Openstack Nova APIs

Openstack Nova APIsDiego Parrilla

¿Quién Soy? Diego Parrilla Stackops CEO & Founderdiego.parrilla@stackops.com www.nubeblog.com twitter.com/nubeblog www.stackops.com twitter.com/stackops Diego Parrilla diego.parrilla@stackops.com

La infraestructura ya no es una ventaja competitiva  La infraestructura ya no es necesaria  Se buscan formas pago por su uso  Las formas de pago deben ser de alta granularidad  Debe ser muy elástica, ¡igual tenemos éxito!  Así aparece la Infraestructura como Servicio Diego Parrilla diego.parrilla@stackops.com 3

Las empresas empiezan a ‘infectarse’ Tecnologías que usan IaaS y no ‘hierro’ Procesos de gestión adaptadas al IaaS: metodologías ágiles. La aplicación prevalece sobre la infraestructura Ingenieros con perfiles nuevos e ideas diferentes (Devops) Diego Parrilla diego.parrilla@stackops.com 4

Software to provision virtual machines on standard hardware at massive scaleOpenStack ComputeA community creating open source software tobuild public and private clouds Software to reliably store billions of objects distributed across standard hardwareOpenStackObject Storage Diego Parrilla diego.parrilla@stackops.com

OpenStack Community Today Diego Parrilla diego.parrilla@stackops.com

Company launched in March 2011 FiguresTotal Downloads >22000Platforms deployed with our distro (15/3/2012) >14000Clients registered (15/3/2012) >3000 Diego Parrilla diego.parrilla@stackops.com

 SysAdmins Python developers Java developers FrontEnd developers (ExtJS) Diego Parrilla diego.parrilla@stackops.com

¿Qué es un DevOp? Conjunto de principios, métodos y prácticas para la colaboración e integración entre desarrolladores y operaciones. Combinación de ‘developer’ y ‘operations’ Operaciones programadas usando este tipo de plataformas y herramientas. De operaciones reactivas, a unas más ágiles y automatizadas. Meta: producir software y/o servicios más rápida y eficientemente. Diego Parrilla 9 diego.parrilla@stackops.com

Diseño de soluciones Los desarrolladores ganan poder en el diseño de las soluciones. La aplicación dicta sus propias necesidades de recursos. Desarrollo ‘pasa el marrón’ a Operaciones. Operaciones se defiende poniendo barreras. Actitud defensiva. Para evitarlo el ecosistema de la app debe gestionarse por software. Diego Parrilla 10 diego.parrilla@stackops.com

Mantenimiento automatizado Aparecen nuevas herramientas que automatizan tareas cotidianas de los SysAdmins Herramientas que se programan como si fuera un Framework más:  Chef,  Puppet,  Fabric… Sistemas que se gestionan como servicios mediante APIS. Diego Parrilla 11 diego.parrilla@stackops.com

Cloud Users EC2 Openstack Glance Quantum Northbridge APIs Keystone Southbridge APIs Platform Admins Admin StackOps Diego Parrilla diego.parrilla@stackops.com

http://api.openstack.org Diego Parrilla diego.parrilla@stackops.com

Diego Parrilladiego.parrilla@stackops.com

Solicitar token a Keystonecurl -s -d"{"auth":{"passwordCredentials": {"username": "$NOVA_USERNAME", "password": "$NOVA_API_K EY"}}}" -H "Content-type: application/json" http:// $HOST_IP:5000/v2.0/tokens{"access": {"token": {"expires": "2012-03-24T11:38:43", "id": "8fd10194-5e6c-41f6-9301-f83a1fcff9c7"}, "user": {"id": "1", "roles": [{"id": "1", "name": "Admin"}, {"id": "3", "name": "KeystoneAdmin"}, {"id": "4", "name": "KeystoneServiceAdmin"}], "name": "admin"}}} Diego Parrilla diego.parrilla@stackops.com

Usando el token con Glance (I)IMAGE_NAME=ttylinux-uec-amd64-12.1_2.6.35-22_1’tar -zxf ./$IMAGE_NAME.tar.gz -C /tmp/imagesRVAL=`glance add -A $AUTH_TOKEN name="ttylinux-kernel" is_public=true container_format=aki disk_format=aki < /tmp/images/$IMAGE_NAME-vmlinuz*`KERNEL_ID=`echo $RVAL | cut -d":" -f2 | tr -d " "`glance add -A $AUTH_TOKEN name="ttylinux" is_public=true container_format=ami disk_format=ami kernel_id=$KERNEL_ID < /tmp/images/$IMAGE_NAME.imgroot@nova-controller:/var/lib/stackops# glance index -A $AUTH_TOKENID Name Disk Format Container Format Size---------------- ------------------------------ -------------------- -------------------- --------------10 ttylinux ami ami 251658249 ttylinux-kernel aki aki 4404752root@nova-controller:/var/lib/stackops# Diego Parrilla diego.parrilla@stackops.com

Usando el token con Glance (II)curl -H "X-Auth-Token:$AUTH_TOKEN" http://GLANCE_HOST:9292/v1/images{"images":[{"name": "ttylinux", "container_format": "ami", "disk_format": "ami", "checksum": "10047a119149e08fb206eea89832eee0", "id": 10, "size": 25165824}, {"name": "ttylinux-kernel", "container_format": "aki", "disk_format": "aki", "checksum": "3ed2965d3f8d877a3ee3e061fd648e9a", "id": 9, "size": 4404752}]} Diego Parrilla diego.parrilla@stackops.com

EC2 Query API vs Openstack API Diego Parrilla diego.parrilla@stackops.com

EC2 Query API Basada en GET y POST + Parámetros Cada petición debe ir firmada?Action=DescribeImages&AWSAccessKeyId=10QMXFEV71ZS32XQFTR2&SignatureVersion=1&Timestamp=2006-12-08T07%3A48%3A03Z&Version=2007-01-03 Message Authentication Code (HMAC) con función hash SHA-1&Signature=GjH3941IBe6qsgQu%2Bk7FpCJjpnc%3D Diego Parrilla diego.parrilla@stackops.com

Openstack API REST Basada en el API de Rackspace Extensible:  Quantum  System Usage?Action=DescribeImages&AWSAccessKeyId=10QMXFEV71ZS32XQFTR2&SignatureVersion=1&Timestamp=2006-12-08T07%3A48%3A03Z&Version=2007-01-03 Diego Parrilla diego.parrilla@stackops.com

Obtener lista de servicios del tenant Necesitamos username, password y tenantIdcurl -s -d "{"auth":{"passwordCredentials": {"username": "$NOVA_USERNAME", "password": "$NOVA_API_KEY"}, "tenantId ":”$TENANT_ID"}}" -H "Content-type: application/json" http://$HOST_IP:5000/v2.0/tokens{"access": {"token": {"expires": "2015-02-05T00:00:00", "id": "999888777666", "tenant": {"id": "1", "name": "admin”}},"serviceCatalog": [{"endpoints": [{"adminURL": "http://10.0.2.15:8774/v1.1/1", "region": "nova", "internalURL": "http://10.0.2.15:8774/ v1.1/1", "publicURL": "http://10.0.2.15:80/v1.1/1"}], "type": "compute", "name": "nova"},{"endpoints": [{"adminURL": "http://10.0.2.15:9292/v1.1/1", "region": "nova", "internalURL": "http://10.0.2.15:9292/ v1.1/1", "publicURL": "http://10.0.2.15:9292/v1.1/1"}], "type": "image", "name": "glance"},{"endpoints": [{"adminURL": "http://10.0.2.15:35357/v2.0", "region": "nova", "internalURL": "http://10.0.2.15:5000/v2.0", "publicURL": "http://10.0.2.15:5000/v2.0"}], "type": "identity", "name": "keystone"}],"user": {"id": "1", "roles": [{"tenantId": "1", "id": "1", "name": "Admin"}, {"id": "1", "name": "Admin"}, {"id": "3", "name": "KeystoneAdmin"}, {"id": "4", "name": "KeystoneServiceAdmin"}], "name": "admin"}}} Diego Parrilla diego.parrilla@stackops.com

Obtener lista de imagenes disponibles Necesitamos el tokencurl -i http://10.0.2.15:80/v1.1/1/images/detail -H "X-Auth-Token: 999888777666"{"images": [{"status": "ACTIVE", "updated": "2012-03-23T12:06:15Z", "name": "ttylinux", "links": [{"href": "http://10.0.2.15/v1.1/1/images/10", "rel": "self"}, {"href": "http://10.0.2.15/1/images/10", "rel": "bookmark"}], "created": "2012-03-23T12:06:14Z", "progress": 100, "id": "10", "metadata": {"kernel_id": "9", "min_disk": 0, "min_ram": 0, "owner": null}}, {"status": "ACTIVE", "updated": "2012-03-23T12:06:13Z", "name": "ttylinux-kernel", "links": [{"href": "http://10.0.2.15/v1.1/1/images/ 9", "rel": "self"}, {"href": "http://10.0.2.15/1/images/9", "rel": "bookmark"}], "created": "2012-03-23T12:06:13Z", "progress": 100, "id": "9", "metadata": {"min_disk": 0, "owner": null, "min_ram": 0}}]} Diego Parrilla diego.parrilla@stackops.com

Obtener lista de ‘sabores’ disponibles Necesitamos el tokencurl -i http://10.0.2.15:80/v1.1/1/flavors -H "X-Auth-Token: 999888777666"{"flavors":[{"id": 3, "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/3", "rel": "self"}, {"href": "http://10.0.2.15/1/flavors/3", "rel": "bookmark"}], "name": "m1.medium"}, {"id": 4, "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/4", "rel": "self"}, {"href": "http:// 10.0.2.15/1/flavors/4", "rel": "bookmark"}],"name": "m1.large"}, {"id": 1, "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/1", "rel": "self"}, {"href": "http://10.0.2.15/1/flavors/1", "rel": "bookmark"}], "name": "m1.tiny"}, {"id": 5, "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/5", "rel": "self"}, {"href": "http:// 10.0.2.15/1/flavors/5", "rel": "bookmark"}], "name": "m1.xlarge"}, {"id": 2, "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/2", "rel": "self"}, {"href": "http://10.0.2.15/1/flavors/2", "rel": "bookmark"}], "name": "m1.small"}]} Diego Parrilla diego.parrilla@stackops.com

Obtener informacion m1.tiny Necesitamos el token la referencia a la m1.tinycurl -i http://10.0.2.15:80/v1.1/1/flavors/1 -H "X-Auth-Token: 999888777666"{"flavor": {"rxtx_quota": 0, "name": "m1.tiny", "links": [{"href": "http://10.0.2.15/v1.1/1/flavors/1", "rel": "self"}, {"href": "http://10.0.2.15/1/flavors/1", "rel": "bookmark"}], "ram": 512, "vcpus": 1, "rxtx_cap": 0, "swap": 0, "disk": 0, "id": 1}} Diego Parrilla diego.parrilla@stackops.com

Arrancar una VM m1.tiny con ttylinux Necesitamos el token, la referencia a la m1.tiny y a la imagen ttylinuxcurl -i http://10.0.2.15:80/v1.1/1/servers -X POST -d {"server": {"flavorRef": "1", "name": "Test3", "imageRef": „10"}} -H "X-Auth-Token: 999888777666" -H "Accept: application/json" -H "Content-type: application/json"{"server": { "status": "BUILD", "updated": "2012-03-24T01:29:40Z", "hostId": "", "user_id": "admin", "name": "Test3", "links": [{"href": "http://10.0.2.15/v1.1/1/servers/3", "rel": "self"}, {"href": "http://10.0.2.15/1/servers/3", "rel": "bookmark"}], "addresses": {}, "tenant_id": "1", "image": {"id": “10", "links": [{"href": "http://10.0.2.15/1/images/10", "rel": "bookmark"}]}, ….: {}}} Diego Parrilla diego.parrilla@stackops.com

Ver el estado del despliegue de la VM Necesitamos el token y el ID de la VMcurl -i http://10.0.2.15:80/v1.1/1/servers/3 -H "X-Auth-Token: 999888777666"{"server": {"status": "ACTIVE", "updated": "2012-03-24T01:29:48Z", "hostId": "0efed51f62cbab80576f1d3e4c540a35d5aaa76dab99fe6a2aabf838", "user_id": "admin", "name": "Test3", "links": [{"href": "http://10.0.2.15/v1.1/1/servers/3", "rel": "self"}, {"href": "http:/ /10.0.2.15/1/servers/3", "rel": "bookmark"}], "addresses": {"service": [{"version": 4, "addr": "10.0.0.4"}]}, "tenant_id": "1", "image": {"id": “10", "links": [{"href": "http://10.0.2.15/1/images/10", "rel": "bookmark"}]}, "created": "2012-03-24T01:29:40Z", "uuid": "c404217a-fccf-41ce-969f-3e442c4e1b92", … …}} Diego Parrilla diego.parrilla@stackops.com

Terminar y borrar una VM Necesitamos el token y el UUID (No el ID) de la VMcurl -i http://10.0.2.15:80/v1.1/1/servers/632b9f58-20f3-4c95-9dca-bbae8c9e02b8 -X DELETE -H "X-Auth-Token: 999888777666"HTTP/1.1 204 No Content Diego Parrilla diego.parrilla@stackops.com

¡Muchas Gracias! www.openstack.org docs.openstack.org apis.openstack.org wiki.openstack.org docs.stackops.orgdiego.parrilla@stackops.com Diego Parrilla diego.parrilla@stackops.com
