Separation of Concerns
Separation of concerns About Joshua  Joshua Thijssen, NoxLogic / Techademy  Freelance Consultant, Developer, Trainer  D...
Separation of concerns About Stephan  Stephan Hochdörfer, bitExpert AG  Department Manager Research Labs  enjoying PHP ...
Separation of concerns It is what I sometimes have called the separation of concerns, which [...] is   yet the only availa...
Separation of concerns   SoC […] is the process of breaking a     computer program into distinct   features that overlap i...
Separation of concerns It`s all about focusing!
Separation of concerns One step a time. Focus on the details!
Separation of concerns<?php$items = array();$token = file_get_contents("https://graph.facebook.com/oauth/access_token?..."...
Separation of concerns<?php                                                    Controller part!$items = array();$token = f...
Separation of concerns<?php$items = array();$token = file_get_contents("https://graph.facebook.com/oauth/access_token?..."...
Separation of concerns Very unstable. Not safe for changes....
Separation of concerns „Make everything as simple as possible...“
Separation of concerns Establish boundaries
Separation of concerns What are the boundaries?                   Presentation Layer
Separation of concerns What are the boundaries?                   Presentation Layer                         Business Layer
Separation of concerns What are the boundaries?                   Presentation Layer                         Business Laye...
Separation of concerns Isolate functionality, break it apart!
Separation of concerns<?phpnamespace AcmeDemoBundleController;use SymfonyBundleFrameworkBundleControllerController;use Sen...
Separation of concerns    $feed = file_get_contents("http://search.twitter.com/search.json?...");    $feed = json_decode($...
Separation of concerns Focus on one responsibility a time!
Separation of concerns<?phpnamespace AcmeDemoBundleController;use SymfonyBundleFrameworkBundleControllerController;use Sen...
Separation of concerns                                                 Twitter connector    $feed = file_get_contents("htt...
Separation of concerns Interfaces as a contract
Separation of concerns<?phpinterface ConnectorInterface {  /**   * Will return an array of the latest posts.   * return ar...
Separation of concerns<?phpclass FacebookConnector implements ConnectorInterface {  protected $handle;    public function ...
Separation of concerns<?phpclass FacebookConnector implements ConnectorInterface {  protected $handle;    public function ...
Separation of concerns<?phpclass FacebookConnectorV2 extends FacebookConnector {    protected function getAccessToken() { ...
Separation of concerns<?phpnamespace AcmeDemoBundleController;use SymfonyBundleFrameworkBundleControllerController;use Sen...
Separation of concerns<?phpnamespace AcmeDemoBundleController;use SymfonyBundleFrameworkBundleControllerController;use Sen...
Separation of concerns Will improve the testability!
Separation of concerns Will reduce tight coupling!
Separation of concerns Will increase component reuse!
Separation of concerns The value of separation                Why should I do it?
Separation of concerns The value of separation      1. Getting rid of code duplication
Separation of concerns The value of separation   2. Application becomes more stable        and easier to understand
Separation of concerns The value of separation    3. Single responsibility offers clear              extension points
Separation of concerns The value of separation        4. Increases the reusability of                 components
Separation of concerns How to separate the concerns?
Separation of concerns How to separate? Horizontal Separation                   Presentation Layer                        ...
Separation of concerns How to separate? Horizontal Separation ./symfony    |-app    |---cache    |---config    |---Resourc...
Separation of concerns How to separate? Service Separation                 Service Interface Layer                        ...
Separation of concerns How to separate? Service Separation                Frontend / UI Webservers            REST API    ...
Separation of concerns How to separate? Vertical Separation        Module A         Module B   Module C
Separation of concerns How to separate? Vertical Separation ./symfony    |-app    |---cache    |---config    |---Resources...
Separation of concerns How to separate? Vertical Separation       Presentation      Presentation   Presentation          L...
Separation of concerns How to separate? Vertical Separation ./symfony    |-app    |---cache    |---config    |---Resources...
Separation of concerns Cross-cutting concerns?     How to deal with security or logging                  aspects?
Separation of concerns How to separate? Aspect Separation Aspects                         Presentation Layer              ...
Separation of concerns How to separate? Aspect Separation <?php namespace AcmeProductsAspects; /**  * @FLOW3Aspect  */ cla...
Separation of concerns Dependency Direction
Separation of concerns Dependency Direction        "High-level modules should not         depend on low-level modules.    ...
Separation of concerns Inverting Concerns       Presentation          Layer        Business         Layer        Resource ...
Separation of concerns Inverting Concerns       Presentation      UI     Presentation          Layer       Component    La...
Separation of concerns Inverting Concerns      The goal of Dependency Injection        is to separate the concerns of     ...
Separation of concerns What are the benefits? Let`s recap....
Separation of concerns What are the benefits?             1. Facilitate reusability
Separation of concerns What are the benefits?        2. Ensure the maintainability
Separation of concerns What are the benefits?        3. Increasing the code quality
Separation of concerns What are the benefits?   4. Enables everyone to understand             the application
Separation of concerns What are the benefits?        5. Allows developers to work         on components in isolation
Thank you!
http://joind.in/6244
