EIN STALL VOLLERTRÜFFELSCHWEINE(PHP)-Profiling-Tools im ÜberblickRené Bruns - TNG Big Techday

ÜBER MICH René Bruns  Entwickler seit 2001  seit 2009 bei Travian Games  seit 2011 Technical Director 2

UND WER SEID IHR? 3

UND WER SEID IHR?Entwickler? 3

UND WER SEID IHR?Entwickler? Systemadministratoren? 3

UND WER SEID IHR?Entwickler? Systemadministratoren? QA? 3

UND WER SEID IHR?Entwickler? Systemadministratoren? C*O? QA? 3

UND WER SEID IHR?Entwickler? Projektmanager? Systemadministratoren? C*O? QA? 3

PROFILING? 4

PROFILING?ProfilerEs gibt unterschiedliche Problembereiche in derSoftwareentwicklung, die durch ineffiziente Programmierungausgelöst werden. Ein Profiler hilft dem Entwickler durchAnalyse und Vergleich von laufenden Programmen dieProblembereiche aufzudecken.http://de.wikipedia.org/wiki/Profiler_(Programmierung) 5

AUSGANGSSITUATION SLOW!!11! 6

PROFILING FRÜHER(?)class Main{ public static function run() { $otherClass = new OtherClass(); $otherClass->doNothingImportant(); $dummy = new SlowClass(); $dummy->slowFunction(10); }}Main::run(); 7

PROFILING FRÜHER(?)class Main{ public static function run() { $start = microtime(true); printf ("Before OC: %f" . PHP_EOL, microtime(true) - $start); $otherClass = new OtherClass(); $otherClass->doNothingImportant(); printf ("After OC: %f" . PHP_EOL, microtime(true) - $start); printf ("Before SC: %f" . PHP_EOL, microtime(true) - $start); $dummy = new SlowClass(); $dummy->slowFunction(10); printf ("After SC: %f" . PHP_EOL, microtime(true) - $start); }}Main::run(); 8

PROFILING FRÜHER(?)class Main{ public static function run() { $start = microtime(true); printf ("Before OC: %f" . PHP_EOL, microtime(true) - $start); $otherClass = new OtherClass(); $otherClass->doNothingImportant(); printf ("After OC: %f" . PHP_EOL, microtime(true) - $start); printf ("Before SC: %f" . PHP_EOL, microtime(true) - $start); $dummy = new SlowClass(); $dummy->slowFunction(10); printf ("After SC: %f" . PHP_EOL, microtime(true) - $start); }} $ php Main.php Before OC: 0.000625Main::run(); After OC: 0.004919 Before SC: 0.005099 .......... After SC: 10.013932 8

PROFILING HEUTE Viele verschiedene Fehlerquellen  Browser  Frontend  Backend  Datenbank  Services Schwachstelle suchen Vom Groben in‘s Feine 9

SCHRITT 1: MELDUNG ÜBERPRÜFEN He‘s dead, Jim! 10

SCHRITT 2: URSACHE EINKREISEN Browser 11

SCHRITT 2: URSACHE EINKREISEN Browser Frontend 11

SCHRITT 2: URSACHE EINKREISEN Browser Frontend Backend 11

SCHRITT 2: URSACHE EINKREISEN Browser Frontend Backend DB 11

BROWSER Langsamer JS-Code Zu hoher Speicherverbrauch Zu viele CSS-Selektoren Langsame Ladezeiten  Zu viele parallele Downloads  Offen gehaltene Verbindungen  Netzwerk  Internet Antwort vom Server zu langsam -> Backend 12

GOOGLE CHROME 13

GOOGLE CHROME 14

GOOGLE CHROME 15

GOOGLE CHROME 16

GOOGLE CHROME 17

GOOGLE CHROME 18

GOOGLE CHROME 19

FRONTEND / BACKEND Unnötige Schreib- / Lesezugriffe in Schleifen Log-Ausgaben Schleifen sind unnötig geschachtelt Unnötig langsame Befehle benutzt  RegExp statt == Externer Service reagiert langsam Datenbankabfrage dauert zu lange --> DB 20

XDEBUG PHP Extension by Derick Rethans Kann per INI-Direktive aktiviert werden breites Einsatzspektrum  Debugger  Profiler  Tracer  StackTrace-Formatter  ... hoher Memory-/ CPU-/ IO-Footprint Niemals(!) dauerhaft im Produktivbetrieb verwenden 21

XDEBUG 22

XDEBUG$ php -d xdebug.profiler_enable=1 -d xdebug.profiler_output_dir=. Main.php.......... 22

XDEBUG$ php -d xdebug.profiler_enable=1 -d xdebug.profiler_output_dir=. Main.php..........$ ls -l ca*-rwxrwxrwx 1 rene staff 4461 11 Jun 13:53 cachegrind.out.69408 22

XDEBUG$ php -d xdebug.profiler_enable=1 -d xdebug.profiler_output_dir=. Main.php..........$ ls -l ca*-rwxrwxrwx 1 rene staff 4461 11 Jun 13:53 cachegrind.out.69408$ cat cachegrind.out.69408version: 1creator: xdebug 2.2.0cmd: /Volumes/TCDATA/Sourcen/git/ProfilingTalk/Main.phppart: 1positions: lineevents: Timefl=/Volumes/TCDATA/Sourcen/git/ProfilingTalk/OtherClass.phpfn=require_once::/Volumes/TCDATA/Sourcen/git/ProfilingTalk/OtherClass.php1 42fl=/Volumes/TCDATA/Sourcen/git/ProfilingTalk/SlowClass.phpfn=require_once::/Volumes/TCDATA/Sourcen/git/ProfilingTalk/SlowClass.php10 22

XDEBUG Cachegrind-Files können via KCachegrind, WinCachegrind, WebGrind oder PhpStorm-IDE ausgewertet werden. Bsp. PhpStorm: 23

XDEBUG Cachegrind-Files können via KCachegrind, WinCachegrind, WebGrind oder PhpStorm-IDE ausgewertet werden. Bsp. PhpStorm: 24

XDEBUG 25

XHPROF PHP Extension by Facebook Kann codeseitig aktiviert werden Profiler only sehr schlanker Footprint, daher auch im Livebetrieb einsetzbar (Monte Carlo-Algorithmus) 26

XHPROFheader.php:include_once /usr/lib/php/pear/xhprof_lib/utils/xhprof_lib.php;include_once /usr/lib/php/pear/xhprof_lib/utils/xhprof_runs.php;xhprof_enable(XHPROF_FLAGS_CPU + XHPROF_FLAGS_MEMORY);footer.php:include_once /usr/lib/php/pear/xhprof_lib/utils/xhprof_lib.php;include_once /usr/lib/php/pear/xhprof_lib/utils/xhprof_runs.php;$xhprof_data = xhprof_disable();$xhprof_runs = new XHProfRuns_Default();$run_id = $xhprof_runs->save_run($xhprof_data, testrene);echo "http://localhost/~rene/xhprof_html/index.php?run={$run_id}&source=testrenen"; 27

XHPROF$ php -d auto_append_fileo_prepend_file="header.php" -d auto_append_file="footer.php" Main.php..........http://localhost/~rene/xhprof_html/index.php?run=4fd61a7e92aeb&source=testrene 28

XHPROF$ php -d auto_append_fileo_prepend_file="header.php" -d auto_append_file="footer.php" Main.php..........http://localhost/~rene/xhprof_html/index.php?run=4fd61a7e92aeb&source=testrene$ cat 4fd61a7e92aeb.testrenea:14:{s:23:"main()==>load::Main.php";a:5:{s:2:"ct";i:1;s:2:"wt";i:459;s:3:"cpu";i:1220;s:2:"mu";i:10408;s:3:"pmu";i:0;}s:43:"main()==>load::ProfilingTalk/OtherClass.php";a:5:{s:2:"ct";i:1;s:2:"wt";i:798;s:3:"cpu";i:113;s:2:"mu";i:6880;s:3:"pmu";i:0;}s:47:"main()==>run_init::ProfilingTalk/OtherClass.php";a:5:{s:2:"ct";i:1;s:2:"wt";i:14;s:3:"cpu";i:10;s:2:"mu";i:1104;s:3:"pmu";i:0;}s:42:"main()==>load::ProfilingTalk/SlowClass.php";a:5:{s:2:"ct";i:1;s:2:"wt";i:467;s:3:"cpu";i:87;s:2:"mu";i:9648;s:3:"pmu";i:0;}s:46:"main()==>run_init::ProfilingTalk/SlowClass.php";a:5:{s:2:"ct";i:1;s:2:"wt";i:9;s:3:"cpu";i:7;s:2:"mu";i:1104;s:3:"pmu";i:0;}s:36:"OtherClass::doNothingImportant==>pow";a:5:{s:2:"ct";i:1;s:2:"wt";i:1655;s:3:"cpu";i:926;s:2:"mu";i:1176;s:3:"pmu";i:0;}[...]} 28

XHPROF 29

XHPROF 30

DATENBANK Unnötige Daten geladen Kein/falscher Index benutzt Daten werden nach der Abfrage noch sortiert Langsame IOs Falsche Systemeinstellungen (Buffer Sizes, ...) 31

DB - EXPLAINselect LastName, FirstName, sum(UnitPrice * Quantity) from employees e inner joinorders o on e.EmployeeID = o.EmployeeID inner join "Order Details" od on o.OrderID= od.OrderID group by LastName, FirstName; 32

DB - EXPLAINselect LastName, FirstName, sum(UnitPrice * Quantity) from employees e inner joinorders o on e.EmployeeID = o.EmployeeID inner join "Order Details" od on o.OrderID= od.OrderID group by LastName, FirstName;sqlite> explain query plan [...];0|0|0|SCAN TABLE employees AS e (~1000000 rows)0|1|1|SEARCH TABLE orders AS o USING AUTOMATIC COVERING INDEX (EmployeeID=?) (~7 rows)0|2|2|SEARCH TABLE Order Details AS od USING INDEX sqlite_autoindex_Order Details_1(OrderID=?) (~10 rows)0|0|0|USE TEMP B-TREE FOR GROUP BY 32

DB - EXPLAINselect LastName, FirstName, sum(UnitPrice * Quantity) from employees e inner joinorders o on e.EmployeeID = o.EmployeeID inner join "Order Details" od on o.OrderID= od.OrderID group by LastName, FirstName;sqlite> explain query plan [...];0|0|0|SCAN TABLE employees AS e (~1000000 rows)0|1|1|SEARCH TABLE orders AS o USING AUTOMATIC COVERING INDEX (EmployeeID=?) (~7 rows)0|2|2|SEARCH TABLE Order Details AS od USING INDEX sqlite_autoindex_Order Details_1(OrderID=?) (~10 rows)0|0|0|USE TEMP B-TREE FOR GROUP BYsqlite> explain [...];0|Trace|0|0|0||00|1|SorterOpen|3|5|0|keyinfo(2,BINARY,BINARY)|00|2|Integer|0|7|0||00|3|Integer|0|6|0||00|4|Null|0|10|11||00|5|Gosub|9|74|0||00|6|Goto|0|81|0||00|7|OpenRead|0|120|0|3|00| 32

SCHRITT 3: ERFOLG PRÜFEN Hat die Optimierung etwas gebracht? Vorher-Nachher-Check Lasttests Tools  Apache Benchmark (AB)  JMeter 33

APACHE BENCHMARK (AB)$ ab -n 100 -c 10 http://localhost/~rene/talk/Main.phpThis is ApacheBench, Version 2.3 <$Revision: 655654 $>Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/Licensed to The Apache Software Foundation, http://www.apache.org/Benchmarking localhost (be patient).....doneServer Software: Apache/2.2.21Server Hostname: localhostServer Port: 80Document Path: /~rene/talk/Main.phpDocument Length: 11 bytesConcurrency Level: 10Time taken for tests: 56.692 secondsComplete requests: 100Failed requests: 0Write errors: 0Total transferred: 22300 bytesHTML transferred: 1100 bytesRequests per second: 1.76 [#/sec] (mean)Time per request: 5669.198 [ms] (mean)Time per request: 566.920 [ms] (mean, across all concurrent requests)Transfer rate: 0.38 [Kbytes/sec] receivedConnection Times (ms) min mean[+/-sd] median maxConnect: 0 3660 2329.9 5022 6356Processing: 0 1758 3060.0 0 11378Waiting: 0 1757 3059.9 0 11377Total: 5010 5417 1403.8 5030 11378Percentage of the requests served within a certain time (ms) 50% 5030 66% 5040 75% 5052 80% 5063 90% 6316 95% 11378 vorher 98% 11378 99% 11378 100% 11378 (longest request) 34

APACHE BENCHMARK (AB)$ ab -n 100 -c 10 http://localhost/~rene/talk/Main.phpThis is ApacheBench, Version 2.3 <$Revision: 655654 $>Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/Licensed to The Apache Software Foundation, http://www.apache.org/ $ ab -n 100 -c 10 http://localhost/~rene/talk/Main.phpBenchmarking localhost (be patient).....done This is ApacheBench, Version 2.3 <$Revision: 655654 $> Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/ Licensed to The Apache Software Foundation, http://www.apache.org/Server Software: Apache/2.2.21Server Hostname: localhost Benchmarking localhost (be patient).....doneServer Port: 80Document Path: /~rene/talk/Main.php Server Software: Apache/2.2.21Document Length: 11 bytes Server Hostname: localhost Server Port: 80Concurrency Level: 10Time taken for tests: 56.692 seconds Document Path: /~rene/talk/Main.phpComplete requests: 100 Document Length: 11 bytesFailed requests: 0Write errors: 0 Concurrency Level: 10Total transferred: 22300 bytes Time taken for tests: 5.395 secondsHTML transferred: 1100 bytes Complete requests: 100Requests per second: 1.76 [#/sec] (mean) Failed requests: 0Time per request: 5669.198 [ms] (mean) Write errors: 0Time per request: 566.920 [ms] (mean, across transferred: Total all concurrent requests) 22300 bytesTransfer rate: 0.38 [Kbytes/sec] received HTML transferred: 1100 bytes Requests per second: 18.54 [#/sec] (mean)Connection Times (ms) Time per request: 539.458 [ms] (mean) min mean[+/-sd] median max Time per request: 53.946 [ms] (mean, across all concurrent requests)Connect: 0 3660 2329.9 5022 6356 Transfer rate: 4.04 [Kbytes/sec] receivedProcessing: 0 1758 3060.0 0 11378Waiting: 0 1757 3059.9 0 11377 Connection Times (ms)Total: 5010 5417 1403.8 5030 11378 min mean[+/-sd] median max Connect: 0 395 217.3 531 577Percentage of the requests served within a certain time (ms) 0 142 214.4 Processing: 1 559 50% 5030 Waiting: 0 142 214.6 0 559 66% 5040 Total: 512 538 14.9 535 577 75% 5052 80% 5063 vorher Percentage of the requests served within a certain time (ms) 90% 6316 50% 535 95% 11378 66% 541 98% 11378 75% 553 nachher 99% 11378 80% 555 100% 11378 (longest request) 90% 559 95% 559 98% 566 99% 577 100% 577 (longest request) 34

APACHE JMETER verteilte Lasttests Java-Programm Client-Server-Architektur Testen von  HTTP/S  SOAP  DB‘s via JDBC  SMTP, POP3, IMAP  ... 35

JMETER - TESTPLAN ERSTELLEN Manuell oder per HTTP Proxy Server 36

JMETER - TESTPLAN ERSTELLEN Manuell oder per HTTP Proxy Server 37

JMETER - USER EINLOGGEN 38

JMETER - USER EINLOGGEN 39

JMETER - PARALLELE ZUGRIFFE 40

JMETER - PARALLELE ZUGRIFFE 41

JMETER - BERICHTE 42

LINKLISTE  Google Chrome: https://www.google.com/chrome  Chrome DevTools: https://developers.google.com/chrome- developer-tools/?hl=de  Xdebug: http://xdebug.org/  PHPStorm: http://www.jetbrains.com/phpstorm/  KCachegrind: http://kcachegrind.sourceforge.net  WinCacheGrind: http://sourceforge.net/projects/wincachegrind/  Webgrind: http://code.google.com/p/webgrind/  XHProf: http://php.net/xhprof  AB: http://httpd.apache.org/docs/2.0/programs/ab.html  Jmeter: http://jmeter.apache.org/ 43

FRAGEN?GERNE AUCH SPÄTER:MAIL: R.BRUNS@TRAVIANGAMES.COMTWITTER: @RENEBRUNS
