to enable software practitioners to perform data exploration and analysis in order to obtain insightful and actionable information for data-driven tasks around software and services. •Get research problems from real practice •Get feedback from real practice •Collaborate across disciplines •Collaborate with industryDongmei Zhang and Tao Xie, Software Analytics in Practice, mini-tutorial ICSE 2012 SEIP. 55http://research.microsoft.com/en-us/groups/sa/softwareanalyticsinpractice_minitutorial_icse2012.pdf
  56. 56. Thank You Questions? https://sites.google.com/site/asergrp/This work is supported in part by NSF grants CCF-0845272, CCF-0915400, 56CNS-0958235, and ARO grant W911NF-08-1-0443.
  57. 57. Alattin Approach Phase 1: Issue queries and collect relevant code samples. Eg: “lang:java Phase 2: Generate java.util.Iterator next” pattern candidates Open Source Projects on web 1 2 … N Pattern … Candidates Classes and methods Extract classes and methods Phase 3: Mine reused alternative patterns Application Alternative ViolationsUnder Analysis Patterns Detect neglected Phase 4: Detect neglected conditions conditions statically 57
  58. 58. Keys to Making Real Impact Engagement of practitioners ¤ Solving their problem ¤ Champions in product teams ¤ Timing ¤ Culture Walking the last mile ¤ Targeting at real scenarios ¤ Trying out tool has cost ¤ “It works” is not enough ¤ Getting engineering support Combination of expertise ¤ Research capabilities ¤ Engineering skills to build systems ¤ Visualization & design ¤ Communication MSR 2012 58

×
