Adapt and respondMOBILE-FRIENDLY LAYOUTS BEYOND THE DESKTOPPatrick H. Lauke / standards.next / 3 March 2012
mobile webis increasingly important
we need a site that works on iPhone
oh, and on the iPad
“remove iPhone from ass” Peter-Paul Koch, The iPhone obsession       www.quirksmode.org/blog/archives/2010/02/the_iphone_o...
sites that work on (almost)    all mobile devices
3 approaches
1. do nothing
moved beyond WAP or text
modern mobile browserscan handle the “real web”
“but the mobile context...”
“Desktop computers and mobile devices are so different that  the only way to offer a great user experience is to create tw...
twitter.com/#!/stephenhay/status/23350345962889216
2. separate mobile site  (m.flickr.com, mobile.mysite.com, ...)
beware browser sniffing      photo: http://www.flickr.com/photos/timdorr/2096272747/
let the user decide:  diet or full fat?
“refactored” for small displays, not dumbed down for mobile
3. single adaptive site
nothing new
The Sage “... accepts the ebb and flow of things,    Nurtures them, but does not own them,”               Tao Te Ching; 2 ...
how to take “desktop” layout to “mobile”?
CSS 2 Media Types
Media typesall           brailleembossed      handheldprint         projectionscreen        speechtty           tv
CSS 2.1 Media Types<link rel="stylesheet" ...media="print" href="...">@import url("...") print;@media print {    // insert...
CSS 3 Media Queries   “...the new hotness” Jeffrey Zeldman      http://www.zeldman.com/2010/04/08/best-aea-yet/
CSS 3 Media Queries●   builds on CSS 2.1 Media Types concept●   more granular control (not just screen, print...)http://ww...
Media featureswidth                 colorheight                color-indexdevice-width          monochromedevice-height   ...
CSS 3 Media Queries<link rel="stylesheet" ...media="screen and (max-width:480px)" href="...">@import url("...") screen and...
Multiple expressions – and keyword@media screen and (min-width:180px) and (max-width:480px) {    // screen device and widt...
Multiple expressions – comma separated@media screen and (min-width:800px),         print and (min-width:20em) {    // scre...
Negative expressions – not keyword@media not screen and (min-width:800px) {    // not applied to screen device    // with ...
Exclusive expressions – only keyword@media only screen and (min-width:800px) {    // only applied to screen device    // w...
Multiple media queries/* “The absence of a media query is the firstmedia query” Bryan Rieger */@media screen and (max-widt...
http://mediaqueri.es
http://mediaqueri.es
http://mediaqueri.es
http://mediaqueri.es
www.themaninblue.com/writing/perspective/2004/09/21
design approaches using     media queries
easy-readers.net/books/adaptive-web-design
www.alistapart.com/articles/responsive-web-design
grid-based layouts
www.subtraction.com/2007/03/19/oh-yeeaahh
www.subtraction.com/2007/03/19/oh-yeeaahh
www.alistapart.com/articles/fluidgrids
Responsive Web Design™fluid grid + fluid images + media queries
bostonglobe.com
adaptive vs responsive?
“not a magic bullet...”
unsolved mysteries…
www.opera.com/developer/tools/mobile
mobile devices lie
physical vs virtual pixels
viewport metasuggests an initial layout viewport            and zoom
viewport meta<meta name="viewport"content="width=480"><meta name="viewport"content="width=480, user-scalable=no">http://de...
Viewport propertieswidth                 initial-scaleheight                minimum-scaleuser-scalable         maximum-scale
<meta name="viewport"content="width=device-width">
high-dpi devices lie twice
<meta name="viewport"content="width=device-width,target-densitydpi=device-dpi">
“interesting” iOS quirk
confused?a practical example…
<meta name="viewport" content="width=550">
<meta name="viewport" content="width=550">
<meta name="viewport" content="width=550">
<meta name="viewport"content="width=550,maximum-scale=1.0">
<meta name="viewport"content="width=550,maximum-scale=1.0,   target-densitydpi=device-dpi">
maximum-scale=1.0breaks zooming!
JavaScript approaches to selectively    apply viewport meta...argh!
CSS Device Adaptation@viewport {    width: 320px;    zoom: 2.3;    user-zoom: fixed;}www.w3.org/TR/css-device-adaptonly wo...
Viewport propertieswidth / min-width / max-width      user-zoomheight / min-height / max-height   orientationzoom / min-zo...
<meta name="viewport" content="width=550">@-o-viewport {    width: 550px;}
<meta name="viewport"content="width=550,maximum-scale=1.0,target-densitydpi=device-dpi">@-o-viewport {    width: 550px;   ...
/* selective viewport via CSS */@media … {    @-o-viewport {        … /* for propellerheads */    }}
<meta name="viewport" content="width=550,maximum-scale=1.0,target-densitydpi=device-dpi">@media screen {    @-o-viewport {...
<meta name="viewport" content="width=550,maximum-scale=1.0,target-densitydpi=device-dpi">@media screen {    @-o-viewport {...
@-o-viewport {    /* minimum of 550px viewport width */    width: 550px auto; max-zoom: auto;}
more unsolved mysteries
Responsive Web Design™fluid grid + fluid images + media queries
/* fluid image based on parent container */img { max-width:100%; }
Responsive Web Design™fluid grid + fluid images + media queries
stephanierieger.com/the-trouble-with-android
www.zeldman.com/2011/12/29/state-of-the-web-of-apps-devices-and-breakpoints
“embrace the fluidity,   dont fight it”
http://futurefriend.ly
www.opera.com/developer   patrick.lauke@opera.com
