Responsive Websites             Joe Seifi, Sept 2012
Survey
- http://www.bostonglobe.com- http://worldwildlife.org/- http://nd.edu/- http://www.w3.org/- More at http://mediaqueri.es ...
Why?
Why?What?
Why?What?How?
Why?    What?    How?Sample Project
Why?    What?    How?Sample ProjectBest Practices
Why?     What?     How? Sample Project Best PracticesTesting and Tools
Why?
- 7.0 Billion people in the world- 3.5 Billion own a mobile devices (1/2)- 1.3 Billion mobile internet users- 21% had 3G i...
- 71% expect websites to load quickly on their phone- 74% leave a website after waiting 5 seconds- 77% of top websites tak...
Here and Now
Here and Now
2 years early - in 2010      Here and Now
- Websites are not like print. Why do we  design them that way?      Traditional Print
Lots of Web Devices
- Performance- Resolutions and Screen Sizes- Browser Features- Network Connection Speeds Differences in Mobile
What?
@media (min-width: 600px) and (max-width: 700px) {    body{ background-color:red;}}@media (max-width:500px){    body{backg...
How?
3 Main Options
apple.com              apple.com Desktop                 iPhone       1. Do Nothing
yelp.com   m.yelp.com   yelp appsDesktop    iPhone Web   Native Apps2. Separate Website
starbucks.com   starbucks.com   starbucks.com Desktop           iPhone          iPad3. Responsive Website
Responsive Design’s main components1. Flexible Layout2. Media Queries3. Flexible Images     Building Blocks
- Simplify- Only provide the features your users want         Content First
- Design for Mobile First- Optimize for Speed and Performance- Add Functionality for Larger  Resolutions- Load Time Affect...
- Micro-Tasks- Downplay Navigation & Options- Align with user Context and Behavior- Don’t Assume user’s location, speed,  ...
- Pixel Perfect Wireframes & Mockups don’t  make sense anymore- Style Tiles- Page Description Diagrams- Work with “Content...
- Principles of being future friendly  - Acknowledge and embrace    unpredictability.  - Think and behave in a future-frie...
-   BBC Testing Lab Sample    -   iOS - iPhone    -   Symbian S60 - N95    -   Android 2.1 - HTC desire    -   Blackberry ...
- Wanna know the secret to improving your  running? Move your feet. - Paralysis by Analysis - Intimidation of Complexities...
Sample Project
- Mostly Fluid- Column Drop- Layout Shifter- Tiny Tweaks- Off Canvas                   Luke Wroblewski &                  ...
- Mondrain- Basic Gallery- Featured Items- Column Flip- Feature Shuffle                    Joshua Johnson  Responsive Patt...
- Write LESS: Do more!- CSS Pre-compiler- Variables- Functions (aka Mixins)- Operations        LESS can Help
Code: Flexible Layout
Target    _________ = Result     Context 24____ = 1.5em    900               ____ = 93.75% 16             960 Fluid Design...
Media Queries
Mobile Site styles+   @media queries added______________________=   Full Desktop SiteMobile First Approach
1600x1200 1680x1050   1280x1024 1440x900    1280x800 1366x7881024x768 800x600 480x320     320x480 240x320    Breakpoints
<link rel="stylesheet" type="text/css"  media="print, handheld" href="foo.css">           Recognized media types      all ...
<link media="screen and (device-width: 600px)"rel="stylesheet" url=”600.css” />@import url(“600.css”) screen and (device-w...
[min-|max-]width or height[min-|max-]device-width or device-height          [min-|max-]aspect-ratio     [min-|max-]device-...
<meta name="viewport"content="width=device-width, initial-scale=1.0, user-scalable=0" />         Recognized viewport value...
Combine it all together...<meta name="viewport" content="initial-scale=1.0,width=device-width"><link media="all" href=”bas...
import only 1 file<meta name="viewport" content="initial-scale=1.0,width=device-width"><link rel="stylesheet" media="all" ...
- Start with Base css... then cascade upwards- “Enhance” the site only for those browsers  that “Respond” to media query v...
Code: Media Queries
@media only screen and (-webkit-min-device-pixel-ratio : 1.5), only screen and (min-device-pixel-ratio :1.5) {}/* sniff iP...
Code: Responsive Images
<img id="demo" src="http://dummyimage.com/400x300" alt="Responsive Image" data-fullsrc="http://dummyimage.com/800x600"><sc...
http://src.sencha.io/320/http://victorianigro.files.wordpress.com/2012/01/football-                     field-31.jpg      ...
RESS
<picture alt="description"> <source src="small.jpg"> <source src="medium.jpg" media="(min-width:400px)"> <source src="larg...
#test {    background-image: url(assets/no-image-set.png);    background-image: -webkit-image-set(url(assets/test.png) 1x,...
<div id="test">  <div></div></div><style type="text/css">#test div {background-image:url(test.png);width:200px;height:75px...
Beyond the Basics
- @embeded vs. <external- cascade vs. min-max:isolated- default mobile vs. desktop- <!--[conditional vs. <javascript  Zoe ...
- Augment Media Queries with Feature  Detection- Media Query - Main Layout and Graphics- Feature Detection - Improve Desig...
- Screen Size != Browser/Device Capability- May not be using Native Device Browser- Connection & Hardware Speeds vary- Don...
- Progressive Laoding- Concatenation         File Loading
- Less Framework 4- Skeleton Framework- Foundation 3- Starbucks Style Guide- 320 and Up- Mobile BoilerplateResponsive Fram...
-   Top Navigation-   Footer Anchor-   Select Menu-   Toggle-   Off Canvas Nav-   Footer Only-   Hide    Navigation Patterns
video {    max-width: 100%;    height: auto;}.video-container iframe,   .video-container object, .video-container embed { ...
AppendAround<div class="foo" data-set="foobar"></div><div class="bar" data-set="foobar"></div>.bar {display: block;}.foo {...
<style type="text/css">   @media only screen and (max-device-width: 480px) {     table[class=contenttable] {       width:3...
SEO Implications
Testing and Tools
- Xcode > Open Developer Tool > iOS Simulator-   Opera Mini & UC Browser In the    iTunes App Store-   Nokia http://    ww...
- Shaodw - Mac or Windows + Chrome + iOS/Android- weinre - sudo npm -g install weinre - weinre --boundHost localhost --ver...
Performance Tests
- Chrome - Web developer toolbar- Safari - User Agent switching- ResponsivePX.com- mobilephoneemulator.com pxtoem.com- Apt...
Books
Thank You
References
Joe Seifi                                                                      Responsive Images                           ...
