BeJUG JavaFx In Practice Presentation Transcript

  • 1. JavaFX in practice Jo Voordeckers jo.voordeckers@pursuit.be Thursday 28 May 2009 1
  • 2. About the speaker ‣ 2002 .. 2005 - Partner at Imagine-IT ‣ 2006 .. 2007 - Senior Software Engineer at Dolmen ‣ 2007 .. 2008 - Technical Project Leader at Dolmen ‣ 2008 - Founder Pursuit Consulting ‣ Independent Java EE and RIA contractor & consultant ‣ Speaker at: ‣ JavaOne, Devoxx, BeJUG, IT Works, SAI Thursday 28 May 2009 2
  • 3. Agenda ‣ Introduction ‣ Applying all the above ‣ JavaFX Script Language ‣ Media ‣ Scene graph ‣ Remote Services ‣ JavaFX Production Suite ‣ Browser Integration ‣ Styling ‣ Deployment ‣ Animation ‣ Tips and tricks ‣ Transformations ‣ Future of JavaFX ‣ Effects ‣ References ‣ Clipping ‣ Q&A Thursday 28 May 2009 3
  • 4. JavaFX Platform Thursday 28 May 2009 4
  • 5. JavaOne’08 keynote demo ParleysFX Thursday 28 May 2009 5
  • 6. Java’s issues as RIA platform ‣ Slow ‣ 10 - 30s for cold startup ‣ graphic performance ‣ applets often crash browser ‣ Difficult ‣ Java2D ‣ Swing - MVC (without binding & properties) ‣ Dated look & feel ‣ No built-in animation, effect ‣ No decent media support ‣ 10MB Plugin Thursday 28 May 2009 6
  • 7. The answer to RIA on the JVM ‣ Java 6u10 ‣ JavaFX ‣ Browser Plugin v2.0 ‣ JavaFX Scripting language ‣ Hardware rendering ‣ Keyframe Animations ‣ Modularized Java Runtime ‣ Effects ‣ Quick-starter ‣ Media Codecs ‣ Designer tools Thursday 28 May 2009 7
  • 8. Declarative and procedural ‣ JavaScript Object literal Notation (JSON) ‣ Java like procedural syntax Stage { title: quot;BEJUG DEMOquot; scene: Scene { width: 200 height: 200 def t:Text = Text { x: 50 y: 50 content: quot;Click Mequot; onMouseClicked: function(e) { service.registerClick(); t.content = quot;Thanks!quot;; } } content: t } } Thursday 28 May 2009 8
  • 9. Data types JavaFX Java String java.lang.String Boolean java.lang.Boolean Number java.lang.Number Integer java.lang.Integer Object java.lang.Object Void java.lang.Void Duration - var s:String = “hello”; var b:Boolean = true; var n:Number = 0.4; var i:Integer = 99; var o:Object = new java.util.Date(); var d:Duration = 10ms; Thursday 28 May 2009 9
  • 10. Defining variables ‣ var ‣ defines a regular variable ‣ def ‣ defines a constant variable through initial assignment ‣ value can change through binding!! ‣ Statically typed ‣ Compiler can infer the type var result; def numOne = 100; def numTwo = bind result; Thursday 28 May 2009 10
  • 11. Access modifiers JavaFX script, variable, function access modifiers Default, script read/write Package, package read/write Protected, package + subclass read/write Public, read/write from anywhere Public-read, read from anywhere, write from script by default, combine with package or protected Public-init, public-read + init from anywhere var s:String = quot;defaultquot;; package var s:String = quot;packagequot;; protected var s:String = quot;protectedquot;; public var s:String = quot;publicquot;; public-read var s:String = quot;public-readquot;; protected public-read var s:String = quot;protected write public-readquot;; public-init var s:String = quot;public-initquot;; Thursday 28 May 2009 11
  • 12. Sequences ‣ Dynamic array ‣ Powerful list comprehension and manipulation for (fooItem in foos where fooItem.bar == true) { var i = indexof fooItem; println(“Foo with bar at index {i} of {sizeof foos}”); } foosWithoutBar = foos[foo|foo.bar == false]; // Creates new sequence based on the condition insert foo in foos; // Insert object foo into sequence insert bar before foos[3]; // Insert object bar at position 4 delete foos[0]; // Remove the first object from sequence reverse foos; // Reverses the objects in foos Sequences.sort(foos); // Equivalent of java.util.Collections Thursday 28 May 2009 12
  • 13. Functions & closures ‣ Executable block of code ‣ Return value from last expression (Void) ‣ First-class objects: “closures” ‣ Bound - Function public class FilterableList { public-init var list:Object[]; public function filter(predicate : function(o:Object):Boolean) { list = list[item|predicate(item)]; } } function run(__ARGS__ : String[]) { } // Java main() equivalent Thursday 28 May 2009 13
  • 14. Multiple Inheritance ‣ No interfaces, use abstract classes ‣ JavaFX class can extend multiple JavaFX classes ‣ ** will get replaced by mixins in the near future ‣ JavaFX class can implement multiple Java interfaces ‣ JavaFX class can extend 1 Java class (no varargs, enums, generics) public abstract class Clickable extends CustomNode { public abstract function onClick():Void; } public class ListBox extends AbstractList, Clickable { // TODO implement java.util.AbstractList.get(), // Clickable.onClick(), CustomNode.create() } Thursday 28 May 2009 14
  • 15. Binding ‣ Bi-directional binding (with inverse) var x:Integer; Stage { title : quot;BEJUG DEMOquot; scene: Scene { width: 400, height: 200 content: [ Text { x: 20 y: 20 content: bind quot;Location X = {x}quot; }, Rectangle { width: 20 height: 20 fill: Color.BLUE x: bind x y: 50 onMouseDragged: function(e:MouseEvent) { x = (e.dragAnchorX + e.dragX as Integer) - 10; } } ] } } Thursday 28 May 2009 15
  • 16. Bound functions var x:Integer; bound function percentage():Integer { x * 100 / s.width as Integer; } var s:Stage = Stage { title : quot;BEJUG DEMOquot; scene: Scene { width: 400, height: 200 content: [ Text { x: 20 y: 20 content: bind quot;Location X = {x}, % = {percentage()}quot; }, Rectangle { width: 20 height: 20 fill: Color.BLUE x: bind x, y: 50 onMouseDragged: function(e:MouseEvent) { x = (e.dragAnchorX + e.dragX as Integer) - 10; } } ] } } Thursday 28 May 2009 16
  • 17. Triggers var x:Integer on replace oldVal { if (x < 25) { x = 25; } else if (x > 75) { x = 75; } }; Stage { title : quot;BEJUG DEMOquot; scene: Scene { width: 400, height: 200 content: [ Text { x: 20, y: 20, content: bind quot;Location X = {x}quot; }, Rectangle { width: 20, height: 20, fill: Color.BLUE x: bind x, y: 50 onMouseDragged: function(e:MouseEvent) { x = (e.dragAnchorX + e.dragX as Integer) - 10; } } ] } } Thursday 28 May 2009 17
  • 18. Bind for class CoolList extends CustomNode { public var list:String[]; override public function create():Node { Group { content: bind for (item in list) Group { translateY: 25 * indexof item content: [ Rectangle { fill: Color.BLUE width: bind s.width height: 20 }, Text { x: 10, y: 15, content: item } ] } } } } var s:Stage = Stage { title : quot;BEJUG DEMOquot; scene: Scene { width: 400, height: 200 content: CoolList { list: [ quot;Firstquot;, quot;Secondquot;, quot;Lastquot; ] } } } Thursday 28 May 2009 18
  • 19. Init and postinit ‣ No support for constructors ‣ Closest equivalent: optional init and postinit function blocks ‣ ** postinit might get removed in future releases public class MyControl extends Control { public var myVar:Number; override var skin = MyControlSkin{}; // initialized before myVar } public class MyControl extends Control { public var myVar:Number; postinit {skin = MyControlSkin{}; } // initialized after myVar } Thursday 28 May 2009 19
  • 20. Exceptions - throw, try, catch, finally ‣ JavaFX support Java exceptions if (foo == null) throw new RuntimeException(“Foo is null”); try { connectAndDisplayShoppingList(); } catch (e: Exception) { showErrorMessage(e); } finally { closeConnection(); } Thursday 28 May 2009 20
  • 21. Magic variables ‣ __ARGS__ command line arguments ‣ function run(__ARGS__ : String[]): java.lang.Object { } ‣ __DIR__ Java URI to the directory of the current script ‣ __FILE__ Java URI to the current script (class file) ‣ __PROFILE__ Profile the runtime is using: ‣ desktop, mobile, browser ‣ Often used to reference packaged (JAR) resources ‣ Image { url: quot;{__DIR__}images/close.pngquot; } cache: true } Thursday 28 May 2009 21
  • 22. Getting started SceneGraph ‣ Stage - Hybrid Application and/or Applet container ‣ Style (Shaped Windows) Group ‣ Opacity ‣ Applet drag events Overview Presentation ‣ Position & Size Panel ViewPanel ‣ Title ‣ Close-action Collapsible Panel ‣ Scene - Root of the scene graph ‣ “Graph data structure that holds Left Right Collapse Splitter ‣ Container Container Button the spatial representation (Group) (Group) (Rectangle) (Shape) ‣ of the graphical scene” TopLists Presentations Panel Panel (HBox) (HBox) Thursday 28 May 2009 22
  • 23. Node’s most interesting properties ‣ transforms or: ‣ hover ‣ translateX/Y ‣ onMouseXXX ‣ scaleX/Y ‣ onKeyXXX ‣ rotateX/Y ‣ boundsInLocal, boundsInParent, boundsInScene ‣ effect ‣ blocksMouse ‣ visible ‣ clip ‣ opacity ‣ id ‣ cache ‣ styleClass Thursday 28 May 2009 23
  • 24. CustomNode public class MyButton extends CustomNode { override public function create():Node { Group { content: [ Rectangle { width: 200, height: 40, arcHeight: 10, arcWidth: 10 fill: LinearGradient { startX: 0, endX: 0, startY: 0, endY: 1 stops: [ Stop { color: Color.BLACK, offset: 0 }, Stop { color: Color.BLUE, offset: 1 }, ] } }, Text { x: 100, y: 10, textOrigin: TextOrigin.TOP content: quot;Buttonquot; fill: Color.WHITE, textAlignment: TextAlignment.CENTER } ] } } } Thursday 28 May 2009 24
  • 25. Production Suite ‣ Produces FXD files (FXZ = zipped) ‣ Adobe Photoshop plugin ‣ Adobe Illustrator plugin ‣ SVG to FXD converter ‣ FXD Viewer ‣ Integrate into JavaFX ‣ UIStub ‣ FXDLoader Thursday 28 May 2009 25
  • 26. JavaFX in style Rectangle { arcWidth: 10; arcHeight: 10; } .bg { fill: #ccccff; stroke: #333399; } var stylesheets : String = “{__DIR__}default.cssquot;; Stage { scene: Scene { stylesheets: bind stylesheets } } Rectangle { x: 10 y: 70 width: 200 height: 50 fill: Color.RED styleClass: quot;bgquot; } Thread on forum has more details: http://forums.sun.com/thread.jspa?threadID=5357325&tstart=0 Thursday 28 May 2009 26
  • 27. Animations def t2 = Timeline { ‣ First class citizen in JavaFX autoReverse: true repeatCount: 10 keyFrames: [ at (0s) { ‣ Key-frame based r2 => 0 }, ‣ Interpolators at (1s) { r2 => 150 tween ‣ Callback functions Interpolator.EASEBOTH }, ] ‣ Timeline can be nested! }; ‣ Interpolates: numbers, colors, shapes (morphing) ‣ + any class that extends Interpolatable !! Thursday 28 May 2009 27
  • 28. Transformations ‣ Affine transformations supported on all Node objects ‣ Translate ‣ Rotate ‣ Scale ‣ Shear ‣ PerspectiveTransform ‣ NOT an affine transform! ‣ @see Effects Thursday 28 May 2009 28
  • 29. Effects ‣ One or more inputs (Effect chaining) ‣ Effect Types ‣ Reflection ‣ PerspectiveTransform Text { effect: Reflection { ‣ Glow input: MotionBlur { angle: 180 } } ‣ Blur translateX: 20 translateY: 20 ‣ DropShadow content: quot;BeJUG JavaFX in practicequot; fill: Color.RED font: Font { name: quot;Verdanaquot;, size: 20 } ‣ ColorAdjust }, ‣ @see JavaFX.com EffectsPlayground DEMO by Chris Campbell Thursday 28 May 2009 29
  • 30. Clipping ‣ Think “digital scissors” ‣ Intersection of clip shape ‣ and Node defines the visual ‣ portion of the Node ‣ Often used to slide a group of Nodes out of the scene Rectangle { width: 100, height: 100 fill: Color.BLUE clip: Circle { centerX: 75, centerY: 75, radius: 50 } } Thursday 28 May 2009 30
  • 31. Building a website menu ‣ Combines following JavaFX functionality ‣ Binding ‣ For-each ‣ CustomNode ‣ Timeline ‣ KeyFrames ‣ Interpolators ‣ Effects ‣ DropShadow ‣ Node Clipping Thursday 28 May 2009 31
  • 32. Media in JavaFX ‣ Easy to play video and audio content ‣ MediaView ‣ Effects, Transformations, Animations, Clipping ‣ MediaPlayer ‣ Streaming, progressive download, buffering, seeking, ... ‣ There is a business case for media! Thursday 28 May 2009 32
  • 33. Media support Thursday 28 May 2009 33
  • 34. MediaPlayer in 10 lines ‣ MediaPlayer - Controller ‣ MediaView - View ‣ Media - Model ‣ Don’t use {__DIR__} media playing from JAR URI’s not supported! def mp:MediaPlayer = MediaPlayer { media: Media { source: quot;file:/path/to/movie.movquot; } } content: [ MediaView { mediaPlayer: mp, fitWidth: 400, fitHeight: 200 onMouseClicked: function(e) { if (mp.status == mp.PLAYING) mp.stop() else mp.play(); } }, ] Thursday 28 May 2009 34
  • 35. Browser integration ‣ JavaScript calling into JavaFX public function setColor(red: Number, green: Number, blue: Number) : Void { color = Color { red: red, green: green, blue: blue }; } public function run(args: String[]) { Stage { scene: Scene { fill: Color.DARKGRAY content: [ Circle { centerX : 125 centerY : 125 radius: 100 fill: bind color } ] } } } var app = document.getElementById(quot;myAppletquot;); app.script.setColor(1.0, 0.0, 0.0); Thursday 28 May 2009 35
  • 36. Browser integration ‣ JavaFX calling into JavaScript ‣ DOM manipulation through org.w3c.dom.html.HTMLDocument import javafx.stage.AppletStageExtension; // Show a document in a new browser window AppletStageExtension.showDocument(quot;http://my.company.com/quot;); // Show a document in a frame of the current browser window AppletStageExtension.showDocument(quot;http://my.company.com/quot;, quot;LEFT_FRAMEquot;); AppletStageExtension.eval(quot;someJavaScriptFunction()quot;); var window: netscape.javascript.JSObject = FX.getArgument(quot;javafx.appletquot;) as netscape.javascript.JSObject; // Now can interact with the JSObject APIs and call JavaScript // functions, etc. defined in the window scope Thursday 28 May 2009 36
  • 37. JavaFX Application Architecture JavaFX Controls and Components Models (JavaFX or Java) Controller (JavaFX or Java) Communication Layer (JavaFX or Java) Façade exposing the Services Enterprise Services (Spring beans / EJB) Database or Integration Layer Thursday 28 May 2009 37
  • 38. Remote Services ‣ RemoteTextDocument ‣ PullParser ‣ Restful XML & JSON services ‣ Support linear mode forward, seek, … ‣ JFXtras - http://jfxtras.org/ ‣ JSONHandler ‣ JFXWorker ‣ Whatever you like as long as it runs on the JVM! Thursday 28 May 2009 38
  • 39. RemoteTextDocument ‣ Fetches remote document asynchronously in a String ‣ document ‣ done ‣ failed ‣ canceled var remoteTextDocument:RemoteTextDocument = RemoteTextDocument { url: quot;http://api.flickr.com/services/feeds/photos_public.gnequot;; } var doc:String = bind remoteTextDocument.document on replace { if (remoteTextDocument.done) java.lang.System.out.println(quot;doc = {doc}quot;); } Thursday 28 May 2009 39
  • 40. PullParser with XML override function onPullEvent(event : Event) : Void { if (quot;Resultquot;.equals(event.qname.name) and event.level == 1) { total = event.getAttributeValue( QName{name:quot;totalResultsAvailablequot;}); } } def pullParser = PullParser { documentType: PullParser.XML; onEvent: onPullEvent } def httpRequest : HttpRequest = HttpRequest { method: HttpRequest.GET location: “http://url.to/service” onInput: function(is: InputStream) { try { pullParser.input = is; pullParser.parse(); } finally { is.close(); } } } httpRequest.enqueue(); Thursday 28 May 2009 40
  • 41. JFXtras JFXWorker ‣ Leverages SwingWorker for background task execution ‣ desktop profile ‣ Required when not using JavaFX asynchronous API’s! ‣ Call into any Java communication API or library ‣ JAX-* var listData:Object; ‣ Java RMI def myWorker = JFXWorker { ‣ Spring Remoting / WS inBackground: function():Object { return service.call(); } ‣ AMF onDone: function(result:Object) { listData = result; } } myWorker.start(); Thursday 28 May 2009 41
  • 42. JFXtras JSONHandler ‣ Glassfish v2 + Jersey JAX-RS Sample (with CustomerDB) ‣ Implement JavaFX counterpart of Java entities ‣ Implement JSONHandler ‣ Call JSONHandler.parse(); var customers:Customer[]; def handler:JSONHandler = JSONHandler { url: quot;http://localhost:8080/CustomerDB/resources/customers/quot; rootClass: quot;jaxrs.CustomerResultquot; onDone: function(result:Object, isSequence:Boolean) { customers = (result as CustomerResult).customer; } } Thursday 28 May 2009 42
  • 43. Deployment ‣ Deployment toolkit ‣ JavaScript library hosted at java.com ‣ Autodetects & installs correct Java version <html> <script src=quot;http://java.com/js/deployJava.jsquot;></script> <script> var attributes = {codebase:'http://yourdomain.com/YourApplet', code:'javafx.application.Applet.class', archive:'YourApplet.jar, javafxrt.jar, Scenario.jar, javafxgui.jar’, width:500, height:500, java_arguments:'-Djnlp.packEnabled=true'}; var parameters = {quot;ApplicationClassquot;: quot;com.yourdomain.YourAppletquot;, quot;draggablequot;:quot;truequot;}; var version = '1.6.0' ; deployJava.runApplet(attributes, parameters, version); </script> </html> Thursday 28 May 2009 43
  • 44. JNLP ‣ Since 6u10 also for applets ‣ Library dependencies ‣ eg: JavaFX runtime ‣ Runtime settings ‣ Memory ‣ Commandline arguments ‣ Native libraries ‣ Security settings ‣ Escape browser sandbox Thursday 28 May 2009 44
  • 45. Tips and tricks ‣ Wrap custom components in a ‣ Pre-scale Images Group ( Image.width, Image.height ) ‣ Comment logical parts of the ‣ Background loading SceneGraph ‣ Integer instead of Number ‣ Avoid unnecessary bindings ‣ Use javafx.util.Sequences ‣ Cache complex components ( Node.cache: true ) ‣ Use Java code for the heavy lifting ‣ Transparent Rectangle to capture mouse events ‣ Avoid the non-common profile classes (eg: Swing components) ‣ Small Scene graph Thursday 28 May 2009 45
  • 46. What to expect ‣ JavaFX 1.5 (released at JavaOne ’09) ‣ Skinnable native JavaFX components (common profile) ‣ JavaFX “Designer’s Tool” ‣ JavaFX Runtime improvements (bugs, performance, documentation) ‣ Netbeans plugin improvements (bugs and features) ‣ Java App Store (aka Project Vector) ‣ Future ‣ Mixins instead of multiple inheritance ‣ Mac OS X Java 6 “update 10” ‣ Linux & Solaris media support!? Thursday 28 May 2009 46
  • 47. Resources ‣ http://JavaFX.com ‣ 50+ samples with source code ‣ Tutorials and JavaFX API’s ‣ Netbeans SDK with JavaFX ‣ JavaFX editor and sample applications ‣ JavaFX Production Suite ‣ http://JFXpert.com ‣ Many tutorials by “PRO JavaFX Platform” author Jim Weaver ‣ http://jfxstudio.wordpress.com ‣ 70+ samples from the community Thursday 28 May 2009 47
  • 48. Q & A Thursday 28 May 2009 48
