Insulating Solid Wall BuildingsRisks, opportunities and the need       for a new approach             Neil May            ...
STBA research for DECCKey Findings•Traditional buildings perform differently in somerespects from modern buildings, both i...
• A systemic approach ( ie a holistic approach  considering interactions rather than an approach  based upon individual me...
Recommendations• Policy issues  – New conventions  – New standards  – New assessment and training• Delivery issues  – A ne...
Conclusion• If these recommendations are taken up, then  some of the main risks to traditional buildings  of the Green Dea...
Fabric First?• Is fabric first the correct approach for traditional  buildings and particularly when it comes to  insulati...
The problem of false certainty• The difficulty of multiple factor complexity• The complexity of situations where people  a...
The opportunity of uncertainty• The acceptance of a situation where there  are no easy answers or perhaps no  answers at a...
Solid walls•   Thermal and energy performance•   Moisture•   Health•   Community and culture?
Thermal and Energy           Performance• Background issue of U values of  traditional walls and calculation methods• Ther...
Old walls bad – new walls goodSAP energy assessment of dwellings based on age of stock.Review of Sustainability of Existin...
Thermal issues: Traditional walls• Do not conform to type of wall suited to BR 443  (using BS 9496) – ie discreet layers o...
l       e       s         1 R              u                                         All U-value results 2009-2011 - BR 44...
Average in situ U-value for stone & brick wallsAppendix S SAP 2009 – Stone 2.1 & 2.4 W/m2K, Brick 2.1 W/m2K    In situ U-v...
Trinity College results - monitoring• Walls bone dry (extensive heating)• Some very wet joists (one façade at ground level...
Trinity College results -monitoring• Very different material properties between the two brick  samples• Initial monitoring...
Consequences• We need more research and better  understanding of solid wall thermal  performance• We need to be careful of...
Practical limits: Thermal BridgesRefurbishment of a traditional stone wall with 60 mm insulation on the   inside   Reveal ...
Thermal Limits (Internal Insulation)
Thermal Bridges: Party Wall Issues              Before                                 After    13,1 °C                 13...
External Insulation versus Internal?Energy loss through external wall in %                                                ...
RealityAssessing the execution of retrofitted external wall  insulation for pre-1919 dwellings in Swansea (UK);
Assessing the execution of retrofitted external wall insulation for  pre-1919 dwellings in Swansea (UK); Joanne Hopper et ...
Assessing the execution of retrofitted external wallinsulation for pre-1919 dwellings in Swansea (UK); JoanneHopper et al ...
Detail in BBA Certificate                             As applied on site   Assessing the execution of retrofitted external...
Energy/Carbon Rebound effects• Warm Front• BedZed• Traditional buildings?
Energy principlesEvery home is differentParity Projectsanalysis of 40 homesin London, built within5 years of each otheraro...
Moisture: more unknowns•   Material data•   Weather data•   Moisture physics•   Durability of fabric over time•   Construc...
Building Health & Human         Health
Conflicting understanding of mouldrisk?• Driven rain is not so important in Germany as  UK• IBP sees presence of oxygen as...
Modelling Protocols• BS EN 13788 (BS 5250) versus EN 15026EN 13788             EN 15026Steady state         DynamicMonthly...
Driven rain and internal VCLs: Average     water content of an external (German)                       wall      water con...
Internal Insulation Approaches  Non breathable     Breathable
100mm Pavaflex on 9”solid brick, 0 DR
Swansea, SWLondon, SWPavadentro on 9” solid brick, 1%DR
Swansea, SWSwansea, NPavadentro on 9” solid brick, 1%DR
Problems with Modelling• Human error• Manipulation• Data errors/ unknowns (ie OSB µ = 30/175)    – Material data    – Weat...
Problems with WUFI modelsClimate chamber – Pavadentro (sec.1)                                        RH - simulated       ...
What is the reality?• How do things happen in reality?• What happens when things are not done  right?• What about users? O...
Health Performance?IGT on Low Carbon ConstructionRecommendation 8.3:“that, to avoid the risk of a new generation ofsick bu...
Health – VERY complex• Interaction insulation, airtightness and  ventilation with fabric moisture, living  conditions and ...
Real Dangers of Bad Energy    Efficient Building Envelopes• Increased Cardio-Respiratory illness  (Lancet)• UCL research f...
Modern ventilation?• Work by AECOM for Part F 2010• Airtightness in new buildings was better than  predicted (on completio...
Big UNKNOWNS• Effect on community• Effect on culture• Effect on relationship with the natural  environment
Radical retrofit requires            rethinking• Is fabric the best place to start?• How do buildings relate to lifestyle ...
Why not fabric first?• People first• Buildings don’t use energy, people do• Its highly complicated and we don’t know  most...
STBA proposalWe need to accept our current lack ofknowledge and the possibly unresolvablecomplexity of this situation and ...
STBA Proposed GuidanceStructure for traditional building             retrofit
Can use for services also
Solid wall buildings• Different in some details from all other  buildings, but principles and the necessary  approach are ...
Thank you for listening www.natural-building.co.uk
