Blue Ruby
A Ruby VM for the ABAP Web Application Server




Anne Hardy
Juergen Schmerder
Murray Spork
Daniel Vocke

SDN Me...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Blue Ruby – Who?



  SAP Research Americas and China

   Platform Research
                   Anne Hardy


    Blue Ruby
...
Blue Ruby – What?
  Combine the best of both worlds

  ABAP Application Server                              Ruby

      Kn...
Blue Ruby – Why?


  Why a dynamic language?                               Why inside the ABAP VM?

      Agile developmen...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Programming Models Evolve
Faster Than Platforms

Timeless Software (Vishal Sikka)[1]
      Best of both worlds: the flexib...
A New Programming Model for Light-Weight
Application Extension Scenarios

 Light-weight extensions: e.g. situational and d...
Lazy developers want an embedded
scripting environment

Runtime benefits:
     Locality: extension logic runs in the backe...
Why Ruby?


Could have chosen any scripting language - but:
      Ruby is fun
      Ruby is cool
      Support for DSLs
  ...
Potential Use Cases


Scenarios we have already experimented with:
    Composing and adapting RFCs, BAPIs, Enterprise Serv...
Vision: A Different Type of Developer
(to what SAP usually caters for)

 Can Blue Ruby open up the ABAP stack to non-ABAP ...
Platform-as-a-Service on the inside


                   INSIDE THE ENTERPRISE                      OUTSIDE THE ENTERPRISE...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Blue Ruby Architecture




© SAP 2008 / Page 15
From Ruby to ABAP




© SAP 2008 / Page 16
Blue Ruby Virtual Machine




© SAP 2008 / Page 17
Blue Ruby
  Building Blocks

   Blue Ruby Compiler
  Towards a self-hosting Ruby environment

   Blue Ruby Runtime
  Exten...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Implementation Status – the good news


  Completeness                                         Performance
               ...
Implementation Status – the bad news


  Completeness                                      Performance
                   ...
Existing Blue Ruby demo applications


       Rails Application                  Atom/RSS Reader




       Coghead Applic...
Next steps – SDN Collaboration


         Trial system available outside SAP firewall
              Terms: NDA / trial agr...
Agenda




  1.     Blue Ruby – Who, What and Why
  2.     Use Cases for Blue Ruby
  3.     Technical Overview of Blue Rub...
Thank you!




© SAP 2008 / Page 26
Grid




© SAP 2008 / Page 27
Definition and halftone values of colors


         SAP Blue         SAP Gold        SAP Light Gray           SAP Gray    ...
Copyright 2008 SAP AG
  All rights reserved

  No part of this publication may be reproduced or transmitted in any form or...
