2 December 2005
Introduction to Databases
Object and Object-Relational Databases
Prof. Beat Signer
Department of Computer ...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 2May 16, 2014
Impedance Mismatch Revisited
 Combination ...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 3May 16, 2014
Impedance Mismatch Revisited ...
 Note tha...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 4May 16, 2014
Object Databases
 ODBMSs use the same data...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 5May 16, 2014
Persistent Programming Languages
 Several ...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 6May 16, 2014
Persistent Programming Languages ...
 pers...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 7May 16, 2014
ObjectStore Example
 Persistence by reacha...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 8May 16, 2014
ObjectStore Example ...
 Post processing
(...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 9May 16, 2014
ODBMS History
 First generation ODBMS
 19...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 10May 16, 2014
ODBMS History ...
 Second generation ODBM...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 11May 16, 2014
ODBMS History ...
 Further developments
...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 12May 16, 2014
The Object-Oriented Database Manifesto
 M...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 13May 16, 2014
The Object-Oriented Database Manifesto ......
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 14May 16, 2014
The Object-Oriented Database Manifesto ......
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 15May 16, 2014
The Object-Oriented Database Manifesto ......
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 16May 16, 2014
The Object-Oriented Database Manifesto ......
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 17May 16, 2014
Object Data Management Group (ODMG)
 Obje...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 18May 16, 2014
ODMG Object Model
 ODMG object model is b...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 19May 16, 2014
Types
 Specification
 properties (attrib...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 20May 16, 2014
Type Specifications
 Interface defines on...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 21May 16, 2014
Objects
 Atomic objects
 user defined
 ...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 22May 16, 2014
Literal Types
 Atomic literals
 long, lo...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 23May 16, 2014
Relationship Example
 One-to-one, one-to-...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 24May 16, 2014
Behaviour
 Behaviour is specified as a se...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 25May 16, 2014
Inheritance of Behaviour
 A subtype may
...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 26May 16, 2014
Inheritance of State and Behaviour
 Keywo...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 27May 16, 2014
Object Definition Language (ODL) Example
A...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 28May 16, 2014
ODL Example ...
module Education {
excepti...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 29May 16, 2014
ODL Example ...
class Session (extent sess...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 30May 16, 2014
ODL Example ...
interface StudentI {
attri...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 31May 16, 2014
ODL Example ...
class Professor extends Em...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 32May 16, 2014
Object Databases
 Many ODBMS also impleme...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 33May 16, 2014
Object-Relational Mapping (ORM)
 "Automat...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 34May 16, 2014
Object-Relational Databases
 The object-r...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 35May 16, 2014
Object-Relational Databases ...
 Since SQ...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 36May 16, 2014
Object vs. Object-Relational Databases
 O...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 37May 16, 2014
Homework
 Study the following chapters of...
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 38May 16, 2014
Exercise 11
 Transaction Management
Beat Signer - Department of Computer Science - bsigner@vub.ac.be 39May 16, 2014
References
 A. Silberschatz, H. Korth and...
2 December 2005
Next Lecture
Future Trends and Review
Upcoming SlideShare
Loading in...5
×

Object and Object-Relational Databases - Lecture 12 - Introduction to Databases (1007156ANR)

10,296
-1

Published on

This lecture is part of an Introduction to Databases course given at the Vrije Universiteit Brussel.

Published in: Education, Technology
0 Comments
7 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
10,296
On Slideshare
0
From Embeds
0
Number of Embeds
2
Actions
Shares
0
Downloads
539
Comments
0
Likes
7
Embeds 0
No embeds

No notes for slide

Object and Object-Relational Databases - Lecture 12 - Introduction to Databases (1007156ANR)

  1. 1. 2 December 2005 Introduction to Databases Object and Object-Relational Databases Prof. Beat Signer Department of Computer Science Vrije Universiteit Brussel http://www.beatsigner.com
  2. 2. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 2May 16, 2014 Impedance Mismatch Revisited  Combination of SQL with a host language  mix of declarative and procedural programming paradigms  two completely different data models  different set of data types  Interfacing with SQL is not straightforward  data has to be converted between host language and SQL due to the impedance mismatch  ~30% of the code and effort is used for this conversion!  The problem gets even worse if we would like to use an object-oriented host language  two approaches to deal with the problem - object databases (object-oriented databases) - object-relational databases
  3. 3. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 3May 16, 2014 Impedance Mismatch Revisited ...  Note that it would be easier to use the SQL AVG operator public float getAverageCDLength() { float result = 0.0; try { Connection conn = this.openConnection(); Statement s = conn.createStatement(); ResultSet set = s.executeQuery("SELECT length FROM CD"); int i = 0; while (set.next()) { result += set.getInt(1); i++; } return result/i; } catch (SQLException e) { System.out.println("Calculation of average length failed."); return 0; } }
  4. 4. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 4May 16, 2014 Object Databases  ODBMSs use the same data model as object-oriented programming languages  no object-relational impedance mismatch (due to uniform model)  An object database combines the features of an object- oriented language and a DBMS (language binding)  treat data as objects - object identity - attributes and methods - relationships between objects  extensible type hierarchy - inheritance, overloading and overriding as well as customised types  declarative query language
  5. 5. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 5May 16, 2014 Persistent Programming Languages  Several approaches have been proposed to make transient programming language objects persistent  persistence by class - declare that a class is persistent - all objects of a persistent class are persistent whereas objects of non-persistent classes are transient - not very flexible; we would like to have persistent and transient objects from a single class - many ODBMSs provide a mechanism to make classes persistence capable  persistence by creation - introduce new syntax to create persistent objects - object is either persistent or transient depending on how it was created  persistence by marking - mark objects as persistent after creation but before the program terminates
  6. 6. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 6May 16, 2014 Persistent Programming Languages ...  persistence by reachability - one or more objects are explicitly declared as persistent objects (root objects) - all the other objects are persistent if they are reachable from a root object via a sequence of one or more references - easy to make entire data structures persistent
  7. 7. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 7May 16, 2014 ObjectStore Example  Persistence by reachability via specific database roots  Persistence capable classes  post-processor makes specific classes persistent capable  Persistent aware classes  can access and manipulate persistent objects (not persistent)  Three states after a persistent object has been loaded  hollow: proxy with load on demand (lazy loading)  active: loaded in memory and flag set to clean  stale: no longer valid (e.g. after a commit) Person ariane = new Person("Ariane Peeters") db.createRoot("Persons", ariane);
  8. 8. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 8May 16, 2014 ObjectStore Example ...  Post processing (1) compile all source files (2) post-process the class files to generate annotated versions of the class files (3) run the post-processed main class javac *.java osjcfp –dest . –inplace *.class java mainClass
  9. 9. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 9May 16, 2014 ODBMS History  First generation ODBMS  1984 - George P. Copeland and David Maier, Making Smalltalk a Database System, SIGMOD 1984  1986 - G-Base (Graphael, F)  1987 - GemStone (Servio Corporation, USA)  1988 - Vbase (Ontologic) - Statice (Symbolics) David MaierGeorge P. Copeland
  10. 10. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 10May 16, 2014 ODBMS History ...  Second generation ODBMS  1989 - Ontos (Ontos) - ObjectStore (Object Design) - Objectivity (Objectivity) - Versant ODBMS (Versant Object Technology)  1989 - The Object-Oriented Database System Manifesto  Third generation ODBMS  1990 - Orion/Itasca (Microelectronis and Computer Technology Cooperation, USA) - O2 (Altaïr, F) - Zeitgeist (Texas Instruments)
  11. 11. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 11May 16, 2014 ODBMS History ...  Further developments  1991 - foundation of the Object Database Management Group (ODMG)  1993 - ODMG 1.0 standard  1996 - PJama (Persistent Java)  1997 - ODMG 2.0 standard  1999 - ODMG 3.0 standard  2001 - db4o (database for objects)  ...
  12. 12. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 12May 16, 2014 The Object-Oriented Database Manifesto  Malcolm Atkinson, François Bancilhon, David DeWitt, Klaus Dittrich, David Maier and Stanley Zdonik, The Object-Oriented Database System Manifesto, 1989 Malcolm Atkinson François Bancilhon David DeWitt Klaus Dittrich David Maier Stanley Zdonik
  13. 13. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 13May 16, 2014 The Object-Oriented Database Manifesto ...  The Object-Oriented Database System Manifesto by Atkinson et al. was an attemp to define object-oriented databases  defines 13 mandatory features that an object-oriented database system must have - 8 object-oriented system features - 5 DBMS features  optional features - multiple inheritance, type checking, versions, ...  open features - points where the designer can make a number of choices
  14. 14. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 14May 16, 2014 The Object-Oriented Database Manifesto ...  Object-oriented system features  complex objects - complex objects built from simple ones by constructors (e.g. set, tuple and list) - constructors must be orthogonal  object identity - two objects can be identical (same object) or equal (same value)  encapsulation - distinction between interface (public) and implementation (private)  types and classes - type defines common features of a set of objects - class as a container for objects of the same type  type and class hierarchies  overriding, overloading and late binding
  15. 15. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 15May 16, 2014 The Object-Oriented Database Manifesto ...  computational completeness - should be possible to express any computable function using the DML  extensibility - set of predefined types - no difference in usage of system and user-defined types  DBMS features  persistence - orthogonal persistence (persistence capability does not depend on the type)  secondary storage management - index management, data clustering, data buffering, access path selection and query optimisation  concurrency - atomicity, consistency, isolation and durability (ACID) - serialisability of operations
  16. 16. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 16May 16, 2014 The Object-Oriented Database Manifesto ...  recovery - in case of hardware or software failures, the system should recover  ad hoc query facility - high-level declarative query language  The OODBMS Manifesto lead to discussion and reactions from the RDBMS community  Third-Generation Database System Manifesto, Stonebraker et al.  The Third Manifesto, Darwen and Date  Issues not addressed in the manifesto  database evolution  constraints  object roles  ...
  17. 17. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 17May 16, 2014 Object Data Management Group (ODMG)  Object Database Management Group (ODMG) was founded in 1991 by Rick Cattel  standardisation body including all major ODBMS vendors  Defines a standard to increase the porta- bility accross different ODBMS products  Object Model  Object Definition Language (ODL)  Object Query Language (OQL)  language bindings - C++, Smalltalk and Java bindings Rick Cattell
  18. 18. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 18May 16, 2014 ODMG Object Model  ODMG object model is based on the OMG object model  Basic modelling primitives  object: unique identifier  literal: no identifier  An object's state is defined by the values it carries for a set of properties (attributes or relationships)  An object's behaviour is defined by the set of operations that can be executed  Objects and literals are categorised by their type (common properties and common behaviour)
  19. 19. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 19May 16, 2014 Types  Specification  properties (attributes and relationships)  operations  exceptions  Implementation  language binding  a specification can have more than one implementation
  20. 20. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 20May 16, 2014 Type Specifications  Interface defines only abstract behaviour  attribute declarations in an interface define only abstract behaviour (can be implemented as a method!)  Class defines abstract behaviour and abstract state  Literal defines abstract state
  21. 21. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 21May 16, 2014 Objects  Atomic objects  user defined  no built-in atomic object types  Collection objects  Set<t>  Bag<t>  List<t>  Array<t>  Dictionary<t,v>  Structured objects  Date, Interval, Time, Timestamp
  22. 22. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 22May 16, 2014 Literal Types  Atomic literals  long, long long, short, unsigned long, unsigned short, float, double, boolean, octet, char, string, enum  Collection literals  set<t>  bag<t>  list<t>  array<t>  dictionary<t,v>  Structured literals  date, interval, time, timestamp  user defined structures (struct)
  23. 23. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 23May 16, 2014 Relationship Example  One-to-one, one-to-many or many-to-many relationships with referential integrity maintained by the system class Assistant { ... relationship set<ExerciseGroup> leads inverse ExerciseGroup::isLeadBy; ... } class ExerciseGroup { ... relationship Assistant isLeadBy inverse Assistant::leads; ... }
  24. 24. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 24May 16, 2014 Behaviour  Behaviour is specified as a set of operation signatures  An operation signature defines  name of the operation  names and types of arguments  type of return value  names of exceptions
  25. 25. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 25May 16, 2014 Inheritance of Behaviour  A subtype may  define new behaviour in addition to the one defined in its supertypes  refine a supertype's behaviour interface Contact {...} interface Person : Contact {...} interface ETHPerson : Person {...}
  26. 26. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 26May 16, 2014 Inheritance of State and Behaviour  Keyword EXTENDS  A subclass inherits all the properties and behaviour of its superclass interface Contact {...} interface Student {...} class Person : Contact {...} class ETHPerson extends Person : Student {...}
  27. 27. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 27May 16, 2014 Object Definition Language (ODL) Example Assistant Professor Employee Salary Lecture Exercise Session Course StudentI Student teaches isTaughtBy leads isLeadBy hasPrerequisites isPrerequisiteFor attends isAttendedBy hasSessions isSessionOf one-to-one many-to-many one-to-many is-a extends
  28. 28. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 28May 16, 2014 ODL Example ... module Education { exception SessionFull{}; ... class Course (extent courses) { attribute name; relationship Department offeredBy inverse Department::offers; relationship list<Session> hasSessions inverse Session::isSessionOf; relationship set<Course> hasPrerequisites inverse Course::isPrerequisiteFor; relationship set<Course> isPrerequisiteFor inverese Course::hasPrerequisites; }; class Salary (extent salaries) { attribute float base; attribute float bonus; }; ... }
  29. 29. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 29May 16, 2014 ODL Example ... class Session (extent sessions) { attribute string number; relationship Course isSessionOf inverse Course::hasSessions; relationship set<Student> isAttendedBy inverse Student::attends; }; class Lecture extends Session (extent lectures) { relationship Professor isTaughtBy inverse Professor::teaches; }; class Exercise extends Session (extent exercises) { attribute unsigned short maxMembers; relationship Assistant isLeadBy inverse Assistant::leads; };
  30. 30. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 30May 16, 2014 ODL Example ... interface StudentI { attribute string name; attribute Address address; relationship set<Session> attends inverse Session::isAttendeBy; }; class Student : StudentI (extent students) { attribute Address address; relationship set<Session> attends inverse Session::isAttendedBy; }; class Employee (extent employees) { attribute string name attribute Salary salary; void hire(); void fire() raises (NoSuchEmployee); };
  31. 31. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 31May 16, 2014 ODL Example ... class Professor extends Employee (extent professors) { attribute enum Type{assistant, full, ordinary} rank; relationship worksFor inverse Department:hasProfessors; relationship set<Lectures> teaches inverse Session::isTaughtBy; }; class Assistant extends Employee : StudentI (extent assistants) { attribute Address address; relationship Exercise leads inverse Exercise::isLeadBy relationship set<Session> attends inverse Session::isAttendedBy; };
  32. 32. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 32May 16, 2014 Object Databases  Many ODBMS also implement a versioning mechanism  Many operations are performed by using a navigational rather than a declarative interface  following pointers  In addition, an object query language (OQL) can be used to retrieve objects in a declarative way  some systems (e.g. db4o) also support native queries  Faster access than RDBMS for many tasks  no join operations required  However, object databases lack a formal mathematical foundation!
  33. 33. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 33May 16, 2014 Object-Relational Mapping (ORM)  "Automatic" mapping of object-oriented model to relational database  developer has to deal less with persistence-related programming  Hibernate  mapping of Java types to SQL types  generates the required SQL statements behind the scene  standalone framework  Java Persistence API (JPA)  Enterprise Java Beans Standard 3.0  use annotations to define mapping  javax.persistence package
  34. 34. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 34May 16, 2014 Object-Relational Databases  The object-relational data model extends the relational data model  introduces complex data types  object-oriented features  extended version of SQL to deal with the richer type system  Complex data types  new collection types including multisets and arrays  attributes can no longer just contain atomic values (1NF) but also collections  nest and unnest operations for collection type attributes  ER concepts such as composite attributes or multivalued attributes can be directly represented in the object-relational data model
  35. 35. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 35May 16, 2014 Object-Relational Databases ...  Since SQL:1999 we can define user-defined types  Type inheritance can be used for inheriting attributes of user-defined types
  36. 36. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 36May 16, 2014 Object vs. Object-Relational Databases  Object databases  complex datatypes  tight integration with an object-oriented programming language (persistent programming language)  high performance  Object-relational databases  complex datatypes  powerful query languages  good protection of data from programming errors
  37. 37. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 37May 16, 2014 Homework  Study the following chapters of the Database System Concepts book  chapter 22 - sections 22.1-22.11 - Object-based Databases
  38. 38. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 38May 16, 2014 Exercise 11  Transaction Management
  39. 39. Beat Signer - Department of Computer Science - bsigner@vub.ac.be 39May 16, 2014 References  A. Silberschatz, H. Korth and S. Sudarshan, Database System Concepts (Sixth Edition), McGraw-Hill, 2010  Malcolm Atkinson, François Bancilhon, David DeWitt, Klaus Dittrich, David Maier and Stanley Zdonik, The Object-Oriented Database System Manifesto, 1989
  40. 40. 2 December 2005 Next Lecture Future Trends and Review
