Songbird

  1. Songbird Integrating Media & The Web 2009-04-19 Stephen Lau stevel@songbirdnest.com
  2. we mozilla open standards open web open source
  3. Songbird in One Slide • Cross platform media player • Built on Mozilla (XULRunner) • Customisable • Extensions • Skins Feathers • Open APIs • Client side via extensions • Web side via Webpage API • Desktop client, NOT a web service
  4. What If.... • You could only read your news from CNN • You could only buy Sony laptops • You could only buy BMW cars • You could only browse the web with Internet Explorer • You could only buy music from Apple’s iTunes Store • You could only sync with an Apple iPod
  5. AOL (The Internet)
  6. CompuServe AOL (en larg ed 100 x) (The Internet)
  7. Extensions • Just like Firefox • Can be easily ported (in most cases) • Many Firefox extensions already support Songbird • Full access to all of Songbird’s APIs • Examples: • Service Integration • Device Support • Media player functionality • Easily integrate with the web: • Pull in web content • Push content up to the web
  8. Mozilla Technologies & APIs (aka the buzzword & acronym slide) AJAX, Canvas, CSS, DOM, E4X, HTML, JS, RDF RSS, SVG, XBL, XML, XPath, XSLT, XUL SpiderMonkey, Gecko, XULRunner
  9. What can I do with it? Pros: Pretty much anything Cons: Pretty much anything
  10. Media Interaction • APIs for querying metadata • Controlling playback • Creating local and remote media items • Creating playlists • Observers/listeners • AJAX, and anything else “webby”
  11. Songbird Points of Integration Display Panes Media Views Faceplate Browser Areas
  12. Demo Time! (sorry for anyone viewing the PDF) just imagine a really compelling and cool demo (and then imagine me delivering it)
  13. mashTape Screenies (in case the network is teh suck)
  14. Last.fm Screenies (#@$()#*@ network)
  15. More Extension Screenies (pity about the network)
  16. The Songbird Library
  17. Adding an item // Get the library manager service var libraryManager = Components.classes[quot;@songbirdnest.com/Songbird/library/Manager;1quot;] .getService(Components.interfaces.sbILibraryManager); // Get the user’s main library var mainLib = libraryManager.mainLibrary; // Need to construct an IO URI representing the actual resource (e.g. test.mp3) var ioService = Components.classes[quot;@mozilla.org/network/io-service;1quot;] .getService(Components.interfaces.nsIIOService); var songURI = ioService.newURI(“http://whacked.net/test.mp3”, null, null); // Set any properties we may want to set var props = Components.classes[quot;@songbirdnest.com/Songbird/Properties/MutablePropertyArray;1quot;] .createInstance(Ci.sbIMutablePropertyArray); props.appendProperty(“http://whacked.net/#myWhizzyProperty, quot;OMG! BEST SONG EVER!quot;); // Add the song to the user’s library var mySong = mainLib.createMediaItem(songURI, props);
  18. Finding an item // If you know the GUID.... var mySong = mainLib.getItemByGuid(“some_guid_here”); // ... or you can get it by index in the list/library var mySong = mainLib.getItemByIndex(42); // ... or you can enumerate it by a property var myListener = { items: [], onEnumerationBegin: function() { }, onEnumeratedItem: function(list, item) { this.items.push(item); } onEnumerationEnd: function() { } }; mainLib.enumerateItemsByProperty(“http://whacked.net/#myWhizzyProperty”, “OMG! BEST SONG EVER!”, myListener, Components.interfaces.sbIMediaList.ENUMERATIONTYPE_LOCKING); alert(myListener.items.length + “ items found with ‘Some Arbitrary Value’”);
  19. Removing an item // ... from previous slide // iterate through each item that matched our enumeration for (mySong in myListener.items) { // remove it from the library mainLib.remove(mySong); }
  20. Managing Playback
  21. Media Core APIs
  22. Media Core APIs
  23. Mediacore Manager IDL: http://src.songbirdnest.com/source/xref/client/components/mediacore/base/public/sbIMediacoreManager.idl API Reference: http://developer.songbirdnest.com/add-on-api/docs/trunk/interfacesb_i_mediacore_manager.html • Get a reference to the Mediacore Manager: var gMM = Components.classes[quot;@songbirdnest.com/Songbird/Mediacore/Manager;1quot;] .getService(Components.interfaces.sbIMediacoreManager); • The central point for all media playback/event management • Most playback/sequence/control handled by .playbackControl or .sequencer
  24. Mediacore Manager • Events: • sbIMediacoreEvent • http://developer.songbirdnest.com/add-on-api/docs/trunk/interfacesb_i_mediacore_event.html • Sample events: Metadata change, Duration change, Track change • Stream start, Stream End, etc. • Add a listener: const Ci = Components.interfaces; var myListener = { onMediacoreEvent: function(ev) { switch (ev.type) { case Ci.sbIMediacoreEvent.TRACK_CHANGE: var mediaItem = ev.data; alert(quot;track changed to: quot; + mediaItem.guid); break; case Ci.sbIMediacoreEvent.STREAM_END: alert(quot;track has endedquot;); break; case Ci.sbIMediacoreEvent.STREAM_STOP: alert(quot;track was stoppedquot;); break; } } gMM.addListener(myListener);
  25. What’s going on?
  26. Data Remotes Asynchronously observe specific data remotes and trigger listeners based on data changes in the player, e.g. • Track change • Play/pause state • Volume change/mute What’s playing? • metadata.title • metadata.artist • metadata.album
  27. Data Remotes Example: myObserver = { observe: function ( aSubject, aTopic, aData) { if (aTopic == “faceplate.playing” && aData == 1) { var mediaItem = gMM.sequencer.currentItem; var artist = mediaItem.getProperty(SBProperties.artistName); alert(artist + “? weren’t they a one-hit wonder?”); } } } Components.utils.import(quot;resource://app/components/sbProperties.jsmquot;); const SB_NewDataRemote = new Components.Constructor( quot;@songbirdnest.com/Songbird/DataRemote;1quot;, quot;sbIDataRemotequot;, quot;initquot;); var sbDataRemote = SB_NewDataRemote(“faceplate.playing”, null); sbDataRemote.bindObserver(myObserver, true);
  28. Songbird Audio Codec Architecture Songbird Songbird Media Cores X Windows Media SDK GStreamer Quicktime ... M4P* WMA* GStreamer Plugins X FLAC Quicktime DirectShow ACM MP3 ... AAC WMA MP3 ... Extension points MP3 ... ... *DRM protected formats Windows only ... X Mac only Linux only ACM Codecs QT Plugins DShow Codecs
  29. Feathers • Customise Songbird’s appearance • CSS, XUL • Use Web technologies: • Flash • SVG • Canvas • Simple to customise: You don’t have to be a developer to make a Feather
  30. A Picture is Worth A Thousand Words
  31. Sparkle
  32. YABS (Yet Another Black Skin)
  33. Pure Player Medium Player Mini Player
  34. Webpage API • Javascript’able interactions with Songbird • Integrate into user’s media player • Build your site, not a media player • Observe and interact with Songbird’s media functionality
  35. What can I do with it? • Query what’s currently playing • Attach asynchronous listeners/observers to media player actions • Enumerate and observe user library • Build site-local libraries and playlists • Download playlists and items to the user’s main library
  36. What’s happening right this minute Metadata on the currently playing track: • songbird.currentArtist • songbird.currentTrack • songbird.currentAlbum Current activity and state: • songbird.playing • songbird.paused • songbird.repeat • songbird.shuffle • songbird.position • songbird.volume • songbird.mute Synchronous and asynchronous observers
  37. List & Library Integration • Use lists to represent playlists, or conceptual lists: • Shopping cart • Favourite songs/tracks • Recommended tracks (“You might also like...”) • Relevant songs (“Other people who bought also bought...”) • Playback main library (e.g. the user’s) lists • Playback site library (e.g. local to the website) lists • Remote playlists, e.g. .m3u, .pls • Playlists built programmatically using the Webpage API • Download lists and individual media items to the user’s library
  38. WebPlaylist Can be populated either automatically (i.e. via Songbird’s automatic scraping) or programmatically via Webpage API
  39. Current Media Player Activity <script type=”text/javascript”> function onLoad() { if (songbird.playing) { alert(“I love ” + songbird.currentArtist + “ too”); } } </script>
  40. Observing Your Media Player var obs = { observe: function ( aSubject, aTopic, aData) { if (aTopic == “metadata.artist”) { alert(“Current artist:” + aData); } else if (aTopic == “metadata.album”) { alert(“Current album:” + aData); } else if (aTopic == “metadata.title”) { alert(“Current track:” + aData); } } } songbird.addListener(quot;metadata.titlequot;, obs); songbird.addListener(quot;metadata.artistquot;, obs); songbird.addListener(quot;metadata.albumquot;, obs);
  41. Observing Your Media Player More asynchronous events: downloadstart downloadcomplete Fired when Songbird downloads triggered by Library integration APIs (covered later) are initiated or completed beforetrackchange trackchange playerstopped Fired when media track events happen. event.item argument is the mediaItem
  42. Enumerate User Libraries User library: • mediaItems (represent items/tracks) • mediaLists (ordered lists of mediaItems) • mediaLibraries (unordered collection of mediaItems & lists) • songbird.mainLibrary • .createMediaItem() • .createSimpleMediaList() • .getPlaylists() • .getItemByGuid() • .enumerateAllItems() • .enumerateItemsByProperty() • http://developer.songbirdnest.com/webpage-api/docs/files/ trunk/sbIRemoteLibrary-idl.html#Library
  43. Enumerate User Libraries var propArtist = quot;http://songbirdnest.com/data/1.0#artistNamequot;; var listener = { onEnumerationBegin: function() { this.artists = new Object(); return true; }, onEnumeratedItem: function(list, item) { metadata = item.getProperty(propArtist); if ((metadata != null) && (metadata != '') && (metadata != 'quot;quot;')) { if (this.artists[metadata]) this.artists[metadata]++; else this.artists[metadata] = 1; } return true; }, onEnumerationEnd: function() { return true; } }; var mainlib = songbird.mainLibrary; songbird.mainLibrary.enumerateAllItems(listener, 0); for (artist in listener.artists) { alert(quot;You have quot; + this.artists[artist] + quot; tracks by quot; + artist); }
  44. List & Library Integration // Create a default site-specific library var library = songbird.siteLibrary; // Set the scope of the site library songbird.setSiteScope(quot;whacked.netquot;, quot;/musicquot;); // Create a media item and put it in the library var mediaItem = library.createMediaItem(quot;http://whacked.net/music/wired-01.mp3quot;); // Make a playlist var mediaList = library.createSimpleMediaList(quot;TheWiredCDquot;); mediaList.add(mediaItem); // Let's be obnoxious and play it, whether the user requested it or not songbird.playMediaList(mediaList); // I'm sure the user loved it so much - let's integrate it into their library for them songbird.downloadItem(mediaItem);
  45. Download Event Monitoring var trackNameProp = quot;http://songbirdnest.com/data/1.0#trackNamequot; function onDlStart(aEvent) { alert(aEvent.item.getProperty(trackNameProp) + quot; started downloadingquot;) } function onDlComplete(aEvent) { alert(aEvent.item.getProperty(trackNameProp) + quot; finished downloadingquot;); alert(aEvent.status); } document.addEventListener(quot;downloadstartquot;, onDlStart, false); document.addEventListener(quot;downloadcompletequot;, onDlComplete, false); songbird.downloadItem(mediaItem);
  46. • Get involved in mozilla Taiwan! • Localisation • Testing/QA • Development http://moztw.org
  47. Upcoming Events! • Mozilla Firefox 3.5 New Developer Features: Overview • 04/28 @ 19:00-21:00 Tim G.T. Chien • http://go2.tw/moztwfirefox35 • JavaScript in Firefox (1) • 05/05 @ 19:00-22:00 (othree) • http://go2.tw/moztw5extprea • JavaScript in Firefox (2) • 05/07 @ 19:00-22:00 (othree) • http:/go2.tw/moztw5extpreb • Firefox Extension Development (1) • 05/09 @ 09:00-17:00 (Littelbtc) • http:/go2.tw/moztw5exta • Firefox Extension Development (2) • 05/23 @ 09:00-17:00 (Littelbtc) • http:/go2.tw/moztw5extb
  48. Thanks! IRC: •irc://irc.mozilla.org/#songbird Developer List: • http://groups.google.com/group/songbird-dev User Support: • http://getsatisfaction.com/songbird Stephen Lau (stevel@songbirdnest.com) http://whacked.net
  49. Copyright 2009 Pioneers of the Inevitable, Inc. Some rights reserved. All trademarks and logos are properties of their respective owners. Any use of non-POTI trademarks or logos should not be construed as endorsement of or by Songbird or POTI, Inc. This presentation is licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 3.0 Unported License http://creativecommons.org/licenses/by-nc-sa/3.0/ Cloud photo by saital: http://flickr.com/photos/saital/17949827/

×
