Thoughts on Deployment


   roger@10Gen.com
        @rogerb
Congratulations !

  Development done ?

Toll ! Ready to Deploy :-)
some points to consider
Agenda
• Sizing Your Hardware
   • memory   / cpu / disk io
• Software
   • os / filesystem
• Installing MongoDB
• EC2 Not...
Sizing Hardware: Memory
• Memory Mapped files
   • Maps DB on Filesystem to Memory
   • Minor Page Faults - in memory - ch...
Sizing Hardware: CPU
• MongoDB uses multiple cores
   • For working-set queries, CPU usage is minimal
   • Generally, fast...
Sizing Hardware: I/O
• Disk I/O determines performance of non-working set queries
• More Disks = Better
    • Improved thr...
IOStat
   iostat
  -­‐x
  2
   iostat
  -­‐w
  1
            disk0                      disk1                         ...
OS
• For production: Use a 64bit OS
   • 32bit has 2G limit
   • Clients can be 32 bit
• MongoDB supports (little endian o...
Filesystem
• All data, namespace files stored in data directory
   • Possible to create links
   • Better to aggregrate IO...
Filesystem


• MongoDB is filesystem-neutral:
   • ext3, ext4 and XFS are most used
   • ext4 / XFS preferred (posix_filea...
MongoDB Version Policy


• Production: run even numbers
   • 1.4.x, 1.6.x, 1.8.x
•Development
   •1.5.x, 1.7.x
• Critical ...
Installing MongoDB

• Installing from Source
   • Requires Scons, C++ compiler, Boost libraries, ...

• Installing from Bi...
EC2 Notes

• Default storage instance is EXT3
   • For best performance, reformat to EXT4 / XFS

• Use Striping (using MDA...
More EC2 Notes


• EBS snapshots can be used for backups
   • EBS can disappear
• S3 can be used for longer term backups
•...
Security
• Mongo supports basic security
• We encourage to run mongoDB in a safe environment
• Authenticates a User on a p...
Backup
• Typically backups are driven from a slave
• Eliminates impact to client / application traffic to master
Backup



•Two main Strategies
   • mongodump / mongorestore
   • Filesystem
   • Filelock + fsync
mongodump


• binary, compact object dump
• each consistent object is written
• not necessarily consistent from start to f...
Filesystem Backup

• MUST
   •fsync - flushes buffers to disk
   • lock - blocks writes
      db.runCommand({fsync:1,lock:...
Durability


 What failures do you need to recover from?
• Loss of a single database node?
• Loss of a group of nodes?
Durability - Master only

• Write acknowledged
when in memory on
master only
Durability - Master + Slaves
• W=2
•Write acknowledged
when in memory on
master + slave
• Will survive failure of a
single...
Durability - Master + Slaves +
                 fsync
• W=n
•Write acknowledged
when in memory on
master + slaves
• Pick a...
Slave delay
• Protection against app
faults
• Protection against
administration mistakes
• Slave runs X amount of
time beh...
Scale out
read

       shard1   shard2   shard3

                                    mongos
  /

       rep_a1   rep_a...
Monitoring

   • We like Munin ..
   • ... but other frameworks
       work as well


   • Primary function:
   • Measure ...
Thank You :-)
  @rogerb
download at mongodb.org

                conferences,
  appearances,
  and
  meetups
                                  ...
Deployment
Upcoming SlideShare
Loading in …5
×

Deployment

1,642 views
1,586 views

Published on

Notes / Considerations for deployment. Feedback / commments welcome :-)

0 Comments
7 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total views
1,642
On SlideShare
0
From Embeds
0
Number of Embeds
153
Actions
Shares
0
Downloads
37
Comments
0
Likes
7
Embeds 0
No embeds

No notes for slide

Deployment

  1. 1. Thoughts on Deployment roger@10Gen.com @rogerb
  2. 2. Congratulations ! Development done ? Toll ! Ready to Deploy :-)
  3. 3. some points to consider
  4. 4. Agenda • Sizing Your Hardware • memory / cpu / disk io • Software • os / filesystem • Installing MongoDB • EC2 Notes • Security • Backup • Durability • Upgrading • Monitoring • Scaling out
  5. 5. Sizing Hardware: Memory • Memory Mapped files • Maps DB on Filesystem to Memory • Minor Page Faults - in memory - cheap • Major Page Faults - not in memory - from disk - expensive • Indices • Part of the regular DB files • Can be completely in memory .. • Or partially • Working set should be as much in memory as possible, but
  6. 6. Sizing Hardware: CPU • MongoDB uses multiple cores • For working-set queries, CPU usage is minimal • Generally, faster CPU are better • Aggregation, Full Tablescans •Makes heavy use of CPU / Disk •Instead of counting / computing: • cache / precompute • Map Reduce • Currently Single threaded •Parallel in sharded environments. • This restriction may be eliminated, investigating options
  7. 7. Sizing Hardware: I/O • Disk I/O determines performance of non-working set queries • More Disks = Better • Improved throughput, Reduced Seek times • Raid 0 - Striping: improved write performance • Raid 1 - Mirroring: survive single disk failure • Raid 10 - both • Flash •Expensive, getting cheaper •Significantly reduced seek time, increased IO throughput • Network •It’s easy to saturate your network
  8. 8. IOStat iostat  -­‐x  2 iostat  -­‐w  1 disk0 disk1 disk2 cpu load average KB/t tps MB/s KB/t tps MB/s KB/t tps MB/s us sy id 1m 5m 15m 12.83 3 0.04 2.01 0 0.00 12.26 2 0.02 11 5 83 0.35 0.26 0.25 11.12 75 0.81 0.00 0 0.00 0.00 0 0.00 60 24 16 0.68 0.34 0.28 4.00 3 0.01 0.00 0 0.00 0.00 0 0.00 60 23 17 0.68 0.34 0.28 avg-cpu: %user %nice %system %iowait %steal %idle 0.00 0.00 7.96 29.85 0.50 61.69 Device: rrqm/s wrqm/s r/s w/s rsec/s wsec/s avgrq-sz avgqu-sz await svctm %util sda1 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 sda2 0.50 4761.19 6.47 837.31 75.62 43681.59 51.86 38.38 42.33 0.46 38.41 Monitor  disk  transfers  :   >  200  -­‐  300  Mb/s  on  XL  EC2,    but  your  mileage  may  vary CPU  usage >  30  %  during  normal  operations
  9. 9. OS • For production: Use a 64bit OS • 32bit has 2G limit • Clients can be 32 bit • MongoDB supports (little endian only): • Linux • Windows • Solaris (joyent)
  10. 10. Filesystem • All data, namespace files stored in data directory • Possible to create links • Better to aggregrate IO across disks •File Allocation
  11. 11. Filesystem • MongoDB is filesystem-neutral: • ext3, ext4 and XFS are most used • ext4 / XFS preferred (posix_fileallocate()) • improved performance for file allocation • Support for NTFS for windows
  12. 12. MongoDB Version Policy • Production: run even numbers • 1.4.x, 1.6.x, 1.8.x •Development •1.5.x, 1.7.x • Critical bugs are back ported to even versions
  13. 13. Installing MongoDB • Installing from Source • Requires Scons, C++ compiler, Boost libraries, ... • Installing from Binaries (easiest) • curl -O http://downloads.mongodb.org/_os_/_version_ • Upgrading database • Install new version of MongoDB • Stop previous version • Start new version
  14. 14. EC2 Notes • Default storage instance is EXT3 • For best performance, reformat to EXT4 / XFS • Use Striping (using MDADM or LVM) aggregates I/O •This is a good thing • EC2 can experience spikes in latency • 400-600mS •This is a bad thing
  15. 15. More EC2 Notes • EBS snapshots can be used for backups • EBS can disappear • S3 can be used for longer term backups • Use Amazon availability zones • High Availability • Disaster Recovery
  16. 16. Security • Mongo supports basic security • We encourage to run mongoDB in a safe environment • Authenticates a User on a per Database basis • Start database with --auth • Admin user stored in the admin database use admin db.addUser("administrator", "password") db.auth(“administrator”, “password”) • Regular users stored in other databases use personnel db.addUser("joe", "password") db.addUser(“fred”, “password”, true)
  17. 17. Backup • Typically backups are driven from a slave • Eliminates impact to client / application traffic to master
  18. 18. Backup •Two main Strategies • mongodump / mongorestore • Filesystem • Filelock + fsync
  19. 19. mongodump • binary, compact object dump • each consistent object is written • not necessarily consistent from start to finish • mongorestore to restore database • database does not have to be up to restore
  20. 20. Filesystem Backup • MUST •fsync - flushes buffers to disk • lock - blocks writes db.runCommand({fsync:1,lock:1}) • Use file-system / LVM / storage snapshot • unlock db.$cmd.sys.unlock.findOne();
  21. 21. Durability What failures do you need to recover from? • Loss of a single database node? • Loss of a group of nodes?
  22. 22. Durability - Master only • Write acknowledged when in memory on master only
  23. 23. Durability - Master + Slaves • W=2 •Write acknowledged when in memory on master + slave • Will survive failure of a single node
  24. 24. Durability - Master + Slaves + fsync • W=n •Write acknowledged when in memory on master + slaves • Pick a “majority” of nodes • fsync in batches (since it blocking)
  25. 25. Slave delay • Protection against app faults • Protection against administration mistakes • Slave runs X amount of time behind
  26. 26. Scale out read shard1 shard2 shard3 mongos  /   rep_a1 rep_a2 rep_a3 config  server mongos  /   rep_b1 rep_b2 rep_b3 config  server mongos  /   rep_c2 rep_c2 rep_c3 config  server write
  27. 27. Monitoring • We like Munin .. • ... but other frameworks work as well • Primary function: • Measure stats over time
  28. 28. Thank You :-) @rogerb
  29. 29. download at mongodb.org conferences,  appearances,  and  meetups http://www.10gen.com/events Facebook                    |                  Twitter                  |                  LinkedIn http://bit.ly/mongoN   @mongodb http://linkd.in/joinmongo

×
