JavaFX and Scala – Like Milk and Cookies    Stephen Chin                Luc Duponcheel    JavaFX Evangelist, Oracle   Inde...
Meet the Presenters        Stephen Chin                 Luc Duponcheel  Family Man                 Motorcyclist           ...
JavaFX 2.0 PlatformImmersive Application Experience>   Cross-platform    Animation, Video, Charting>   Integrate Java, Jav...
JavaFXScala                 4
JavaFX With Java
JavaFX in Java>   JavaFX API uses an enhanced JavaBeans    pattern>   Similar in feel to other UI toolkits (Swing,    Pivo...
Vanishing Circles                    7
Application Skeletonpublic class VanishingCircles extends Application {  public static void main(String[] args) {    Appli...
Create the CirclesList<Circle> circles = new ArrayList<Circle>();for (int i = 0; i < 50; i++) {  final Circle circle = new...
Setup Bindingcircle.strokeWidthProperty().bind(Bindings   .when(circle.hoverProperty())   .then(4)   .otherwise(0));      ...
Setup Event Listenerscircle.addEventHandler(MouseEvent.MOUSE_CLICKED,                        new EventHandler<MouseEvent>(...
Begin the AnimationTimeline moveCircles = new Timeline();for (Circle circle : circles) {  KeyValue moveX = new KeyValue(ci...
JavaFX With Scala               13
Java vs. Scala DSLpublic class VanishingCircles extends Application {                                   object VanishingCi...
object VanishingCircles extends JFXApp {  stage = new Stage {    title = "Disappearing Circles"    width = 800    height =...
object VanishingCircles extends JFXApp {  stage = new Stage {    title = "Disappearing Circles"    width = 800    height =...
object VanishingCircles extends JFXApp {  stage = new Stage {    title = "Disappearing Circles"    width = 800    height =...
object VanishingCircles extends JFXApp {  stage = new Stage {    title = "Disappearing Circles"    width = 800            ...
object VanishingCircles extends JFXApp {  stage = new Stage {    title = "Disappearing Circles"    width = 800            ...
Binding in ScalaInfix Addition/Subtraction/Multiplication/Division:height <== rect1.height + rect2.heightAggregate Operato...
Animation in Scalaval timeline = new Timeline {  cycleCount = INDEFINITE  autoReverse = true  keyFrames = for (circle <- c...
JavaFX Script-like animationAnimation in Scala       syntax: at (duration) {keyframes}val timeline = new Timeline {  cycle...
Animation in Scalaval timeline = new Timeline {  cycleCount = INDEFINITE  autoReverse = true  keyFrames = for (circle <- c...
Animation in Scalaval timeline = new Timeline {  cycleCount = INDEFINITE  autoReverse = true  keyFrames = for (circle <- c...
Event Listeners in Scala>   Supported using the built-in Closure syntax>   Arguments for event objects>   100% type-safe  ...
Event Listeners in Scala>   Supported using the built-in Closure syntax>   Arguments for event objects          Optional e...
Jumping Frogs PuzzleImage by renwest: http://www.flickr.com/photos/19941963@N00/438340463                                 ...
Jumping Frogs Puzzle>   My first ScalaFX program>   Similar to (but more concise as) my version using    JavaFX 1.2>   Aft...
Applicationobject JumpingFrogsPuzzle extends JFXApp {  stage = new Stage {    title = TITLE    scene = new Scene {    cont...
Frogtrait   Frog {  def   movesToRight: Boolean  def   movesToLeft: Boolean}class   LeftFrog() extends Frog {  def   moves...
Model (frogMap)var frogMap: Map[Int, Frog] = _private val frogAtPosition = (i: Int) =>  frogMap(i)val positionOf = (frog: ...
Model (move)private val move =  (next: Int => Int) => (frog: Frog) =>  frogMap = (for {    entry@(_, aFrog) <- frogMap    ...
View (jump)private val jump =  (length: Int) =>  (direction: (Double, Double) => Double) =>  (frogShape: FrogShape) => {  ...
View (control)private val control: Unit => Unit = { _ =>  view.frogShapes.foreach {    frogShape => frogShape.onMouseClick...
ScalaFX Internals a.k.a. How to Write Your Own Scala DSLWith quotes from Stephen Colebourne (@jodastephen) to helpus keep ...
Application Initialization>   JavaFX Requires all UI code executed on the    Application Thread>   But our ScalaFX Applica...
DelayedInit>    Introduced in Scala 2.9>    How to Use It:1.    Extend a special trait called DelayedInit2.    Implement a...
Hierarchical Implicit Conversions>   ScalaFX defines a set of proxies that mirror the    JavaFX hierarchy>   JavaFX classe...
N-Level Implicit Precedence>   Scala throws an exception if two implicits have the    same precedence>   Classes that are ...
Properties>   JavaFX supports properties of type Boolean,    Integer, Long, Float, Double, String, and Object>   Propertie...
@specialized>   Special annotation that generates primitive    variants of the class>   Improves performance by avoiding  ...
Bindings>    How does Scala know what order to evaluate this     in?text <== when (rect.hover || circle.hover&& !disabled)...
Operator Precedence Rules>   First Character Determines Precedence    Lowest Precedence       10. (all   letters)     Exce...
Operator Precedencetext <== when (rect.hover || circle.hover            11       10                               9&& !dis...
Conclusion>   You can use Scala and JavaFX together.>   ScalaFX provides cleaner APIs that are tailor    designed for Scal...
Stephen Chin                     steveonjava@gmail.com                     tweet: @steveonjavaPro JavaFX 2 Platform Availa...
