Kinect krishna kumar-itkan

Where you are the controller

Krishna Kumar, Sr. Developer Evangelist - Academic [email_address]

Started as a $30,000 prototype Vision: Shift the world from thinking “We need to understand technology” to " Technology needs to understand us "

Option A:
Why Kinect ?

Why Kinect ?
Option You:

What is Kinect ?

What is Kinect ?
An extraordinary new way to play,
where you are the controller
Voice Recognition Face Recognition You Recognition Gesture Recognition “ Xbox”

Kinect knows what to do! “ Xbox?!” “ Let’s Play!”

“ What are those things?” ① ③ ②

“ What are those things?” 3D Depth Sensors ① ③

Projected Invisible IR pattern

Depth Computation

Depth Map

“ What are those things?” RGB Camera ②

“ What are those things?” Multi-array Microphone

“ What are those things?” Motorized Tilt

Combination of RGB camera, depth sensor and multi-array microphone
RBG camera delivers three basic color components
Depth sensors “sees” the room in 3-D
Microphone locates voices by sound and extracts ambient noise
Software makes all the magic possible
Skeletal Tracking
Face, Gesture Recognition
Audio Echo cancellation
Audio Beam Forming
Speech Recognition

Scope of Microsoft Research
Significant Investment
Investing > $9B in R&D (MSR & product dev)
Staff of over 850 in 55 research areas
International Research lab locations :
Redmond, Washington (Sept, 1991)
San Francisco, California (1995)
Cambridge, United Kingdom (July, 1997)
Beijing, People’s Republic of China (Nov, 1998)
Mountain View, California (July, 2001)
Bangalore, India (January, 2005)
Cambridge, Massachusetts (February, 2008)
Turning ideas into reality.
research.microsoft.com

Scope of Microsoft Research
Research Areas
research.microsoft.com

How does Kinect know what I do? “ Xbox?!” “ Let’s Play!”

Microsoft Research: Object Recognition J. Shotton, J. Winn, C. Rother, A. Criminisi, TextonBoost : Joint Appearance, Shape and Context Modeling for Multi-Class Object Recognition and Segmentation. European Conference on Computer Vision, 2006

Microsoft Research: Human Body Tracking
Wide range of motion
But limited agility
And not real-time
Infinite number of movements
R Navaratnam, A Fitzgibbon, R Cipolla The Joint Manifold Model for Semi-supervised Multi-valued Regression IEEE Intl Conf on Computer Vision, 2007

XBox calls MSR: September 2008
“ We need a body tracker with
All body motions…
All agilities…
10x Real-time…
For multiple players…
… and it has to be 3D  ”
MSR’s response?

Teach the Computer/Machine Learning
Step 1: Collect A LOT of Data
Teams visit households across the globe, filming real users
Hollywood motion capture studio generates billions of CG images

Training Data

Training
Millions of training images -> millions of classifier parameters
Very far from “embarrassingly parallel”
New algorithm for distributed decision-tree training
Major use of DryadLINQ
available for download
Distributed Data-Parallel Computing Using a High-Level Programming Language M Isard, Y Yu International Conference on Management of Data (SIGMOD), July 2009

Recognize Joint Angles
Classify each pixel’s probability of being each of 32 body parts
Determine probabilistic cluster of body configurations consistent with those parts
Present the most probable to the user
t=1 t=2 t=3

Programmers View

A Platform is Born

Consumer Technologies Push The Envelope Price: $6000 Price: $150

Play Space Field of View and Operational Area
Play Space : Ideally need 12ft x 12ft of play space though you can make do with 10ft x 10ft
Player Position : Ideally is 6-10 feet away from camera

Lighting and Environment
Fluorescent or LED lighting are recommended
No direct light on player
No direct light into sensor lens
In a stage environment, all lights need to be Infrared-filtered
To avoid lighting noise do not intersect sensor lens fields of view
Avoid playing in/next to reflective surfaces

Clothing Considerations
Avoid anything that conceals your arms or legs
Avoid wearing flowing clothing such as scarves or long dresses and skirts
Long skirts hide the legs and scarves are often mistaken for arms
Avoid baggy jackets or overly baggy clothing
Generally, anything that hides the human form should be removed for optimal game play
If players with long hair are having difficulty playing, encourage them to pull their hair back and try playing again

Kinect with more than just games
Use your voice or a wave of your hand to:
Video Kinect with others*
Manage your media gallery
Music with Last.fm*
HD movies with Zune
Get in the game with ESPN*
* with Xbox LIVE Gold membership

XBOX LIVE More Ways to Connect with Family and Friends VIDEO KINECT FAMILY CENTER SOCIAL NETWORKS
Connect with family and far away friends, all from the comfort of your living room with Xbox LIVE Video Chat
Experience the ease and convenience of chat on the big screen with Kinect-enabled auto camera zoom and pan.
Family Center makes it easy to manage multiple user accounts and edit privacy settings from a single location
Ensure safe, secure fun for the whole family
Connect with friends, share photos and updates through Facebook and Twitter

ESPN Home-field advantage in your living room
Access over 3,500 live global events from ESPN3.com, including out-of-market programming plus fresh video clips from ESPN.com
Enjoy features like HD programming and on-demand viewing, participate in polls, predictions and trivia.
See what the Xbox LIVE community is watching and declare what team you’re rooting for
With Kinect™ control the action right from your couch with just your voice or the wave of your hand
Featured Content:
NCAA Football, NCAA Basketball, College Bowl Games, NBA, MLB, Soccer, Golf and Tennis majors

Where can Kinect go?
Air Guitar Hero?
Shopping in 3D?
Remote Replacement?
Dance Instructor?
Education?
Personal Trainer?
Physical Therapy?
“ Xbox?”

The Kinect SDK
Provides both Unmanaged and Managed API
Unmanaged API – Concepts work in C++
Managed API – Concepts work in both VB/C#
Samples & documentation to get you started
Assumes some programming experience
http://research.microsoft.com/kinectsdk/

The Kinect Sensor
A hybrid device containing the following input devices:
A color (RGB) camera
A depth sensor
A microphone array
A tilt sensor
Play space control is done through a tilt motor
Pitch +/- 27 degrees

RGB CAMERA MULTI-ARRAY MIC MOTORIZED TILT 3D DEPTH SENSORS

Kinect USB cable

The Innards

The Vision System IR laser projector IR camera RGB camera

Kinect video output
30 HZ frame rate; 57deg field-of-view
8-bit VGA RGB 640 x 480 12-bit monochrome 320 x 240

The Audio System

Demo: Multichannel Echo Cancellation Input Stream (What the mic array hears) Post-MEC (What APIs present) MEC

The Kinect SDK
Provides access to:
RGB feed
Depth feed
Skeletal Tracking capabilities
Audio Beam data
Speech Recognition

Data Streams
Color stream at 640x480 resolution; 32BPP
Depth stream at 320 x 240 resolution; 16BPP
Skeletal Joint positions
Frame #s, TimeStamps, Tilt sensor data
Echo-canceled audio
Higher level systems
Speech recognition

RGB Camera Fundamentals

Camera Data

RGB stream Format
Upto 640 x 480 resolution
Upto 32 bits per pixel
Data contained in ImageFrame.Image.Bits
Array of bytes public byte [] Bits;
Array
Starts at top left of image
Moves left to right, then top to bottom

Stride Stride - # of bytes from one row of pixels in memory to the next

Demos::RGB Camera

Depth Camera Fundamentals

Camera Data

Depth Map Format
320 x 240 resolution
16 bits per pixel
Upper 13 bits: depth in mm: 800 mm to 4000 mm range
Lower 3 bits: segmentation mask
Depth value 0 means unknown
Shadows, low reflectivity, and high reflectivity among the few reasons
Segmentation index
0 – no player
1 – skeleton 0
2 – skeleton 1
…

Depth Byte Buffer
ImageFrame.Image.Bits
Array of bytes public byte [] Bits;
Array
Starts at top left of image
Moves left to right, then top to bottom
Represents distance for pixel

Calculating Distance
2 bytes per pixel (16 bits)
Depth – Distance per pixel
Bitshift second byte by 8
Distance (0,0) = ( int )(Bits[0] | Bits[1] << 8 );
DepthAndPlayer Index – Includes Player index
Bitshift by 3 first byte (player index), 5 second byte
Distance (0,0) = ( int )(Bits[0] >> 3 | Bits[1] << 5 );

Demos::Depth Camera

Skeletal Tracking Fundamentals

Human Depth Sensing Object pattern similarity determines disparity

Kinect Depth Sensing IR pattern similarity determines disparity IR Projector IR Camera

Provided Data

Pipeline Architecture Title Space

Skeleton API

Joints
Maximum two players tracked at once
Six player proposals
Each player with set of <x, y, z> joints in meters
Each joint has associated state
Tracked, Not tracked, or Inferred
Inferred - Occluded, clipped, or low confidence joints
Not Tracked - Rare, but your code must check for this state

Provided Data
Depth and segmentation map

Depth Map Format
320 x 240 resolution
16 bits per pixel
Upper 13 bits: depth in mm: 800 mm to 4000 mm range
Lower 3 bits: segmentation mask
Depth value 0 means unknown
Shadows, low reflectivity, and high reflectivity among the few reasons
Segmentation index
0 – no player
1 – skeleton 0
2 – skeleton 1
…

Demos::Skeletal Tracking

Audio Fundamentals

Going Inside the Kinect
Four microphone array with hardware-based audio processing
Multichannel echo cancellation (MEC)
Sound position tracking
Other digital signal processing (noise suppression and reduction)

Audio Data

Speech Recognition
Grammar – What we are listening for
Code – GrammarBuilder, Choices
Speech Recognition Grammar Specification (SRGS)
C:Program Files (x86)Microsoft Speech Platform SDKSamplesSample Grammars
Note: Set AutomaticGainControl = false

Grammar

< rule id ="Confirmation_YesNo" scope ="public">
< example > yes </ example >
< example > no </ example >
< one-of >
< item >
< ruleref uri ="#Confirmation_Yes" />
</ item >
< item >
< ruleref uri ="#Confirmation_No" />
</ item >
</ one-of >
< tag > out = rules.latest() </ tag >
</ rule >
</ rule >
 < rule id ="Confirmation_Yes" scope ="public"> < example > yes </ example > < example > yes please </ example > < one-of > < item > yes </ item > < item > yeah </ item > < item > yep </ item > < item > ok </ item > </ one-of > < item repeat ="0-1"> please </ item > < tag > out._value = "Yes"; </ tag >

Demos::Audio
