Analysis of Security and Compliance using Sun UltraSPARC T-Series
Servers
Ramesh Nagappan, Principal Security Engineer
Cha...
Agenda


•  Oracle Security and Compliance Portfolio          <Insert Picture Here>

  –  Technologies Overview
•  Securit...
The Perfect Storm: IT Insecurity
     Security has taken unprecedented importance ….everywhere!

  Security is one of tod...
IT Security: Pre-judicial Barriers
  Security is often considered as an afterthought or a retrofit
   solution.
   o  Man...
Security & Compliance
Who is behind the scene
Security & Compliance Infrastructure
Security Components of a Oracle SPARC Enterprise T-Series Server
Exploring Security
Role and Relevance of Cryptography
        Adopting Cryptography for IT Security

  Cryptography plays a vital role in
  ...
Adopting Cryptography: Pain Points
  Common challenges and stumbling issues

  Cryptographic functions tends to be comput...
Applied Cryptography
  Common security applications using Crypto mechanisms

  SSL
   o  De-facto standard for securing H...
Security vs. Performance
   Understanding the overheads with Cryptography – SOA Scenario




        SSL using RSA-2048 an...
Anatomy of SSL
  Ciphers vs. Execution times




“Significant time” spent on cryptographic functions with specified cipher...
Effect of Cryptographic Acceleration
      Understanding the performance gains for an SSL scenario




Significant perform...
Cryptographic Acceleration
Using
Oracle SPARC Enterprise T-Series Servers
On-chip Crypto Accelerators: Evolution
        The UltraSPARC T-Series Processor Family


  UltraSPARC T1 – 8 Crypto Acce...
Cryptographic Capabilities and Algorithms
     T3 Processor




16
On-Chip Crypto Accelerators
   System Characteristics
  Crypto Accelerators operate in parallel with CPU speed
   deliver...
On-chip vs Off-chip Accelerators
Comparison with Commercial Accelerators
SPARC T-Series – Onchip Crypto
Comparison with Commercial Accelerators/HSMs


                                        6 Cr...
Accessing On-chip Crypto Accelerators
     Operational Characteristics

  Access to accelerators are
   managed using Sol...
Sun Cryptographic Accelerator 6000 – PCIe Card
  A full-fledged Hardware Security
   Module (HSM)
   o    Secure Key Stor...
SCA 6000 – Usage Scenarios




  Tested and Certified for use in FIPS and NON-FIPS modes
   o  Oracle Database Advanced S...
Enabling Cryptographic Acceleration

Applied Techniques and Usage Scenarios
Solaris Cryptographic Framework
  Common framework for
   performing /consuming / integrating
   cryptographic providers....
Solaris KSSL
  Facilitates an SSL Proxy service for applications and performs
   SSL operations right in the Solaris Kern...
Using KSSL for Transport-layer Security
     Applied Scenario




26
End-to-End Transaction Security
           Applied Use Cases


           HTTP

                           HTTP        HTT...
Performance Studies
Secure Performance
   With and Without Acceleration
                                   ^134h>96can#A*IC!
                 ...
Secure Performance
   With and Without Acceleration
                                   ^134h>96can#A*IC!
       4704 1234 ...
SPARC Enterprise T-Series
Only Enterprise Server with Built-in Crypto

                                          6 Crypto ...
Effect of Accelerated SSL vs No SSL
Weblogic SSL Performance on T3 : Using KSSL vs. JCE vs. No SSL
Oracle TDE performance using T3
•  T3 crypto speeds up query execution by 3-5x !!
Achieving Compliance
HIPAA-HITECH Compliance Scenario
       Rules of Thumb: Encrypt PHI – in transit, in situ




           HTTP
            ...
HIPAA-HITECH Options
       Rules of Thumb: Mitigation Strategies




                                                    ...
PCI-DSS Compliance Scenario
       Rules of Thumb: Especially in situ, Even Warehoused Data




           HTTP
          ...
PCI-DSS Options
       Rules of Thumb: Mitigation Strategies




                                                         ...
Summary
The cost of security
  Better TCO with T3 crypto




                             }
Twice server capacity = half
       th...
Program Agenda Example


•  Our understanding of XYZ         <Insert Picture Here>

•  Capabilities and value drivers
•  B...
Q&A

Chad Prucha, albert.prucha@oracle.com
Ramesh Nagappan, ramesh.nagappan@oracle.com
