  • 1. www.schultzandsummers.com Our Company & Expertise New Orleans Levee Branson Airport
  • 2. SSE Owners
    • Water treatment and distribution
    • Wastewater collection and treatment
    • Storm water drainage
    • Construction observation
    • Roads, highways and bridges
    • Subdivisions
    • Commercial site development
    • Environmental site assessment
    • Environmental permitting
    • Generation, transmission and distribution systems for electric utilities
    • Right-of-way acquisition
    • Project Funding
    •
    Expertise in Civil Engineering   Stanley Schultz, P.E., R.L.S – Principal Bob Summers, P.E., – Principal Founder of Schultz Engineering in 1997 Joined ownership in 2007 became Schultz and Summers Engineering
  • 3. April 29, 2011 Satellite View of Flooding
  • 4.   IMPACT
    • Reached a record height over 400 feet.
    • Large agricultural areas and small farmsteads are swallowed by deep waters
    • Small towns and portions of large cities being flooded by muddy inundations
    • Part of the area where the Mississippi and Ohio rivers meet has received over 2 feet of rain in a little over three weeks.
    Wappapello Lake in Wayne County (AP Photo/Daily American Republic, Paul Davis) Tuesday, May 3, 2011 Wappapello Lake flows over its emergency spillway and into the already swollen St. Francis River.
  • 5.   IMPACT
    • Record Rainfall of 21.39 inches for April 2011
    • 1000 Homes Evacuated
    • Highway 60 Closure
    Butler County Black River Levee Area
  • 6.   IMPACT
    • Hundreds of Homes Flooded
    • Branson Landing Flooded
    • April 27, 2011 the height of Table Rock Lake reached a record level of 935.3 feet.
    • Unprecedented Water Release of 68,000 cubic feet per second.
    Branson Flooding in Taney County
  • 7.   IMPACT As predicted, the two-mile hole in the levee flooded 130,000 acres of nearby farmland in what is known as the Birds Point-New Madrid Floodway . Birds Point Flooding Area May 2, 2011 In an effort to spare Cairo, Illinois, and reduce downstream flooding, the U.S. Army Corps of Engineers used explosives to breach a protective levee near the confluence of the Ohio and Mississippi Rivers.
  • 8. Birds Point USACE Levee Map Satellite View of Affected Area
  • 9. Our Levee Work In New Orleans
  • 10.
    • ALTA/ACSM
    • Boundary
    • Engineering design
    • Construction layout
    • Mortgage
    • Floodplain Certification
    •
    •
    • ALTA/ACSM
    • Boundary
    • Engineering design
    • Construction layout
    • Mortgage
    • Floodplain Certification
    •
    •
    Land Surveying   Materials Testing
    • Concrete Testing
    • Soil Testing
    • Aggregate Testing
    • Asphalt Testing
    •
    Materials Testing & Land Surveying   “ They have a proven track record for dependable service, accurate test results and competitive pricing.” - William Wheeler, QC Manager Archer Western Contractors   “ They have a proven track record for dependable service, accurate test results and competitive pricing.” - William Wheeler, QC Manager Archer Western Contractors
  • 11. USACE BPA QA Projects Table 2. Quality Assurance – In Progress Federal Projects Customer Project Project Number USACE - New Orleans, LA WBV 09a Eastern Tie-In, Hero to Oakville, Phase II W912P8-10-C-0089 Quality Assurance – Completed Federal Projects Customer Project Project Number USACE - New Orleans, LA LPV 147 Floodgate and Tie Ins W912P8-10-D-0010-0003 USACE - New Orleans, LA LPV 7D.2 Almedia/Walker Drainage Structure - Phase 2 W912P8-09-D-0048-0002 USACE - New Orleans, LA Bonne Carre Upper Guide Levee Enlargement W912P8-09-D-0052-0006 USACE - New Orleans, LA WBV 18.2 Lake Cataouache Levee Enlargement, Phase 2 W912P8-09-C-0105 USACE - New Orleans, LA WBV 14g.2 Estelle PS and Vicinity Floodwalls W912P8-09-D-0045-0002 USACE - New Orleans, LA LPV 18.2 Williams Boulevard Floodgate W912P8-09-D-0046-0004 USACE - New Orleans, LA Utility Relocation (Reach5) W912P8-10-Z-0002 USACE - New Orleans, LA Bayou Trepagnier Complex Floodwall W912P8-09-D-0043-0004 USACE - New Orleans, LA Reach 2A Shell Pipeline W912P8-09-D-0052-0005 USACE - New Orleans, LA LPV 3d.2 Airport Levee W912P8-08-D-0044-0004 USACE - New Orleans, LA LPV-06e.2 Floodwall under I-310 W912P8-10-C-0075 USACE - New Orleans, LA LPV 04.2a Reach 1A Cross Bayou to St. Rose & Gulf South Floodwall, Ph. 2 W912P8-09-D-0052-0004 USACE - New Orleans, LA LPV 19.2 Reach 4, 3rd Enlargement Lakefront Levee W912P8-09-D-0046-0003 USACE - New Orleans, LA LPV 00.2 Reach 1, 4th Enlargement W912P8-09-D-0046-0002 USACE - New Orleans, LA Reach 2A W912P8-09-D-0046-0005 USACE - New Orleans, LA WBV 14f.2 Hwy 45 Levee, Phase 2 W912P8-08-D-0040-0002 USACE - New Orleans, LA LPV 04.2b Reach 1B Phase 2, from I-310 to Walker Drainage Structure W912P8-09-D-0045-0005 USACE - New Orleans, LA LPV 12a.2 Duncan Pump Station W912P8-09-C-0106 USACE - New Orleans, LA SELA 18, Dwyer Road Intake Canal W912P8-08-C-0093 USACE - New Orleans, LA LPV 16.2 Bonnabel Blvd. Flood Gate W912P8-09-D-0044-0002 Quality Assurance – In-Process Federal Projects Customer Project Project Number USACE - New Orleans, LA WBV 09a Eastern Tie-In, Hero to Oakville, Phase II W912P8-10-C-0089
  • 12. Cost of Labor – One Mile of New Levee Alternative 1: Prevailing Wage Rates for Butler County Per Hour Operator $46.22 Labor $33.85 Truck Driver $35.69 Quantity Unit Production Trucking Labor (per 30) Labor (Per 4) Equipment Labor (per 5) Total Unit Price Earthwork 189,200.00 CY 3000 $675,254.80 $85,392.27 $145,747.07 $906,394.13 $4.79 Alternative 2: Local Wage Rates for Butler County Per Hour Operator $25.00 Labor $15.00 Truck Driver $17.00 Quantity Unit Production Trucking Labor (per 30) Labor (Per 4) Equipment Labor (per 5) Total Unit Price Earthwork 189,200.00 CY 3000 $283,800.00 $37,840.00 $63,066.67 $438,313.33 $2.32
  • 13.
    • USACE Disaster Operations Public Law 84-99
    • Emergency Watershed Protection Program (EWP)
    • Federal Appropriations
    • Wave Easement recording fees
    • Streamline condemnation proceedings
    • Reduced environmental hurdles and roadblocks
    • Reduce Liability on Emergency Levee work
    FUNDING OPTIONS & STREAMLING SUGGESTIONS SEMA/FEMA SEMA/FEMA
  • 14. USACE Disaster Operations Public Law 84-99
    • Local district must request to participate in this program
    • USACE assigns project manager and team to assess damage and costs
    • Funding decision is made at the division level
    • It is a 75%-25% match program
  • 15. Emergency Watershed Protection Program (EWP)
    • 75% - 25% match
    • 25% can be in-kind from the local sponsor
    • Only available in an area where an emergency has been declared
    • Non-emergency work can go on for years
  • 16. Federal Appropriations
    • 1 Billion to Repair Levee
    • Passed Committee
    • If passed in the Senate and the President signs it will be available October 1, 2011
    • JoAnn Emerson is working with members up and down the Mississippi River to support this funding
    Emerson: $1 Billion to Repair Levee System WASHINGTON – U.S. Rep. JoAnn Emerson (MO-08) said that a Chairman’s amendment to the House Energy and Water Appropriations Act of 2012 included an additional $1 BILLION for the U.S. Army Corps of Engineers to repair levees throughout the United States, with $589.5 MILLION set aside at her request for the Mississippi River and Tributaries system .   That system includes the Birds Point levee and Mississippi River levees which border the Eighth Congressional District. U.S. Rep. Jo Ann Emerson
  • 17. Streamline Suggestions
    • Streamline Condemnation Proceedings
    • Reduced Environmental Hurdles and Roadblocks
    • Reduce Liability on Emergency Levee Work
  • 18. Thank you for this opportunity, are there any questions?
