Stockholm Game Developer Forum 2010<br />Parallel Futures of a Game Engine (v2.0)<br />Johan Andersson<br />Rendering Arch...
Background<br />DICE<br />Stockholm, Sweden<br />~250 employees<br />Part of Electronic Arts<br />Battlefield & Mirror’s E...
http://badcompany2.ea.com/<br />3<br />
http://badcompany2.ea.com/<br />4<br />
Outline<br />Current parallelism<br />Futures<br />Q&A<br />Slides will be available online later today<br />http://public...
Current parallelism<br />6<br />
Levels of code in Frostbite<br />Editor (C#)<br />Pipeline (C++)<br />Game code (C++)<br />System CPU-jobs (C++)<br />Syst...
Levels of code in Frostbite<br />Editor (C#)<br />Pipeline (C++)<br />Game code (C++)<br />System CPU-jobs (C++)<br />Syst...
General ”game code” (1/2)<br />This is the majority of our 1.5 million lines of C++<br />Runs on Win32, Win64, Xbox 360 an...
General ”game code” (2/2)<br />PS3 is one of the main challenges<br />Standard CPU parallelization doesn’t help (much)<br ...
Levels of code in Frostbite<br />Editor (C#)<br />Pipeline (C++)<br />Game code (C++)<br />System CPU-jobs (C++)<br />Syst...
Job-based parallelism<br />Essential to utilize the cores on our target platforms<br />Xbox 360: 6 HW threads<br />PlaySta...
What is a Job for us?<br />An asynchronous function call<br />Function ptr + 4 uintptr_t parameters<br />Cross-platform sc...
Frostbite CPU job graph<br />Build big job graphs:<br /><ul><li>Batch, batch, batch
Mix CPU- & SPU-jobs
Future: Mix in low-latency GPU-jobs</li></ul>Job dependencies determine:<br /><ul><li>Execution order
Sync points
Load balancing
i.e. the effective parallelism</li></ul>Intermixed task- & data-parallelism<br /><ul><li>aka Braided Parallelism
aka Nested Data-Parallelism
aka Tasks and Kernels</li></ul>14<br />
Data-parallel jobs<br />15<br />
Task-parallel algorithms & coordination<br />16<br />
17<br />Timing View: Battlefield Bad Company 2 (PS3)<br />
Rendering jobs<br />Rendering systems are heavily divided up into CPU-& SPU-jobs<br />Jobs:<br />Terrain geometry [3]<br /...
Occlusion culling job example<br />Problem: Buildings & env occlude large amounts of objects<br />Obscured objects still h...
Solution: Software occlusion culling<br />Rasterize coarse zbuffer on SPU/CPU<br />256x114 float<br />Low-poly occluder me...
GPU occlusion culling<br />Ideally want to use the GPU, but current APIs are limited:<br />Occlusion queries introduces ov...
Levels of code in Frostbite<br />Editor (C#)<br />Pipeline (C++)<br />Game code (C++)<br />System CPU-jobs (C++)<br />Syst...
Shader types<br />Generated shaders [1]<br />Graph-based surface shaders<br />Treated as content, not code<br />Artist cre...
Futures<br />24<br />
3 major challenges/goals going forward:<br />How do we make it easier to develop, maintain & parallelize general game code...
Challenge 1<br />“How do we make it easier to develop, maintain & parallelize general game code?”<br />Shared State Concur...
Challenge 1 - Task parallelism<br />Multiple task libraries<br />EA JobManager<br />Dynamic job graphs, on-demand dependen...
Challenge 2 - Definition<br />”Real-time interactive graphics & simulation at Pixar level of quality”<br />Needed visual f...
Challenge 2 - Problems<br />Problems & limitations with current GPU model:<br />Fixed rasterization pipeline<br />Compute ...
Challenge 2 - Solutions<br />Absolutely a job for a high-throughput oriented data-parallel processor<br />With a highly fl...
”Pipelined Compute Shaders”<br />Queues as streaming I/O between compute kernels<br />Simple & expressive model supporting...
”Pipelined Compute Shaders”<br />Wanted for next major DirectX and OpenCL/OpenGL<br />As a standard, as soon as possible<b...
Language?<br />Future DP language is a big question<br />But the concepts & infrastructure are what is important!<br />Cou...
Future hardware (1/2)<br />Single main memory & address space<br />Critical to share resources between graphics, simulatio...
Future hardware (2/2)<br />2015 = 40 TFLOPS, we would spend it on:<br />80% graphics<br />15% simulation<br />4% misc<br /...
Conclusions<br />Future is an interleaved mix of task- & data-parallelism<br />On both the HW and SW level<br />But progra...
Thanks to<br />DICE, EA and the Frostbite team<br />The graphics/gamedev community on Twitter<br />Steve McCalla, Mike Bur...
References<br />Previous Frostbite-related talks:<br />[1] Johan Andersson. ”Frostbite Rendering Architecture and Real-tim...
Questions?<br />Email:johan.andersson@dice.se   Blog: http://repi.se    Twitter: @repi<br />39<br />For more DICE talks: h...
Bonus slides<br />40<br />
Game development<br />2 year development cycle<br />New IP often takes much longer, 3-5 years<br />Engine is continuously ...
Game engine requirements (1/2)<br />Stable real-time performance<br />Frame-driven updates, 30 fps <br />Few threads, inst...
Upcoming SlideShare
Loading in...5
×

Parallel Futures of a Game Engine (v2.0)

29,915

Published on

Game engines have long been in the forefront of taking advantage of the ever
increasing parallel compute power of both CPUs and GPUs. This talk is about how the
parallel compute is utilized in practice on multiple platforms today in the Frostbite game
engine and how we think the parallel programming models, hardware and software in
the industry should look like in the next 5 years to help us make the best games possible.

1 Comment
7 Likes
Statistics
Notes
No Downloads
Views
Total Views
29,915
On Slideshare
0
From Embeds
0
Number of Embeds
44
Actions
Shares
0
Downloads
185
Comments
1
Likes
7
Embeds 0
No embeds

No notes for slide
  • Xbox 360 version + offline super-high AA and resolution
  • ”Glue code”
  • Better code structure!Gustafson’s LawFixed 33 ms/fWe don’t use threads for anything that can be a bit computationally heavy, jobs instead
  • Data-layout
  • We have a lot of jobs across the engine, too many to go through so I chose to focus more on some of the rendering.Our intention is to move all of these to the GPU
  • Conservative
  • Want to rasterize on GPU, not CPU CPU Û GPU job dependencies
  • Simple keywords as override &amp; sealed have been a help in other areas
  • No low-latency GPU contextsNested data-parallelism
  • Would require multi-vendor open ISA standard
  • With nested data parallelism inside kernels
  • OpenCL
  • Isolate systems/areasWe do not use exceptions, nor much error handling
  • Havok &amp; Kynapse
  • Bindings to C very interesting!
  • Parallel Futures of a Game Engine (v2.0)
