A Network Visualization of Structure Activity Landscapes<br />Rajarshi Guha<br />NIH Chemical Genomics Center<br />March 2...
Structure Activity Relationships<br />Similar molecules will have similar activities<br />Small changes in structure will ...
Exceptions Are Easy to Find<br />Ki = 39.0 nM<br />Ki = 1.8 nM<br />Ki = 10.0 nM<br />Ki = 1.0 nM<br />Tran, J.A. et al., ...
Structure Activity Landscapes<br />Rugged gorges or rolling hills?<br />Small structural changes associated with large act...
Structure Activity Landscapes<br />
Characterizing the Landscape<br />A cliff can be numerically characterized<br />Structure Activity Landscape Index (SALI)<...
Fingerprints<br />Lots of types of fingerprints<br />Indicates the presence or absence of a structural feature <br />Length...
Visualizing the SALI Matrix<br />
Visualizing SALI Values<br />Alternatives?<br />A heatmap is an easy to understand visualization<br />Coupled with brushin...
Visualizing the SALI Graph<br />Nodes are ordered such that the tail node in an edge has lower activity than the head node...
Varying the Cutoff<br />The cutoff controls the complexity of the graph <br />Higher cut offs will highlight the most signifi...
Varying Fingerprint Methods<br />Shorter fingerprints will lead to more “similar” pairs<br />Requires a higher cutoff to foc...
Varying the Similarity Metric<br />
Different Molecular Representations<br />The nature of the representation can significantlyaffect the landscape<br />SALI ma...
Different Activity Representations<br />Using the Hill parameters from a dose-response curve represents richer data than a...
SALI Curves from DRCs<br />No difference in major cliffs<br />Some of the minor cliffs are highlighted using the DRC inste...
Better Visualization - SALIViewer<br />http://sali.rguha.net<br />
Glucocorticoid Inhibitors<br />62 dihydroquinolinederivatives<br />IC50’s reported, some values were censored<br />50% SAL...
Glucocorticoid Inhibitors<br />62 dihydroquinolinederivatives<br />IC50’s reported, some values were censored<br />50% SAL...
Glucocorticoid Inhibitors<br />Moving from ally or phenylethyl to ethyl causes a 6-fold increase in activity<br />Reducing...
Glucocorticoid Inhibitors<br />Generated using a 30% cutoff<br />
Glucocorticoid Inhibitors<br />Suggests that electrondensity is also important<br />Lower π density possibly correlates to...
Glucocorticoid Inhibitors<br />These observations match those made by Takahashi et al.<br />More detailed graphs exhibit l...
SALI Graphs & Predictive Models<br />The graph view allows us to view SAR’s and identify trends easily<br />The aim of a Q...
Measuring Model Quality<br />A QSAR model should easily encode the “rolling hills”<br />A good model captures the most sig...
SALI Curves<br />
QSAR Model Comparisons<br />QSAR has traditionally used statistical or machine learning methods<br />But ‘Q’ is for quanti...
QSAR Model Comparisons<br />Derived from a pharmacophore model<br />Derived from a docking model<br />Holloway, K. et al, ...
Acknowledgements<br />John Van Drie<br />Gerry Maggiora<br />MicLajiness<br />JurgenBajorath<br />
