EYES
Anatomy and Landmarks of Eyes
<ul><li>The eye is the sensory organ that transmit visual stimuli to the brain for interpretation </li></ul><ul><li>It occ...
2 <ul><li>4 rectus & 2 </li></ul><ul><li>2 oblique muscles </li></ul><ul><li>are innervated </li></ul><ul><li>by CN 3 & CN...
<ul><li>1.EXTERNAL EYE </li></ul><ul><li>Eyelid  </li></ul><ul><li>Conjunctiva </li></ul><ul><li>Lacrimal gland </li></ul>...
<ul><li>Eyebrows </li></ul><ul><li>Eyelids </li></ul><ul><li>Eyelashes </li></ul>

<ul><li>2.INTERNAL EYE </li></ul><ul><li>3 layers  </li></ul><ul><li>1.Sclerotic coat </li></ul><ul><li>> this tough layer...

<ul><li>2. Choroid coat </li></ul><ul><li>> this middle layer is deeply pigmented with melanin </li></ul><ul><li>Reduces r...

<ul><li>3. Retina </li></ul><ul><li>> forms the inner layer of the eye  </li></ul><ul><li>> it contains the light receptor...

Eye Examination <ul><li>One of the best ways to protect vision- it can detect eye problems at their earliest stage </li></ul>
Who gives eye exam? <ul><li>Ophthalmologists- or any medical doctors who provide full eye care such as : </li></ul><ul><li...
<ul><li>Optometrists  </li></ul><ul><li>- diagnosing common eye disorders and treating selected eye diseases with drugs </...
<ul><li>Opticians  </li></ul><ul><li>- fill prescriptions for eyeglasses </li></ul><ul><li>- some opticians also sell and ...
<ul><li>A complete eye exam begins with your medical history: </li></ul><ul><li>- Are you having any eye problem now? </li...
<ul><li>What health problems have you had in recent years? </li></ul><ul><li>Are you taking any medications? </li></ul><ul...
<ul><li>Has anyone in the family had eye problems such as cataracts or glaucoma </li></ul><ul><li>Has anyone in your famil...
Eye Examination <ul><li>PROCEDURE… </li></ul>
<ul><li>Eyeball  </li></ul><ul><li>>Position and alignment of the eyes </li></ul><ul><li>a. Stand in front of the patient ...
<ul><li>The eyeball –observe the position within the confines of the bony orbit ( socket) </li></ul>
<ul><li>External examination </li></ul><ul><li>>Examination of the eyes is carried out in a systematic manner beginning wi...
<ul><li>Surrounding structures </li></ul><ul><li>Eyebrows  </li></ul><ul><li>> note for the amount , distribution </li></u...
<ul><li>Eyelids  </li></ul><ul><li>Assess the palpebral fissure with the patient looking straight ahead and observe the re...
<ul><li>Note for the ability to open and close the eyes completely </li></ul><ul><li>Observe for ptosis  </li></ul><ul><li...
<ul><li>Tremors  </li></ul><ul><li>Redness  </li></ul><ul><li>Swelling/edema of the lids </li></ul><ul><li>Note whether th...
<ul><li>Procedure for everting </li></ul><ul><li>the eyelid and removing </li></ul><ul><li>a foreign body </li></ul>

<ul><li>Eyeball tension </li></ul><ul><li>> apply gentle pressure from the fingertips </li></ul><ul><li>( L&R forefingers)...
<ul><li>Lacrimal apparatus </li></ul><ul><li>Inspect the regions of lacrimal gland and  </li></ul><ul><li>Lacrimal sac for...
<ul><li>Press on the lacrimal </li></ul><ul><li>sac; if fluid can be </li></ul><ul><li>expressed thru the </li></ul><ul><l...
<ul><li>INTERNAL EXAMINATION </li></ul>
<ul><li>Conjunctivae & Sclerae </li></ul><ul><li>Ask the patient to look </li></ul><ul><li>up as you depress both </li></u...
<ul><li>Cornea  </li></ul><ul><li>With oblique lighting </li></ul><ul><li>from a penlight </li></ul><ul><li>inspect for cl...
<ul><li>Iris, Pupils & Lens </li></ul><ul><li>> With the light shining  </li></ul><ul><li>directly from the temporal  </li...
<ul><li>Pupillary reaction </li></ul><ul><li>- Pupillary size changes in response to light and to the effort of focusing o...
<ul><li>a) The light reaction  </li></ul><ul><li>Direct light reflex: </li></ul><ul><li>> From the lateral side of each ey...
<ul><li>Indirect light reflex: </li></ul><ul><li>Ask the patient to rest the radial side of his L or R hand in between the...
<ul><li>b) The near reaction </li></ul><ul><li>- When a person shifts gaze fr. a far object to a near one, the pupils cons...

<ul><li>Eye muscle test </li></ul><ul><li>- This test examines the muscles that  </li></ul><ul><li>that control eye moveme...
<ul><li>EXTRAOCULAR  </li></ul><ul><li>MUSCLE TEST </li></ul><ul><li>>Position yourself 2 ft </li></ul><ul><li>in front of...

<ul><li>Convergence  </li></ul><ul><li>> Is the reflexive movement of the eyes medially when we view close objects causing...
<ul><li>Convergence test </li></ul><ul><li>- hold the target in the midline and at the eye level about 50 cm (20 inch) fro...
<ul><li>Lid lag </li></ul><ul><li>The inability of the upper eyelid to follow the eye’s downward movement </li></ul><ul><l...
<ul><li>Lid lag test </li></ul><ul><li>- hold the finger or a penlight as a target in the midline above the eye level 20 i...
Testing Vision <ul><li>Visual Acuity </li></ul><ul><li>- This test measures how clearly you can  </li></ul><ul><li>can see...
<ul><li>Snellen Chart </li></ul><ul><li>Done when gross visual acuity is fair </li></ul><ul><li>This is a test for far vis...
<ul><li>SNELLEN CHART  Pinhole test </li></ul>
<ul><li>Jaeger Test </li></ul><ul><li>> for  near vision  </li></ul><ul><li>> subject read at one </li></ul><ul><li>foot o...
<ul><li>Visual field test (perimetry) </li></ul><ul><li>- visual field is the area in front of you that you can see withou...
<ul><li>Confrontation test </li></ul>
<ul><li>Tangent screen exam </li></ul><ul><li>- sit a short distance from a screen and stare at a target at its center.  <...
<ul><li>Automated perimetry </li></ul><ul><li>- computer program is used that flashes small lights as you look into a spec...
<ul><li>Slit-lamp examination </li></ul><ul><li>- it uses a microscope that enlarges and illuminate the front of the eye w...

OPHTHALMOSCOPIC EXAM <ul><li>OPHTALMOSCOPY or FUNDOSCOPY </li></ul><ul><li>-  method of inspecting the eye grounds from a ...

<ul><li>Appertures of the ophthalmoscope </li></ul><ul><li>Small apperture – small pupils </li></ul><ul><li>Red free filte...

<ul><li>Optic disc </li></ul><ul><li>- note for its clarity, disc margin should be sharp and well defined </li></ul><ul><l...
<ul><li>-The physiologic cup if present is normally yellowish white. Its horizontal diameter is usually less than half the...
<ul><li>Identify the arterioles and veins </li></ul><ul><li>1) color  </li></ul><ul><li>A- light red  V- dark red </li></u...
<ul><li>The A:V ratio is generally 3:5 to 2:3 </li></ul>
<ul><li>Macula  </li></ul><ul><li>This is an avascular area, somewhat larger than the disc with no distinct margin </li></...
<ul><li>b. To bring it into your vision, ask the patient to look directly at the light </li></ul><ul><li>c. In the center ...



<ul><li>Glaucoma test ( tonometry)  </li></ul><ul><li>- measures intraocular pressure- pressure inside the eyes. </li></ul...
SIGNS
Eyeballs <ul><li>Exophthalmos  </li></ul><ul><li>- increase in the volume of the orbital content causing a protrusion of t...

<ul><li>Palpebral fissures </li></ul><ul><li>Widened palpebral fissures </li></ul><ul><li>- uncovers the upper border of t...
EYELIDS WIDENED PALPEBRAL FISSURE
<ul><li>(+) Lid lag test (Von Graefe sign) </li></ul><ul><li>- seen in hyperthyroidism </li></ul>
<ul><li>2. Narrowed palpebral fissure: </li></ul><ul><li>Enophthalmos </li></ul><ul><li>- the globe is recessed in the orb...
<ul><li>Failure of lid closure: </li></ul><ul><li>Paralysis of orbicularis muscle </li></ul><ul><li>- seen in Bell’s palsy...
BELL’S PALSY
<ul><li>2. Failure of lid opening: </li></ul><ul><li>Ptosis </li></ul><ul><li>- indicates a congenital or acquired weaknes...
<ul><li>Ptosis  </li></ul>
<ul><li>Lid swelling: palpebral edema </li></ul><ul><li>a) inflammatory edema  </li></ul><ul><li>- redness , warmth, pain ...
<ul><li>Swollen eyelids </li></ul>
<ul><li>Lid inversion ( Entropion ) </li></ul><ul><li>a) spastic </li></ul><ul><li>Occurs only in the lower lid </li></ul>...
<ul><li>b) Cicatricial  </li></ul><ul><li>- occurs in either lid </li></ul><ul><li>- due to contracture of scar tissue </l...
LID INVERSION (INTROPION)
<ul><li>Lid eversion ( Ectropion) </li></ul><ul><li>Lid turns outward </li></ul><ul><li>Both lids affected by spastic or c...
<ul><li>LID EVERSION (ECTROPION) </li></ul>
<ul><li>Xanthelasma </li></ul><ul><li>- yellow lid plaques </li></ul><ul><li>- painless, non pruritic occur in the upper a...

<ul><li>Chalazion or meibomian cyst </li></ul><ul><li>- a granulomatous inflammation of the meibomian gland in the upper a...
<ul><li>Chalazion  </li></ul>
<ul><li>Sty  </li></ul><ul><li>- lid pustule/external hordeolum </li></ul><ul><li>- acute suppurative inflammation of the ...
<ul><li>Sty  </li></ul>
<ul><li>Dacryoadenitis  </li></ul><ul><li>- obstruction of the lacrimal gland producing viral or bacterial infection </li>...
DACRYOADENITIS
Sclera
<ul><li>Icteric sclerae </li></ul>
Conjunctiva
<ul><li>Pale Palpebral Conjunctiva </li></ul>
<ul><li>Pterygium  </li></ul><ul><li>An abnormal growth of conjunctiva that extends over the cornea from the limbus. </li>...

<ul><li>Subconjunctival Hemorrhage </li></ul><ul><li>Bright red blood in a sharply defined are surrounded by a normal appe...
Subconjunctival Hemorrhage
<ul><li>Chemosis ( conjunctival edema) </li></ul><ul><li>- swelling of the eye surface membrane because of accumulation of...

<ul><li>Conjunctivitis  </li></ul><ul><li>- a condition in which the conjunctiva becomes inflamed or infected . </li></ul>...
<ul><li>Conjunctivitis  </li></ul>
Pupils
<ul><li>Mydriasis  </li></ul><ul><li>Pupillary dilatation </li></ul><ul><li>( > 5 mm diameter) </li></ul><ul><li>May be du...
<ul><li>Miosis  </li></ul><ul><li>- Pupillary constriction </li></ul><ul><li>( < 3 mm in diameter) </li></ul><ul><li>- may...

Cornea <ul><li>Cloudy cornea </li></ul><ul><li>- seen in congenital syphilis </li></ul><ul><li>- Hutchinson triangle : </l...

<ul><li>Arcus senilis </li></ul><ul><li>- gray band of opacity in the periphery of the cornea which is composed of lipid d...

<ul><li>Circus senilis </li></ul>
<ul><li>Corneal ulcer </li></ul><ul><li>- infective condition of the cornea involving disruption of its epithelial layer w...

Lens <ul><li>Cataract  </li></ul><ul><li>- opacity occuring in the lens due to denaturation of lens caused by aging </li><...
<ul><li>Cataract  </li></ul>
EOM muscles
<ul><li>Strabismus  </li></ul><ul><li>- a condition in which both eyes do not focus on an object simultaneously </li></ul>
<ul><li>2 kinds </li></ul><ul><li>a) paralytic </li></ul><ul><li>- caused by impairment of one or more  </li></ul><ul><li>...
<ul><li>b) Non paralytic strabismus </li></ul><ul><li>- has no primary muscle weakness </li></ul><ul><li>- patient can foc...
<ul><li>When one eye is covered, the other one will move to  focus on the object if the covered eye is the dominant one </...
<ul><li>Cranial nerve 3 palsy </li></ul>
Visual Field


<ul><li>A= total blindness </li></ul><ul><li>right eye </li></ul><ul><li>B= nasal hemianopsia </li></ul><ul><li>of the rig...
<ul><li>Hemianopsia  </li></ul><ul><li>-involves nerves projecting from both eyes </li></ul><ul><li>caused by lesion in th...
<ul><li>Homonymous hemianopsia </li></ul><ul><li>- defect on the same side of each field </li></ul><ul><li>e.g.  </li></ul...
<ul><li>(R) Homonymous Hemianopsia (L) </li></ul>
<ul><li>Bitemporal heteronymous hemianopsia </li></ul><ul><li>- caused by a lesion of the decussating fibers in  the optic...
Retina
<ul><li>Papilledema ( choked disc) </li></ul><ul><li>Due to inc.ICP </li></ul><ul><li>causes CSF to </li></ul><ul><li>comp...
<ul><li>Macula  </li></ul><ul><li>- common site for  </li></ul><ul><li>diabetes mellitus </li></ul><ul><li>- microaneurysm...
<ul><li>Retinal spots </li></ul>
Symptoms
<ul><li>Diplopia or double vision </li></ul><ul><li>- eyes not aligned </li></ul><ul><li>- perception of 2 visual images d...
<ul><li>Blurred vision </li></ul><ul><li>- loss of sharp focus of light on the retina </li></ul><ul><li>- may be due to op...
<ul><li>Visual loss </li></ul><ul><li>- injury or impairment to any portion of the visual pathway </li></ul><ul><li>Acute ...
<ul><li>Pain in the eye </li></ul><ul><li>Careful examination of the cornea, anterior chamber, iris, retina are mandatory ...
<ul><li>Causes: </li></ul><ul><li>endocrine – thyrotoxicosis </li></ul><ul><li>idiopathic – cluster headache </li></ul><ul...
Thank You




<ul><li>Corneal ulcer </li></ul>
<ul><li>Cataract </li></ul>
<ul><li>Eye Hemorrhage </li></ul>
Grades of Retinal Hypertension <ul><li>1 Narrowing in terminal branches of vessels </li></ul><ul><li>2 General narrowing o...
Grades of Retinal Sclerosis <ul><li>1 Thickening of vessels with slight depresion of veins at arteriolar- venular crossing...


<ul><li>(Lower) Homonymous Hemianopsia (Upper) </li></ul>
<ul><li>Diabetic Retinopathy </li></ul>
