    Designing an android sensor subsystem costillo 20120214 Designing an android sensor subsystem costillo 20120214 Presentation Transcript

    • Designing An Android Sensor Subsystem Pitfalls and Considerations Jen Costillo jen@rebelbot.com
    • Simple Choices User Battery experience performance2/14/2012 Costillo- Android Builders Summit 2012 2
    • Established or Innovative Product? Established Innovation-Driven • Will I be making another • Do I have new sensors new product in 6 types? months? • Are features more • Is the reference design important than release considered good enough date? for the application? • Are money and resources no problem?2/14/2012 Costillo- Android Builders Summit 2012 3
    • Forsaking Reference Designs2/14/2012 Costillo- Android Builders Summit 2012 4
    • Going On Your Own • If you make your own, • But… – You’re on your own – power ↓ – Integration pains – Control code size – Test time ↑ – Control mechanical – Gesture testing footprint becomes a challenge – In-house expertise – Calibration blues – Larger mechanical footprint2/14/2012 Costillo- Android Builders Summit 2012 5
    • Android Universe Android Application Application SensorManager Frameworks Sensor JNI Sensor Service Sensor Manager Libraries Sensor HAL Interface Kernel Driver Sensor Driver Linux Kernel Sensor Hub/ Coprocessor Sensors Hardware2/14/2012 Costillo- Android Builders Summit 2012 6
    • Application Frameworks Libraries Linux Kernel HARDWARE Hardware2/14/2012 Costillo- Android Builders Summit 2012 7
    • Hardware Architecture2/14/2012 Costillo- Android Builders Summit 2012 8
    • Sensor Selection • Limited types • New type • Latency • Power consumption2/14/2012 Costillo- Android Builders Summit 2012 9
    • Sensor Sampling Rate2/14/2012 Costillo- Android Builders Summit 2012 10
    • Sampling Rates: The 3 Rates Under-sampling Over-sampling • Inaccurate, sluggish • Accurate, smooth response response • Slight power savings • Power-hungry Sampling Rate2/14/2012 Costillo- Android Builders Summit 2012 11
    • Polling versus Interrupt Pros: Pros: • Simplicity • Low power • Throttle Sleep Mode data • Use fewer throughput timers Cons: Cons: • Less sleep • Complex • Latency ↑ program • Data loss structure2/14/2012 Costillo- Android Builders Summit 2012 12
    • Interfaces2/14/2012 Costillo- Android Builders Summit 2012 13
    • Wake up events and power considerations Application Internal External Processor only Coprocessor Processor D C CC Reference supported Reference supported More processor selection Most power hungry Most work done for More outcome control you Most customized Footprint impact2/14/2012 Costillo- Android Builders Summit 2012 14
    • Sensor Subsystem/Hub • Separate processor or part of the Application processor • How to evaluate? – Latency – Power consumption – Low power modes2/14/2012 Costillo- Android Builders Summit 2012 15
    • Hardware Summary Power Latency = Consumption Max(sensorsn) Sensor = Σ sensorsn + + dedicated Solution any dedicated processing processor time • Use tie-breaker criteria2/14/2012 Costillo- Android Builders Summit 2012 16
    • Application Frameworks Libraries Linux Kernel KERNEL Hardware2/14/2012 Costillo- Android Builders Summit 2012 17
    • Kernel Driver Application Processor Peripheral Shared Interface Memory Microcontroller Sensor Coprocessor2/14/2012 Costillo- Android Builders Summit 2012 18
    • Application Frameworks Libraries Linux Kernel LIBRARIES AND SERVICES Hardware2/14/2012 Costillo- Android Builders Summit 2012 19
    • Sensor HAL and Services • HAL device/<vendor>/<board name>/libsensors • Service frameworks/base/services/sensorservice • Manager frameworks/base/libs/gui2/14/2012 Costillo- Android Builders Summit 2012 20
    • Sensor Fusion Libraries Linux Kernel Sensor Hub Sensors http://en.wikipedia.org/wiki/Sensor_fusion https://www.llnl.gov/news/newsreleases/2010/NR-10-01-06.html2/14/2012 Costillo- Android Builders Summit 2012 22
    • Gesture Detection Algorithm Application Android Processor SensorService Co- Sensor Hub Processor Sensors MPU with Barometer Proximity Gyro/Accel Compass2/14/2012 Costillo- Android Builders Summit 2012 23
    • Gesture Detection Comparison Make Buy Application • Powerful processor Minimal Off-load AppPro Schedule Impact In-house Already Tested expertise &tuned Complete Compact code solution Sensor hub • Off-load to cheaper power • Wake up Event Handling2/14/2012 Costillo- Android Builders Summit 2012 24
    • Calibration2/14/2012 Costillo- Android Builders Summit 2012 25
    • Application Frameworks Libraries Linux Kernel OTHER CONSIDERATIONS Hardware2/14/2012 Costillo- Android Builders Summit 2012 26
    • Testing Methodologies • Creating tools • Checkpoints at all levels • Ensure the application processor can see each of your sensors • Compatibility Test Suite (CTS) at application level - /cts/tests/tests/hardware… SensorTest.java • Test services - /frameworks/base/services/sensorservice/tests • Manufacturing tests2/14/2012 Costillo- Android Builders Summit 2012 27
    • QUESTIONS? JEN@REBELBOT.COM Additional resources http://processors.wiki.ti.com/index.php/Android_Sensor_PortingGuide http://www.kandroid.org/online-pdk/guide/sensors.html2/14/2012 Costillo- Android Builders Summit 2012 28
