PL/SQL Unit Testing
   Can Be Fun!
     with a little help
        from Ruby
Raimonds Simanovskis

github.com/
    rsim
What is good
  code?
                   Test
  Correct
               functionality!
                   Test
Fast enough
 ...
How is it done?
        try something...

    dbms_output.put_line(...)

 it is obvious that there are no bugs


testers s...
What are typical
       problems?
        Trying and not testing

       Tests are not repeatable

     Manual verificatio...
Types of tests
         unit tests

      integration tests
                                programmer’s
performance & int...
Test Driven Development
Good unit tests
           Automatic, run fast

Wide code coverage including edge cases

              Repeatable

   Inde...
How to do it when
 programming in
    PL/SQL?
created by Steven Feuerstein, 1999

based on “xUnit”-style frameworks

    not maintained anymore :(
Example
    substring from start until end position
CREATE OR REPLACE FUNCTION betwnstr (
   string_in   IN   VARCHAR2,
  ...
Tests
CREATE OR REPLACE PACKAGE ut_betwnstr AS   CREATE OR REPLACE PACKAGE BODY ut_betwnstr AS

  PROCEDURE ut_setup;     ...
Results
                 exec utplsql.test('betwnstr', recompile_in => FALSE);
.
>        SSSS      U         U     CCC   ...
Visual testing tools
Quest Code Tester   SQL Developer 2.1
Why used just by few?
 Too large / too verbose test code?

   Hard to read, too much noise?

    Hard to test complex case...
ruby-plsql-spec
                ideal language
                for writing tests

             powerful testing tools
 RSp...
Demo
ruby-plsql gem
plsql.connect! "hr","hr","xe"

plsql.test_uppercase('xxx')              # => "XXX"
plsql.test_uppercase(:p_...
Benefits
      Compact, readable syntax

Powerful features also for complex tests

 Best practices from Ruby community

  ...
More information
 http://blog.rayapps.com/2009/11/27/oracle-plsql-
                unit-testing-with-ruby/

http://blog.ra...
JRuby meetup
      Tuesday, September 21

5:30 - 7:00 Networking + beer + food
7:00 - 8:00 Lightning talks


         @ En...
Upcoming SlideShare
Loading in...5
×

PL/SQL Unit Testing Can Be Fun!

13,471

Published on

Published in: Technology
0 Comments
5 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
13,471
On Slideshare
0
From Embeds
0
Number of Embeds
8
Actions
Shares
0
Downloads
94
Comments
0
Likes
5
Embeds 0
No embeds

No notes for slide

PL/SQL Unit Testing Can Be Fun!

  1. 1. PL/SQL Unit Testing Can Be Fun! with a little help from Ruby
  2. 2. Raimonds Simanovskis github.com/ rsim
  3. 3. What is good code? Test Correct functionality! Test Fast enough performance! Test after Maintainable changes!
  4. 4. How is it done? try something... dbms_output.put_line(...) it is obvious that there are no bugs testers should test, that’s their job
  5. 5. What are typical problems? Trying and not testing Tests are not repeatable Manual verification of results Testing is done too late in development
  6. 6. Types of tests unit tests integration tests programmer’s performance & integration responsibility tests exploratory & usability tests
  7. 7. Test Driven Development
  8. 8. Good unit tests Automatic, run fast Wide code coverage including edge cases Repeatable Independent from execution order Using real and understandable test data
  9. 9. How to do it when programming in PL/SQL?
  10. 10. created by Steven Feuerstein, 1999 based on “xUnit”-style frameworks not maintained anymore :(
  11. 11. Example substring from start until end position CREATE OR REPLACE FUNCTION betwnstr ( string_in IN VARCHAR2, start_in IN INTEGER, end_in IN INTEGER ) RETURN VARCHAR2 IS l_start PLS_INTEGER := start_in; BEGIN IF l_start = 0 THEN l_start := 1; END IF; RETURN (SUBSTR (string_in, l_start, end_in - l_start + 1)); END;
  12. 12. Tests CREATE OR REPLACE PACKAGE ut_betwnstr AS CREATE OR REPLACE PACKAGE BODY ut_betwnstr AS PROCEDURE ut_setup; PROCEDURE ut_setup AS PROCEDURE ut_teardown; BEGIN NULL; PROCEDURE ut_normal_usage; END ut_setup; PROCEDURE ut_first_index_null; PROCEDURE ut_teardown AS END ut_betwnstr; BEGIN NULL; END ut_teardown; PROCEDURE ut_normal_usage AS BEGIN utassert.eq('Normal usage', betwnstr('abcdefg', 2, 5), 'bcde'); END ut_normal_usage; PROCEDURE ut_first_index_null AS BEGIN utassert.isnull('First index is null', betwnstr('abcdefg', NULL, 5)); END ut_first_index_null; END ut_betwnstr;
  13. 13. Results exec utplsql.test('betwnstr', recompile_in => FALSE); . > SSSS U U CCC CCC EEEEEEE SSSS SSSS > S S U U C C C C E S S S S > S U U C C C C E S S > S U U C C E S S > SSSS U U C C EEEE SSSS SSSS > S U U C C E S S > S U U C C C C E S S > S S U U C C C C E S S S S > SSSS UUU CCC CCC EEEEEEE SSSS SSSS . SUCCESS: "betwnstr" . > Individual Test Case Results: > SUCCESS - betwnstr.UT_FIRST_INDEX_NULL: ISNULL "First index is null" Expected "" and got "" > SUCCESS - betwnstr.UT_NORMAL_USAGE: EQ "Normal usage" Expected "cde" and got "cde" > > > Errors recorded in utPLSQL Error Log: > > NONE FOUND
  14. 14. Visual testing tools Quest Code Tester SQL Developer 2.1
  15. 15. Why used just by few? Too large / too verbose test code? Hard to read, too much noise? Hard to test complex cases? No best practices how to write tests? Nobody is using, why should I use?
  16. 16. ruby-plsql-spec ideal language for writing tests powerful testing tools RSpec with “readable” syntax library for calling ruby-plsql PL/SQL procedures from Ruby
  17. 17. Demo
  18. 18. ruby-plsql gem plsql.connect! "hr","hr","xe" plsql.test_uppercase('xxx') # => "XXX" plsql.test_uppercase(:p_string => 'xxx') # => "XXX" plsql.test_copy("abc", nil, nil) # => { :p_to => "abc", # :p_to_double => "abcabc" } plsql.test_copy(:p_from => "abc", :p_to => nil, :p_to_double => nil) # => { :p_to => "abc", # :p_to_double => "abcabc" } plsql.hr.test_uppercase('xxx') # => "XXX" plsql.test_package.test_uppercase('xxx') # => 'XXX' plsql.hr.test_package.test_uppercase('xxx') # => 'XXX' plsql.logoff
  19. 19. Benefits Compact, readable syntax Powerful features also for complex tests Best practices from Ruby community Based on needs from real projects Open-source – “free as in beer” :)
  20. 20. More information http://blog.rayapps.com/2009/11/27/oracle-plsql- unit-testing-with-ruby/ http://blog.rayapps.com/2010/01/06/screencasts-of- oracle-plsql-unit-testing-with-ruby/ http://github.com/rsim/ruby-plsql-spec
  21. 21. JRuby meetup Tuesday, September 21 5:30 - 7:00 Networking + beer + food 7:00 - 8:00 Lightning talks @ Engine Yard 500 3rd Street, Suite 510
