  1. 1. Siebel Web Architecture Upgrading from Siebel 2000 to 7
  2. 2. Siebel Web Architecture Overview <ul><li>At a high level, the Siebel architecture consists of: </li></ul><ul><ul><li>Web clients that access the business data </li></ul></ul><ul><ul><li>A Web server that handles interactions with the Web clients </li></ul></ul><ul><ul><li>Servers that manage the business data and provide batch and interactive services for clients </li></ul></ul><ul><ul><li>A relational database and file system that store business data </li></ul></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel File System Siebel Server(s)
  3. 3. Siebel Clients <ul><li>Display the interactive Siebel application used to manage the Siebel data </li></ul><ul><li>Runs in a variety of environments </li></ul><ul><ul><li>Web browsers, WML devices, and PDAs (Windows CE and Palm) </li></ul></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel File System Siebel Server(s)
  4. 4. Web Server <ul><li>Identifies and passes Siebel requests from Web clients to the Siebel servers </li></ul><ul><li>Passes completed HTML application pages back to Web clients </li></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel File System Siebel Server(s)
  5. 5. Siebel Web Server Architecture <ul><li>Consists of a third-party Web server with the following additional Siebel components </li></ul><ul><ul><li>Virtual directories </li></ul></ul><ul><ul><li>Siebel Web Server Extensions (SWSE) </li></ul></ul><ul><ul><li>Configuration file (.CFG) </li></ul></ul>Web Server Virtual Directories SWSE Eapps.cfg Siebel Web Client Siebel Gateway Name Server
  6. 6. Virtual Directory <ul><li>Exists on the Web server to receive inbound Web client requests for each installed Siebel eBusiness application, and forwards these requests to SWSE </li></ul>Web Server Virtual Directories SWSE Eapps.cfg Siebel Web Client Siebel Gateway Name Server
  7. 7. Siebel Web Server Extension (SWSE) <ul><li>Receives and parses inbound HTTP requests from Web clients </li></ul><ul><li>Creates and manages connections to the Siebel Servers or Load Balancer (if implemented) </li></ul><ul><li>Routes requests to the appropriate Siebel Server components </li></ul>Web Server Virtual Directories SWSE Eapps.cfg Siebel Web Client Siebel Gateway Name Server
  8. 8. Eapps.cfg <ul><li>Used by the SWSE </li></ul><ul><ul><li>Is a single configuration file for all Siebel applications </li></ul></ul><ul><li>Contains configuration information, including: connectivity information, login, and security settings </li></ul><ul><li>Contains a connect string for each Siebel application </li></ul>Web Server Virtual Directories SWSE Eapps.cfg Siebel Web Client Siebel Gateway Name Server
  9. 9. Siebel Gateway Name Server <ul><li>Is a Windows service or Unix daemon process </li></ul><ul><li>Dynamically registers Siebel Server and component availability </li></ul><ul><li>Stores component definitions and assignments, operational parameters, and connectivity information </li></ul><ul><ul><li>Stored in siebns.dat file located in ea77gtwysrvrADMIN </li></ul></ul>Siebel Web Client Web Server Siebel Gateway Name Server Enterprise Siebel Server(s)
  10. 10. Enterprise Server <ul><li>Is a logical collection of Siebel Servers that support users accessing a single database server and a single file system </li></ul><ul><li>Logically groups Siebel Servers for common administration via Siebel Server Manager </li></ul><ul><li>Supports sharing of common configuration information </li></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel File System Siebel Server(s)
  11. 11. Siebel Servers <ul><li>Execute tasks to manage the business data </li></ul><ul><ul><li>Interactive processing (for example: supports the Web client running Siebel Call Center) </li></ul></ul><ul><ul><li>Background processing (for example: workflow and business process automation) </li></ul></ul><ul><ul><li>Batch processing (for example: volume data importing) </li></ul></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel File System Siebel Server
  12. 12. Siebel Server Architecture <ul><li>Consists of the following entities: </li></ul><ul><ul><li>Siebel Server </li></ul></ul><ul><ul><ul><li>Siebel Repository File (.SRF) </li></ul></ul></ul><ul><ul><ul><li>Configuration File (.CFG) and Component Parameters </li></ul></ul></ul><ul><ul><ul><li>Siebel Web Templates (.SWT) </li></ul></ul></ul><ul><ul><ul><li>Server components </li></ul></ul></ul>Siebel Web Client Web Server Siebel Gateway Name Server Database Server Enterprise Siebel Server .SRF .CFG .SWT Server Components
  13. 13. Siebel Server <ul><li>Is a Windows service or Unix daemon process </li></ul><ul><li>Is the platform that supports interactive, batch, and background processing for all Siebel clients </li></ul><ul><li>Controls server components running on a machine </li></ul>Siebel Web Client Web Server Siebel Gateway Name Server Enterprise Siebel Server .SRF .CFG .SWT Server Components
  14. 14. Siebel Repository File (.SRF) <ul><li>Separate binary file that defines one or more Siebel applications </li></ul><ul><li>Specifies the: </li></ul><ul><ul><li>Data presentation </li></ul></ul><ul><ul><li>Business rules and processes </li></ul></ul><ul><ul><li>Data organization and storage </li></ul></ul>Enterprise Siebel Server .SRF .CFG .SWT Server Components
  15. 15. Siebel Configuration File (.CFG) and Component Parameters <ul><li>Specify initialization settings of the application at run time, for example: </li></ul><ul><ul><li>Application parameters </li></ul></ul><ul><ul><li>Security settings </li></ul></ul><ul><ul><li>Siebel Gateway Name Server </li></ul></ul><ul><ul><li>Enterprise Server </li></ul></ul>Enterprise Siebel Server .SRF .CFG .SWT Server Components
  16. 16. Siebel Web Templates (.SWT) <ul><li>Set of template files that specify how to render the UI in the user’s browser </li></ul><ul><ul><li>HTML files with embedded Siebel tags defining content </li></ul></ul>Enterprise Siebel Server .SRF .CFG .SWT Server Components
  17. 17. Server Component <ul><li>Is a program that executes on a Siebel Server </li></ul><ul><li>Performs a specific function or job </li></ul><ul><li>Examples include: </li></ul><ul><ul><li>Importing and exporting data </li></ul></ul><ul><ul><li>Configuring the database to monitor for user-defined conditions </li></ul></ul><ul><ul><li>Processing of client requests </li></ul></ul>Enterprise Siebel Server .SRF .CFG .SWT Server Components <ul><li>Examples: </li></ul><ul><li>Application Object Manager </li></ul><ul><li>File System Manager </li></ul><ul><li>Synchronization Manager </li></ul><ul><li>Assignment Manager </li></ul><ul><li>Enterprise Integration Mgr </li></ul>
  18. 18. Application Object Manager <ul><li>Is a server component that creates and processes data at multiple levels </li></ul><ul><ul><li>UI layer </li></ul></ul><ul><ul><li>Business layer </li></ul></ul><ul><ul><li>Data layer </li></ul></ul><ul><li>Provides the environment in which Siebel applications run </li></ul><ul><ul><li>Used by thin clients (Mobile client uses Siebel.exe) </li></ul></ul>Enterprise Siebel Server Server Components AOM File System Manager Within the AOM, UI layer is supported by the Siebel Web Engine. Data layer is supported by the Data Manager.
  19. 19. Database Server <ul><li>Stores data used by Siebel e Business Applications in a predefined database schema </li></ul><ul><li>Supports a variety of third-party relational database management system (RDBMS) </li></ul>Database Server Enterprise Siebel Server Server Components AOM File System Manager The Data Manager, within the AOM, controls access to the Database Server
  20. 20. Siebel File System <ul><li>Is a shared directory that stores compressed files used by Siebel applications </li></ul><ul><ul><li>Examples: Product literature, sales tools, presentations </li></ul></ul><ul><li>Read/write access is controlled by the File System Manager server component </li></ul><ul><ul><li>Easier security administration </li></ul></ul><ul><ul><ul><li>Only the user with administrative privileges for the Siebel Server needs access privileges to the file system directories </li></ul></ul></ul>Enterprise Siebel Server Server Components AOM File System Manager Siebel File System Files System Manager controls access to the Siebel File System 0/3
  21. 21. Uploading an Attachment Using the FSM <ul><li>Attachments are copied from the user's hard drive and transferred to the Siebel Server </li></ul><ul><li>The FSM component compresses the file, and then stores the compressed file in the Siebel File System </li></ul><ul><ul><li>Compression and renaming of the files is automated by the FSM </li></ul></ul>Enterprise Siebel Server Server Components AOM File System Manager Siebel File System Siebel Web Client Web Server Siebel Gateway Name Server File File 2. FSM compresses and renames file 1. File uploaded from local machine 3. File stored in the File System Database Server 1/3
  22. 22. Downloading an Attachment Using the FSM <ul><li>The attachment download request is received by the FSM, which retrieves the requested file </li></ul><ul><ul><li>Decompresses the file and restores its original name </li></ul></ul><ul><li>The file is sent back to the user's Web browser </li></ul>Enterprise Siebel Server Server Components AOM File System Manager Siebel File System Siebel Web Client Web Server Siebel Gateway Name Server File File 2. FSM decompresses and renames file 3. File downloaded to local machine 1. File retrieved from File System Database Server 2/3
  23. 23. Configuring File System Connectivity <ul><li>Web Clients always connect using the FSM </li></ul><ul><li>Mobile Web Clients connect directly to their local file system and synchronise files using the Synchronisation Manager </li></ul><ul><li>Dedicated Web Clients can connect directly to the file system or use the FSM </li></ul><ul><ul><li>Modify the FileSystem parameter in the .cfg file </li></ul></ul>[ServerDataSrc] FileSystem = RBMBFS01siebfileatt [ServerDataSrc] FileSystem = *FSM* Directly access the file system Access the file system using the FSM 3/3
  24. 24. Web Usage Login Scenario <ul><li>Siebel Web Client (browser) sends the URL to the Web server </li></ul><ul><ul><li>URL specifies: </li></ul></ul><ul><ul><ul><li>Either HTTP or HTTPS protocol </li></ul></ul></ul><ul><ul><ul><li>Web server machine name </li></ul></ul></ul><ul><ul><ul><li>Application and language </li></ul></ul></ul><ul><li>URL initially connects to the virtual directory on the Web server </li></ul>1. Browser sends URL to Web server Siebel Web Client < browser > Web Server <websrvr1> Virtual Directory [/callcenter_enu] http://websrvr1/callcenter_enu 2. Connects to the virtual directory on the specified Web server
  25. 25. Web Usage Login Scenario Continued <ul><li>Virtual directory forwards request to the Siebel Web Server Extension (SWSE) installed on the Web server </li></ul><ul><li>SWSE uses the eapps.cfg file to obtain connection parameters </li></ul>Web Server <websrvr1> Virtual Directory [/callcenter_enu] SWSE Eapps.cfg 4. SWSE locates the requested section in eapps.cfg Siebel Web Client < browser > 3. Virtual directory specifies to use SWSE
  26. 26. Web Usage Login Scenario Continued <ul><li>Eapps.cfg specifies the location of the Gateway, Gateway port number, Enterprise, Application Object Manager, and load balancer information for initial connection </li></ul><ul><ul><li>Contains Siebel Server information in the case of no load balancing </li></ul></ul>Siebel Server <SS1> Enterprise – <Siebel> Application Object Manager SCCObjMgr_enu Web Server <websrvr> Siebel Gateway Name Server <gtwysrvr> 5. eapps.cfg specifies connect string values
  27. 27. Web Usage Login Scenario Continued <ul><li>Application Object Manager reads configuration file and component parameters, which specify SRF location, application, and so forth </li></ul>Siebel Server Enterprise <Siebel> Application Object Manager SCCObjMgr_enu .CFG .SRF Database Server Database Server 6. Application Object Manager reads CFG file (or component parameters)
  28. 28. Web Usage Login Scenario Continued <ul><li>The SWE, as part of the Application Object Manager, reads a set of Web templates that are stored on the Siebel Server and creates HTML pages for the data requested </li></ul>Siebel Server Application Object Manager SWE .SWT Database Server Database Server 7. SWE reads Web Templates and creates HTML pages Enterprise <Siebel> .CFG .SRF HTML login page
  29. 29. Web Usage Login Scenario Continued <ul><li>Application Object Manager sends the completed Web page to the Web server, which passes it back to the Web client </li></ul>Web Server <websrvr1> Siebel Server <SS1> Enterprise – <Siebel> Application Object Manager SCCObjMgr_enu HTML login page Siebel Call Center
  30. 30. Physical Architecture <ul><li>The Siebel Gateway Name Server, Siebel Server, Database Server, and File System can be implemented on one machine or spread across multiple machines </li></ul><ul><li>The Siebel Server(s) should have a high-speed LAN connection to the Database Server </li></ul>Siebel Gateway Name Server Enterprise Server Firewall Firewall High-speed LAN Web Server SWSE Siebel Server Siebel File System Database Server Siebel Server
