Pacemaker Overview <ul><li>Stuart Allen </li></ul><ul><li>Technical Head  </li></ul><ul><li>Southampton General </li></ul>...
Indications for Pacing The normal & pathological ECG Stuart Allen 06
Impulse Formation and  Conduction Disturbances Stuart Allen 06
“ Normal Heart Rhythm” (Function) Stuart Allen 06
Normal Heart Function Stuart Allen 06 Sinoatrial Node
Normal Heart Function Stuart Allen 06 Atrioventricular Node
Normal Heart Function Stuart Allen 06 Bundle of HIS
Normal Heart Function Stuart Allen 06 Left Bundle Branch (LBB) Anterior Fascicle of LBB Posterior Fascicle of LBB Right Bu...
Normal Heart Function Stuart Allen 06 Purkinje Fibers
Normal Heart Function Stuart Allen 06 Vent. Systole
Normal Heart Function Stuart Allen 06 Vent. Diastole
Stuart Allen 06 The ECG
Normal Values <ul><li>PR Interval:  120 to 210 msec </li></ul><ul><li>QRS Interval: 80 to 110 msec </li></ul>Stuart Allen 06
60,000  Interval   = Heart Rate Stuart Allen 06 Rate:Interval Relationship
Rate:Interval Relationship Stuart Allen 06 The Rate is  :  ?  ?  Interval : 750 msec
Stuart Allen 06 The Rate is  : 750 Interval : 750 msec 60,000 80 bpm Rate:Interval Relationship
Stuart Allen 06 The interval is : 50 Rate : 50 bpm   60,000 1200 ms Rate:Interval Relationship
Stuart Allen 06 Rate:Interval Relationship Interval  (ms)  200  400  600  800  1000  1200  1400  1600  Rate (bpm/ppm)  300...
Stuart Allen 06 Rate:Interval Relationship 25 mm is 1 sec. 5 mm = 0.2 sec. 1 mm = 0.04 sec . 25 mm/second
“ Abnormal Heart Rhythm” (Indications for Pacing) Stuart Allen 06
Definitions.... <ul><li>Bradycardia: R < 60 bpm </li></ul><ul><li>Tachycardia: R >  100 bpm </li></ul><ul><li>Flutter: R >...
Pacemaker Indication Classifications <ul><li>Class I   – Conditions for which there is evidence and/or general agreement t...
Pacemaker Indication Classifications <ul><li>Evidence supporting current recommendations are  ranked as levels A, B, and C...
Sinus Node Dysfunction <ul><li>Sick Sinus Syndrome </li></ul><ul><li>Sinus bradycardia </li></ul><ul><li>Sinus arrest </li...
<ul><li>Class I Indications </li></ul><ul><li>Sinus node dysfunction with documented   symptomatic sinus bradycardia </li>...
Sinus Node Dysfunction – Sinus Bradycardia <ul><li>Persistent slow rate from the SA node. The parameters from this wavefor...
Sinus Node Dysfunction – Sinus Arrest <ul><li>Failure of sinus node discharge resulting in the absence of atrial depolaris...
Sinus Node Dysfunction – SA Exit Block <ul><li>Transient blockage of impulses from the SA node </li></ul><ul><ul><li>Rate ...
Sinus Node Dysfunction –  Brady-Tachy Syndrome <ul><li>Intermittent episodes of slow and fast rates from the SA node or at...
Chronotropic Incompetence (CI) Stuart Allen 06 Max Rest Heart Rate Time Start Activity Stop Activity Quick Unstable Slow N...
AV Block <ul><li>First-degree AV block </li></ul><ul><li>Second-degree AV block </li></ul><ul><ul><li>Mobitz types I and I...
<ul><li>Class I Indications </li></ul><ul><li>3rd   degree AV block associated with: </li></ul><ul><ul><li>Symptomatic bra...
AV Block – Indications <ul><li>Class II Indications </li></ul><ul><li>Class IIa: </li></ul><ul><ul><li>Asymptomatic CHB wi...
AV Block – Indications <ul><li>Class III Indications </li></ul><ul><li>Asymptomatic 1st   degree AV block  </li></ul><ul><...
First-Degree AV Block <ul><li>AV conduction is delayed, and the PR interval is prolonged (> 210 ms or 0.21 seconds) </li><...
Second-Degree AV Block –  Mobitz I (Wenckebach) <ul><li>Progressive prolongation of the PR interval until a ventricular be...
Second-Degree AV  Block – Mobitz II <ul><li>Regularly dropped ventricular beats </li></ul><ul><ul><li>2:1 block (2 P waves...
Third-Degree AV Block <ul><li>No impulse conduction from the atria to the ventricles </li></ul><ul><ul><li>Ventricular rat...
Bifascicular / Trifascicular Block Stuart Allen 06
<ul><li>Class I Indications </li></ul><ul><li>Intermittent 3rd   degree AV block </li></ul><ul><li>Type II 2nd degree AV b...
Bifascicular Block Stuart Allen 06 Right bundle branch block and left posterior hemiblock
Bifascicular Block Stuart Allen 06 Right bundle branch block  and left anterior hemiblock
Bifascicular Block Stuart Allen 06 Complete left bundle branch block
Trifascicular Block <ul><li>Complete block in the right bundle branch and complete or incomplete block in both divisions o...
ECG Recording: <ul><li>Rate </li></ul><ul><li>Rhythm </li></ul><ul><ul><li>regular  or  irregular? </li></ul></ul><ul><ul>...
What is a Pacemaker? Stuart Allen 06
What is a Pacemaker? A Pacemaker System consists of a  Pulse Generator  plus  Lead (s) Stuart Allen 06
What is a Pacemaker? Stuart Allen 06
<ul><li>Pulse generator: power source or battery </li></ul><ul><li>Leads or wires </li></ul><ul><li>Cathode (negative elec...
<ul><li>Contains a battery that provides the energy for sending electrical impulses to the heart </li></ul><ul><li>Houses ...
Stuart Allen 06 Battery Connector Hybrid Telemetry antenna Output capacitors Reed (Magnet) switch Clock Defibrillation pro...
Stuart Allen 06 Components of an IPG
What is a Pacemaker? Stuart Allen 06
<ul><li>Deliver electrical impulses from the pulse generator to  the heart </li></ul><ul><li>Sense cardiac depolarisation ...
Pacing Lead Components <ul><li>Conductor  </li></ul><ul><li>Connector Pin </li></ul><ul><li>Insulation </li></ul><ul><li>E...
How do pacemakers work? Stuart Allen 06
How do pacemakers work? <ul><li>Modes and Codes </li></ul><ul><ul><li>NBG Code </li></ul></ul><ul><ul><li>Mode Selection <...
Modes and Codes Stuart Allen 06
NBG Code Stuart Allen 06 V: Ventricle V: Ventricle T: Triggered P: Simple programmable P: Pace A: Atrium A: Atrium I: Inhi...
Mode Selection for Optimal Pacing Therapy Stuart Allen 06
Providing Optimal Pacing Therapy <ul><li>Heart rate increase </li></ul><ul><li>Stroke volume maximisation </li></ul><ul><l...
Cardiac Output Cardiac Output (l/min)= Heart Rate x Stroke Volume Stuart Allen 06
Heart Rate Stuart Allen 06 x x x x SV x  HR Age 65-80 (N=16) 130 120 110 100 90 80 70 Heart Rate (BPM) Stroke Volume (mL/M...
Proven Benefits of Atrial Based Pacing Stuart Allen 06 Study Results Higano  et al.  1990 Gallik  et al.  1994 Santini  et...
Proven Benefits of Atrial Based Pacing Stuart Allen 06 Study Results Rosenquist 1988 Santini 1990 Stangl 1990 Zanini 1990 ...
Patient Mode Preference Stuart Allen 06 DDDR 59% DDIR 13% Any Dual 9% No Preference 9% DDD 5% VVIR 5% Sulke N, et al.  J A...
Optimal Pacing Mode (BPEG)  <ul><li>Sinus Node Disease - AAI (R) </li></ul><ul><li>AVB - DDD </li></ul><ul><li>SND + AVB -...
Alternative Pacing Mode <ul><li>Sinus Node Disease - AAI </li></ul><ul><li>AVB - VDD </li></ul><ul><li>SND + AVB - DDD + D...
Inappropriate Pacing Mode <ul><li>Sinus Node Disease - VVI + VDD </li></ul><ul><li>AVB - AAI + DDI </li></ul><ul><li>SND +...
Mode Selection Decision Tree Stuart Allen 06 DDIR with SV PVARP DDDR with MS N VVI VVIR Are they chronic? Y Y N DDD, VDD D...
Summary of Pacemaker Indications <ul><li>Sinus node dysfunction </li></ul><ul><li>AV block (Congenital, acquired, surgical...
Pacing Modes Stuart Allen 06
Pacing Modes Stuart Allen 06 Output circuit VVI AMP Ventricular Demand
Stuart Allen 06 Pacing Modes Programmed lower rate 50 mm/s VVI
Pacing Modes Stuart Allen 06 Output circuit VVIR AMP Sensor Ventricular Demand
Pacing Modes Stuart Allen 06 VVI R Programmed lower rate 50 mm/s Sensor indicated rate
Pacing Modes Stuart Allen 06 Programmed lower rate 50 mm/s Sensor indicated rate VVI R
Pacing Modes Stuart Allen 06 Output circuit AAI AMP Atrial Demand
Pacing Modes Stuart Allen 06 Programmed lower rate 50 mm/s AAI
Pacing Modes Stuart Allen 06 Output circuit AAIR AMP Atrial Demand Sensor
Pacing Modes Stuart Allen 06 Programmed lower rate 50 mm/s AAIR Sensor indicated rate
Pacing Modes Stuart Allen 06 Output circuit VAT AMP Atrial Synchronised
Pacing Modes Stuart Allen 06 Output circuit DVI AMP A-V Sequential Output circuit Output circuit VDD AMP AMP
Pacing Modes Stuart Allen 06 VDD = Refract.Sensing = Blanking = Refract.periode = Stimulatie = Sensing V A
Pacing Modes Stuart Allen 06 Output circuit DVI AMP A-V Sequential Output circuit
Pacing Modes Stuart Allen 06 Programmed lower rate 50 mm/s DVI
Pacing Modes Stuart Allen 06 Output circuit DVIR AMP A-V Sequential Output circuit Sensor
Pacing Modes Stuart Allen 06 Output circuit DDI(R) AMP Output circuit Timing & Control AMP A-V Universal Sensor
Pacing Modes Stuart Allen 06 Output circuit DVI AMP A-V Sequential Output circuit Output circuit DDD AMP A-V Universal Out...
Stuart Allen 06 Pacing Modes Output circuit DVI AMP A-V Sequential Output circuit Output circuit DDDR AMP A-V Universal Ou...
Pacing Modes - Summary Stuart Allen 06 Output circuit VVI AMP Ventricular Demand Output circuit VAT AMP Atrial Synchronise...
