CACHING FOR CASH -
   BENCHMARKING
Scott MacVicar + Helgi Þormar Þorbjörnsson
             php|works 2008
GOALS



Learn how to find slow pages

Locate slow blocks of code

Apply minor optimisations
THOUGHT STEPS



Things seem a bit slow

Take a guess whats slow

Browse lots of code
SYSTEM COMPONENTS


Appliation Server

Database Server

Application

Database

Network
PAGE BENCHMARKING



Single Request doesn’t matter

Average time for maximum amount of users

Hopefully at worst it scales...
REQUIREMENTS


Same hardware configuration

Same server configuration

Same network interface speed (100mbps)

Basically you...
STEPS TO BENCHMARK



Record server load

Run our tests at least 3 times

Take average of tests
BENCHMARKING TOOLS



Apache Bench

Apache Flood

Siege
APACHE BENCH


Shows requests per
second

Bundled with Apache

Gives relative idea of
load
APACHE BENCH - DEMO

1000 Requests with 5 at a time
ab -n 1000 -c 5 http://localhost/phpBB3/index.php

1000 requests with ...
ISSUES WITH APACHE BENCH



Synthetic Benchmark

No way to emulate users
APACHE FLOOD



Profile driven
benchmarking

XML Based config

Use variables on pages
XML FORMAT


URLLIST

FARM

FARMER

PROFILE
URLIST



Simple group of URLs

Supports postdelay and predelay
FARMER


Single User

Can use URLLIST in various ways

  Random Order

  Round Robin

  Keep-Alive
FARM



It’s where the farmers work

Controls the way the farmers work

Creates farmers too
PROFILE


Runtime configuration

Can change various settings

  socket

  report
USE CASES



User visits main page

User visits main page then download page

User visits main page then download and down...
SINGLE PAGE


                Keep Alive
 Page   Image                Image
SINGLE PAGE XML
TWO PAGE VISITS


                       Keep Alive
   Page        Image                Image

     30 secs
      later

 ...
TWO PAGE VISITS XML
TWO PAGE VISITS AND
   DOWNOAD
                         Keep Alive
     Page        Image                Image

       30 ...
TWO PAGE VISIT AND
 DOWNOAD XML
SETUP A PROFILE



enable keepalive

use the relative times output format

check for 200 OK
PROFILE XML
JOE THE FARMER
FARM FOR JOE TO WORK ON
RUNNING FLOOD



flood <configuration.xml> > output.file

anaylze-relative output.file
VMWARE INSTALL


                                                         Run
     Run VMware-                            ...
TASK
• Visit http://localhost/phpBB3/
• View a forum after 20 seconds
• View a thread after 5 seconds
• Click reply after ...
SIEGE



Provides functionality of Apache Bench and Flood

Supports GET and POST with a simple syntax

Benchmark and Inter...
SIEGE COMMANDS

1000 Requests with 5 at a time
siege -b -r 1000 -c 5 http://localhost/phpBB3/index.php

10 seconds with co...
SPROXY


Creates local socks proxy on your machine

Set your browser to use the local proxy, port 9001

Browse your site w...
OTHER BENCHMARKING
         TOOLS


JMeter

httperf

Web Application Stress Tool

OpenWebLoad
PROFILING
WHAT IS PROFILING


Examines the performance characteristics

Records every function call

Tracks execution time

Tracks m...
PROFILING TOOLS



XDebug

apd
XDEBUG



Debugger

Code Coverage

Memory and Executon time
XDEBUG PROTECTIONS



Stack overflow in PHP

Infinite Recursion
ERROR MESSAGE HELPING
XDEBUG HELPFUL ERROR
     MESSAGES
MORE ERROR MESSAGE
     HELPING
EXECUTION TIME
MEMORY USAGE
EXECUTION TRACE


xdebug.auto_trace=1

xdebug.trace_output_dir=/tmp

xdebug.collect_params=1

xdebug.collect_return=1

xde...
EXECUTION TRACE
PARTIAL EXECUTION TRACE

Tracing only parts of an application with
xdebug_start_trace() and xdebug_stop_trace().

Fetching...
CODE COVERAGE


Finds unexecuted code

xdebug_start_code_coverage()

xdebug_get_code_coverage()

xdebug_stop_code_coverage...
CODE COVERAGE SAMPLE
CODE COVERAGE OUTPUT
PROFILING


Execute action as normal in browser

Outputs cachegrind file

INI settings:
xdebug.profiler_enable=1 ; enable pr...
PROFILING CONTINUED


Locate parts of the code that is slow

Work down tree to find the slow sections

Can it be cached? Ca...
VIEWING PROFILE


KCacheGrind

MacCallGrind

WinCacheGrind

Carica CacheGrind
PROFILING DEMO
TASK

sudo nano -w /etc/php.d/xdebug.ini
remove ; from xdebug.profiler_enabled=1

Profile a page on Wordpress

Profile a page...
APD


Lives in PECL

Similar to XDebug

Doesn’t require KCachegrind

Still only PHP 4
APD



apd_set_pprof_trace() to enable profiler

pprof is a script to interpret the trace

Outputs to apd.dumpdir
BRINGING IT TOGETHER



Use profiler with benchmarks

Profiling can be run on production sites

Optimise slow code
RESOURCES


Lunch - back at 1pm for Caching

http://talks.macvicar.net/

http://httpd.apache.org/test/flood/

http://xdebug...
