    Oracle LOB Internals and Performance Tuning Oracle LOB Internals and Performance Tuning Presentation Transcript

    • RMOUG Training Days 2004 LOB Internals and Performance Tuning Tanel Põder independent consultant http://integrid.info 1/4011-Feb-04 Tanel Põder RMOUG Training Days
    • Agenda• Introduction & about• Storing large content in Oracle database• LOB internal architecture• LOB physical storage planning• LOB cache layer tuning• Accessing and loading LOBs• Dev/architecture strategies• Temporary LOBs• Summary 2/40Tanel Põder RMOUG Training Days
    • Introduction & About• Name: Tanel Põder• Experience: 7 years as Oracle DBA• Occupation: independent consultant• Company: integrid.info• Other: Europe, Middle-East & Africa Oracle User Group BoD member• Oracle Certified Master DBA• More information and presentations: http://integrid.info 3/40Tanel Põder RMOUG Training Days
    • Storing Content in Oracle• CHAR/VARCHAR2 - 2000/4000 byte limit• RAW - 2000 byte limit• LONG/LONG RAW - always stored in row - no random access - one column per table - hard to maintainLOBs - a powerful way for storing,accessing and maintaining large contentin Oracle database 4/40Tanel Põder RMOUG Training Days
    • Large Content in VARCHARs• DBA_SOURCE SQL> desc dba_source Name Null? Type ------------------- -------- --------------- OWNER VARCHAR2(30) NAME VARCHAR2(30) TYPE VARCHAR2(12) LINE NUMBER TEXT VARCHAR2(4000)• Oracle holds its PL/SQL source code in VARCHAR2 pieces• Source is split up by rows 5/40Tanel Põder RMOUG Training Days
    • Large content in LONGs• DBA_VIEWS SQL> desc dba_views Name Null? Type -------------------- -------- -------------- OWNER NOT NULL VARCHAR2(30) VIEW_NAME NOT NULL VARCHAR2(30) TEXT_LENGTH NUMBER TEXT LONG . . .• LONGs are used in data dictionary despite they’ve been deprecated a long time ago… 6/40Tanel Põder RMOUG Training Days
    • LOB Concepts• Able to store large content – 4GB in 9i, 2-128TB in 10g (232-1 blocks)• Must also cope with some small content• Store both binary and character content• Ability for random access• Be manageable – Partitioning, reorganizing• Can be used in parallel operations• External objects accessible and domain indexable 7/40Tanel Põder RMOUG Training Days
    • LOB Architecture• A LOB can be either stored inline with row – enable storage in row option – Will be automatically moved ouf of line if it grows large• … or can be defined to always remain out- of-line – disable storage in row option• A LOB can also reside outside the database (BFILEs) – Can be indexed using Oracle Text 8/40Tanel Põder RMOUG Training Days
    • Inline LOB Architecture• create table emp (id number, name varchar2(100), fingerprint blob) lob (fingerprint) store as lob_fingerprint (enable storage in row); LOB Item LOB Index LEAF BLOCK LOB Column ID NAME FINGERPRINT 1 SCOTT 10100101011101 SEG BIT 2 CLARK null HDR MAP 101001 101001 3 KING 101001010101 4 BLAKE 101001 5 … inode 6 … inode 101001 7 … empty_clob() 8 … … 9 … … LOB Segment 9/40Tanel Põder RMOUG Training Days
    • Multiple LOBs in a Table• create table emp (id number, name varchar2(100), fingerprint blob, picture blob) lob (fingerprint) store as lob_fprint (enable storage in row) lob (picture) store as lob_picture (enable storage in row); LEAF BLOCK SEG BIT ID NAME FINGERPRINT PICTURE HDR MAP 101001 101001 1 SCOTT 10100101011101 101001 2 CLARK null 101001 101001 3 KING 101001010101 inode 4 BLAKE 101001 101001 5 … inode LEAF BLOCK 6 … 101001010101 7 … inode SEG BIT HDR MAP 101001 101001 8 … 9 … 101001 10/40Tanel Põder RMOUG Training Days
    • Out-of-line LOB Architecture• create table emp (id number, name varchar2(100), fingerprint blob, picture blob) lob (fingerprint) store as lob_fprint (enable storage in row) lob (picture) store as lob_picture (disable storage in row); BR LOB Index … FINGERPRINT PICTURE LEAF LEAF LEAF … 10100101011101 LOB ID … … LOB ID SEG BIT … 101001010101 LOB ID HDR MAP 101001 101001 … 101001 LOB ID … … null … … 101001010101 LOB ID … … LOB ID 101001 101001 … … … … … … LOB Segment 11/40Tanel Põder RMOUG Training Days
    • LOB Column Internal Structures• enable storage in row inline LOB Max. total column size 4000 bytes LOB LOCATOR LOB INODE DATA No LOB index entries 20 bytes 16 bytes max 3964 bytes No LOB segment entries• enable storage in row out-of-line LOB Up to 12 4-byte relative DBAs are LOB LOCATOR LOB INODE POINTERS TO DATA stored inline. If LOB grows larger, LOB 20 bytes 16 bytes 0-48 bytes (12xRDBA) index will be used to find data chunks• disable storage in row DATA alloc. in chunks LOB LOCATOR 20 bytes DATA inodes in index leafs LOB index stores inodes for large LOB items, also for old chunk versions for providing read consistency 12/40Tanel Põder RMOUG Training Days
    • LOB Locator Structure• LOB locator is a pointer to LOB instances physical location – Locator works the same way for both persistent and temporary LOBs – 20 bytes in size – Contains 10 byte LOB ID (2B+8B LOB OID) – Includes some metainformation• LOB locator column dump and structure:len(2), vsn(2), flg(4), bytl(2), lobid(10), inode(16), datacol 1: [36] 00 54 00 01 02 0c 80 00 00 02 00 00 00 01 00 00 00 02 8c d1 <- LOB locator 00 10 09 00 00 00 00 00 00 00 00 00 00 00 00 00 <- kdlinode 13/40Tanel Põder RMOUG Training Days
    • LOB inode Structure• LOB inode is a structure for keeping track of chunks belonging to a LOB item• LOB inode information can be kept in-row – Stores RDBAs (relative DBAs) for chunks – Requires 16 bytes + 4 bytes per chunk in lobitem – max 12 chunks inline• LOB inode information can be kept in LOB index – disable storage in row LOBs – enable storage in row LOBs with over 12 chunks – Old versions for LOB chunks 14/40Tanel Põder RMOUG Training Days
    • An Inline LOB inode Examplecreate table t (a number, b clob) tablespace lobtest lob (b) store as lob_tx (enable storage in row tablespace lobtest nocache nologging);insert into t values (1,NULL);• The column simply has NULL value (or isnt stored in row)insert into t values (2,empty_clob());col 1: [36] 00 54 00 01 02 0c 80 00 00 02 00 00 00 01 00 00 00 02 8c d1 00 10 09 00 00 00 00 00 00 00 00 00 00 00 00 00• The column stores 20-byte LOB locator, 16-byte inode structure, but no pointers to chunks, since the LOB is emptyinsert into t values (3,X);col 1: [38] 00 54 00 01 02 0c 80 00 00 02 00 00 00 01 00 00 00 02 8c d2 00 12 09 00 00 00 00 00 00 02 00 00 00 00 00 01 58 00• The inserted value itself is stored in row (CLOBs are always in fixed width 2- byte charset) 15/40Tanel Põder RMOUG Training Days
    • An Inline LOB inode Example Contdinsert into t values (4, rpad(X, 1000, X));col 1: [2036] 00 54 00 01 02 0c 80 00 00 02 00 00 00 01 00 00 00 02 8c d3 <-loc. 07 e0 09 00 00 00 00 00 07 d0 00 00 00 00 00 01 <-inode 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 <- data 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 ...• The total column size doesnt exceed 4000 bytes, thus stored in the rowinsert into t values (5, rpad(X, 2000, X));col 1: [40] 00 54 00 01 02 0c 80 00 00 02 00 00 00 01 00 00 00 02 8c d4 <-loc. 00 14 05 00 00 00 00 00 0f a0 00 00 00 00 00 02 03 c0 00 14 <-RDBA• The column is stored out-of line since its total size with 20-byte locator and 16- byte inode structure would exceed 4000 bytes• Instead a 4-byte relative datablock address pointing to first block of the LOB chunk is stored inline• Still no LOB index entries are inserted 16/40Tanel Põder RMOUG Training Days
    • A Quick Look Into LOB datablockalter system dump datafile 15 block 20;Start dump data blocks tsn: 18 file#: 15 minblk 20 maxblk 20buffer tsn: 18 rdba: 0x03c00014 (RDBA) (15/20)scn: 0x0000.002ec55d seq: 0x02 flg: 0x04 tail: 0xc55d1b02frmt: 0x02 chkval: 0xe8ea type: 0x1b=LOB BLOCKLong field block dump:Object Id 8582LobId: 000100028CD4 PageNo 0Version: 0x0000.00000001 pdba: 058 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 0058 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 0058 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 0058 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00 58 00.............. 17/40Tanel Põder RMOUG Training Days
    • LOB Index Structure• A B-tree like index structure – Leafs contain pointers to LOB chunks (RDBAs) – Contains the inode if disable storage in row LOB – One LOB item may have several associated rows in index, when lobitem consists of many chunks – Is subject to normal caching, logging and undo mechanisms (unlike LOB segments)• Has to be stored in the same tablespace with the LOB segment – That way addressing can be done using RDBAs – Logically related segments also grouped physically 18/40Tanel Põder RMOUG Training Days
    • disable storage in row LOB indexrow#9[7536] flag: ------, lock: 2, len=50, data:(32): 00 20 03 00 00 00 00 7d 1d 4c 00 00 00 00 00 01 <- kdlinode 01 80 00 eb 01 80 00 ec 01 80 00 ed 01 80 00 ee <- RDBAscol 0; len 10; (10): 00 00 00 01 00 00 00 00 2f 46 <- LOB IDcol 1; len 4; (4): 00 00 00 00row#10[7486] flag: ------, lock: 2, len=50, data:(32): 01 80 00 ef 01 80 00 f0 01 80 01 39 01 80 01 3a <- only RDBAs 01 80 01 3b 01 80 01 3c 01 80 01 3d 01 80 01 3e <- only RDBAscol 0; len 10; (10): 00 00 00 01 00 00 00 00 2f 46 <- LOB IDcol 1; len 4; (4): 00 00 00 04 <- offset for above chunks in LOBrow#11[7436] flag: ------, lock: 2, len=50, data:(32): 01 80 01 3f 01 80 01 40 01 80 01 41 01 80 01 42 01 80 01 43 01 80 01 44 01 80 01 45 01 80 01 46col 0; len 10; (10): 00 00 00 01 00 00 00 00 2f 46col 1; len 4; (4): 00 00 00 0c 19/40Tanel Põder RMOUG Training Days
    • LOB Segment Structure• A bunch of datablocks organized in chunks – Chunks are sometimes called pages or fatblocks• A Chunk is the minimum size of IO for LOBs• Read consistency and rollback is implemented by creating versions of chunks – During update, a new LOB ID is created – A new version of updated chunks is created – New locators inode and chunk pointers in LOB indexes point to new chunk version• Old chunks are retained in LOB segment – Depending on PCTVERSION or RETENTION 20/40Tanel Põder RMOUG Training Days
    • Changes Inside LOB Segment• Users access LOBs using locators• A locator allows read consistent access to a LOB instance ROOT LOB Index – Even when LOB chunks are 2 2 1 1 1 updated by another transaction SEG BIT HDR MAP 101001 101001 – Old locators pointers are kept in LOB index 101001 – Old chunk versions are 101001 read, if they are over- 101001 written, ret. ORA-1555 LOB Segment 21/40Tanel Põder RMOUG Training Days
    • (N)CLOB charset issues• (N)CLOBs are always fixed-width starting from 8i (UTF-8, AL32UTF16) – Varying width charsets are converted to fixed width internally – Fixed width charsets will remain unchanged• AL16UTF16 is always Big-Endian encoded – big-endian means that most significant byte of a word is stored first• UCS2 encoding is platform dependent• Comparing different-endian internal data structures may user more CPU 22/40Tanel Põder RMOUG Training Days
    • Little Endian vs. Big Endian• Little endian stores less significant values of a word first (to lower memory address): Original Little Endian Big Endian Character X: 00 58 58 00 00 58• Transparent to user, but may have performance impact• 10g automatically stores all (N)CLOB in Big-E – Use this query select o.name, c.name from obj$ o, col$ to find old-fashioned c, lob$ l where l.obj#=o.obj# LOBs and o.obj#=c.obj# – Convert them to a and l.intcol# = c.intcol# and c.type#=112 new table using and bitand(l.property, 512) = 1; CTAS 23/40Tanel Põder RMOUG Training Days
    • LOB Storage Planning and Tuning• LOB block Size – Blocksize can be different from table block size – Chunk sizes are multiples of Oracle blocks• Chunk Size – Bigger for big LOBs – Bigger allow Oracle to do multiblock reads – Bigger sizes keep LOB indexes smaller• PCTVERSION / RETENTION• Caching (file system read, HW read/write)• Asynch IO 24/40Tanel Põder RMOUG Training Days
    • Block Size ConsiderationsSQL> create table tl (a clob);SQL> insert into tl values (rpad(X, 1982, X));SQL> insert into tl values (rpad(X, 1982, X));SQL> analyze table tl compute statistics;SQL> select blocks, avg_space from user_tables where table_name = TL; BLOCKS AVG_SPACE---------- ---------- PCTFREE 10% 2 4070SQL> truncate table tl;SQL> alter table tl pctfree 0; PCTUSED 40%SQL> insert into tl values (rpad(X, 1982, X));SQL> insert into tl values (rpad(X, 1982, X));SQL> analyze table tl compute statistics; DatablockSQL> select blocks, avg_space from user_tables where table_name = TL; BLOCKS AVG_SPACE---------- ---------- May cause space and IO wastage 1 62 especially in FREELIST managed tables 25/40Tanel Põder RMOUG Training Days
    • Partitioned LOBs• Similar to regular table partitioning• LOB segment partitions have to be in same blocksize – But LOB segment block size may differ from parent table segments blocksize• Partitioned LOBs are fully supported for tables• 10g supports partitioned IOT with LOBs• Eases backup & recovery in VLDBs 26/40Tanel Põder RMOUG Training Days
    • LOB Cache Layer Tuning• LOBs can have following internal caching attributes: create table t (a clob) – CACHE lob (a) store as lob_a (disable storage in row – NOCACHE nocache nologging); – CACHE READS (8.1.6+)• Despite any settings, in-line LOBs are cached anyway, they are regular columns in a row• LOB indexes are always cached• Client side caching can be done using OCI and Thick JDBC – Uses lob buffering subsystem (LBS) 27/40Tanel Põder RMOUG Training Days
    • CACHE LOB• Reads&writes are done through buffer cache• Any modifications will be logged – Only redo vectors for actual changes in the block are logged• Modifications are asynchronously written to disk by DBWR• Can saturate buffer cache heavily – Especially for older databases withoug buffer cache touch count mechanism – There is no _small_table_threshold parameter for LOBs to avoid large buffered scans 28/40Tanel Põder RMOUG Training Days
    • CACHE LOB Continued• Consider different blocksize and buffer pool for LOBs Server PGA• Wait event: – db file seq/scattered read 101001 – P1: file number – P2: first DBA DBWR – P3: blockcount• Good for accessing and modifying the same data frequently 29/40Tanel Põder RMOUG Training Days
    • NOCACHE LOB• Server process reads blocks directly to PGA• Writes are done also by server process• Server process waits until writes completed• Even though buffer cache is passed, some coordination work still required Server• Wait event: PGA – direct path read / write (lob) – P1: file number – P2: first DBA – P3: blockcount 30/40Tanel Põder RMOUG Training Days
    • CACHE READS LOB• Reads will be done through buffer cache• Writes are direct• Good for frequently read, but rarely modified data• Particularily good in environments with huge incoming data feeds, where writes can be cached and batched on client side or in OCI• Where caching writes would cause too much logging 31/40Tanel Põder RMOUG Training Days
    • LOB Logging Attributes• Inline LOBs are always logged!• LOB indexes are always logged!• CACHE LOBs are always logged!• NOLOGGING works only for NOCACHE and CACHE READS LOBs• Using LOGGING NOCACHE LOB, the whole chunks will be logged, despite the size of updated content – performance impact• NOLOGGING NOCACHE LOB introduces backup & recovery issues 32/40Tanel Põder RMOUG Training Days
    • Nologging Direct IO Implications• Controlfile updates on every NOLOGGING operation – Extreme controlfile parallel read and write events• Set event 10359 at level 1 to avoid controlfile updates – Documented in 9.0.1 docs and Note 1058851.6 – The event doesnt change recoverability, only RMANs ability detect files needing backup – Affects undrecoverable_change# in V$DATAFILE• Backup & Recovery considerations 33/40Tanel Põder RMOUG Training Days
    • Developer Strategies• Simply storing and reading LOBs is relatively simple• Frequently manipulated LOBs may become resource hungry• Use temporary LOBs – Support in PL/SQL, OCI, JDBC – dbms_lob.createtemporary()• Use LOB Buffering Subsystem (LBS) – Allows to buffer, modify and batch updates to LOBs in client side 34/40Tanel Põder RMOUG Training Days
    • Temporary LOBs• Regular LOBs stored in database are called internal persistent LOBs• Temporary LOBs are in-session structures used for efficient LOB manipulation – In-memory objects in UGA – “paged” to temporary tablespace – No logging, rollback or CR mechanisms – Is empty when instatiated – Can be instatiated using CACHE or NOCACHE attribute• Very lightweight 35/40Tanel Põder RMOUG Training Days
    • Architectural Strategies• Uniform access to LOBs whether stored inside or outside the database (BFILEs) – The same code can be reused despite the storage type (although BFILEs are read only)• When loading, buffer and bundle at client side as much as possible – Means less calls to database and less direct write requests if NOCACHE or CACHE READS LOBs• Use LOB random access facilities if required – A major benefit over LONGs 36/40Tanel Põder RMOUG Training Days
    • General Recommendations• The best way for optimizing performance of an operation is not to do the operation at all – Cache, bundle, etc.. – However, caching is not always the best approach• Several bugs related to ASSM and LOBs – Free space never reused, etc.. – Use manual (freelist) segment space mgmt. – Any new functionality (such partitioned IOT with LOBs) should be evaluated and tested carefully• Incremental backups of fairly static content 37/40Tanel Põder RMOUG Training Days
    • Summary• LOBs should be used instead of LONGs – However in some cases RAW or VARCHAR may be better• Can be enable storage in row or disable storage in row – Disable storage in row always out of line, leaving 20-byte LOB locator in row – Content accessed through LOB index – Enable storage in row keeps content in row if content+overhead <= 4000 bytes (3964+20+16)• NOCACHE, CACHE, CACHE READS, LOGGING, NOLOGGING DaysTanel Põder RMOUG Training options 38/40
    • LOB Internals and Performance Tuning Tanel Põder Thank you! http://integrid.info tanel@integrid.info 39/40 Tanel Põderintegrid.info RMOUG Training Days
