Transcript

  • 1. MongoDB and PHP
  • 2. My name isSteve Francia @spf13
  • 3. • 15+ years building the internet• Father, husband, skateboarder• Chief Solutions Architect @ 10gen• Author of upcoming O’Reilly publication “PHP and MongoDB”
  • 4. Introduction to MongoDB
  • 5. Why MongoDB?
  • 6. MongoDB Goals• OpenSource• Designed for today • Today’s hardware / environments • Today’s challenges• Easy development• Reliable• Scalable
  • 7. • Company behind MongoDB • AGPL license, own copyrights, engineering team • support, consulting, commercial license revenue• Management • Google/DoubleClick, Oracle, Apple, NetApp • Funding: Sequoia, Union Square, Flybridge • Offices in NYC, Redwood Shores & London • 60+ employees
  • 8. A bit of history
  • 9. 1974The relational database is created
  • 10. 1979
  • 11. 1979 1982-1996
  • 12. 1979 1982-1996 1995
  • 13. Computers in 1995•Pentium 100 mhz•10base T•16 MB ram•200 MB HD
  • 14. Cell Phones in 2011•Dual core 1.5 Ghz•WiFi 802.11n (300+ Mbps)•1 GB ram•64GB Solid State
  • 15. How about a DBdesigned for today?
  • 16. It started with DoubleClick
  • 17. Signs something needed•doubleclick - 400,000 ads/second•caching is de rigueur•complex ORM frameworks•computer architecture increasing in complexity•cloud computing
  • 18. Requirements We need enough functionality to handle broad set of use cases•strong consistency / atomicity•secondary indexes•ad hoc queries
  • 19. Trim unneeded features Leave out a few things so we can scale•no choice but to leave out relational•distributed transactions are hard to scale
  • 20. Needed a scalable data model Considered....•key/value•columnar / tabular•document oriented (JSON inspired)
  • 21. MongoDB philosphy• Keep functionality when we can (key/ value stores are great, but we need more)• Non-relational (no joins) makes scaling horizontally practical• Document data models are good• Database technology should run anywhere VMs, cloud or straight metal
  • 22. MongoDB is: Application Document Oriented { author: “steve”, High date: new Date(), text: “About MongoDB...”,Performance tags: [“tech”, “database”]} Fully Consistent Horizontally Scalable
  • 23. MongoDB•JSON Documents•Querying/Indexing/Updating similar to relational databases•Traditional Consistency•Auto-Sharding
  • 24. Under the hood•Written in C++•Available on most platforms•Data serialized to BSON•Extensive use of memory-mapped files
  • 25. Database Landscape
  • 26. This has led some to say“MongoDB has the bestfeatures of key/ valuesstores, document databasesand relational databases inone. John Nunemaker
  • 27. Use Cases
  • 28. CMS / BlogNeeds:• Business needed modern data store for rapid development and scaleSolution:• Use PHP & MongoDBResults:• Real time statistics• All data, images, etc stored together, easy access, easy deployment, easy high availability• No need for complex migrations• Enabled very rapid development and growth
  • 29. Photo Meta-DataProblem:• Business needed more flexibility than Oracle could deliverSolution:• Use MongoDB instead of OracleResults:• Developed application in one sprint cycle• 500% cost reduction compared to Oracle• 900% performance improvement compared to Oracle
  • 30. Customer AnalyticsProblem:• Deal with massive data volume across all customer sitesSolution:• Use MongoDB to replace Google Analytics / Omniture optionsResults:• Less than one week to build prototype and prove business case• Rapid deployment of new features
  • 31. Online DictionaryProblem:• MySQL could not scale to handle their 5B+ documentsSolution:• Switched from MySQL to MongoDBResults:• Massive simplification of code base• Eliminated need for external caching system• 20x performance improvement over MySQL
  • 32. E-commerceProblem:• Multi-vertical E-commerce impossible to model (efficiently) in RDBMSSolution:• Switched from MySQL to MongoDBResults:• Massive simplification of code base• Rapidly build, halving time to market (and cost)• Eliminated need for external caching system• 50x+ improvement over MySQL
  • 33. Tons morePretty much if you can use a RDMBS or Key/Value MongoDB is a great fit
  • 34. In Good Company
  • 35. MongoDB in PHP
  • 36. Relational made normalized data look like this
  • 37. Document databases makenormalized data look like this
  • 38. Terminology RDBMS MongoTable, View ➜ CollectionRow ➜ JSON DocumentIndex ➜ IndexJoin ➜ Embedded DocumentPartition ➜ ShardPartition Key ➜ Shard Key
  • 39. Documents to ObjectsDocuments to Arrays Tables to Documents { PostObject Object( [title] => MongoDB title: ‘MongoDB’, [contributors] => Array( contributors: [ [0] => PersonObject Object( { name: ‘Eliot Horowitz’, [name] => Eliot Horowitz [email] => eh@10gen.com email: ‘eh@10gen.com’ }, ) { name: PersonObjectMerriman’, [1] => ‘Dwight Object( email: ‘dm@10gen.com’ } [name] => Dwight Merriman [email] => dm@10gen.com ], ) model: { ) relational: false, [model] => ModelObject Object( [relational] => awesome:=>true [awesome] 1 }) ) }
  • 40. Documents to Objects Documents to Arrays Tables to Documents{ array( PostObject Object( title: ‘MongoDB’, "title" =>=> MongoDB [title] MongoDB, "contributors" =>=> Array( [contributors] array( contributors: [ array( => PersonObject Object( [0] { name: ‘Eliot Horowitz’, name => Eliot Horowitz, [name] => Eliot Horowitz email: ‘eh@10gen.com’ }, email => eh@10gen.com [email] => eh@10gen.com ), ) { name: ‘Dwight Merriman’, array( => PersonObject Object( [1] email: ‘dm@10gen.com’ } name => Dwight Merriman, [name] => Dwight Merriman email => dm@10gen.com [email] => dm@10gen.com ], ) ) model: { ),) relational: false, "model" =>=> ModelObject Object( [model] array( relational => false, [relational] awesome: true awesome => true [awesome] 1 } ) )} )
  • 41. Documents to Objects Documents to Arrays Tables to Documents{ array( PostObject Object( title: ‘MongoDB’, "title" =>=> MongoDB [title] MongoDB, "contributors" =>=> Array( [contributors] array( contributors: [ array( => PersonObject Object( [0] { name: ‘Eliot Horowitz’, name => Eliot Horowitz, [name] => Eliot Horowitz email: ‘eh@10gen.com’ }, email => eh@10gen.com [email] => eh@10gen.com ), ) { name: ‘Dwight Merriman’, array( => PersonObject Object( [1] email: ‘dm@10gen.com’ } name => Dwight Merriman, [name] => Dwight Merriman email => dm@10gen.com [email] => dm@10gen.com ], ) ) model: { ),) relational: false, "model" =>=> ModelObject Object( [model] array( relational => false, [relational] awesome: true awesome => true [awesome] 1 } ) )} )
  • 42. MongoDB speaks PHP
  • 43. This has led some to say“The single best interface(API) of any phpextension.   Matthew Weier OPhinney
  • 44. PHP DriverInstalling the driver $ pecl install mongoAdd to php.ini extension = mongo.so
  • 45. Connecting to the DB$connection = new Mongo();$db = $connection->selectDB(blog);$posts = $db->post;If the DB or collection doesn’t exist,mongoDB will create it on connect.
  • 46. DocumentsBlog Post Document$p1 = array("author" => "roger", "date" => new MongoDate(), "text" => "about mongoDB...", "tags" => array(tech, databases) );$posts->save($p1);
  • 47. Queryingprint_r($posts->findOne());> db.posts.findOne()Array( [_id] => MongoId Object(> { _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), [$id] => 4e9796764a18173a17000000 author : "roger", ) date : "Sat Jul 24 2010 19:47:11", [author] => roger text : "About MongoDB...", [date] => MongoDate Object( tags : [ "tech", "databases" ] } [sec] => 1318557302 [usec] => 581000 ) [text] => about mongoDB... [tags] => Array( Note: _id is unique, but can be anything [0] => tech [1] => databasesyou’d like ))
  • 48. Queryingprint_r($posts->findOne());> db.posts.findOne()Array( [_id] => MongoId Object(> { _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), [$id] => 4e9796764a18173a17000000 author : "roger", ) date : "Sat Jul 24 2010 19:47:11", [author] => roger text : "About MongoDB...", [date] => MongoDate Object( tags : [ "tech", "databases" ] } [sec] => 1318557302 [usec] => 581000 ) [text] => about mongoDB... [tags] => Array( Note: _id is unique, but can be anything [0] => tech [1] => databasesyou’d like ))
  • 49. Inserting Objectsclass PostObj { public $comments = array(); public function __construct($author, $title, $content){ $this->author = $author; $this->title = $title; $this->content = $content; }}$posts->insert(new PostObj("Steve", "My first blog post", "Hello, World!"));
  • 50. MongoIdAn autogenerated primary key$x = array("foo" => 1, "bar" => 2);$db->baz->save($x);var_dump($x[_id]);Result:object(MongoId)#4 (1) { ["$id"]=> string(24) "4e9cc76a4a1817fd21000000"}
  • 51. MongoIdAn autogenerated primary keyobject(MongoId)#4 (1) { ["$id"]=> string(24) "4e9cc76a4a1817fd21000000"} 4e9cc76a4a1817fd21000000 |------||----||--||----| ts mac pid inc
  • 52. Update Operations $set, $unset, $inc, $push, $pushAll, $pull, $pullAll, $bit$change = array($push => array(comments => array( author => Fred, created => new MongoDate(), comment => Best post ever!. ) ) );$posts->update(array("_id" => $id), $change);
  • 53. Nested DocumentsArray( { _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), [_id] => MongoId Object ( [$id] => 4e9796764a18173a17000000 ) author : "roger", [author] => roger date : "Sat Apr 24 2011 19:47:11", [comments] => Array( text : "About MongoDB...", [0] => Array( [author] => Fred tags : [ "tech", "databases" ], [created] => MongoDate Object( [sec] => 1318899392 comments : [ [usec] => 176000 ) { [comment] => Dumb post. ) ) author : "Fred", [date] => MongoDate Object( date : "Sat Apr 25 2010 20:51:03 GMT-0700", [sec] => 1318557302 [usec] => 581000 ) text : "Best Post Ever!" [tags] => Array( } [0] => tech ) ] [1] => databases}) [text] => about mongoDB...
  • 54. Nested DocumentsArray( { _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), [_id] => MongoId Object ( [$id] => 4e9796764a18173a17000000 ) author : "roger", [author] => roger date : "Sat Apr 24 2011 19:47:11", [comments] => Array( text : "About MongoDB...", [0] => Array( [author] => Fred tags : [ "tech", "databases" ], [created] => MongoDate Object( [sec] => 1318899392 comments : [ [usec] => 176000 ) { [comment] => Dumb post. ) ) author : "Fred", [date] => MongoDate Object( date : "Sat Apr 25 2010 20:51:03 GMT-0700", [sec] => 1318557302 [usec] => 581000 ) text : "Best Post Ever!" [tags] => Array( } [0] => tech ) ] [1] => databases}) [text] => about mongoDB...
  • 55. Querying$posts = $blog->find(array( "author" => "Roger"));$commentsByFred = $blog->find(array( "comments.author" => "Fred"));$commentsByFred = $blog->find(array( "comments.author" => new MongoRegex("/fred/i")));
  • 56. It’s all about the $ $ instead of >, <, =, etc. $gt, $gte, $lt, $lte, $eq, $neq, $exists, $set, $mod, $where, $in, $nin, $inc $push, $pull, $pop, $pushAll, $popAll$c->find(array("x" => array($gt => 4)));$c->find(array("x" => array(“$gt” => 4)));
  • 57. It’s all about the $ $ instead of >, <, =, etc. $gt, $gte, $lt, $lte, $eq, $neq, $exists, $set, $mod, $where, $in, $nin, $inc $push, $pull, $pop, $pushAll, $popAll$c->find(array("x" => array($gt => 4)));$c->find(array("x" => array(“$gt” => 4)));
  • 58. Adjust the behavior in php.ini or using ini_set()php.ini---------------mongo.cmd = ":"$c->find(array("x" => array(:gt => 4))); orini_set("mongo.cmd", ".");$c->find(array("x" => array(.gt => 4)));
  • 59. Indexing including secondary and compound indexes$people->ensureIndex(array("age" => 1));$people->ensureIndex(array( "name" => -1, "ts" => -1, "comments.author" => 1));
  • 60. More Indexing// Index nested documents$posts->ensureIndex( array("comments.author" => 1) )$posts->find( array("comments.author" => "Fred") )// Index on tags (multi-key index)$posts->ensureIndex( array("tags" => 1 ) )$posts->find( array("tags" => "tech") )// geospatial index$posts->ensureIndex( array("author.location" => "2d") )$posts->find( array("author.location" => array( $near => array(22,42)));
  • 61. Cursors$cursor = $c->find(array("foo" => "bar"))foreach ($cursor as $id => $value) { echo "$id: "; var_dump( $value );}$a = iterator_to_array($cursor);
  • 62. Paging$page_num = 3;$results_per_page = 10;$cursor = $results->find() ->sort(array("ts" => -1)) ->skip($page_num * $results_per_page) ->limit($results_per_page);
  • 63. Rich Documents{ _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), line_items : [ { sku: ‘tt-123’, name: ‘Coltrane: Impressions’ }, { sku: ‘tt-457’, name: ‘Davis: Kind of Blue’ } ], address : { name: ‘Banker’, street: ‘111 Main’, zip: 10010 }, payment: { cc: 4567, exp: Date(2011, 7, 7) }, subtotal: 2355}
  • 64. Grid FS
  • 65. Storing FilesUnder 16mb
  • 66. Storing Big Files>16mb stored in 16mb chunks
  • 67. Storing Big FilesWorks with replicatedand sharded systems
  • 68. A better network FS• GridFS files are seamlessly sharded & replicated.• No OS constraints... • No file size limits • No naming constraints • No folder limits • Standard across different OSs• MongoDB automatically generate the MD5 hash of the file
  • 69. Storing Files$grid = $db->getGridFS();// The files location in the File System$path = "/tmp/";$filename = "movie.mp4";// Note metadata field & filename field$storedfile = $grid->storeFile($path . $filename,array("metadata" => array("filename" => $filename),"filename" => $filename));// Return newly stored files Document IDecho $storedfile;
  • 70. Storing Data$grid = $db->getGridFS();$filename = "zelda.jpg";$storedfile = $grid->storeBytes("ÿØÿà^@^PJFIF^@^A^A^A,^G^E^E^G,...", array("metadata" => array("filename" =>$filename), "filename" => $filename));
  • 71. Streaming Data$gridFS = $db->getGridFS();// Find image to stream$image = $gridFS->findOne("zelda.jpg");// Stream image to browserheader(Content-type: image/jpeg);echo $image->getBytes();
  • 72. PHP Libraries for MongoDB
  • 73. Libraries & Frameworks• Doctrine MongoDB ODM • Zend Framework• Active Mongo • Lithium• Mongo Queue • Symfony2• Morph • Fuel• Mandango • Fat Free Framework
  • 74. Doctrine MongoDB ODM• Provides full validation• Seamless integration with Doctrine ORM • Useful for hybrid solutions• Follows same persistence model as Doctrine• Uses a Document Manager & annotations• Supports embedded and referenced objects• Can use mongo’s query interface• Supports in place updates https://github.com/doctrine/mongodb-odm
  • 75. Mandango•Very light and fast•Event support•Supports embedded and referenced objects•uses the mongo query syntax•Lacking validation, but events can be utilized to validate https://github.com/mandango/mandango
  • 76. Active Mongo•Uses ActiveRecord (active document) interface•Supports full validation•Supports in place updating•Uses native query interface•Supports referenced documents https://github.com/crodas/ActiveMongo
  • 77. Morph•Follows the Active Record model•Has own query object (Morph_Query)•Doesn’t provide validation•Doesn’t support embedded or referenced objects. https://github.com/a-musing-moose/morph
  • 78. Mongo Queue An extensible job/message queueing system that uses mongodb as the persistent storage engine.• Fully Configurable• Distributed• Atomic Locking• Priority Support• Worker Timeout Support• Stable https://github.com/skiz/mongo_queue
  • 79. http://spf13.com http://github.com/spf13 @spf13 Questions? download at mongodb.orgPS: We’re hiring!! Contact us at jobs@10gen.com
