Hybrid MongoDB  Applications  with Relational Databases
Today’s Agenda•Who I am•Why MongoDB w/intro•Why Hybrid•Hybrid Case Studies•How OpenSky implemented Hybrid MySQL / MongoDB
My name isSteve Francia     @spf13
•15+ years building the  internet (13 years using SQL)•Father, husband,  skateboarder•Chief Solutions Architect @  10gen r...
• Company behind MongoDB • AGPL license, own copyrights, engineering team • support, consulting, commercial license revenu...
Before 10gen Iworked    for     http://opensky.com
OpenSky was the firste-commerce site built    on MongoDB
Why MongoDB
Why MongoDB                My Top 10 Reasons 10. Great developer experience  9. Speaks your language  8. Scale horizontall...
Why MongoDB                My Top 10 Reasons 10. Great developer experience  9. Speaks your language  8. Scale horizontall...
MongoDB is          Application      Document                           Oriented                           { author: “stev...
Under the hood• Written in C++• Runs on nearly anything• Data serialized to BSON• Extensive use of memory-mapped files  i.e...
Database Landscape                            MemCacheScalability & Performance                                           ...
This has led    some to say“MongoDB has the bestfeatures of key/valuesstores, document databasesand relational databases i...
Why Hybrid?
Reasons to build a  hybrid application•Friction in existing application caused  by RDBMS•Transitioning an existing applica...
Reasons Not to builda hybrid application•Aggregation (at least not very soon)•Lack of clear understanding of needs•Backups...
HybridApplications...  but I don’t   want to complicate    things
Most  RDMBSapplicationsare already  hybrid
Typical RDMBS  Application        Memcache App         RDBMS
Typical HybridRDMBS Application          MongoDB   App           RDBMS
Most of the same     rules apply•Application partitions data between  two (or more) systems.•Model layer tracks what conte...
Hybrid is easier thanRDMBS + MemCache• Always know where to find a piece of data.• Data never needs expiring.• Data not dup...
Typical RDBMSretrieval operation       exists & up to date?        if yes... then done     Memcache       if no, query DB ...
Typical HybridRetrieval Operation         find        return   MongoDB  App   OR        query        return   RDBMS
Typical RDMBSwrite operation       insert or update row         confirm written         RDBMS      assemble into object(s)A...
Typical RDMBSwrite operation         insert or update row            confirm written              RDBMS        assemble int...
Typical RDMBS   write operation               insert or update row                  confirm written              RDBMS     ...
Typical HybridWrite Operation      save document           return        MongoDBApp        OR      insert or update       ...
Typical HybridWrite Operation      save document           return        MongoDBApp        OR      insert or update       ...
Hybrid Use Cases
ArchivingWhy Hybrid:• Existing application built on MySQL• Lots of friction with RDBMS based archive storage• Needed more ...
ReportingWhy Hybrid:• Most of the functionality written in MongoDB• Reporting team doesn’t want to learn MongoDBSolution:•...
E-commerceWhy Hybrid:• Multi-vertical product catalogue impossible to model in RDBMS• Needed transaction support RDBMS pro...
How        implemented a      hybrid MongoDB /      MySQL solution       http://opensky.com
Doctrine (ORM/ODM)   makes it easy
Data to store in SQL•Order•Order/Shipment•Order/Transaction•Inventory
Data to store in  MongoDB
Data to store in        MongoDB• User               • Event• Product            • TaxRate• Product/Sellable   • ... and th...
The most boring SQL    schema ever
CREATE TABLE `product_inventory` (   `product_id` char(32) NOT NULL,   `inventory` int(11) NOT NULL DEFAULT 0,   PRIMARY K...
Did you noticeInventory is in SQLBut it’s also property in your Mongo collections?
CREATE TABLE `product_inventory` (   `product_id` char(32) NOT NULL,   `inventory` int(11) NOT NULL DEFAULT 0,   PRIMARY K...
Inventory is transient
Inventory is         transient• Product::$inventory is effectively a  transient property•Note how I said “effectively”? .....
Accuracy is only important when there’s contention
Accuracy is only important when there’s contention•For display, sorting and alerts, we can  use the value stashed in Mongo...
Accuracy is only important when there’s contention•For display, sorting and alerts, we can  use the value stashed in Mongo...
Inventory kept insync with listeners
Inventory kept in sync with listeners•Every time a new product is created,  its inventory is inserted in SQL
Inventory kept in sync with listeners•Every time a new product is created,  its inventory is inserted in SQL•Every time an...
Inventory kept in sync with listeners•Every time a new product is created,  its inventory is inserted in SQL•Every time an...
Be careful what you        lock
Be careful what you         lock1. Acquire inventory row lock and begin   transaction2. Check current product inventory3. ...
Making MongoDBand RDBMS relations     play nice
Products aredocuments stored  in MongoDB
/** @mongodb:Document(collection="products") */class Product{    /** @mongodb:Id */    private $id;    /** @mongodb:String...
Orders are entitiesstored in an RDBMS
/**  * @orm:Entity  * @orm:Table(name="orders")  * @orm:HasLifecycleCallbacks  */class Order{     /**      * @orm:Id @orm:...
So how does an    RDBMS have areference to something outside the database?
Setting the Productclass Order {    // ...    public function setProduct(Product $product)    {        $this->productId = ...
• $productId is mapped and persisted• $product which stores the Product  instance is not a persistent entity  property
Retrieving ourproduct later
OrderPostLoadListeneruse DoctrineORMEventLifecycleEventArgs;class OrderPostLoadListener{    public function postLoad(Lifec...
All Together Now// Create a new product and order$product = new Product();$product->setTitle(Test Product);$dm->persist($p...
Read more about      this techniqueJon Wage, one of OpenSky’s engineers, firstwrote about this technique on his personalblo...
http://spf13.com                                http://github.com/spf13                                @spf13           Qu...
