  • 1. MQL-to-SQL a JSON-based query language for RDBMS data access from AJAX applications
  • 2. Welcome! <ul><li>Roland Bouman, Leiden, the Netherlands
  • 3. Ex-MySQL, ex-Sun Microsystems
  • 4. Web & BI developer at Strukton Rail
  • 5. Author </li><ul><li>“Pentaho Solutions”
  • 6. “Pentaho Kettle Solutions” </li></ul><li>http://rpbouman.blogspot.com , @rolandbouman </li></ul>
  • 7. Agenda <ul><li>The data access problem
  • 8. What's wrong with SQL?
  • 9. The Metaweb Query Language (MQL)
  • 10. MQL-to-SQL
  • 11. Demo
  • 12. Questions </li></ul>
  • 13. Agenda <ul><li>The data access problem
  • 14. What's wrong with SQL?
  • 15. The Metaweb Query Language (MQL)
  • 16. MQL-to-SQL
  • 17. Demo
  • 18. Questions </li></ul>
  • 19. The Data Access Problem <ul><li>Web application </li></ul><ul><li>Classical Client/Server </li></ul>SQL Resultset SQL Resultset RDBMS HTTP Browser Desktop Application ?
  • 20. The Data Access Problem <ul><li>Build a service </li><ul><li>Protocol on top of HTTP: REST, RPC
  • 21. Data format: JSON, XML </li></ul><li>Advantage: controlled data access
  • 22. Disadvantage: controlled=limited </li></ul>
  • 23. The Data Access Problem <ul><li>Advantage: unlimited data access
  • 24. Disadvantage: unlimited=uncontrolled </li></ul>SQL SQL Resultset JSON <ul><li>Build a query service </li><ul><li>Example: dbslayer </li></ul></ul>
  • 25. Agenda <ul><li>The data access problem
  • 26. What's wrong with SQL?
  • 27. The Metaweb Query Language (MQL)
  • 28. MQL-to-SQL
  • 29. Demo
  • 30. Questions </li></ul>
  • 31. What's wrong with SQL? <ul><li>Nothing of course, it's great!!! </li><ul><li>very powerful
  • 32. expressive syntax
  • 33. declarative
  • 34. designed for the RDBMS
  • 35. portable
  • 36. well supported </li></ul></ul>
  • 37. What's wrong with SQL? <ul><li>SQL is very powerful </li><ul><li>...way too powerful </li></ul><li>SQL has expressive syntax </li><ul><li>...and too hard to parse and generate </li></ul><li>SQL is declarative </li><ul><li>...but not enough </li></ul><li>SQL is designed for the RDBMS </li><ul><li>...can't escape relational model </li></ul></ul>
  • 38. SELECT f.title , f.description , f.release_year , f.length , f.rating , a.first_name , a.last_name , l.name FROM film f INNER JOIN language l ON f.language_id = l.id LEFT JOIN film_actor fa ON f.id = fa.film_id LEFT JOIN actor a ON fa.actor_id = a.id SQL not declarative enough Spoken in Has cast Starring in
  • 39. SELECT f.title , f.description , f.release_year , f.length , f.rating , a.first_name , a.last_name , spoken_in.name FROM film f RELATE spoken_in language l , has_cast film_actor fa RELATE starring_in actor a SQL not declarative enough Spoken in Has cast Starring in
  • 40. SQL can't escape the RM Unnormalized data Split off – multivalued attributes – repeating groups First normal form (1NF) Higher normal forms (>= 3NF) Remove redundancy Denormalized data (1NF) SQL queries: – JOIN operation ??? Header – line 1a – line 2b header line 1a line 2b header 1 2 line 1a line 2b header line 1a header line 2b
  • 41. SQL can't escape the RM
  • 42. SELECT f.* , l.*, ol.* , (SELECT * FROM film_category fc INNER JOIN category c ON fc.category_id = c.id WHERE fc.film_id = f.film_id) , (SELECT * FROM film_actor fa INNER JOIN actor a ON fa.actor_id = a.id WHERE fa.film_id = f.film_id) FROM film f INNER JOIN language l ON f.language_id = l.id INNER JOIN language ol ON f.original_language_id = ol.id SQL can't escape the RM
  • 43. SELECT f.* , l.*, ol.* , c.*, a.* FROM film f INNER JOIN language l ON f.language_id = l.id INNER JOIN language ol ON f.original_language_id = ol.id LEFT JOIN film_category fc ON f.id = fc.film_id LEFT JOIN category c ON fc.category_id = c.id LEFT JOIN film_actor fa ON f.id = fa.film_id LEFT JOIN actor a ON fa.actor_id = a.id SQL can't escape the RM
  • 44. How do we get rid of SQL? <ul><li>Object relational mapper?
  • 45. NoSQL? </li><ul><li>Document databases
  • 46. ACID
  • 47. Schema flexibility </li></ul><li>Can we preserve the RM? </li></ul>
  • 48. Agenda <ul><li>The data access problem
  • 49. What's wrong with SQL?
  • 50. The Metaweb Query Language (MQL)
  • 51. MQL-to-SQL
  • 52. Demo
  • 53. Questions </li></ul>
  • 54. The Metaweb Query Language <ul><li>MQL – rhymes with “pickle”
  • 55. Native query language of Freebase </li><ul><li>http://www.freebase.com/
  • 56. http://www.freebase.com/docs </li></ul><li>JSON over HTTP </li><ul><li>Natural fit for AJAX applications </li></ul></ul>
  • 57. Freebase MQL Services <ul><li>http://api.freebase.com/api/service/mqlread? query ={&quot;query&quot;:[{ Your MQL here }]}
  • 58. http://api.freebase.com/api/service/mqlread? queries ={&quot;q1&quot;: {&quot;query&quot;:[{ Your MQL here }]}, &quot;q2&quot;: {&quot;query&quot;:[{ Your MQL here }]}}
  • 59. http://api.freebase.com/api/service/mqlwrite </li></ul>
  • 60. JSON <ul><li>Subset of JavaScript </li><ul><li>Object : set of property/value pairs
  • 61. Scalar: boolean, null, number, string
  • 62. Array: list of values </li></ul></ul>{ &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id&quot; : 1 , &quot;title&quot; : &quot;ACADAMY DINOSAUR&quot; , &quot;language&quot; : { &quot;language_id&quot; : 1 , &quot;language_name&quot; : &quot;English&quot; } , &quot;category&quot; :[ &quot;Action&quot; , &quot;Adventure&quot; ] }
  • 63. JSON is great for AJAX <ul><li>Modern Web applications </li><ul><li>Asynchronous JavaScript and XML
  • 64. ...except it's JSON rather than XML </li></ul><li>1 to 1 runtime representation </li><ul><li>XML requires mapping, DOM traversal
  • 65. JSON support in all modern browsers </li></ul><li>Cross-domain requests (JSONP) </li><ul><li><script> injection </li></ul></ul>
  • 66. MQL Queries <ul><li>JSON-based </li><ul><li>Both Query and Result </li></ul><li>MQL is “query by example” </li><ul><li>MQL Query is an object template
  • 67. Finds objects matching the template
  • 68. Fills in value placeholders in template </li></ul><li>Query & Result symmetry </li><ul><li>Easy to parse, easy to generate </li></ul></ul>
  • 69. Basic MQL query { &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id&quot; : 1 , &quot;title&quot; : &quot;ACADAMY DINOSAUR&quot; , &quot;language&quot; : { &quot;language_id&quot; : 1 , &quot;language_name&quot; : &quot;English&quot; }, &quot;category&quot;: [ &quot;Action&quot; , &quot;Adventure&quot; ] } { &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id&quot; : 1 , &quot;title&quot; : null , &quot;language&quot; : { &quot;language_id&quot; : null , &quot;name&quot; : null }, &quot;category&quot; : [] } Query: Result: <ul><li>Property/value pairs act as filter
  • 70. Value placeholders return data </li></ul>
  • 71. Meta: Objects & Properties <ul><li>Objects are bags of properties
  • 72. Properties </li><ul><li>name/value pairs
  • 73. Single- or multi-valued (array)
  • 74. Value can be scalar or object </li></ul><li>No explicit relationships </li><ul><li>Implicit: properties with object values </li></ul></ul>
  • 75. Meta: Types <ul><li>Types define a bag of properties </li><ul><li>Objects may have multiple types
  • 76. Types are grouped in domains </li></ul><li>In MQL, use the type property </li><ul><li>type : &quot;/domainname/typename&quot; </li></ul><li>Property has exactly 1 expected type </li></ul>
  • 77. MQL Joins/subqueries <ul><li>Implicit via object-type properties
  • 78. Can't specify join conditions </li></ul>
  • 79. MQL operators <ul><li>Property/value act as equals operator
  • 80. Explicit operators for advanced filters
  • 81. != , < , <= , >= , > </li><ul><li>Have their usual meaning </li></ul><li>|= and !|= test for membership </li><ul><li>&quot;one of&quot; and &quot;not one of&quot; </li></ul><li>~= for word pattern matching </li></ul>
  • 82. MQL operators { &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id&quot;: 1 } { &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id < &quot; : 2 , &quot;title ~= &quot; : &quot;ACADEMY&quot; , &quot;language != &quot; : &quot;Danish&quot; , &quot;category |= &quot; : [ &quot;Action&quot;, &quot;Adventure&quot; ], &quot;film_id&quot; : null } Query: Result: <ul><li>Operators follow the property name
  • 83. Operations not returned in the result </li></ul>
  • 84. MQL property aliases { &quot;type&quot; : &quot;/sakila/film&quot; , &quot;film_id&quot; : null , &quot;title&quot; : null , &quot;1:category&quot; : &quot;Action&quot;, &quot;2:category&quot; : &quot;Adventure&quot; } Query: <ul><li>Implement an AND operation </li></ul>
  • 85. MQL directives <ul><li>Reserved property names </li><ul><li>limit
  • 86. return: count
  • 87. cursor
  • 88. * wildcard </li></ul></ul>
  • 89. Agenda <ul><li>The data access problem
  • 90. What's wrong with SQL?
  • 91. The Metaweb Query Language (MQL)
  • 92. MQL-to-SQ L
  • 93. Demo
  • 94. Questions </li></ul>
  • 95. MQL-to-SQL <ul><li>Implementation of mqlread service </li><ul><li>PHP using PDO database access
  • 96. MySQL, PostgreSQL, SQLite, Oracle
  • 97. http://code.google.com/p/mql-to-sql
  • 98. GPL
  • 99. Lacks many features, has many bugs
  • 100. don't use in hospitals and airplanes </li></ul></ul>
  • 101. MQL-to-SQL <ul><li>MQL domain maps to a SQL schema
  • 102. MQL type maps to a SQL table
  • 103. MQL property maps to </li><ul><li>SQL column
  • 104. Relationship (foreign key) </li></ul><li>Mappings defined in JSON file </li></ul>
  • 105. MQL-to-SQL index.php config.php <?php include 'config.php' ; ...code... ?> <?php $connection_file_name = ''; $metadata_file_name = ''; ?>
  • 106. MQL-to-SQL metadata file { &quot;domains&quot; : { &quot;sakila&quot; : { &quot;schema_name&quot; : &quot;&quot; , &quot;types&quot; : { &quot;actor&quot; : { &quot;properties&quot; : { &quot;actor_id&quot; : { &quot;column_name&quot; : &quot;actor_id&quot; , &quot;nullable&quot; : false , &quot;type&quot; : &quot;/type/int&quot; }, &quot;starring_in&quot; : { &quot;type&quot; : &quot;/sakila/film_actor&quot; , &quot;direction&quot; : &quot;referenced<-referencing&quot; , &quot;join_condition&quot; : [ { &quot;referencing_column&quot; : &quot;actor_id&quot; , &quot;referenced_column&quot; : &quot;actor_id&quot; },
  • 107. Agenda <ul><li>The data access problem
  • 108. What's wrong with SQL?
  • 109. The Metaweb Query Language (MQL)
  • 110. MQL-to-SQL
  • 111. Demo
  • 112. Questions </li></ul>
  • 113. Agenda <ul><li>The data access problem
  • 114. What's wrong with SQL?
  • 115. The Metaweb Query Language (MQL)
  • 116. MQL-to-SQL
  • 117. Demo
  • 118. Questions </li></ul>
  • 119. Finally <ul><li>I need your feedback
  • 120. Love to see this inside a RDBMS </li><ul><li>drizzle plugin?
  • 121. MySQL plugin?
  • 122. PostgreSQL SP language? </li></ul><li>http://code.google.com/p/mql-to-sql/
  • 123. Online query editor </li></ul>

×
