Concentrated Solar Thermal Power
Technnology Training

Session 3 – Point Focus Technologies




      By Manuel A. Silva P...
Session 3.
        Point Focus Technologies:
       Parabolic Dish
            and
  Central Receiver Systems


Manuel...
Central Receiver Systems  ‐ CRS




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-...
Solar Thermal Power Plant.
Basic configuration



         Beam irradiance



                            Concentrator

 ...
Central Receiver System




               http://www1.eere.energy.gov/solar/power_towers.html
The heliostat

• “an instrument consisting of a mirror mounted on an axis moved
  by clockwork by which a sunbeam is stea...
Heliostat



                                              Incident ray




                                              ...
Glass – metal heliostat




    http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
       focus-technologi...
Glass – metal heliostat




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technolo...
Glass – metal heliostats




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technol...
Stretched membrane heliostats




    http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
       focus-tech...
Stretched membrane heliostats




         http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
            ...
Heliostat field layout


• Surrounding field
• North (south) field

• Secondary concentration
• Secondary concentrator opt...
North field
                          1000




                           800




                           600




     ...
Surrounding field




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologies-d...
Geometrical performance of heliostats




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        ...
Cosine factor



                           Yearly average cosine factor for a
                           north heliostat...
Reflectivity

• Reflectivity of a new, clean mirror ≈ 0.90 ÷ 0.94
Shading and blocking




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologie...
Atmospheric attenuation




    http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
       focus-technologi...
Spillage




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologies-dish-stirl...
CRS – Receiver

• Function: to receive concentrated solar radiation and
  transform it to thermal power (enthalpy increas...
Types of receivers for CRS plants


                       External                          Cavity




                  ...
Cavity




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologies-dish-stirlin...
Molten salt cavity receiver




4.5 MWt molten salt receiver tested under a cost shared program with US utilities and indu...
External, cylindrical




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technolog...
External, cylindrical receiver




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-t...
Receiver – working fluids


•   Water / Steam
•   Air
•   Molten salts
•   Sodium




       http://www.leonardo-energy.or...
CRS (PS10, sat. steam)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technolog...
PS10 and PS20 (Abengoa Solar, Spain)
CRS (Gema Solar, Molten salts)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-t...
Gema Solar (Torresol Energy, Spain)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        fo...
Gema Solar
Design Data
Total Reflective Area                                        285.200  m2
Number of heliostats      ...
CRS: Pros and cons.

• Pros:
   –   Ability to achieve high temperatures
   –   Wide industrial base for most components
 ...
Sierra Solar (e‐Solar, USA)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-tech...
Unit #1 (100 kW hybrid GT) (Aora Solar, Israel)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point...
Parabolic dishes
Parabolic dish systems

• Combine a paraboloidal concentrator (parabolic dish) with a
  Power Conversion Unit (PCU) direc...
Solar Village (Arabia Saudí)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-tec...
Parabolic dish ‐ Direct Steam Generation




                Dish collector field at Shenandoah, GA
                • Indu...
Parabolic dish – Stirling engine experiences
(source: Mancini et al. JSEE 2003)
Parabolic dish – Stirling engine

•High performance
   –   High concentration ratio
   –   High temperature
   –   Modular...
Dish – Stirling systems. Main elements


•   Structure
•   Concentrator
•   Tracking system
•   PCU
•   Control




      ...
Structural optical surface




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-techn...
Space frame structures
Stretched membrane
Glass mirror‐faceted


                                            • Spherically curved mirrors
                          ...
Full surface paraboloid
                                          • The entire surface forms a
                          ...
Stretched membrane. Single facet

                         • Membrane
                            – Preshaped (vacuum not ...
Stretched membrane ‐ multifaceted


                            • Avoid the need for
                              presha...
Polar tracking




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologies-dish...
Elevation ‐ azimuth tracking
Receiver


• Absorbs concentrated solar energy and converts it
  to thermal energy that heats the working fluid
  (gas) ...
Directly illuminated tubes receiver




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        fo...
Reflux receiver
• Intermediate heat transfer fluid
• Decouple receiver and engine
   – Pool boiler. The absorbed surface i...
Reflux receiver

• Heat pipe.  A wick draws the liquid metal from a
  small sump




     http://www.leonardo-energy.org/...
Striling Engine


• The Stirling cycle




      http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
      ...
Stirling engines


• Kinematic
• Free piston




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
 ...
State of the art

• Most efficient solar to electric technology.
• Pre‐commercial experiences
   – Increase reliability
  ...
Tessera Suncatcher
http://www.tesserasolar.com/




       http://www.leonardo-energy.org/csp-training-course-lesson-3-poi...
Infinia
http://www.infiniacorp.com/

• 3 kW Free piston engine




     http://www.leonardo-energy.org/csp-training-course...
Infinia




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
        focus-technologies-dish-stirli...
Eurodish
  sbp.de

• 10 kW kinematic Stirling engine (SOLO V161)
• 8.5 m diameter concentrator




           http://www.l...
Tessera – SES Maricopa Solar Plant (AZ, USA)




     http://www.leonardo-energy.org/csp-training-course-lesson-3-point-
 ...
