Writing HTML5 Web Apps          Google App Engine             Backbone.js              Require.js                jQuery   ...
Agenda Why do you need to learn how to program HTML5 web  apps? A walkthrough over the To-Do list anatomy   https://git...
Why? Web Apps = Software as a Service   Cross OS/platform/browser   Cuts costs on deployment and maintenance   Scales ...
Brief Introduction Google App Engine - Solid, scalable server framework   Platform as a Service Backbone.js - Proven MV...
The To-Do List
Web App Architecture             Front End            Backbone.js                      REST API            Back End       ...
Back-End
Dataset We want to create a Todo list item table. Start by adding a Google App Engine model# the Todo model.class Todo(d...
Request Handler Serves all web requests We implement a main handler and REST APIdef main(): application = webapp.WSGIApp...
Main Request Handler When we access http://www.todolist.com, the app is  downloaded to our computer and starts to run.cla...
REST API Standard REST API is used to let clients control datasets, using four  CRUD operations:    Create a new item – ...
REST API – GET (get all tasks)class TodoListHandler (webapp.RequestHandler): def get(self):  # serialize all Todos,  # inc...
REST API – POST (add a new task)class TodoListHandler (webapp.RequestHandler): def post(self):  data = simplejson.loads(se...
REST API – PUT (update a task)class TodoItemHandler (webapp.RequestHandler): def put(self, id):  data = simplejson.loads(s...
REST API – DELETE (delete a task)class TodoItemHandler (webapp.RequestHandler): def delete(self, id):  # find the requeste...
Front-End
Backbone.js Architecture – MVC   Server Model                     Database               Backbone REST Sync    Model      ...
Backbone.js Architecture – REST SyncCollection Operations   Collection      Model Operations      GET /tasks              ...
Web App Directory Structure index.html – Main entry point    css      todos.css – Defines the style    js      libs  ...
index.html Loads the stylesheet<link  rel="stylesheet"  href="css/todos.css”/> Loads the main.js script<script  data-mai...
main.js Configures paths and known libraries text is used for require.js text loading (for templates)require.config({ pa...
main.js – cont. Load the app view (views/app.js) Notice there is no need to add the JS extension Require.js supplies us...
views/app.js – The AppView Backbones "View" is actually a "View Controller". The view  itself is the template combined wi...
views/app.js – The AppView (cont.) The define function allows us to depend on  libraries, template files and other module...
views/app.js – The AppView (cont.) The "View" captures and delegates events on DOM  elementsevents: { "keypress #new-todo...
views/app.js – The AppView (cont.) We add some handlers on the Todos collection to get  notified when its updated. Then,...
collections/todos.js – Todo Collection       Backbone Collections are model arrays which synchronize with the server.   ...
models/todo.js – Todo Model Holds the Todo item data Defines the default values and methods related to the data The "de...
views/todos.js – Todo View Bind the view to the model Render function uses the model data to render the templatedefine([...
views/todos.js – Todo View(cont.) Manipulate the views model according to triggered eventsevents: {    "click .check" : "...
templates/todos.html Template files are used to build the views either:   Once (and then update using jQuery)   On ever...
Questions?
Upcoming SlideShare
Loading in...5
×

Writing HTML5 Web Apps using Backbone.js and GAE

18,353

Published on

A walkthrough of how to write a complete HTML5 web app (both front end and back end) using Google App Engine (Python), Backbone.js, Require.js, underscore.js and jQuery.

Published in: Technology, Design
0 Comments
43 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
18,353
On Slideshare
0
From Embeds
0
Number of Embeds
35
Actions
Shares
0
Downloads
372
Comments
0
Likes
43
Embeds 0
No embeds

No notes for slide

Writing HTML5 Web Apps using Backbone.js and GAE

  1. 1. Writing HTML5 Web Apps Google App Engine Backbone.js Require.js jQuery Ron Reiter © 2012
  2. 2. Agenda Why do you need to learn how to program HTML5 web apps? A walkthrough over the To-Do list anatomy  https://github.com/ronreiter/webapp-boilerplate
  3. 3. Why? Web Apps = Software as a Service  Cross OS/platform/browser  Cuts costs on deployment and maintenance  Scales easily  Google App Engine, Amazon, Heroku, etc. Mobile Apps  Cross device development cuts development costs  WebView  PhoneGap
  4. 4. Brief Introduction Google App Engine - Solid, scalable server framework  Platform as a Service Backbone.js - Proven MVC framework  LinkedIn mobile, Foursquare, Do.com, Groupon, Posterous, Basecamp mobile, Kicksend, etc... Require.js - Modular JavaScript Loader  Module dependency management  JavaScript minification & bundling jQuery - DOM Manipulation Framework  Creating dynamic content and replacing Flash
  5. 5. The To-Do List
  6. 6. Web App Architecture Front End Backbone.js REST API Back End Google App Engine
  7. 7. Back-End
  8. 8. Dataset We want to create a Todo list item table. Start by adding a Google App Engine model# the Todo model.class Todo(db.Model): content = db.StringProperty() done = db.BooleanProperty() order = db.IntegerProperty()
  9. 9. Request Handler Serves all web requests We implement a main handler and REST APIdef main(): application = webapp.WSGIApplication([ # index.html (/, MainHandler), # REST interface (/todos, TodoListHandler), (/todos/(d+), TodoItemHandler), ], debug=True) util.run_wsgi_app(application)
  10. 10. Main Request Handler When we access http://www.todolist.com, the app is downloaded to our computer and starts to run.class MainHandler(webapp.RequestHandler): def get(self): self.response.out.write( template.render("index.html", {}))
  11. 11. REST API Standard REST API is used to let clients control datasets, using four CRUD operations:  Create a new item – using HTTP POST requests  Read a list of items – using HTTP GET requests  Update a single item – using HTTP PUT requests  Delete a single item – using HTTP DELETE requests Similar to SQL, but this is a customized interface and not a way to access a database REST API uses XML or JSON serialization (Javascript Object Notation) to encode and decode objects We’ll use JSON
  12. 12. REST API – GET (get all tasks)class TodoListHandler (webapp.RequestHandler): def get(self): # serialize all Todos, # include the ID in the response todos = [] for todo in Todo.all(): todos.append({ "id" : todo.key().id(), "content" : todo.content, "done" : todo.done, "order" : todo.order, }) # send them to the client as JSON self.response.out.write(simplejson.dumps(todos))
  13. 13. REST API – POST (add a new task)class TodoListHandler (webapp.RequestHandler): def post(self): data = simplejson.loads(self.request.body) # load JSON data of the object todo = Todo( content = data["content"], done = data["done"], order = data["order"], ).put() # create the todo item # send it back, and include the new ID. self.response.out.write(simplejson.dumps({ "id" : todo.id(), "content" : data["content"], "done" : data["done"], "order" : data["order"], }))
  14. 14. REST API – PUT (update a task)class TodoItemHandler (webapp.RequestHandler): def put(self, id): data = simplejson.loads(self.request.body) # load the updated model todo = Todo.get_by_id(int(id)) # get it model using the ID from the request path todo.content = data["content"] todo.done = data["done"] todo.order = data["order"] todo.put() # update all fields and save to the DB # send it back using the updated values self.response.out.write(simplejson.dumps({ "id" : id, "content" : todo.content, "done" : todo.done, "order" : todo.order, }))
  15. 15. REST API – DELETE (delete a task)class TodoItemHandler (webapp.RequestHandler): def delete(self, id): # find the requested model and delete it. todo = Todo.get_by_id(int(id)) todo.delete()
  16. 16. Front-End
  17. 17. Backbone.js Architecture – MVC Server Model Database Backbone REST Sync Model View Backbone.Model HTML + CSS DOM Manipulation With jQuery and templating Controller Backbone.View View EventsModel Events
  18. 18. Backbone.js Architecture – REST SyncCollection Operations Collection Model Operations GET /tasks PUT /tasks/38 POST /tasks View Model DELETE /tasks/38 PUT /tasks/39 View Model DELETE /tasks/39 PUT /tasks/40 View Model DELETE /tasks/40 PUT /tasks/41 View Model DELETE /tasks/41
  19. 19. Web App Directory Structure index.html – Main entry point  css  todos.css – Defines the style  js  libs  require.js, jQuery, Backbone, Underscore  models  todo.js – The todo item model  collections  todos.js – The todo item collection  views  todos.js – The todo item view  App.js – The app view  templates  stats.html  todo.html – The todo item template  main.js – Require.js entry point
  20. 20. index.html Loads the stylesheet<link rel="stylesheet" href="css/todos.css”/> Loads the main.js script<script data-main="js/main" src="js/libs/require/require.js"></script>
  21. 21. main.js Configures paths and known libraries text is used for require.js text loading (for templates)require.config({ paths: { jquery: libs/jquery/jquery-min, underscore: libs/underscore/underscore-min, backbone: libs/backbone/backbone-optamd3-min, text: libs/require/text }});
  22. 22. main.js – cont. Load the app view (views/app.js) Notice there is no need to add the JS extension Require.js supplies us with a function to run Javascript code only after certain modules have been loaded. This allows us to create a dependency model, and a new way to write Javascript modules.require([views/app], function(AppView){ var app_view = new AppView;});
  23. 23. views/app.js – The AppView Backbones "View" is actually a "View Controller". The view itself is the template combined with CSS. Creating a new view either means  creating a new DOM element using JavaScript/jQuery or templating  Using an existing one in the DOM Since there is only one app, we’ll use an existing element for the AppView. However, task views are more dynamic, and they will create new DOM elements.
  24. 24. views/app.js – The AppView (cont.) The define function allows us to depend on libraries, template files and other modules we wrote. Every dependency in the list corresponds to an argument of the function to execute once all modules are loaded.define([ jquery’, underscore, backbone, collections/todos’, views/todos, text!templates/stats.html ], function($, _, Backbone,Todos, TodoView, statsTemplate) { var AppView = Backbone.View.extend({ ...
  25. 25. views/app.js – The AppView (cont.) The "View" captures and delegates events on DOM elementsevents: { "keypress #new-todo": "createOnEnter", "click .todo-clear a": "clearCompleted”},
  26. 26. views/app.js – The AppView (cont.) We add some handlers on the Todos collection to get notified when its updated. Then, we fetch the Todos collection from the server. Once the data is loaded, addAll will be executed.initialize: function() { Todos.bind(add, this.addOne); Todos.bind(reset, this.addAll); Todos.fetch();},
  27. 27. collections/todos.js – Todo Collection Backbone Collections are model arrays which synchronize with the server. The AppView listens for changes on this collection, and can add new models to it.define([ underscore, backbone, models/todo’], function(_, Backbone, Todo){ var TodosCollection = Backbone.Collection.extend({ model: Todo, url: /todos, done: function() { return this.filter(function(todo){ return todo.get(done); }); } });
  28. 28. models/todo.js – Todo Model Holds the Todo item data Defines the default values and methods related to the data The "define" function needs to return the model class. When "model/todo" will be required, it will be received.define([underscore, backbone], function(_, Backbone) { var TodoModel = Backbone.Model.extend({ defaults: { content: "empty todo...”, done: false, order: 0 } }); return TodoModel;});
  29. 29. views/todos.js – Todo View Bind the view to the model Render function uses the model data to render the templatedefine([jquery, underscore, backbone’, models/todo, text!templates/todos.html ], function($, _, Backbone, Todo, todosTemplate){ var TodoView = Backbone.View.extend({ model: Todo, template: _.template(todosTemplate), initialize: function() { this.model.bind(change, this.render); this.model.bind(destroy, this.remove); }, render: function() { $(this.el).html(this.template(this.model.toJSON())); ...
  30. 30. views/todos.js – Todo View(cont.) Manipulate the views model according to triggered eventsevents: { "click .check" : "toggleDone", ...}// Toggle the "done" state of the model.toggleDone: function() { this.model.save({done : !this.model.get("done")});},
  31. 31. templates/todos.html Template files are used to build the views either:  Once (and then update using jQuery)  On every update (if youre lazy) Use <%- ... -> for escaping HTML<div class="todo <%= done ? done : %>"> <div class="display"> <input class="check" type="checkbox" <%= done ? checked="checked" : %> /> <div class="todo-content"><%- content %></div> <span class="todo-destroy"></span> </div> <div class="edit"> <input class="todo-input" type="text" value="<%- content %>" /> </div></div>
  32. 32. Questions?
