NICOLE SULLIVAN




Design Fast Websites
don’t blame the rounded corners!
Exceptional Performance
         at Yahoo!
Quantify and improve the
performance of all Yahoo!
   products worldwide
Y! Performance Research
    Engineering Team




     Nicole Sullivan, Anande Kishore (intern),
   Stoyan Stefanov, Philip...
Make your users happy

• Users care if sites are fast.
• I can’t give you the solution
• I can help you understand the pro...
Why talk about
performance?
1: Because fast is better
2: Because sites are bigger
Modern web sites &
applications have changed
      architecturally.
From 2003 to 2008:
   97K to 312K.
25.7 to 49.9 objects.
In past 12 months, Top 1000 sites:
       From 250K to 310.4K.
WebSiteOptimization.com/speed/tweak/average-web-page
3: Time is money
+100 ms
Amazon:1% drop in sales


       +100 ms
+400 ms
Yahoo!: 5-9% drop in
   full-page traffic

     +400 ms
+500 ms
Google: 20% fewer
    searches

    +500 ms
Users care about
 performance!
Performance Fruit
(some low, some high)
Web Dev Philosophy

• Work out of respect for the design.
• Designers make our code as beautiful and
  clever on the outsi...
9 Best Practices
1. Create a component         5. Avoid non-standard
   library of smart objects      browser fonts.

2. U...
1
    Create a component
          library
         of smart objects
Components
  are like legos
Mix and match to create diverse
     and interesting pages.
Site-wide legos:
• Headings
• Lists (e.g. action list, external link list,
   product list, or feature list)
• Module head...
Reusing elements
  makes them
   performance “freebies”
Legos first
Design individual pages only once all the legos have
                   been defined.
Avoid redundancy
Nearly identical
  modules
Headings 3 and 5 are too similar.
Rule of thumb:
If two modules look too similar to include on
the same page, they are too similar to include
together in a ...
2
    Use consistent
    semantic styles
A   Heading should not become a        Heading


        in another part of the page.
Consistent site-wide
Consistency
Writing more rules to overwrite
 the crazy rules from before.

  e.g. Heading should behave
  predictably in a...
How about an
  example?
  Personal finance
3
    Design modules to be
         transparent
           on the inside.
Contour blocks       Background blocks       Content Objects -
                                         headings, paragrap...
Making it look
                 fab
        Requires careful choice of pixels.



               Bonus: Consider PNG8 for
...
Pitfalls
Variable or gradient
   backgrounds.
4
    Optimize images and
          sprites
Optimize sprites
1. How many pages
   does your property
   have?

2. Is your site modular?
   (hint: it should be!)

3. H...
9 Image Optimizations
1. Combine like colors      6. Reduce anti-aliased pixels -
                               via size ...
Careful with Logos
Very recognizable so small changes will be noticed
                   more easily.
Try progressively
enhanced PNG8
Avoid filters
    Why is the AlphaImageLoader used?

 IE6 and earlier don’t natively support alpha
transparency. This filter...
Problem with filters

• Blocks rendering, freezes the browser
• Increased memory consumption
• Per element, not per image!
Solution: Avoid
          AlphaImageLoader
1. BEST: avoid completely, use PNG8 which degrades gracefully in IE < 7

2. Fal...
Progressively
enhanced PNG8
Build a binary transparency image.
  In Fireworks, add a few alpha
        transparent pixels.
IE6




                                          Firefox
                                          Opera
                ...
Experimental Data
  Removing Alpha Image Loader



                            100ms
                            Yahoo! se...
Crush images

Step 1: Quality, Designer chooses quality (e.g. via save
for the web)
Step 2: Non-lossy compression to squea...
demo




http://smushit.com
5
    Avoid non-standard
      browser fonts.
6
    Use columns
      rather than rows.
7   Choose your bling
       carefully.
     Consider your market and users.
8
     Be flexible.
    Extensible height and width.
• Grids control width
• Content controls height
9
    Learn to love grids.
Flickr Photo Credits:


•   idigit_teddy: http://www.flickr.com/photos/design_inspiration/238542495/


•   lucianvenutian: ...
Thanks!
Nate Koechley - YUI. High Performance
Websites:
✴   http://www.slideshare.net/natekoechley/high-performance-web-si...
Let’s keep talking...
 http://developer.yahoo.com/performance/
           http://stubbornella.org
