Theodore E. Scott, PE, CPESC, LEED AP Stormwater Maintenance, LLC Stormwater Consulting, Inc. 128 Cockeysville Road, Suite...
<ul><li>Environmental Site Design (ESD) </li></ul>Low Impact Development (LID) Better Site Design Green Infrastructure Sus...
ESD Philosophy Replicate Existing (Woods!) hydrology Small scale practices Non-structural techniques Site planning techniq...
Defining ESD to the MEP -  “THE RULES” <ul><li>Design process </li></ul><ul><li>Site and resource mapping </li></ul><ul><l...
ESD Design & Review Process
Site and Resource Mapping
Better Site Design <ul><li>CWP 1998 </li></ul><ul><li>Narrow streets & sidewalks  </li></ul><ul><li>Cul-de-sacs – smaller ...
Better Site Design <ul><li>Reduce impervious areas </li></ul><ul><li>Road widths, parking, etc.  </li></ul>
Better Site Design <ul><li>Open vegetated channels </li></ul>
Better Site Design <ul><li>Site fingerprinting </li></ul>
Better Site Design <ul><li>Clustering </li></ul>
Better Site Design <ul><li>Maintain Existing  Drainage  Patterns </li></ul><ul><li>Minimize storm drains </li></ul><ul><li...
It all starts with Land Planning…
… which leads to Engineering.
Computations  P E  = Proposed Runoff less Woods Runoff Hydrologic Soil Group B  %I  RCN*  PE=1'' 1.2'' 1.4'' 1.6'' 1.8'' 2...
Computations  <ul><li>1” Storm Runoff – MANDITORY to treat with ESD Practices </li></ul><ul><li>1 Year Storm (2.6”+/-) tre...
Computational Resources www.MdESD.org
Computational Resources www.MdESD.org
Computational Resources Local Municipalities
ESD Practices
ESD  Design  Philosophy <ul><li>Site design priorities </li></ul><ul><li>Eliminate stormwater impacts with materials  sele...
ESD Practices  <ul><li>Group 1: </li></ul><ul><li>Alternative Surfaces </li></ul><ul><li>Group 2: </li></ul><ul><li>Nonstr...
Group 1: Alternative Surfaces <ul><li>A-1 Green Roofs </li></ul><ul><li>Thickness Options:  2 ”, 3”, 4”, 6”, 8” </li></ul>
Group 1: Alternative Surfaces <ul><ul><li>A-2 Permeable Pavements </li></ul></ul>
Group 1: Alternative Surfaces
Group 1: Alternative Surfaces <ul><li>A-3 Reinforced Turf </li></ul>
Group 2: Nonstructural Practices <ul><ul><li>N-1 Disconnection of rooftop runoff </li></ul></ul>
Group 2: Nonstructural Practices <ul><ul><li>N-2 Disconnection of non-rooftop runoff </li></ul></ul>
Group 2: Nonstructural Practices <ul><ul><li>N-3 Sheetflow to conservation area </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-1 Rainwater Harvesting </li></ul></ul><ul><ul><li>Rain barrel sizing for full...
Group 3: Micro-scale Practices <ul><ul><li>M-2 Submerged Gravel wetlands </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-3 Landscape Infiltration </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-4 Infiltration Berm </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-5 Dry wells </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-6 Micro-bioretention </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-6 Micro-Bioretention  Max DA = 20,000 sf </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-6 Micro-bioretention </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-7 Rain gardens  Max DA 2000sf/10000sf </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-8 Swales </li></ul></ul>
Group 3: Micro-scale Practices <ul><ul><li>M-9 Enhanced Filters  Provides recharge </li></ul></ul>
Residential  Design Example
Existing Conditions 1.75 acre lot B Soils
Proposed Conditions 3 Lots 25% Impervious Target P E  = 1.6 inches
PERMEABLE PAVING Alternative Surfaces 8600 sf PERMEABLE PAVING Target P E  = 1.6 inches Proposed P E  = 0.17 inches
ESD Practices at or Near Sources DISCONNECTIONS SWALE Target P E  = 1.6 inches Proposed P E  = 0.30 inches RAIN BARRELS
Integrated Small-Scale Practices RAIN GARDENS
SWALE RAIN GARDENS DISCONNECTIONS PERMEABLE PAVING All Practices Target P E  = 1.6 inches Proposed P E  = 0.99 inches
TIME CHECK Theodore E. Scott, PE, CPESC, LEED AP Stormwater Maintenance, LLC Stormwater Consulting, Inc. 128 Cockeysville ...
Commercial Design Example
Example Project  Traditional 2000 Design Approach SAND FILTER U/G CMP Cpv
Example Project  Design Approach #1 MICRO-BIORETENTION REVERSED GRADES
Example Project  Design Approach #2 CISTERN PERMABLE PAVING SWALE GREENROOF
Example Project  Design Approach #3 MICRO-BIORETENTION PERMABLE PAVING SWALE
Example Project  Design Approach #4 SUBMERGED WETLANDS RAIN GARDEN PLANTER BOXES MICRO-BIORETENTION
THANKS! Theodore E. Scott, PE, CPESC, LEED AP Stormwater Maintenance, LLC Stormwater Consulting, Inc. 128 Cockeysville Roa...
