Examples of Specialized Legal Metadata to the Digital Environment, From the U.S. Code of Federal Regulations<br />Thomas R...
The Problem: “Islands”<br />Governments create multiple sources of law<br />The sources are interrelated, but exist as iso...
The Problem: Example<br />Example: How to find all regulations issued pursuant to US Food, Drug, & Cosmetic Act, 21 U.S.C....
One Solution: “Ponts”<br />In the print environment, specialized legal metadata sources were created, to make explicit rel...
Ponts: Proprietary vs. Public Domain<br />Proprietary ponts are of limited use in digital environment because of usage res...
Public domain ponts—like those created by U.S. federal government, which are free from copyright, 17 U.S.C. § 105—lack usa...
Example of a Pont: The PTOA<br />Parallel Table of Authorities & Rules (PTOA)<br />Metadata in the Code of Federal Regulat...
PTOA: Excerpt<br />1 U.S.C.  <br />  112.................................................................1 Part 2  <br />1...
PTOA in Print: Human-Dependent<br />Most ponts created for print environment require human intervention to ensure connecti...
PTOA: Preparing It for Digital<br />Goals:<br />Disintermediation:<br />Make PTOA processable by software without human in...
PTOA: Preparing It for Digital (cont’d)<br />Recommended formats:<br />XML <br />RDF/OWL<br />Why XML & RDF/OWL?<br />Open...
PTOA: Use Cases<br />Information Retrieval & Discovery<br />Bidirectional discovery<br />Revelation of implicit relationsh...
PTOA: Obstacles to Preparation for Digital Use<br />Semantics (Ambiguity)<br />Granularity<br />Directionality<br />Data Q...
PTOA Obstacles: Semantics<br />1. Relationships between sources are ambiguous<br />Relationships represented in a PTOA row...
PTOA Obstacles: Semantics (cont’d)<br />2. Some PTOA rows list multiple sources on one or both sides:<br />1 U.S.C.  <br /...
PTOA Obstacles: Semantics (cont’d)<br />Result: In many PTOA rows, relationships between sources are multiple and complex<...
PTOA Obstacles: Granularity<br />PTOA regulation cites refer only to the “Part” level of CFR<br />But the relationships in...
PTOA Obstacles: Granularity: Example<br />“1 U.S.C. […]<br />“112a--112b................................22 Part 181”<br />...
PTOA Obstacles: Granularity (cont’d)<br />So each PTOA row must be analyzed & divided into multiple rows at accurate level...
PTOA Obstacles: Directionality<br />In PTOA, retrieval and discovery can only occur in one direction: from statute to regu...
PTOA Obstacles: Directionality<br />But in digital world, PTOA could add great value if it were bidirectional: if it enabl...
PTOA Obstacle: Data Quality<br />Production of PTOA is decentralized: each individual agency creates rows for its regulati...
Digital PTOA: XML Example: Barebones, No Fixes<br /><?xml version="1.0" encoding="UTF-8"?><br />  <ptoa><br />       <ptoa...
Digital PTOA: XML: Now with URNs, Granularity, Ranges<br /><?xml version="1.0" encoding="UTF-8"?><br />  <ptoa><br /><ptoa...
Digital PTOA: RDFS/OWL: Bidirectionality & Disambiguation<br /><owl:ObjectPropertyrdf:ID="implicitlyAuthorizes"><br /> <ow...
Digital PTOA: RDFS/OWL: Granularity<br /><owl:ObjectProperty<br />rdf:ID="hasUSCSectionFragment"><br />  <rdfs:domain<br /...
Challenges to Adapting the PTOA for the Digital Environment<br />Much relevant information is implicit, might not be autom...
Challenges to Adapting the PTOA for the Digital Environment (cont’d)<br />Inter-coder reliability needs to be tested & kep...
Related Research<br />Earlier studies of print-based ponts introduced into digital environment: Al-Kofahi et al. (2001); D...
Similar Projects<br />Legislation.gov.uk (Legislative Information Retrieval): Table of Legislative Effects, CEN MetaLex (l...
Other Ponts to Examine<br />Already Known:<br />Congressional Record: “History of Bills & Resolutions,” http://tinyurl.com...
Other Ponts to Examine (cont’d)<br />To Be Discovered:<br />Legal information professionals might examine legal research b...
Digital PTOA: Next Steps<br />Spring 2011: Receive input from colleagues at conferences<br />Summer & Fall 2011: Build pro...
References (1/7)<br />Administrative Conference of the United States. 1971. Report of the Committee on Information, Educat...
References (2/7)<br />Bennett, D. and Harvey, A. 2009. Publishing Open Government Data: W3C Working Draft 8 September 2009...
References (3/7)<br />Dabney, D. P. 1986. The curse of Thamus: An analysis of full-text legal document retrieval. Law Libr...
References (4/7)<br />García, R. and Gil, R. 2008. A Web ontology for copyright contracts management. Int. J. Electron. Co...
References (5/7)<br />Mersky, R. M. and Dunn, D. J. 2002. Fundamentals of Legal Research. 8th ed. Foundation Press, New Yo...
References (6/7)<br />Office of the Federal Register. 1949. Parallel tables of statutory authorities and rules. In Code of...
References (7/7)<br />Thomson Reuters. 2010. Using Related Materials on WestlawNext. Thomson Reuters, Eagan, MN. <br />Uni...
