## Applied Statistics And Doe MayankPresentation Transcript

• Applied Statistics and DOE
Mayank
• Applied Statistics
Measures of central tendency (central position of data)
µ
Mean
Population :
Sample:
Median
Mode
Measures of dispersion (spread of data)
Variance
σ2
s2
Population :
Sample:
Standard deviation
σ
s
Population :
Sample:
Coefficient of variation
• Measures of Central tendency
Data: 34, 43, 81, 106, 106 and 115
Mean
Average Σx/n =80.83
Mode
Highest frequency =106
Median
Middle score (81+106)/2 =93.5
• Measures of dispersion
Variance:
Standard deviation:
x
SS
SS/(n-1)
MS
sd
√MS
Most of the data lies between 44.5±4,57 = 39to 49
• Measures of dispersion
Coefficient of Variance
CV = s/ *100%
4.57/44.5*100% = 10.28%
Standard deviation is 10.28% of the mean
• Measures of dispersion
Normal Distribution
Example: IQ Score
• Measures of dispersion
Normal Distribution
IQ Score
Count
Score
&lt;55
115
130
145
100
85
70
55
145&lt;
• Measures of dispersion
Normal Distribution
34.13%
34.13%
Probability
13.59%
13.59 %
Score
2.14%
2.14%
0.13%
0.13%
0.0031%
0.0031%
0.000028%
0.000028%
Sd from
-6σ
-5σ
-4σ
-2σ
-1σ

-3σ

μ
68.2689%
95.4499%
99.7300%
99.9936%
99.999942669%
99.999999802%
• Measures of dispersion
Normal Distribution
Six Sigma
DPMO
DPHO
LSL
USL
Sd from
-6σ
-5σ
-4σ
-2σ
-1σ

-3σ

μ
99.999999802%
• Measures of dispersion
Normal Distribution
LSL
LSL
USL
USL
• Measures of dispersion
Normal Distribution
1.5 σ
LSL
USL
3.4 DMPO
-6σ
-5σ
-4σ
-2σ
-1σ

-3σ

μ
• Statistical significance tests
Significance tests
Z- test
t- test
F- test
ANOVA
• Statistical significance tests
Z - test
Z-value :
How many standard deviations away from mean?
+ve z: values are above the mean,
-ve z: values are below the mean
Population
Sample
Group compared to population
1 point compared to population
• Statistical significance tests
Z - test
Sample :
BMI
Mean ( ) = 26.20
Standard deviation (s) = 6.57
What is the probability that of a person having BMI
19.2 sdbelow the mean
19.2 sd above the mean
A person with a BMI of 19.2 has a z score of:
So this person has a BMI 1.07 standard deviations below the mean
• Statistical significance tests
Z - test
Sample :
Probability
&lt;19.6
&gt;19.6
Sd
16 %
84 %
-1σ
μ
Standard deviation
Z score
0
-1
• Statistical significance tests
Z - test
Population :
Test group : Employee having two wheeler
Test : Commuting time from home to Biocon
Claim : Average commuting time is less than 24 min
At 0.01 level of significance (α=0.01):
Is there enough evidence to support the research claim???
Samples : 30
18 16 23 19 25 48 13 17 20 23
16 21 18 16 29 15 8 19 20 7
15 16 24 15 6 11 14 23 18 12
• Statistical significance tests
Z - test
Population :
Assumption: Population is normally distributed
Probability
Score
24
Mean
X
• Statistical significance tests
Z - test
Population :
Hypothesis testing
Test vs Population
Comparison of means:
Null hypothesis : H0
No difference (Claim not true)
H0 : x ≥ µ
µ = 24
Alternate hypothesis : H1
It is different (Claim is true)
H1 : x &lt; µ
• Statistical significance tests
Z - test
Population :
Probability
Probability
24
Mean
X
Z value
Score
Level of significance
α = 0.01
Critical
value
Z
0
-2.33
• Statistical significance tests
Z - test
Population :
Ztest&lt; Zcritical
Ztest&gt;Zcritical
Rejection region
Acceptance region
-2.33
Z
= 18.2
s = 7.7
Z = - 4.13
µ = 24
n = 30
• Statistical significance tests
Z - test
Population :
Rejection region
-2.33
- 4.13
Z
So is test value is significantly different (lower) than the mean
Yes: There are significant evidence to reject the null hypothesis
H0 : s ≥ 24
Rejected
and therefore accept the claim
H1 : s &lt; 24
Significantly supported
• Statistical significance tests
t - test
Comparison of means between two groups
H0:
H1:
Null hypothesis will be rejected
ttest &gt; tcritical
Null hypothesis will not be rejected
ttest &lt; tcritical
• Statistical significance tests
t - test
Comparison of means between two groups
Signal
Difference between group means
t =
=
Noise
Variability of groups
• Statistical significance tests
t - test
Effect of fertilizer on plant height
Case 1
Fertilizer
w/o Fertilizer
27.15 – 17.9
t test =
= 2.4
t critical with 38 df
at 0.05 significance level
= 2.03
Plant height
df = 2n-2
ttest &gt; tcritical
So is significantly different from
H0:
Rejected
H1:
s2
• Statistical significance tests
t - test
Case 2
Fertilizer
w/o Fertilizer
t critical =2.03
1.3
t test =
Plant height
ttest &lt; tcritical
So is not significantly different from
H0:
Not rejected
Rejected
H1:
s2
• Statistical significance tests
t - test
Overview
• Statistical significance tests
F - test
Comparison of variances
where and are the sample variances
F =
The F hypothesis test is defined as:
H0: =
Rejected
Ha:
&lt;
&gt;

If Ftest &gt; Fcritical (at significant level)
• Statistical significance tests
ANOVA
ANalysisOf VAriance
One way :
• Effect of one factor (variable)
Two way :
• Effect of two factors (variables)
• Effect of interaction
• Statistical significance tests
One way ANOVA
Strategy:
Compare variability within group MSwg to between groups MSbg
MSbg
F =
MSwg
Group 1
Group 1
Group 2
Group 2
Between groups
Within groups
• Statistical significance tests
One way ANOVA
Is there any impact of exam room temperature on student performance?
Factor ( Independent Variable):
Temperature (cold, optimum, hot)
Effect ( Dependent Variable):
Score (marks obtained)
Null hypothesis (H0) : No effect (µ1= µ2 = µ3)
Alternate hypothesis (H1) : There is an effect (µ1 ≠ µ2 ≠ µ3)
• Statistical significance tests
One way ANOVA
C
O
H
Cold
Opt
Hot
Number of Attendees
SS
= X̄
• Statistical significance tests
One way ANOVA
MSbg
=
=
F =
6.40
MSwg
Fcriticalfor
Numerator degrees of freedom : 2
Denominator degrees of freedom : 33
At significance level (α) : 0.05
=
4.17
Ftest &gt; Fcritical
So there are enough evidence to reject null hypothesis
H0: All means are same (no effect of Temperature)
Rejected
At 95% confidence level we can say:
That the variation between means is not just by chance
Examination Room temperature matters significantly
• Statistical significance tests
Two way ANOVA
Factors ( Independent Variable):
1) Gender:
Man Woman
2) Type of sport
Indoor Outdoor
Effect ( Dependent Variable):
1) Number of participants
Relative impact of gender or type of sprot?
Any interaction between gender and type of sport?
Null hypothesis (H0a) : No effect of gender
Null hypothesis (H0b) : No effect of type of sport
Null hypothesis (H0c) : No interaction
Alternate hypothesis (H1) : There is an effect
• Statistical significance tests
Two way ANOVA
Man Woman
s

g->
Indoor
Outdoor
• Statistical significance tests
Two way ANOVA
Indoor Outdoor
Null hypothesis (H0a) : No effect of gender
Rejected
Rejected
Null hypothesis (H0b) : No effect of type of sports
Rejected
Null hypothesis (H0c) : No interaction
• Statistical significance tests
Two way ANOVA
Factors ( Independent Variable):
1) Temperature:
30 35
2) pH
5 7
Effect ( Dependent Variable):
1) Total product (g)
pH 7
pH 5
30o C 35o C
• Regression and correlation
Regression analysis:
Investigation of relationship between variables
• Regression and correlation
Regression analysis:
Investigation of relationship between variables
y = -0.951x + 50.49
y = ax +b
R² = 0.955
One independent variable
Simple linear regression
• Regression and correlation
Regression analysis:
Simple linear regression
y = ax + b
Non linear
Multiple linear regression
y = a1x1+ a2x2+ a11 x2 + a12 x1x2+b
y = a1x1+ a2x2+ a3x3+ b
Linear
Non Linear
• Regression and correlation
Correlation analysis:
To find how well (or badly) a line fits the observation
What is the strength of this relationship
- r2 (coefficient of determination) or adjusted r2
Is the relationship we have described statistically significant?
-Significant tests
• Regression and correlation
Correlation analysis:
ŷ = ax + b
intercept
slope
ε
= ŷ, predicted value
= y i, true value
ε =residual error =
y - ŷ
A and b values are calculated that minimize Sum of Squares (SS) of residuals =
Σ (y – ŷ)2 : minimum
• Regression and correlation
Correlation analysis:
r2 : Coefficient of determination
Error
Total
(yi – y)2
(y – ŷ)2
Always between 0 and 1
Increase with number of predictor
SSError
= 1-
r2
SSTotal
It can be negative also
SSError/(n-p-1)
= 1-
True representative of relationship strength
SSTotal/(n-1)
n= total observation
p= Number of predictor
• MSbg
MSModel
=
=
F
F
MSwg
MSError
Group 1
Group 1
Group 2
Group 2
Regression and correlation
Correlation analysis:
Statistical significance of relationship
Error
Model
• Design of experiment
One factor at time (OFAT)
Statistical method
Multiple factor at time (MFAT)
• Design of experiment
• Design of experiment
How to select a design?
• Design of experiment- terminology
Independent variable/s
Factors
Continuous
Numeric: any value between lower and upper value
eg. Temperature, pH, concentration
Categorical
Numeric/non-numeric : only characters or levels
eg. Gender, operator, type, temperature
Levels
-1(lower)
+1(higher)
0(middle)
Range of a factor/s
Effects
Dependent variable/s: Response
Main effect/s
Effect/s due to individual factor/s
Interaction effect/s
Effect/s due to interaction of multiple factors
Confounding/Aliasing
When two or more effects can not be distinguished
eg. Main effect is confounded with interaction effects
Main effects and interaction effects are aliased
• Design of experiment
Resolution of a design
Power of a design
Higher order interaction are less significant than lower order interaction
• Design of experiment
Factorial design
Factor
Lf
Full factorial:
Level
• Design of experiment
Factorial design
22
b
a
4 experiments
• Design of experiment
Factorial design
23
c
b
a
8 experiments
• Design of experiment
Factorial design
32
b
a
9 experiments
• Design of experiment
Factorial design
33
c
b
27 experiments
• Design of experiment
Fractional Factorial design
23-1
23
8 experiments
4 experiments
• Design of experiment
Response surface methodology
• Design of experiment
Geometry of some important response surface designs
Box - Behnken
eg. 3 factor 3 level
12 experiments
• Design of experiment
Geometry of some important response surface designs
Central composite design
eg. 2 factor 2level
+
=
• Design of experiment
Geometry of some important response surface designs
Taguchi design
Signal
Media, pH, feed rate
Inner array:
Controllable variables during production
Outer array:
Uncontrollable variables during production
Noise
Temp, DO,
