Using Multi-Touch and
Gestures with Qt
                        10/09/09
Jens Bache-Wiig
Introduction

Jens Bache-Wiig
  •  Worked on Qt since 2005
  •  Platform Team
  •  Interim Widget Pimp




               ...
Agenda

•  Introduction
Concepts
API
Examples
Q&A




                  3
Agenda

Introduction
•  Concepts
API
Examples
Q&A




               4
Concepts

What do we mean when we say multi-touch?




                                           5
Concepts

A widget reacts to multiple touch-points

For example, to zoom/scale content...


      Lorem ipsum dolor sit   ...
Concepts

  Multiple widgets react to multiple touch-points
     For example, moving several sliders at once...




      ...
Concepts

Real life is multi-touch
Do you open a bottle with one finger?
Applications could do it too...



              ...
Concepts

Part of our future since at least 1982...




                                      Disney © 1982




        ...
Concepts




           Sony Pictures © 2009




                                   10
hBp://www.youtube.com
Concepts

What do we mean when we say gestures?




                                        12
Concepts

A way to make common multi-touch use-cases
easy to use in your application

• Standard, platform-specific touch-...
Concepts

What are standard gestures?

•  Built-in multi-touch gestures that work in standard Qt
widgets




             ...
Concepts

Pan gesture

•  Scrolls content
•  Works in all scrollable Qt widgets

         Lorem ipsum dolor sit          U...
Concepts

Pinch gesture

Zoom and/or rotate content




                             16
Agenda

Introduction
Concepts
•  API
Examples
Q&A




               17
API

Multi-touch
  •  New event types
     •  TouchBegin
     •  TouchUpdate
     •  TouchEnd
  •  New QTouchEvent class
 ...
API

QEvent::TouchBegin
  •  First in sequence
  •  Must be accepted to receive following events




                     ...
API

QEvent::TouchUpdate
  •  Normal event indicating activity
  •  Expect more events to follow




                     ...
API

QEvent::TouchEnd
  •  Final event in sequence
  •  No more events without a new TouchBegin




                      ...
API

TouchBegin propagation
  •  When ignored, propagate to widget under first touch-
     point
  •  Widgets never receiv...
API

TouchUpdate, TouchEnd do not propagate




                                         23
API

QTouchEvent
  •  Event class for QWidget and QGraphicsItem
  •  Contains list of active touch points
  •  Device type...
API

QTouchEvent::TouchPoint
  •    Information about one touch-point
  •    Integer identifier
  •    Primary touch-point...
API

Touch events are not sent by default
  •  Must be enabled first
  •  When enabled, TouchBegin event will be accepted
...
API

Qt::WA_AcceptsTouchEvents
  •  Set on QWidget to receive touch events
  •  To handle events, reimplement QWidget::eve...
API

QGraphicsItem::setAcceptsTouchEvents(bool)
  •  Set to true on item to receive touch events
  •  To handle, reimpleme...
API

 Gestures

 •    QGesture and QGestureRecognizer classes
 •    Widgets subscribe to gestures
 •    Using standard ges...
API

QGesture
   •    Base class for more complex gestures
   •    Basic properties and convenience functions
   •    Deli...
API

QGestureRecognizer
  •  “Just” an event filter + state machine
  •  Registered in QApplication
  •  Announces when a ...
API

 How do I use a gesture?
      •  Use grabGesture() to request it
      •  Handle the QGestureEvent and get:
        ...
API

 Implementing custom gestures
 •    Create a state machine:
      - subclass QGestureRecognizer
      - implement fil...
API

Gestures can be simple : Four finger tap
class FourFingerTapGesture : public QGestureRecognizer
{
   virtual Result f...
API

 Gestures can be complex
 •    Event filter could implement a state machine
 •    Continuous gesture going through Qt...
API

Special considerations when implementing and/
or using gestures




                                                36
API

Single gesture on parent widget with children
  •  Should the parent's gesture filter events for children?
GestureCon...
API

 Multiple gestures on a single widget
 •    All gestures filter incoming events in undefined order
 •    Ignored gest...
API

 Gesture has priority over normal event
    handling
 •  Gesture may need several events before
    starting
 •  Norm...
Agenda

Introduction
Concepts
API
•  Examples
Q&A




               40
API

ITAI: PictureBlue
by Ariel Molina




                    h$p://vimeo.com/4990545



                               ...
Examples

Using QTouchEvent...

MyWidget::MyWidget(QWidget *parent) {
  setAttribute(Qt::WA_AcceptsTouchEvents);
}




   ...
Examples

Using QTouchEvent...

bool MyWidget::event(QEvent *e) {
  switch (e->type()) {
  case QEvent::TouchBegin:
  case...
Examples

Using QTouchEvent...

QTouchEvent *te = static_cast<QTouchEvent *>(e);
QList<QTouchEvent::TouchPoint> points = t...
Examples

Using QTouchEvent...

// determine scale factor
QTouchEvent::TouchPoint p0 = touchPoints.first();
QTouchEvent::T...
Examples

Using QTouchEvent...

// determine angle between previous and current pos
QTouchEvent::TouchPoint p0 = touchPoin...
And now some gestures...
Examples

Custom gesture – four finger tap
class FourFingerTapGesture : public QGestureRecognizer {
   virtual QGesture cr...
Examples

Custom gesture – four finger tap
class Label : public QLabel {
   virtual void gestureEvent(QGestureEvent *event...
Agenda

Introduction
Concepts
API
Examples
•  Q&A




               50
Thanks!

Any Questions?




                 51
