Ice Rescue & Hypothermia   Training in Ice Rescue and     Treatment of Immersion           Hypothermia     Rommie L. Duckw...
IntroductionIt‟s 10 O‟clock in the morning on a Saturday in   February and the tones go off for a man   through the ice. Y...
IntroductionAt the end of today, the answer to thatquestion will be…      YES!
Objectives: The Rescuer will demonstrate the ability to  initiate appropriate field treatment for  drowning and immersion...
Course Outline:4 Introduction4 Objectivesn Recognition and Treatment: Drowning  & Immersion Hypothermian Rescuer Safetyn I...
Course Outline:n Course Equipmentn Set up and donningn Hand signals / Tender‟s dutiesn Live Rescuen Extrication Techniques...
Recognition & TreatmentIn order to understand any rescue techniques, one must understand the injury to the victim and the ...
Definition of HypothermiaClinically defined as body core temp of<95 deg. F (<35 deg. C)Simply defined as the body ‟ stempe...
Human EnvironmentHuman beings are tropical beings better designed to shed, not retain heat.
CoolingTypes of Cooling (heat loss)     Conduction      Direct Contact     Convection      Water / Air Movement     R...
CoolingEnvironmental Factors Accelerating Cold     Wind Chill      More convection increases RATE of heat loss.      Ob...
CoolingCooling rates vary greatly with change in   Water temperature and circulation   Time and degree of immersion   T...
FrostbiteFrostbite, trench foot and Chilblains: Cold injury localized to an extremity, usually associated with chilled, hu...
Frostbite
FrostbiteDegrees   1deg.=numbness and erythemia   2deg.=blisters / clear or milky fluid   3deg.=purple or bloody bliste...
FrostbitePrevention for Rescuers!   Stay dry   Dress warm but…   Do NOT overdress   Do NOT induce sweating (antiperspi...
FrostbiteSigns and Symptoms  Numbness  Tingling - Electric shock feeling  Decreased motor function  Pain  Necrosis  ...
FrostbiteTreatment   Remove from cold   Stabilize temperature   Protect the skin   DO NOT RUB   DO NOT initiate rewar...
General Hypothermia  The body‟s reaction to heat loss    and the cold environment.
THE BODY‟S REACTIONHeat senses (primarily through the skin) are connected to the hypothalamus.The body attempts to increas...
THE BODY‟S REACTIONThe body reduces heat loss by...     Peripheral Vasoconstriction       Blood shunting from extremitie...
AssessmentReading temperatures in the field are usually NOT practical.   Field temp. instruments must be both    calibrat...
AssessmentMild Hypothermia (98.6-96 f)   Feeling Cold   Piloerection   Involuntary Shivering   Unable to perform compl...
AssessmentModerate Hypothermia (95-90 f)   Dazed & Confused   Violent Shivering   Difficulty performing simple function...
AssessmentSevere Hypothermia (Below 90 f)   Intermittent or No Shivering   Inability to move   Unconsciousness   Muscl...
The Body‟s ReactionNervous System   Depression   Impaired memory   Impaired Judgment   Excessive Radio Use   Loss of ...
The Body‟s ReactionMetabolism   Increased Catecholamine Production   Major Muscle Groups increase rate 2-5X   Increased...
The Body‟s ReactionRenal System   Decreased ADH   Increase in urinary output 200-350%   Increased pressure on system (I...
The Body‟s ReactionCardiac   Initial Tachycardia   Progressive Bradycardia   Conduction irregularities due to many    m...
The Body‟s ReactionRespiratory System   Increased viscosity of surfactant   Decreased elasticity   Decreased muscle ene...
AfterdropBEFORE we start to treat, understand…How the watermelon freezes, orPATHOPHYSIOLOGY OF AFTER DROP   Shivering   ...
Afterdrop continued Blood begins to “sludge” Skin senses warming resulting in  peripheral vasodilation Pressure Drops (...
Treatment - Mild - Mod.Stop the cooling!Stabilize temperatureApplication of Blankets / CoveringsApplication of heat to hea...
Treatment - SevereStop the cooling!Stabilize temperatureHeat from inside out   Heated humidified O2   Warmed IV fluidsDi...
INTERMISSION
Drowning
Drowning DefinitionsDROWNING: Death by asphyxiation following submersion.NEAR-DROWNING: NEAR-death by asphyxiation followi...
Drowning Statistics As of 1986 drowning was second only to  motor vehicle accidents as a cause of  accidental death in Am...
Ice Rescue VictimsTypical Victims of Ice Related Accidents-Animals-Children-Ice fishermen-Ice Skaters-Snomobilers (4-wheel...
Common Factors:Unprepared for immersion: Two thirds of all drowning victims could not swim and did not intend to be in the...
Common Factors:Underlying Disease: Hypoglycemia, MI, cardiac arrythmias, syncope, seizures, stroke and many other disease ...
PathophysiologyWet Drownings. In 85% of all drownings the victim immediately aspirates water upon submersion. This is term...
PATHOPHYSIOLOGYSalt vs. Fresh: Regardless of submersion in Salt or any variation of fresh water, the end result is the was...
PATHOPHYSIOLOGYContaminants, whether they be from sand, vomit, chemicals, bacteria or suspended particles, are also of con...
Cold Water Reflex:This is an involuntary reflex of the  diaphragm stimulated by cold water. When  the victim is splashed i...
Mammalian Diving Reflex: Marine mammals’ physiological response  when stimulated by cold water submersion  is the shunting...
Mammalian Diving Reflex: Mammalian Dive Reflex theory purports that  some humans, notably children under 5,  may also use ...
Post Immersion Synd.This term describes the occurrence of Adult Respiratory Distress Syndrome (ARDS) in near drowning vict...
Treatment for DrowningAsymptomatic: The asymptomatic patient will most often wish to go home and forget the incident. Beca...
Treatment for DrowningSymptomatic: “No one is dead until they are warm and dead”Always consider C-Spine PrecautionsAirway:...
Treatment for DrowningHistory to note for drowning victims   Age   PMHx   Medications   Trauma   H2O temp   Depth of...
ACLS Interventions
ACLS Interventions
Rewarming Methods34°C to 36°C: Passive  rewarming (remove wet clothing; warm  blankets) Active external rewarming (most ...
Active Internal Rewarming   Warm, humidified O2 (42°C to 46°C)   Warmed IV fluids (42°C to 44°C)   Warm lavage: gastric...
Active Internal RewarmingPatient Warming Devices
BREAK TIME!Rest your… Butts Books Brains
Ice Rescue & Safety  “Well its about freakin‟ time!”
Ice Rescue Safety:   According to national statistics, more rescuers    die each year trying to perform water rescues    ...
Safety for the Rescuer   Dangers are Drowning, Hypothermia and other    bodily injury.   Take a break when you need it s...
Safety for the Rescuer   The turn out gear vapor barrier will trap air.    DEMO
Safety for the RescuerHAZARDS: Physical Hazards       Rocky approach       Steep Approach    Hazardous Materials      ...
Size Up:Begins while enrouteWeatherTime of Day / Day of weekLight Conditions (Glare / Dark)Available ResourcesIce Conditio...
Size Up:On Scene  Spotters (For point-last-seen) Binoculars  911 Caller     Reliability     Point & Time Last Seen  N...
Types of Ice Rescue-Animal rescue  Risk vs. benefit  NEVER risk human life for an animal  rescue  Civilians may go to retr...
Ice ConditionsQuality: much more important than thickness for  weight bearingThickness and quality can vary greatly in dif...
Available ResourcesGeneral rules    Call early, can always send back    Keep it close, but not too close Boats    Differen...
Available ResourcesDispatch : Coordinate multiple resources Fire Engine    Personnel    Lighting    EquipmentSpecial Rescu...
Available ResourcesEquipment NOT to call or use   Any person not wearing PFD   Untrained persons   Human chains      I...
Specialty Ice Rescue DevicesMany different rescue devices are available.
Specialty Ice Rescue Devices  Start on shore
Specialty Ice Rescue Devices Ice Rescue and Immersion Suits
Specialty Ice Rescue Devices For the perfect ensemble: Accessorize!!!
Specialty Ice Rescue Devices Getting to the victim fast.
Specialty Ice Rescue DevicesGrabbing the victim
Specialty Ice Rescue DevicesGrabbing the victim
Specialty Ice Rescue DevicesLet them see you!
Specialty Ice Rescue Devices Rescue sleds and small boats
Specialty Ice Rescue Devices
Specialty Ice Rescue Devices Slide across ice or paddle across water.
Specialty Ice Rescue Devices Pull the victim onto the sled and signal  your crew to pull you both in smoothly.
Specialty Ice Rescue Devices
Specialty Ice Rescue Devices
Specialty Ice Rescue Devices
TODAY’S EQUIPMENT 1) Suit:    a) 16 lbs. buoyant.    b) NOT Water proof    c) Secure seals as best you can    d) Be carefu...
TODAY’S EQUIPMENT FORNFVFD 3) Rope: Reeled or bagged. Poly preferred! 4) Rescue Tube: To reach and/or secure victim 5) Kni...
Ice Rescue TechniquesTender Duties   Prep Equipment   Assist dressing Rescuer   Check Rescuer Signals   Assist Rescuer...
Ice Rescue TechniquesRescuer Duties   Prep Equipment   Get Dressed   Check Tender Signals   Move into position   Stan...
Ice Rescue TechniquesIn any form of water rescue    Reach    Throw    Row    GO!
Ice Rescue TechniquesREACH!   Pike Pole   Ladder   Specialized Rescue Devices   Inflated Hose (less than 50‟ away)NO!...
Ice Rescue TechniquesTHROW!  Throw Bag  Flotation Devices  Specialized Rescue DevicesNO! SPARE TIRE PFD
Ice Rescue TechniquesROW!  Sled  Boat  Specialized Rescue DevicesNO! OPEN PROP ICE CHUNKS
Ice Rescue TechniquesGO! Coordinate w/ IC Use spotters Prep equipmentNO! NOT EQUIPPED NOT READY
Ice Rescue TechniquesMove to Patient  Swim  Slide  Crawl  Tap  Talk
Ice Rescue TechniquesReach to Patient   Pole   Flotation Device   Harness
Ice Rescue TechniquesContact Patient   Grab them from behind   If not already done, connect harness   Remember to talk ...
Ice Rescue TechniquesLift / Push Patient      If possible use floatation device,  harness, special rescue device, etc.  ...
Ice Rescue TechniquesLift / Push Patient      If necessary make direct pt. Contact      Use YOUR buoyancy to lift pt.  ...
Ice Rescue Techniques
Ice Rescue Techniques
Ice Rescue Techniques
Ice Rescue TechniquesDon‟t forget the water / land interface!IC should coordinate RESCUE re-sources with EMS resources.The...
What’s wrong with this picture?
Questions?
