Summarisation levels in sap copa

Summarisation Levels in COPA How to improve your COPA processing time and systemperformance using summarisation levels Verity Solutions Confidential

Summarisation Levels• Summarisation is an important feature in SAP COPA that can lead to leaner runtimes of reporting, planning and assessment transaction processing. This can lead to improved system performance.• SAP COPA is a powerful multi-dimensional reporting tool. Being multi-dimensional is also a disadvantage; multi- dimension leads to larger line item tables. Complex requirements within reporting, planning and assessment could lead to long runtimes.• To alleviate this problem, SAP delivers segment table/ level that summarises data from line item tables. Transaction processing in COPA, without summarisation, initially reads data from segment table/ level. This obviates the need to read or access line item table.• However segment table/ level is a SAP delivered summarised table. It contains all dimensions that are part of your Operating Concern. If your user wants to report on only one slice of the universe of data, processing time would be same as a report that requires a larger slice of the universe of data.• To further summarise selected data from segment table/ level, SAP users can define custom Summarisation Levels. These tables can be defined for the smaller slices of data that is required for the specific purpose (i.e. they can be built fit-to-purpose)• Transaction processing within COPA now, initially, reads data from summarisation tables. By building summarisation levels (in COPA) tailored for specific slices of data, you can significantly reduce those processing times and improve the performance of the system.• The following slides will explain the concept of summarisation, why it is important to SAP COPA, how summarisation levels are defined and built, and how they can be used in SAP Verity Solutions Confidential

This presentation can be read in conjunction with blogs published at www.veritysolutions.com.au Summarisation levels in SAP COPA #1 – an overview (2012/05/09) Summarisation levels in SAP COPA #2 – define your summarisation level (2012/05/16) Summarisation levels in SAP COPA #3 – build your summarisation level (2012/05/23) Summarisation levels in SAP COPA #4 – Tips to optimise your summarisation level (2012/05/30)RELATED BLOGS Verity Solutions Confidential

TECHNICAL ARCHITECTURE Verity Solutions Confidential

Table Architecture in SAP COPA Segment Data is summarised in real time Table/ Level CE3V000 and CE4V000 in segment tablesData is written at a detailed level in line item tables Line Item tables CE1V000 and CE2V000 For the purposes of illustration, only some COPA characteristics are shown in this presentation. For purposes of this presentation, Operating Concern is V000. Verity Solutions Confidential

Actual Line Item table (CE1V000) – an exampleDocument Company Period Customer Product Plant Revenue Profitability number code Segment100000001 V001 007.2011 99001 1451 V005 100 1100000002 V001 007.2011 99002 1451 V005 100 2100000003 V001 007.2011 99001 1431 V005 100 3100000004 V001 007.2011 99001 1431 V001 100 4100000005 V001 007.2011 99002 1451 V005 100 2100000006 V001 007.2011 99001 1431 V005 100 3 Verity Solutions Confidential

Segment Table CE4V000 and Segment Level CE3V000Company Customer Product Plant Profitability code Segment V001 99001 1451 V005 1 V001 99002 1451 V005 2 V001 99001 1431 V005 3 V001 99001 1431 V001 4 Each unique combination of characteristic value will generate a unique Profitability Profitability Period Revenue Segment. Segment 1 007.2011 100 2 007.2011 200 3 007.2011 200 4 007.2011 100 Verity Solutions Confidential

How is data written into COPA tables Search for Yes Update line itemData posted in Profitability PSG table CE1V000 and COPA Segment (PSG) in exists? segment level CE4V000 table CE3V000 No Update line item Create a new entry table CE1V000 and in segment table segment level CE4V000 table CE3V000 Verity Solutions Confidential

How is data read from COPA tables (without summarisation) Search for Yes Extract data fromReport executed in Profitability PSG CE3V000 for that COPA Segment (PSG) in exists? profitability CE4V000 segment > report No Extract data from Search for data in CE1xxxx for that line item table profitability CE1xxxx segment > reportYou should design your reports, assessments, and planning transactions to always read segment table / level.Reading line items could have potentially disastrous consequences to the processing time of the transactionand the performance of the system Verity Solutions Confidential

SEGMENT TABLE ANDSUMMARISATION LEVEL Verity Solutions Confidential

Segment Table and Summarisation Level ..1• Using data in the previous examples, our client has defined a report on product profitability by plant. Characteristic “Customer” is not required for this report.• When this report is executed, SAP will read Segment table/ level. It has to read 4 records in CE4V000 and CE3V000. If the report reads line item table CE1V000, it will read 6 records.• Due to the lower number of entries in segment tables and due to the nature of the structure of these tables and its indexes, it is more efficient to read segment table/ level• However, the disadvantage of Segment tables / level, in our example, is that their structure contains all characteristics from your Operating Concern. Our client wants to report on 2 characteristics product and plant and does not want to report on “Customer”• Hence, the report reads far more records than required due to this structure of the segment table. Verity Solutions Confidential

Segment Table and Summarisation Level ..2• Our client can define Summarisation levels / table to suit their needs; in our example, the client can build a summarisation level with product and plant as characteristics. This table will have only 3 records.• When report is executed, SAP will read this summarisation level first. Since the summarisation level is fit-to-purpose, the processing time of the report is vastly reduced. Verity Solutions Confidential

Segment Table summarised Company Period Customer Product Plant = Profitability code SegmentSegment Table / V001 007.2011 99001 1451 V005 = 1 Level V001 007.2011 99002 1451 V005 = 2 V001 007.2011 99001 1431 V005 = 3 V001 007.2011 99001 1431 V001 = 4 Company Period Product Plant = SummarisationSummarisation code Segment V001 007.2011 1451 V005 = 1 Level V001 007.2011 1431 V005 = 2 V001 007.2011 1431 V001 = 3 Verity Solutions Confidential

How is data read from COPA tables (with summarisation) Search for Yes Extract data from ProfitabilityReport executed PSG summarisation Segment (PSG) in in COPA exists? table for that PSG Summarisation to report tables No Search for data in segment table CE4xxxx Extract data from PSG segment table for exists? Yes that PSG to report No Extract data from Search for data in CE1xxxx for that line item table profitability CE1xxxx segment > report Verity Solutions Confidential

Technical Architecture (with summarisation) Summarisation Data scheduled to summarise Segment in summarisation tables tables K81xxxx and K81xxxx Table/ Level Data is summarised in real time Segment table / in segment tables level CE3V000 and CE4V000 Line Item tablesData is written at a detailed Line item tables CE1V000 and CE2V000 level in line item tables Verity Solutions Confidential

DEFINE YOUR SUMMARISATIONLEVEL Verity Solutions Confidential

Define Summarisation Level - IDDefine a numeric ID for your summarisation level. IMG PathControlling > Profitability Analysis > Tools > Summarisation Levels > Define summarisation levels Verity Solutions Confidential

Define Summarisation Level - overviewOnce summarisation ID is saved, the overview of the summarisation level is generated. Thisoverview presents technical information about the summarisation level. Verity Solutions Confidential

Define Summarisation Level –Select characteristic tosummariseHere you select whichcharacteristics you want tosummarise data by. In ourexample, we will select product andplant. The various entry options are:1. Wildcard “*” – include all values2. Specific entry – include only specific values3. Hashtag # - include values = blank only4. Leave blank – do not include in summarisation Verity Solutions Confidential

Define Summarisation Level – define index for summarisation levelIf you do not define an index, SAP will propose and generate an index. In most cases, thisindex will suffice your needs. If not, you can define a custom index to your summarisationlevel. Verity Solutions Confidential

BUILD YOUR SUMMARISATION LEVEL Verity Solutions Confidential

Build your summarisation level• Once you have defined your summarisation level, you can build it with data.• It is recommended your schedule this build job several times every day (“Refresh”). This will ensure your summarisation level has the most recent data• If you need to delete data in your summarisation tables and rebuild them, use the “Rebuild” option Verity Solutions Confidential

TIPS TO OPTIMISE SUMMARISATIONLEVEL Verity Solutions Confidential

Structure your summarisation levels as a “hierarchy” Company Period Customer Product SummarisationSummarisation code segment Level 2 V001 007.2011 99001 1451 1 V001 007.2011 99002 1451 2 V001 007.2011 99001 1431 3Summarisation level 2 is “nested” within Summarisation level 1. Hence, when you buildSummarisation level 2, it will read data from Summarisation level 1. It is recommended thatyou build “larger” summarisations first. Company Period Customer Product Plant Profitabilit code y segment Summarisation V001 007.2011 99001 1451 V005 1 Level 1 V001 007.2011 99002 1451 V005 2 V001 007.2011 99001 1431 V005 3 V001 007.2011 99001 1431 V001 4 Verity Solutions Confidential

Re-design your assessments, reports structureSegment Company Sales Customer Product Plant Product Class Sales Proposed # code Organisat (derived from Office Cycle ion Product) 1 Y Y Y Y Y 2 2 Y Y Y Y 2 3 Y Y Y Y Y Y 3 4 Y Y Y Y Y 1 5 Y Y Y Y 1 6 Y Y Y Y Y 1You should re-design your reports/ assessments/ planning structures such that it reads a smaller number ofprofitability segments; and those segments exist as summarisation levels or segment table.• Segment 4, 6 can be grouped as Cycle 1.• Discuss with your business whether segment 5 can include “Sales Organisation” as a characteristic. If so, it can be grouped as Cycle 1. If “customer” is a receiver characteristic, it might be reasonable to include “Sales Organisation” as a characteristic.• Segment 1 and 2 can be grouped as Cycle 2. Product Class is derived from characteristic “Product”. Exclude that characteristic and group Segment 1 & 2 into Cycle 2.• Segment 3 is similar to Segment 4 except that it has an additional characteristic “Sales Office”. If this receiver is essential to the segment, then Segment 3 should be assigned to Cycle 3. Verity Solutions Confidential

More tips• If you want to read more tips on summarisation levels, read the blog on our website www.veritysolutions.com.au – Summarisation levels in SAP COPA #1 – an overview (2012/05/09) – Summarisation levels in SAP COPA #2 – define your summarisation level (2012/05/16) – Summarisation levels in SAP COPA #3 – build your summarisation level (2012/05/23) – Summarisation levels in SAP COPA #4 – Tips to optimise your summarisation level (2012/05/30)• You can reach me: Name: Rajesh Shanbhag Mobile: +61 (0)4 1123 8873 Email: rajesh@veritysolutions.com.au• You could leave a comment against the blog• Do not forget to share this presentation/blog with your network using one of the social media icons on this webpage/ blog page Verity Solutions Confidential
