RIPE NCC StatusUpdateIPv4 and moreMarco Hogewoning, Trainer
The five RIRsMarco Hogewoning, 10 March 2011   2
RIPE NCC•   Service region: Europe, Middle East and parts of    Central Asia•   Supports coordination of Internet operatio...
Agenda•   Resource distribution     – IPv4     exhaustion and policy     – IPv6     policy change•   Statistics and measur...
IPv4 Run Out
IPv4 distribution                                           IANA       3 February 2011         AfriNIC                  AR...
Our slice of the IPv4 pie                                      Organisations                         Other IANA           ...
IPv4 exhaustion phases                    IPv4 still available.                                                    Final /...
Business as usual•   As long as there are IPv4 addresses left, the    RIPE NCC will keep on distributing them•   Same allo...
“Run Out Fairly”•    Gradually reduced allocation and assignment     periods•    Needs for “Entire Period” of up to...    ...
Final /8 policy•   Each LIR can get one /22 allocation•   You must meet the criteria for an (additional)    allocation•   ...
Transfer of IPv4 allocations•   LIRs can transfer IPv4 address blocks:     – To    another LIR     – Only      when the bl...
No changes yet•   Policy will only change when the RIPE NCC’s    final /8 is reached•   Be aware of the shorter assignment ...
Registration Data Quality (RDQ) project•   Comparing various information sources:     – RIPE      Database     – Internal ...
Unannounced early registration addresses•   Builds on the RDQ project•   Identify legacy space which is currently not    a...
IPv6
Registration of IPv6 assignments•   Until now:     – Assignments  up to a /48 didn’t need to be registered       in the RI...
Registration of IPv6 assignments (2)•   All assignments must now be registered in the    RIPE Database•   This includes ex...
Grouping of assignments•   New status value: AGGREGATED-BY-LIR•   New attribute called assignment-size•   Create one objec...
Registering all assignments                                        ALLOCATED-BY-RIR ALLOCATED-BY-LIR                 /36  ...
Using AGGREGATED-BY-LIR                                        ALLOCATED-BY-RIR                                           ...
AGGREGATED-BY-LIR   inet6num:                      2001:db8:1000::/36   netname:                       Bluelight   descr: ...
AGGREGATED-BY-LIR   inet6num:                      2001:db8:1000::/36   netname:                       Bluelight   descr: ...
IPv6 Statistics
IPv6 allocations and announcements6000                                                RIPE NCC Allocations                ...
IPv6 statistics•   RIPEness rating system. Stars awarded for:     – Requesting            an allocation     – Creating    ...
IPv6 RIPEness: total (7,350 LIRs)                                  1 star                                  12%            ...
IPv6 RIPEness: Sweden ( 251 LIRs)                                  1 star                                  14%            ...
IPv6 RIPEness: region400300200100 0         Sweden       Norway       Finland       Denmark   Netherlands   France     Spa...
IPv6 RIPEness: region100%75%50%25% 0%          Sweden       Norway       Finland       Denmark   Netherlands   France     ...
Outreach
Training courses•   LIR, IPv6 and Routing Registry courses•   Locations throughout the RIPE NCC service    region•   ‘Stan...
Meetings•   RIPE 62 in Amsterdam, 2 - 6 May 2011•   Regional meetings 2011:     – Damascus,             Syria (14 - 15 May...
Other events•   MENOG IPv6 Roadshows (dates tbc)     –5    day technical workshops     – Amman           (JO), Riyadh (SA)...
Projects
RIPE Database API•   RESTful web interface•   Data returned in XML•   API documentation on RIPE Labs•   For a demo visit h...
RIPEstat•   Toolbox to access the various datasets the RIPE    NCC publishes:     – Resource           registration detail...
More information•   http://ripe.net/v4exhaustion•   http://www.ipv6actnow.org•   http://ripeness.ripe.net•   http://labs.r...
Questions?
Upcoming SlideShare
Loading in...5
×

RIPE NCC Status Update

1,252

Published on

Presentation given by Marco Hogewoning at NETNOD

Published in: Technology
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
1,252
On Slideshare
0
From Embeds
0
Number of Embeds
1
Actions
Shares
0
Downloads
2
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

RIPE NCC Status Update

  1. 1. RIPE NCC StatusUpdateIPv4 and moreMarco Hogewoning, Trainer
  2. 2. The five RIRsMarco Hogewoning, 10 March 2011 2
  3. 3. RIPE NCC• Service region: Europe, Middle East and parts of Central Asia• Supports coordination of Internet operations• Not-for-profit membership organisation• Over 7,000 members• Neutral, impartial, open and transparent• RIPE: self regulated, open to everyoneMarco Hogewoning, 10 March 2011 3
  4. 4. Agenda• Resource distribution – IPv4 exhaustion and policy – IPv6 policy change• Statistics and measurements – IPv6 statistics• Outreach and education – Training courses – Meetings• New projectsMarco Hogewoning, 10 March 2011 4
  5. 5. IPv4 Run Out
  6. 6. IPv4 distribution IANA 3 February 2011 AfriNIC ARIN RIPE NCC APNIC LACNIC ? 7,000 LIRs End UsersMarco Hogewoning, 10 March 2011 6
  7. 7. Our slice of the IPv4 pie Organisations Other IANA AfriNIC LACNICRIPE NCC ARIN APNICMarco Hogewoning, 10 March 2011 7
  8. 8. IPv4 exhaustion phases IPv4 still available. Final /8 policy RIPE NCC can only RIPE NCC continues triggered distribute IPv6 normal operation now time IANA pool RIPE NCC RIPE NCC exhausted reaches pool final /8 exhausted Each of the 5 RIRs received a /8Marco Hogewoning, 10 March 2011 8
  9. 9. Business as usual• As long as there are IPv4 addresses left, the RIPE NCC will keep on distributing them• Same allocation and assignment policies still apply (RIPE-509)• Until the final /8 is reachedMarco Hogewoning, 10 March 2011 9
  10. 10. “Run Out Fairly”• Gradually reduced allocation and assignment periods• Needs for “Entire Period” of up to... – 12 months (January 2010) –9 months (July 2010) –6 months (January 2011) –3 months (July 2011)• 50% has to be used up by half-period Marco Hogewoning, 10 March 2011 10
  11. 11. Final /8 policy• Each LIR can get one /22 allocation• You must meet the criteria for an (additional) allocation• Only when you already have IPv6 addresses• A /16 is reserved for unforeseen circumstances• No provider independent (PI) assignmentsMarco Hogewoning, 10 March 2011 11
  12. 12. Transfer of IPv4 allocations• LIRs can transfer IPv4 address blocks: – To another LIR – Only when the block is not in use – Meets minimum allocation size (/21)• Requests are evaluated by the RIPE NCC• Registered in the RIPE DatabaseMarco Hogewoning, 10 March 2011 12
  13. 13. No changes yet• Policy will only change when the RIPE NCC’s final /8 is reached• Be aware of the shorter assignment period!• And start deploying IPv6 now!Marco Hogewoning, 10 March 2011 13
  14. 14. Registration Data Quality (RDQ) project• Comparing various information sources: – RIPE Database – Internal registration files – RIS (Routing Information Service)• Find and fix inconsistencies• Strengthen data quality where necessaryMarco Hogewoning, 10 March 2011 14
  15. 15. Unannounced early registration addresses• Builds on the RDQ project• Identify legacy space which is currently not announced• Contact the holders about the possibility of returning those addresses• Over 400 organisations contacted already• ~ 500k addresses returned over the past two monthsMarco Hogewoning, 10 March 2011 15
  16. 16. IPv6
  17. 17. Registration of IPv6 assignments• Until now: – Assignments up to a /48 didn’t need to be registered in the RIPE Database – Had to be registered at the LIR level – Very ambiguous policy text – What to register? – What means accessible by the RIR?Marco Hogewoning, 10 March 2011 17
  18. 18. Registration of IPv6 assignments (2)• All assignments must now be registered in the RIPE Database• This includes existing assignments• Method introduced to minimise the number of objects you have to create and maintainMarco Hogewoning, 10 March 2011 18
  19. 19. Grouping of assignments• New status value: AGGREGATED-BY-LIR• New attribute called assignment-size• Create one object covering multiple assignments that share description and contacts• Indicating the size of individual assignmentsMarco Hogewoning, 10 March 2011 19
  20. 20. Registering all assignments ALLOCATED-BY-RIR ALLOCATED-BY-LIR /36 ASSIGNED /44 /48 /48 /56 /48 /48 /48 /56 /56 /48 assignment =< /48Marco Hogewoning, 10 March 2011 20
  21. 21. Using AGGREGATED-BY-LIR ALLOCATED-BY-RIR AGGREGATED-BY-LIR ALLOCATED-BY-LIR /36 ASSIGNED /44 assignment-size: 56 /34 AGGREGATED-BY-LIR assignment-size: 48 /40 hint :) /48 /48 /48 /48 /48Marco Hogewoning, 10 March 2011 21
  22. 22. AGGREGATED-BY-LIR inet6num:        2001:db8:1000::/36 netname:         Bluelight descr:           We want more Bluelight B.V. descr:      Colocation services country:          NL admin-c:         BN649-RIPE tech-c:          BN649-RIPE mnt-by:          BLUELIGHT-MNT notify:          noc@example.net changed:        noc@example.net 20110218 source:         RIPEMarco Hogewoning, 10 March 2011 22
  23. 23. AGGREGATED-BY-LIR inet6num:        2001:db8:1000::/36 netname:         Bluelight descr:           We want more Bluelight B.V. descr:      Colocation services country:          NL admin-c:         BN649-RIPE tech-c:          BN649-RIPE status:          AGGREGATED-BY-LIR assignment-size: 48 mnt-by:          BLUELIGHT-MNT notify:          noc@example.net changed:        noc@example.net 20110218 source:         RIPEMarco Hogewoning, 10 March 2011 23
  24. 24. IPv6 Statistics
  25. 25. IPv6 allocations and announcements6000 RIPE NCC Allocations Total Worldwide Allocations Total Worldwide Announcements50004000300020001000 0 2004 2005 2006 2007 2008 2009 2010 2011Marco Hogewoning, 10 March 2011 25
  26. 26. IPv6 statistics• RIPEness rating system. Stars awarded for: – Requesting an allocation – Creating a route object – Announcing your space – Setting up reverse DNS• Free t-shirt if you make it to 4 stars :)Marco Hogewoning, 10 March 2011 26
  27. 27. IPv6 RIPEness: total (7,350 LIRs) 1 star 12% 2 stars 5%No IPv6 62% 3 stars 9% 4 stars 13%Marco Hogewoning, 10 March 2011 27
  28. 28. IPv6 RIPEness: Sweden ( 251 LIRs) 1 star 14% 2 stars 2%No IPv6 58% 3 stars 8% 4 stars 18%Marco Hogewoning, 10 March 2011 28
  29. 29. IPv6 RIPEness: region400300200100 0 Sweden Norway Finland Denmark Netherlands France Spain Switzerland No IPv6 1 star 2 star 3 star 4 star Marco Hogewoning, 10 March 2011 29
  30. 30. IPv6 RIPEness: region100%75%50%25% 0% Sweden Norway Finland Denmark Netherlands France Spain Switzerland No IPv6 1 star 2 star 3 star 4 star Marco Hogewoning, 10 March 2011 30
  31. 31. Outreach
  32. 32. Training courses• LIR, IPv6 and Routing Registry courses• Locations throughout the RIPE NCC service region• ‘Standalone’ but also in conjunction with other events, like NOG meetings• 33 courses now scheduled until end Q2 2011• See https://lirportal.ripe.net/training/coursesMarco Hogewoning, 10 March 2011 32
  33. 33. Meetings• RIPE 62 in Amsterdam, 2 - 6 May 2011• Regional meetings 2011: – Damascus, Syria (14 - 15 May date changed) – Moscow, Russia (6 - 8 June) – Dubrovnik, Croatia (7 - 9 September TBC) – Muscat, Oman ( 27 - 28 September)• RIPE 63 in Vienna, Austria ( 31 October - 4 November 2011)Marco Hogewoning, 10 March 2011 33
  34. 34. Other events• MENOG IPv6 Roadshows (dates tbc) –5 day technical workshops – Amman (JO), Riyadh (SA), Dubai (AE) and others• Roundtable Meetings – Next one coming up 4 April 2011, Amsterdam (NL) – Invite onlyMarco Hogewoning, 10 March 2011 34
  35. 35. Projects
  36. 36. RIPE Database API• RESTful web interface• Data returned in XML• API documentation on RIPE Labs• For a demo visit http://lab.db.ripe.net/portal/Marco Hogewoning, 10 March 2011 36
  37. 37. RIPEstat• Toolbox to access the various datasets the RIPE NCC publishes: – Resource registration details – Routing Information Service (RIS) – Test Traffic Measurements (TTM)• Public demo sessions every four weeks using webex, see http://labs.ripe.net/ripestatMarco Hogewoning, 10 March 2011 37
  38. 38. More information• http://ripe.net/v4exhaustion• http://www.ipv6actnow.org• http://ripeness.ripe.net• http://labs.ripe.netMarco Hogewoning, 10 March 2011 38
  39. 39. Questions?
