Flickr A Case Study in Rich Internet Application Development Cal Henderson
Hi <ul><li>Cal Henderson </li></ul><ul><li>Flickr Architect </li></ul><ul><li>Yahoo! Inc </li></ul>

flickr.com <ul><li>Over 2 million users </li></ul><ul><li>Over 93 million photos </li></ul><ul><li>368 TB of hard disk spa...
A flickr history <ul><li>Flickr started out as a Massively Multiplayer Online Game called “Game Never Ending” </li></ul><u...
A flickr history <ul><li>Our two year birthday is next week – come to our party! </li></ul><ul><li>Saturday 11 th  Februar...
Vancouver, BC (not in America)
A flickr feature tour <ul><li>Photos! </li></ul><ul><li>On web pages! </li></ul>

A flickr feature tour <ul><li>How does it differ from other photo management services? </li></ul><ul><li>Social network ba...





Flickr architecture <ul><li>Flickr is powered by a bunch of hardware in Texas and Virginia </li></ul><ul><ul><li>A few hun...
Hardware architecture Storage Servers Database Servers Web Servers Interweb
Software architecture Application Logic Page Logic Templates API Client / Browser AJAX
AJAX <ul><li>What’s that all about? </li></ul><ul><li>Asynchronous Javascript and XML </li></ul><ul><ul><li>Jesse James Ga...
AJAX History <ul><li>Started out as loading scripts into  <iframe> ‘s or writing  <script>  tags into the document </li></...
The roundtrip <ul><li>User initiates action </li></ul><ul><li>Browser makes background request </li></ul><ul><li>Server do...
The roundtrip <ul><li>User initiates action </li></ul><ul><li>Browser makes background request </li></ul><ul><li>Server do...
Browser compatibility <ul><li>Sounds too easy? </li></ul><ul><li>Luckily all the browsers implement XmlHttpRequest slightl...
AJAX Abstraction <ul><li>In fact, we care even less about the implementation when trying to get things done </li></ul><ul>...
Debugging AJAX Apps <ul><li>AJAX applications are harder to debug than static web pages </li></ul><ul><ul><li>The client o...
Debugging AJAX Apps <ul><li>The simplest way to see what’s going on is to echo things out to the browser </li></ul><ul><li...


Avoiding  alert() <ul><li>alert()  isn’t always the best solution </li></ul><ul><li>If we want to dump a lot of data, crea...

Sniffing the wire <ul><li>With AJAX applications, we care about the data going over the wire </li></ul><ul><li>If we can s...
Ethereal <ul><li>Ethereal lets us grab and analyze all network traffic </li></ul><ul><ul><li>http://www.ethereal.com/ </li...

Sniffing the wire <ul><li>This is great to see what’s going on, but it’s a read-only tool </li></ul><ul><li>It would be re...
Fiddler <ul><li>Fiddler from Microsoft </li></ul><ul><ul><li>http://www.fiddlertool.com/ </li></ul></ul><ul><ul><li>Free <...

Debuggers <ul><li>Beyond looking at the traffic, we need to be able to see what’s going on in our guts </li></ul><ul><li>I...
Visual Studio <ul><li>Microsoft have a free version of Visual Studio (Visual Studio Express) which contains their IE debug...
Venkman <ul><li>For those of you with a Firefox preference, Venkman provides the same features </li></ul><ul><ul><li>http:...

Dynamic pages <ul><li>Now that we routinely manipulate the DOM, we don’t always know what state the “source” of the page i...
Firefox  <ul><li>Choose ‘custom’ install when installing Firefox </li></ul><ul><li>Adds a “DOM Inspector” option to the to...

IE Dom Tools <ul><li>IE Instant Source Viewer </li></ul><ul><ul><li>http://www.blazingtools.com/is.html </li></ul></ul><ul...

AJAX in the wild <ul><li>We can build whole applications in AJAX, but there are drawbacks </li></ul><ul><li>Having URLs fo...
AJAX in the wild <ul><li>We can use AJAX to allow click-to-edit functionality, avoiding two page roundtrips </li></ul><ul>...

Web 2.0? <ul><li>Web 2.0 is the talk of the town </li></ul><ul><li>Web 2.0 isn’t all about AJAX </li></ul><ul><li>What can...
Five ways to love web 2.0 <ul><li>Collaboration </li></ul><ul><ul><li>Embrace collaborative metadata </li></ul></ul><ul><u...

Five ways to love web 2.0 <ul><li>Aggregation </li></ul><ul><ul><li>Use the data you have </li></ul></ul><ul><ul><li>Creat...

Five ways to love web 2.0 <ul><li>Open APIs </li></ul><ul><ul><li>Help 3 rd  party developers to help you </li></ul></ul><...

Five ways to love web 2.0 <ul><li>Unicode </li></ul><ul><ul><li>Aim for I18n/L10n from the outset </li></ul></ul><ul><ul><...

Five ways to love web 2.0 <ul><li>Open content </li></ul><ul><ul><li>Creative commons </li></ul></ul><ul><ul><li>Allow you...

Questions?
Thank you These slides are available from the conference website and at http://iamcal.com/talks/
