  • 1. Triplificating and Linking XBRL Financial Data Roberto García, Rosa Gil HCI & Data Integration Research Group Universitat de Lleida, Spain 6th International Conference on Semantic Systems, I-SEMANTICS'10, 1-3 September 2010, Graz, Austria
  • 2. Introduction
    • Explore Semantic Web technologies for financial information
    • Most public financial data available as XBRL
    • Reuse this data, map XBRL to RDF
      • Apply generic mapping: ReDeFer
        • XSD2OWL, XML2RDF
    • Publish as Linked Data using Rhizomer
  • 3. Approach
    • Reuse XBRL data and schemas
    • Facilitate roundtrip:
      • XBRL  SW  XBRL
    • Showcase Semantic Web benefits
    • Test data: SEC’s EDGAR voluntary program 1
    1 From 2009, 3 year phased-in schedule, by end 2011 all U.S. public companies plus 8,000 mutual funds
  • 4. ReDeFer
    • Part of the Rhizomik initiative
    • ReDeFer (in and out Semantic Web)
      • RDF2HTML+RDFa
      • RDF2SVG
      • XML2RDF
      • XSD2OWL
      • Use cases: MPEG-7, MPEG-21, …
  • 5. XBRL XML to RDF
    • ReDeFer XML2RDF , model XML tree using triples
      • xsd:element and xsd:atribute  rdf:Property
      • xbrli:id and xbrli:identifier  rdf:Resource ID
      • Other resources, anonymous
    Rendered by RDF2SVG
  • 6. XBRL XSD to OWL
    • XBRL Schemas: XBRL 2.1, US GAAP 1 ,…
    • ReDeFer XSD2OWL
    Core classes and properties for XBRL Instance XSD2OWL mappings 1 Ontologies available from http://rhizomik.net/ontologies/bizontos XML Schema OWL element | attribute rdf:Property owl:DatatypeProperty owl:ObjectProperty [email_address] rdfs:subPropertyOf [email_address] rdfs:range complexType owl:Class complexType//element owl:Restriction extension@base | restriction@base rdfs:subClassOf @maxOccurs, @minOccurs owl:maxCardinality, owl:minCardinality sequence, choice owl:intersectionOf, owl:unionOf
  • 7. XML2RDF plus XSD2OWL
    • Enrich RDF with links to classes for corresponding XSD complexTypes :
  • 8. XBRL Sources
    • SEC’s EDGAR filings data files:
    http://www.sec.gov/Archives/edgar/xbrlrss.xml http://www.sec.gov/Archives/edgar/usgaap.rss.xml XML2RDF XSD2OWL Calculations Labels Presentation Definition
  • 9. XBRL Ontologies adbe-20090828.owl adbe-20090828.rdf adbe-20090529.rdf XBRL 2.1 US-GAAP Non-GAAP adbe-20090529.owl … adbe-20080916.rdf … adbe-20080829.owl
  • 10. Ontology Alignment
    • Integrate ontologies for different filings
      • E.g.: adbe-20080530.owl:InvestmentLeaseReceivable = adbe-20080829.owl:Investment In LeaseReceivable
      • Ontology alignment tools (edit distance)
      • Perform queries across filings
  • 11. Semantic XBRL
    • Dataset size
      • Sept 2010: 9,19 million triples from 2974 XBRL filings
      • Available from http://rhizomik.net/semanticxbrl/
  • 12. Semantic XBRL
    • Linked Data:
      • Links to DBPedia:
        • Companies: Central Index Key (CIK) , name or ticker through dbpprop:redirect
          • dbpedia:Microsoft is dbpprop:redirect of dbpedia:MSFT
        • Units: e.g. USD  dbpedia:United_States_dollar
      • Links to Corporate Ownership RDF Data 1 :
        • (Individual ownership and subsidiaries)
        • Companies: CIK
    1 http://www.rdfabout.com/demo/sec/
  • 13. Architecture
  • 14. Prototype Demo
    • Rhizomer :
    • publish
    • query
    • browse
    • edit
    • mashup (map, timeline,…)
    • etc.
  • 15. Get a context description from its URL http://rhizomik.net/semanticxbrl/adbe-20081216/From20071201-To20081128_None_None_StatementOperatingActivitiesSegmentAxis_KnowledgeWorkerSolutions
  • 16. Reuse Wikipedia data (DBPedia) http://rhizomik.net/semanticxbrl/?query=DESCRIBE <http://dbpedia.org/resource/Adobe_Systems>
  • 17. Get all Investment[In]LeaseReceivable http://rhizomik.net/semanticxbrl/?query=DESCRIBE ?o WHERE { ?s ?p ?o . ?p <http://www.w3.org/2000/01/rdf-schema#subPropertyOf> <http://rhizomik.net/ontologies/bizontos/xbrl-edgar/adbe-20080530.owl#InvestmentLeaseReceivable> . }
  • 18. Integrate different CIK variants
  • 19. Conclusions
    • XBRL tools : for financial information edition and maintenance (formulae, …)
    • Semantic Web tools : data integration (linked data), cross querying, …
      • Across filings, companies, accounting principles,…
    XSD2OWL XML2RDF
  • 20. Future Work
    • Systematic mappings across filings for the same company
    • Explore mappings:
      • Across companies
      • A cross accounting principles …
    • Develop demo webpps:
      • E.g.: show accounting data for ownership/subsidiary networks of companies…
  • 21. Thank you for your attention Roberto García [email_address] http://rhizomik.net/~roberto HCI & Data Integration Research Group Universitat de Lleida, Spain
