High Speed SOA with  Apache Synapse Paul Fremantle VP, Apache Synapse CTO, WSO2 [email_address]
Contents <ul><li>What is Apache Synapse </li></ul><ul><li>History of the project </li></ul><ul><li>Some examples </li></ul...
What is Apache Synapse? <ul><li>Is it? </li></ul><ul><ul><li>A highly performant XML Gateway </li></ul></ul><ul><ul><li>An...
What is Apache Synapse? <ul><li>A lightweight  Enterprise Services Bus (ESB) </li></ul><ul><ul><li>Available as a WAR file...
Flows JMS SMTP inflow log xslt send outflow send xslt log HTTP 8080 HTTPS 8443 JMS SMTP HTTP 8080 HTTPS 8443
Synapse startup <ul><li>Using Bouncy castle JAR for Java 1.5 </li></ul><ul><li>Starting Synapse/Java ... </li></ul><ul><li...
History of the project <ul><li>August 2005 Kicked off as an incubator proposal </li></ul><ul><li>December 2005 Milestone 1...
A really simple example <ul><li>Exposing an existing SOAP endpoint as XML/HTTP, XML/JMS </li></ul><ul><li><definitions>  <...
Some other things you can do  “out of the box” <ul><li>Content-based routing </li></ul><ul><ul><li>Direct messages based o...
Registries and Dynamism Synapse “Registry” HTTP extensible read and cache notify <ul><li>“ Transactional updates” </li></u...
A more detailed example NY Variable Format  records London Existing trade database D2243578XX910 D6233578YYYY9 <FEED> <CAK...
Overview of the flow <ul><li><sequence name=“new york”> </li></ul><ul><li>Flatpack with Variable record config </li></ul><...
Results <ul><li>Replicated a 3 month project is 3 days </li></ul><ul><ul><li>Included enhancing the Flatpack mediator to s...
Google Spreadsheet and CSV Google.com CSV Synapse Http Poller Job CSV to XML Atom
Esper <ul><li>Event Stream Processing project </li></ul><ul><ul><li>http://esper.codehaus.org </li></ul></ul><ul><li>Allow...
Ganglia, Quartz, Esper Synapse Quartz Scheduler Ganglia gmond telnet 8649 <GANGLIA_XML> GMondPoller Job Esper Mediator SEL...
<ul><li><definitions xmlns=&quot;http://ws.apache.org/ns/synapse&quot;> </li></ul><ul><li><task class=&quot;org.fremantle....
Performance <ul><li>Non-blocking IO </li></ul><ul><ul><li>Apache HTTPCore  </li></ul></ul><ul><ul><li>http://hc.apache.org...
Non-blocking graphically <ul><li>This model means: </li></ul><ul><li>Synapse threads never blocked during normal processin...
Demonstrating Performance <ul><li>Synapse by default runs  </li></ul><ul><ul><li>2 listener threads </li></ul></ul><ul><ul...
XSLT performance
Extending Synapse <ul><li>Java Mediators  </li></ul><ul><ul><li>Implement a simple Java API </li></ul></ul><ul><li>Java Co...
Simple Mediator: CSV->XML <ul><li>public boolean mediate(MessageContext mc) { </li></ul><ul><ul><li>DataHandler  dh = Payl...
Tasks – Quartz integration <ul><li>Simple repetitive actions </li></ul><ul><li>Can also be used to start a long-running ac...
Sample task - MessageInjector <ul><li>public class MessageInjector  implements Task, ManagedLifecycle </li></ul><ul><li>{ ...
Script example <script language=&quot;js&quot;><![CDATA[ var rowset = mc.getPayloadXML() var ns = new  Namespace(&quot;htt...
Community Site for extensions http://esbsite.org
Connectors, Adapters, Other projects <ul><li>CSV, Fixed and Variable records – FlatPack, OpenCSV </li></ul><ul><li>FIX tra...
User quotes <ul><li>&quot;Synapse's simplicity of configuration, ease of extensibility, and integration were the key facto...
Futures <ul><li>We continue to add new mediators and transports </li></ul><ul><li>Better support for complete HTTP Proxy  ...
Getting Started
Getting Involved <ul><li>Join us </li></ul><ul><ul><li>[email_address] </li></ul></ul><ul><ul><li>[email_address] </li></u...
Questions?
Upcoming SlideShare
Loading in...5
×

Fast SOA with Apache Synapse

14,289

Published on

Presented at ApacheCon Europe 2008: this presentation introduces the ApacheCon Synapse ESB and the performance benefits of the design.

Published in: Technology

Fast SOA with Apache Synapse

  1. 1. High Speed SOA with Apache Synapse Paul Fremantle VP, Apache Synapse CTO, WSO2 [email_address]
  2. 2. Contents <ul><li>What is Apache Synapse </li></ul><ul><li>History of the project </li></ul><ul><li>Some examples </li></ul><ul><li>Delving into the model </li></ul><ul><li>Performance </li></ul><ul><li>Connectors, Adaptors </li></ul><ul><li>Getting started </li></ul><ul><li>Getting involved </li></ul>
  3. 3. What is Apache Synapse? <ul><li>Is it? </li></ul><ul><ul><li>A highly performant XML Gateway </li></ul></ul><ul><ul><li>An Enterprise Service Bus </li></ul></ul><ul><ul><li>An HTTP proxy server </li></ul></ul><ul><ul><li>A protocol switcher </li></ul></ul><ul><ul><li>A way of hosting message manipulation logic </li></ul></ul>
  4. 4. What is Apache Synapse? <ul><li>A lightweight Enterprise Services Bus (ESB) </li></ul><ul><ul><li>Available as a WAR file, NT Service, Linux Daemon </li></ul></ul><ul><ul><li>Runs as a process with its own Listeners, Tasks and Senders </li></ul></ul><ul><ul><li>Can be deployed standalone or part of a cluster or distributed network </li></ul></ul><ul><ul><li>High performance, asynchronous, streaming design </li></ul></ul><ul><ul><li>Can initiate work – scheduled tasks </li></ul></ul><ul><ul><li>Supports multiple transports including HTTP, JMS, TCP, SMTP and (S)FTP </li></ul></ul><ul><ul><li>Simple to extend </li></ul></ul>
  5. 5. Flows JMS SMTP inflow log xslt send outflow send xslt log HTTP 8080 HTTPS 8443 JMS SMTP HTTP 8080 HTTPS 8443
  6. 6. Synapse startup <ul><li>Using Bouncy castle JAR for Java 1.5 </li></ul><ul><li>Starting Synapse/Java ... </li></ul><ul><li>Using SYNAPSE_HOME: C:SYNAPS~1.1in.. </li></ul><ul><li>Using JAVA_HOME: c:jdk </li></ul><ul><li>Using SYNAPSE_XML: -Dsynapse.xml=&quot;C:SYNAPS~1.1in.. epositoryconfsynapse.xml&quot; </li></ul><ul><li>2007-11-12 12:16:58,250 [-] [main] INFO ServerManager Using the Axis2 Repository C:SYNAPS~1.1in.. epository </li></ul><ul><li>2007-11-12 12:17:01,921 [-] [main] INFO SynapseInitializationModule Initializing Synapse at : Mon Nov 12 12:17:01 GMT 2007 </li></ul><ul><li>2007-11-12 12:17:01,937 [127.0.0.1-pzfdell] [main] INFO SynapseInitializationModule Loading mediator extensions... </li></ul><ul><li>2007-11-12 12:17:01,937 [127.0.0.1-pzfdell] [main] INFO SynapseInitializationModule Initializing the Synapse configuration ... </li></ul><ul><li>2007-11-12 12:17:01,968 [127.0.0.1-pzfdell] [main] INFO XMLConfigurationBuilder Generating the Synapse configuration model by parsing the XML configuration </li></ul><ul><li>(some deleted) </li></ul><ul><li>2007-11-12 12:17:04,359 [127.0.0.1-pzfdell] [main] INFO HttpCoreNIOSender HTTP Sender starting </li></ul><ul><li>2007-11-12 12:17:04,968 [127.0.0.1-pzfdell] [main] INFO HttpCoreNIOListener HTTPS Listener starting on port : 8443 </li></ul><ul><li>2007-11-12 12:17:04,968 [127.0.0.1-pzfdell] [main] INFO ServerManager Starting transport https on port 8443 </li></ul><ul><li>2007-11-12 12:17:05,046 [127.0.0.1-pzfdell] [main] INFO ServerManager Ready for processing </li></ul>
  7. 7. History of the project <ul><li>August 2005 Kicked off as an incubator proposal </li></ul><ul><li>December 2005 Milestone 1 released </li></ul><ul><li>July 2006 Milestone 2 released </li></ul><ul><li>December 2006 Synapse 0.90 released </li></ul><ul><li>January 2007 Graduates from Incubator </li></ul><ul><li>May 2007 Released 1.0 </li></ul><ul><li>December 2007 Becomes a Top Level Project </li></ul><ul><li>January 2008 Synapse 1.1.1 released </li></ul>
  8. 8. A really simple example <ul><li>Exposing an existing SOAP endpoint as XML/HTTP, XML/JMS </li></ul><ul><li><definitions> </li></ul><ul><li><proxy name=“example&quot; transports=“http jms&quot;> </li></ul><ul><li><target> </li></ul><ul><li><endpoint> </li></ul><ul><li> <wsdl uri=“http://remote.com/service?wsdl“ </li></ul><ul><li>service=“RemoteService&quot; </li></ul><ul><li>port=“RemotePort&quot;/> </li></ul><ul><li></endpoint> </li></ul><ul><li><outSequence> </li></ul><ul><li><send/> </li></ul><ul><li> </outSequence> </li></ul><ul><li></target> </li></ul><ul><li></proxy> </li></ul><ul><li></definitions> </li></ul>
  9. 9. Some other things you can do “out of the box” <ul><li>Content-based routing </li></ul><ul><ul><li>Direct messages based on properties or XPath expressions </li></ul></ul><ul><li>Convert from existing formats (CSV, Fixed records, etc) to and from XML </li></ul><ul><li>Transform XML </li></ul><ul><ul><li>Using XSLT or XQuery </li></ul></ul><ul><li>Validate using XML Schema </li></ul><ul><li>Update databases and enhance messages with extra data </li></ul><ul><ul><li>DBLookup and DBReport mediators – any JDBC database </li></ul></ul><ul><li>Switch between SOAP and non-SOAP, any transport </li></ul><ul><ul><li>HTTP, HTTPS, SMTP/POP3, XMPP, JMS, TCP, Filesystem, FTP, AMQP </li></ul></ul><ul><li>Add or handle WS-* support including </li></ul><ul><ul><li>WS-Security, WS-SecureConversation, WS-Trust, WS-ReliableMessaging </li></ul></ul><ul><li>Load balancing, failover, throttling </li></ul>
  10. 10. Registries and Dynamism Synapse “Registry” HTTP extensible read and cache notify <ul><li>“ Transactional updates” </li></ul><ul><li>existing flows continue to use old config </li></ul><ul><li>Also graceful restart </li></ul><ul><li>switch off transport cleanly </li></ul><ul><li>restart Synapse when all work is done </li></ul>
  11. 11. A more detailed example NY Variable Format records London Existing trade database D2243578XX910 D6233578YYYY9 <FEED> <CAK>2243578</CAK> <AccNo>3289019</AccNo> <CAT>AK</CAT> … </FEED> WS-Security (encryption and digital signature) MQ Validation
  12. 12. Overview of the flow <ul><li><sequence name=“new york”> </li></ul><ul><li>Flatpack with Variable record config </li></ul><ul><li>E4X script to reformat XML </li></ul><ul><li>Send to London </li></ul><ul><li></sequence> </li></ul><ul><li><sequence name=“london”> </li></ul><ul><li>DBreport </li></ul><ul><li>Filter </li></ul><ul><li>Send to MQ </li></ul><ul><li></sequence> </li></ul>
  13. 13. Results <ul><li>Replicated a 3 month project is 3 days </li></ul><ul><ul><li>Included enhancing the Flatpack mediator to support Variable Records </li></ul></ul><ul><ul><li>Added WS-Security over original scenario </li></ul></ul><ul><ul><li>1200 lines of config reduced to less than 300 </li></ul></ul><ul><ul><li>Much more maintainable – clean separation of concerns between departments </li></ul></ul>
  14. 14. Google Spreadsheet and CSV Google.com CSV Synapse Http Poller Job CSV to XML Atom
  15. 15. Esper <ul><li>Event Stream Processing project </li></ul><ul><ul><li>http://esper.codehaus.org </li></ul></ul><ul><li>Allows you to define queries on sets of “events” </li></ul><ul><ul><li>SELECT AVG(price) FROM OrderEvent.WIN:TIME(30 sec) </li></ul></ul><ul><li>EsperMediator for Synapse makes it simple to add CEP to your SOA </li></ul>
  16. 16. Ganglia, Quartz, Esper Synapse Quartz Scheduler Ganglia gmond telnet 8649 <GANGLIA_XML> GMondPoller Job Esper Mediator SELECT AVG(CPU_USER) FROM GANGLIA urn:gmond Alert notification IM Atom or JMS urn:cpu
  17. 17. <ul><li><definitions xmlns=&quot;http://ws.apache.org/ns/synapse&quot;> </li></ul><ul><li><task class=&quot;org.fremantle.gmond.GMonTask“ name=“Gmon”> </li></ul><ul><li> <trigger interval=&quot;5000&quot;/> </li></ul><ul><li> <property name=&quot;hostname&quot; value=&quot;localhost&quot;/> </li></ul><ul><li> <property name=&quot;port&quot; value=&quot;8649&quot;/> </li></ul><ul><li><property name=&quot;to&quot; value=&quot;urn:gmond&quot;/> </li></ul><ul><li></task> </li></ul><ul><li><in> </li></ul><ul><li> <filter source=&quot;get-property('To')&quot; regex=&quot;urn:gmond&quot;> </li></ul><ul><li><log/> </li></ul><ul><li><class name=&quot;org.fremantle.esper.EsperMediator&quot;> </li></ul><ul><li><property name=&quot;Configuration&quot; </li></ul><ul><li>value=“./repository/conf/esper.conf.xml&quot;/> </li></ul><ul><li><property name=&quot;statement&quot; </li></ul><ul><li>value=&quot;select avg(cpu_user) from Ganglia.win:length_batch(10) &quot;/> </li></ul><ul><li><property name=&quot;EventToAddress&quot; value=&quot;urn:cpu&quot;/> </li></ul><ul><li></class> </li></ul><ul><li></filter> </li></ul><ul><li><filter source=&quot;get-property('To')&quot; regex=&quot;urn:cpu&quot;> </li></ul><ul><li> <send> </li></ul><ul><li><endpoint> </li></ul><ul><li><address uri=&quot;http://localhost:9090/notfication&quot;/> </li></ul><ul><li></endpoint> </li></ul><ul><li></send> </li></ul><ul><li></filter> </li></ul><ul><li></in> </li></ul><ul><li></definitions> </li></ul>
  18. 18. Performance <ul><li>Non-blocking IO </li></ul><ul><ul><li>Apache HTTPCore </li></ul></ul><ul><ul><li>http://hc.apache.org/httpcomponents-core/httpcore-nio/index.html </li></ul></ul><ul><li>Streaming XML and Binary </li></ul><ul><ul><li>Apache Axiom </li></ul></ul><ul><ul><li>http://ws.apache.org/commons/axiom </li></ul></ul>
  19. 19. Non-blocking graphically <ul><li>This model means: </li></ul><ul><li>Synapse threads never blocked during normal processing </li></ul><ul><li>Number of sockets open >> number of threads </li></ul>TIME Thread2 Incoming req Socket open Thread1 Socket open Request processing Response processing Outgoing resp Outgoing req Incoming resp Synapse
  20. 20. Demonstrating Performance <ul><li>Synapse by default runs </li></ul><ul><ul><li>2 listener threads </li></ul></ul><ul><ul><li>2 sender threads </li></ul></ul><ul><ul><li>8 worker threads </li></ul></ul><ul><li>Added a 100ms thread sleep to the server </li></ul><ul><li>Ran 250 concurrent clients for 10000 runs </li></ul><ul><ul><li>Simply would not have run without NIO </li></ul></ul><ul><li>Also did a simple test comparing: </li></ul><ul><ul><li>346 bytes in/ 1,170 bytes out </li></ul></ul><ul><ul><li>Direct to Axis2: 7.4ms </li></ul></ul><ul><ul><li>Via Synapse: 8.1ms – diff = 0.710ms !! </li></ul></ul>
  21. 21. XSLT performance
  22. 22. Extending Synapse <ul><li>Java Mediators </li></ul><ul><ul><li>Implement a simple Java API </li></ul></ul><ul><li>Java Commands </li></ul><ul><ul><li>Pure POJO with mapping into messages using XPath </li></ul></ul><ul><li>Scripts </li></ul><ul><ul><li>Using the Apache BSF project you can write scripts in JavaScript, Groovy and Ruby </li></ul></ul><ul><li>Synapse extensions </li></ul><ul><ul><li>First class mediators with their own “Domain” XML configuration </li></ul></ul><ul><ul><li>Simply drop the JAR into the classpath </li></ul></ul><ul><li>Tasks </li></ul><ul><ul><li>Repetitive jobs can be run at set intervals </li></ul></ul><ul><li>Registries </li></ul><ul><ul><li>Synapse can dynamically load its configuration from a remote registry </li></ul></ul><ul><li>Transports </li></ul><ul><ul><li>Create new connectors to remote systems </li></ul></ul>
  23. 23. Simple Mediator: CSV->XML <ul><li>public boolean mediate(MessageContext mc) { </li></ul><ul><ul><li>DataHandler dh = PayloadHelper. getBinaryPayload (mc); </li></ul></ul><ul><ul><li>BufferedReader br; </li></ul></ul><ul><ul><li>new BufferedReader(new InputStreamReader(dh.getInputStream())); </li></ul></ul><ul><ul><li>CSVReader csvReader = new CSVReader(br); </li></ul></ul><ul><ul><li>OMFactory fac = OMAbstractFactory. getOMFactory (); </li></ul></ul><ul><ul><li>OMElement el = fac.createOMElement(&quot;csv&quot;, csvNS); </li></ul></ul><ul><ul><li>// create element to hold data </li></ul></ul><ul><ul><li>while ((nextLine = csvReader.readNext()) != null) { </li></ul></ul><ul><ul><li>rownum++; </li></ul></ul><ul><ul><li>// add elements to XML </li></ul></ul><ul><ul><li>} </li></ul></ul><ul><ul><li>br.close(); </li></ul></ul><ul><ul><li>PayloadHelper. setXMLPayload (mc, el); </li></ul></ul><ul><ul><li>return true; </li></ul></ul><ul><li>} </li></ul>
  24. 24. Tasks – Quartz integration <ul><li>Simple repetitive actions </li></ul><ul><li>Can also be used to start a long-running activity at startup </li></ul><ul><li>Uses the Quartz Scheduler to run items </li></ul><ul><ul><li>www.opensymphony.com/quartz </li></ul></ul><ul><li>Tasks must implement the Task interface </li></ul><ul><ul><ul><li>package org.apache.synapse.startup; </li></ul></ul></ul><ul><ul><ul><li>public interface Task </li></ul></ul></ul><ul><ul><ul><li>{ </li></ul></ul></ul><ul><ul><ul><li>public abstract void execute(); </li></ul></ul></ul><ul><ul><ul><li>} </li></ul></ul></ul><ul><li>Tasks may implement the ManagedLifecycle interface </li></ul><ul><li>Properties are set by injection (String and XML) </li></ul>
  25. 25. Sample task - MessageInjector <ul><li>public class MessageInjector implements Task, ManagedLifecycle </li></ul><ul><li>{ </li></ul><ul><li>public void setTo(String url) </li></ul><ul><li>{ to = url; } </li></ul><ul><li>public void setMessage(OMElement elem) </li></ul><ul><li>{ message = elem; } </li></ul><ul><li>public void execute() { </li></ul><ul><li> MessageContext mc = </li></ul><ul><li>synapseEnvironment.createMessageContext(); </li></ul><ul><li>mc.setTo(new EndpointReference(to)); </li></ul><ul><li>PayloadHelper.setXMLPayload(mc, </li></ul><ul><li> message.cloneOMElement()); </li></ul><ul><li>synapseEnvironment.injectMessage(mc); </li></ul><ul><li>} </li></ul><ul><li>} </li></ul>
  26. 26. Script example <script language=&quot;js&quot;><![CDATA[ var rowset = mc.getPayloadXML() var ns = new Namespace(&quot;http://...&quot;); var d6 = rowset..ns::row.(@recordname==&quot;D6&quot;); var output = <FEEDS/> for (var i=0; i<d6.length(); i++) { var row = d6[i]; var cak = row.ns::entry.(@name==“CAK&quot;).text(); … var feed = <FEED> <CAK>{cak}</CAK> <AccNo>{accno}</AccNo> </FEED>; output.appendChild(feed); } mc.setPayloadXML(output); </script>
  27. 27. Community Site for extensions http://esbsite.org
  28. 28. Connectors, Adapters, Other projects <ul><li>CSV, Fixed and Variable records – FlatPack, OpenCSV </li></ul><ul><li>FIX transport using QuickFix/J </li></ul><ul><li>AMQP transport using Apache QPid </li></ul><ul><li>Complex Event Processing based on Esper </li></ul><ul><li>Atom using Apache Abdera </li></ul><ul><li>Rules using Drools </li></ul><ul><li>EDI using Smooks </li></ul><ul><li>BPEL using Apache ODE </li></ul><ul><li>Hessian Binary XML using Hessian </li></ul><ul><li>URLRewriter </li></ul><ul><li>IM Mediator MSN, ICQ, Yahoo, Jabber </li></ul>
  29. 29. User quotes <ul><li>&quot;Synapse's simplicity of configuration, ease of extensibility, and integration were the key factors in our choice. Synapse's speed and stability, non-blocking I/O support, and responsive development community then sealed the decision,&quot; </li></ul><ul><li>&quot;Synapse passed all our performance benchmark, load and memory leak tests with flying colours.&quot; </li></ul><ul><li>“ Thanks for the quick fix. Synapse continues to rock.” </li></ul>
  30. 30. Futures <ul><li>We continue to add new mediators and transports </li></ul><ul><li>Better support for complete HTTP Proxy </li></ul><ul><ul><li>Jointly done with HTTPCore </li></ul></ul><ul><li>More work on a non-XML DSL for Synapse </li></ul><ul><li>Better support for REST </li></ul><ul><ul><li>DELETE and PUT support </li></ul></ul><ul><li>Unifying support for events </li></ul><ul><ul><li>WS-Eventing, Atom, RSS, XMPP </li></ul></ul><ul><li>Improved cluster management </li></ul><ul><ul><li>Graceful restart </li></ul></ul><ul><li>Improved JMX management </li></ul><ul><ul><li>Better granularity </li></ul></ul>
  31. 31. Getting Started
  32. 32. Getting Involved <ul><li>Join us </li></ul><ul><ul><li>[email_address] </li></ul></ul><ul><ul><li>[email_address] </li></ul></ul><ul><li>Raise a JIRA for an improvement you would like </li></ul><ul><ul><li>http://issues.apache.org/jira/browse/SYNAPSE </li></ul></ul><ul><li>Submit a patch </li></ul><ul><li>Contribute a mediator or a task definition </li></ul>
  33. 33. Questions?
