Sparked goes SharePoint 2010 for developers<br />
Who are we?<br />2<br /><ul><li> Roel Hans Bethelehem
SharePoint Solution Architect
Work experience: WUR, Sara Lee, Flora Holland
@rbethleh
E-Mail: roelhans.bethlehem@sparked.nl
Alexander Meijers
SharePoint Solution Architect
Work experience: Facilicom, Logica Intranet
Twitter: @ameijers
E-Mail: alexander.meijers@sparked.nl</li></li></ul><li>SharePoint 2010 Developer Overview<br />
Challenges<br />4<br /><ul><li> What’s new?
 UX Platform
 The Ribbon
 The Toolbar
 Dialog Framework
 Tools
 Web Part Development</li></li></ul><li>What’s new?<br />5<br />
Microsoft SharePoint 2010<br /><ul><li>  Improvements to UI and accessibility features
 Better tools for developers and designers
 End-to-end integration with PowerShell
 Improvements to lists and events
 New client-side object model and runtime
 Enhanced support for developing workflow     applications
Development can now be done on client OS
 New connector framework enhances Search    infrastructure
 User solutions and partially trusted code (sandboxing)</li></ul>What’s new?<br />
UX Platform<br />7<br />
Changes to the UX Platform<br />8<br /><ul><li> General platform improvements
Masterpages (dynamic) + _layouts
 The Ribbon
 Status Bar/Notification Area
 Dialog Framework
 New Theming Infrastructure
 Silverlight Web Part
 Client OM</li></ul>UX Platform<br />Philosophy: Allow users to complete tasks quickly in context with a simple interface ...
Key Platform Investments<br />9<br /><ul><li> Standards and Refactoring
Targeting WCAG 2.0 AA standards
Reduced use of tables
Cross-browser support: IE 7+, Firefox, Safari
 Visual upgrade
UI upgrade separated from database upgrade (can keep V12 UI while running on V14)
 Enhanced vs2010 project templates
Upcoming SlideShare
Loading in...5
×

SharePoint 2010 For Developers

14,702

Published on

This presentation is aimed at developers that want to work with SharePoint 2010.

Published in: Technology
1 Comment
32 Likes
Statistics
Notes
No Downloads
Views
Total Views
14,702
On Slideshare
0
From Embeds
0
Number of Embeds
3
Actions
Shares
0
Downloads
0
Comments
1
Likes
32
Embeds 0
No embeds

No notes for slide
  • IE 6 wordtnietmeerondersteund
  • Note: Currently with Beta1 there is no built-in UI component that allows a user to enable and disable the developer dashboard. However, you can create a simple Console application that does the trick.
  • Transcript of "SharePoint 2010 For Developers"

    1. 1. Sparked goes SharePoint 2010 for developers<br />
    2. 2. Who are we?<br />2<br /><ul><li> Roel Hans Bethelehem
    3. 3. SharePoint Solution Architect
    4. 4. Work experience: WUR, Sara Lee, Flora Holland
    5. 5. @rbethleh
    6. 6. E-Mail: roelhans.bethlehem@sparked.nl
    7. 7. Alexander Meijers
    8. 8. SharePoint Solution Architect
    9. 9. Work experience: Facilicom, Logica Intranet
    10. 10. Twitter: @ameijers
    11. 11. E-Mail: alexander.meijers@sparked.nl</li></li></ul><li>SharePoint 2010 Developer Overview<br />
    12. 12. Challenges<br />4<br /><ul><li> What’s new?
    13. 13. UX Platform
    14. 14. The Ribbon
    15. 15. The Toolbar
    16. 16. Dialog Framework
    17. 17. Tools
    18. 18. Web Part Development</li></li></ul><li>What’s new?<br />5<br />
    19. 19. Microsoft SharePoint 2010<br /><ul><li> Improvements to UI and accessibility features
    20. 20. Better tools for developers and designers
    21. 21. End-to-end integration with PowerShell
    22. 22. Improvements to lists and events
    23. 23. New client-side object model and runtime
    24. 24. Enhanced support for developing workflow applications
    25. 25. Development can now be done on client OS
    26. 26. New connector framework enhances Search infrastructure
    27. 27. User solutions and partially trusted code (sandboxing)</li></ul>What’s new?<br />
    28. 28. UX Platform<br />7<br />
    29. 29. Changes to the UX Platform<br />8<br /><ul><li> General platform improvements
    30. 30. Masterpages (dynamic) + _layouts
    31. 31. The Ribbon
    32. 32. Status Bar/Notification Area
    33. 33. Dialog Framework
    34. 34. New Theming Infrastructure
    35. 35. Silverlight Web Part
    36. 36. Client OM</li></ul>UX Platform<br />Philosophy: Allow users to complete tasks quickly in context with a simple interface and reusable controls<br />
    37. 37. Key Platform Investments<br />9<br /><ul><li> Standards and Refactoring
    38. 38. Targeting WCAG 2.0 AA standards
    39. 39. Reduced use of tables
    40. 40. Cross-browser support: IE 7+, Firefox, Safari
    41. 41. Visual upgrade
    42. 42. UI upgrade separated from database upgrade (can keep V12 UI while running on V14)
    43. 43. Enhanced vs2010 project templates
    44. 44. Client OM
    45. 45. JavaScript and Silverlight wrappers for SharePoint OM</li></ul>UX Platform<br />
    46. 46. Refactoring<br />10<br /><ul><li> CSS
    47. 47. Split into multiple files, only download what’s necessary for the page
    48. 48. Existing sites based on SharePoint CSS will need to be redesigned
    49. 49. JavaScript
    50. 50. Script On Demand allows delaying JavaScript download until it’s needed
    51. 51. Debug versions of files show clear JavaScript before optimizing
    52. 52. SP.* “namespace” an effort to draw a line between “public” and “internal” JavaScript</li></ul>UX Platform<br />
    53. 53. Masterpages + _layouts<br />11<br /><ul><li> Application pages (_layouts) use a dynamic masterpage based on what site they’re accessed from
    54. 54. Can use “~masterurl/default.master” or “~masterurl/custom.master” tokens to reference System or Site masterpage
    55. 55. Page must derive from Microsoft.SharePoint.WebControls.LayoutsPageBase
    56. 56. Exceptions: Pages which reference simple.master
    57. 57. accessdenied, confirmation, error, login, reqacc, signout, webdeleted
    58. 58. These seven pages can be replaced using OM or PowerShell</li></ul>UX Platform<br />
    59. 59. Silverlight Web Part & Client OM<br />12<br /><ul><li> Allows users to quickly add Silverlight apps to SharePoint
    60. 60. Client OM allows Silverlight or JavaScript to access SharePoint data
    61. 61. Fluid Application Model
    62. 62. App can be hosted outside of SharePoint
    63. 63. Still access SharePoint data if given permission</li></ul>UX Platform<br />
    64. 64. The Ribbon<br />13<br />
    65. 65. Design<br />14<br /><ul><li> Fixed position at top of page – doesn’t scroll out of view
    66. 66. Contextual tab model
    67. 67. Controls: near parity with Client Ribbon
    68. 68. Super tool tips</li></ul>The Ribbon<br />
    69. 69. Controls<br />Out of the Box<br />Not in the Box, but…<br /><ul><li> Button
    70. 70. Split button menu
    71. 71. Static
    72. 72. Stated
    73. 73. Drop down & Flyout menus
    74. 74. Customizable
    75. 75. Hierarchical
    76. 76. Checkbox
    77. 77. ToggleButton
    78. 78. Label
    79. 79. Textbox
    80. 80. Combo box
    81. 81. Spinner
    82. 82. Table control
    83. 83. Color picker
    84. 84. In-Ribbon gallery control
    85. 85. Drop down grids can give same functionality
    86. 86. Can also “fake” it with buttons in the Ribbon</li></ul>15<br />The Ribbon<br />
    87. 87. Extensibility<br />16<br /><ul><li>Fully extensible
    88. 88. Remove any of the OOB controls
    89. 89. Add new controls anywhere in the Ribbon
    90. 90. Potential to replace the Ribbon entirely
    91. 91. Backwards compatible
    92. 92. Custom Actions added to Toolbars in v3 will automatically show up in the “Custom Commands” tab in the Ribbon
    93. 93. Adding a control to the Ribbon:
    94. 94. Ribbon XML defines the UI of the control
    95. 95. Simple behavior can be defined declaratively alongside Ribbon XML, more complicated behavior requires a JavaScript Page Component</li></ul>The Ribbon<br />
